PX-500 Crystal Oscillator PX-500 Features • • • • • • 9X14 J Leaded Surface Mount Package Re ow Process Compatible ACMOS, TTL, LVPECL and LVDS MIL-PRF-55310 Class B Screening (optional) Frequency Range: 1 MHZ to 800 MHZ Previous Model: C1300 • • • • Applications Military Systems Avionics and Instrumentation Test Equipment Medical Equipment Performance Speci cations Parameter vs. operating temperature range (referenced to +25°C) Min -15 -25 -50 -100 -25 -50 -100 -50 -100 -15 -25 -50 -100 -20 -25 -50 -100 -25 -50 -100 -65 -100 Typ Max +15 +25 +50 +100 +25 +50 +100 +50 +100 +15 +25 +50 +100 +20 +25 +50 +100 +25 +50 +100 +65 +100 Units 1 Condition 0… +70°C 0… +70°C 0… +70°C 0… +70°C -40… +85°C -40… +85°C -40… +85°C -55… +125°C -55… +125°C @+25°C @+25°C @+25°C @+25°C 0… +70°C 0… +70°C 0… +70°C 0… +70°C -40… +85°C -40… +85°C -40… +85°C -55… +125°C -55… +125°C Frequency Stabilities ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm Initial tolerance Overall tolerance (Referenced to +25°C) (includes operating temperature and initial accuracy) Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com Performance Speci cations Parameter vs. supply voltage change vs. load change vs. aging / 1 year vs. aging / year (following years) Min -2 -1 -3 -1 Typ Max +2 +1 +3 +1 Units ppm ppm ppm ppm Condition VS ± 5% Load ± 5% after 30 days of operation Supply Voltage (Vs) Supply voltage Supply voltage Supply voltage Current consumption (+5 VDC) Current consumption (+3.3 VDC or +2.5 VDC) 4.75 3.135 2.375 5.0 3.3 2.5 5.25 3.465 2.625 15 20 40 6 8 12 16 40 75 100 VDC VDC VDC mA mA mA mA mA mA mA mA mA mA ACMOS or TTL 1.0 to 23.9 MHz ACMOS or TTL 24 to 49.9 MHz ACMOS or TTL 50 to 125.00 MHz ACMOS 1.0 to 14.9 MHZ ACMOS 15.0 to 39.9 MHZ ACMOS 40.0 to 59.9 MHZ ACMOS 60.0 to 84.9 MHZ ACMOS 85.0 to 125.0 MHZ LVPECL or LVDS No load 200 MHz RF Output Signal Load Signal Level (Vol) 4.5 3.0 2.25 10 6 3 45 40 55 60 TTL 10 0.5 4.5 5 3 45 40 55 60 LVPECL 50 Vs -1.62 Vs1.025 1000 600 ohm VDC VDC ps ps into Vcc-2V or There in Equivalent -40....+85°C operating temp -40....+85°C operating temp < 100 MHz >= 100 MHz pF VDC VDC ns ns % % with Vs=5.0V and 15pF load with Vs=5.0V and 15pF load 1.0 to 23.9 MHz 24.0 to 125 MHz @ 1.4V < 15 MHz @ 1.4V >= 15 MHz 15 ACMOS 50 0.5 .3 .25 pF VDC VDC VDC VDC VDC VDC ns ns ns % % with Vs=5.0V and 15pF load with Vs=3.3V and 15pF load with Vs= 2.5V and 15pF load with Vs=5.0V and 15pF load with Vs=3.3V and 15pF load with Vs=2.5V and 15pF load 1.0 to 23.9 MHz 24.0 to 79.9 MHz 80.0 to 125.0 MHz @ 50% < 15 MHz @ 50% => 15 MHz Signal Level (Voh) Rise and fall times for ACMOS (measured 10% to 90%) Duty cycle Signal Load Signal Level (Vol) Signal Level (Voh) Rise and fall times for ACMOS (measured 20% to 80%) Duty cycle Signal Load Signal Level (Vol) Signal Level (Voh) Rise and fall times for ACMOS (measured 20% to 80%) Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com Parameter Duty cycle Jitter (rms) Period Jitter (pk-pk) Signal Load Signal Level (Vol) Signal Level (Voh) Di erential Voltage (Vod) Common Mode (O set) Voltage (Vos) Start-up Time Rise \ Fall Time Duty cycle Jitter (rms) Period Jitter (pk-pk) Min 45 Typ Max 55 10 0.5 40 LVDS Units % ps ps ps Condition @ 50% Vdd BW = 10Hz to 20 MHz BW = 12KHz to 20 MHz 10,000 Samples - Rising edge 60 100 1.2 1.4 140 ohm VDC VDC Between outputs 240 1.125 330 1.2 460 1.375 10 mVpeak V ms ps % ps ps ps measured @ 20% to 80% of Vod @ 50% of Vod BW = 10Hz to 20 MHz BW = 12KHz to 20 MHz 10,000 Samples - Rising edge 600 45 1000 55 5 1 40 Absolute Maximum Ratings Supply voltage (Vs) Operable temperature range Storage temperature range -55 -62 7.0 +125 +125 V °C °C with Vs=5.0VDC and 3.3 VDC Additional Parameters Screening Vectron Veri cation Class B, MIL-PRF-55310, Rev.D Logic “0“ input = Outputs disabled (Tri-state) Logic “1“ or oating input = Outputs enabled) Logic “0“ or oating input = Outputs enabled Logic “1“ input = Outputs disabled (Tri-state) < 2 grams Handling & processing note Standard (All outputs) Output Enable Weight Processing & Packing Standard Environmentals Vibration Shock Acceleration Temperature Cycling Thermal Shock Solderability Leak Test (Fine and Gross) MIL-STD-202, Method 204, Condition G (30 G, 10Hz-2000Hz) MIL-STD-202, Method 213, Condition I (100 G, 6ms, Sawtooth) MIL-STD-883, Method 2001, Condition A (5000 G, Y1 Plane) MIL-STD-883, Method 1010, Condition B MIL-STD-883, Method 107, Condition B MIL-STD-202, Method 208 MIL-STD-883, Method 1014, Condition A1 and C1 Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com Outline Drawing / Enclosure Type A (ACMOS or TTL) Code 0 Height “H” 0.188 (4.77mm) Stand-o 0.043 (1.09mm) Pin Connections 1 2 3 4 Enable/Disable or N/C Ground (Case) Output Supply Type B (LVPECL or LVDS) Code 1 Height “H” 0.188 (4.77mm) Stand-o 0.043 (1.09mm) Pin Connections 1 2 3 4 5 6 Enable/Disable or N/C Enable/Disable or N/C (custom number required) Ground (Case) Output Complementary Output Supply Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com Ordering Information PX - 500 0 - A A T - F K X B - 10M0000000 Frequency Product Family PX: PXO Package 9 x 14 mm Height 0: A 0.188” 1: B 0.188” Supply Voltage D: 5 Vdc E: 3.3 Vdc H: 2.5 Vdc RF Output Code A: ACMOS B: TTL C: LVPECL D: LVDS Temperature Range C: -55°C to +125°C E: -40°C to +85°C T: 0°C to +70°C Screening Option B: “B” Level screening X: No Screening Enable Code A: Enable Hi, Tristate C: Enable Lo, Tristate X: No Enable Temp. Stability Code D: ±15ppm F: ±25ppm K: ±50ppm S: ±100ppm X: Use with Overall Tolerance Code Accuracy Code OR Overall Tolerance (Pullability) Code D: ±15ppm E: ±20ppm F: ±25ppm K: ±50ppm S: ±100ppm Notes: 1. Contact factory for improved stabilities or additional product options. Not all options and codes are available at all frequencies. 2. Unless other stated all values are valid after warm-up time and refer to typical conditions for supply voltage, frequency control voltage, load, temperature (25°C). 3. Phase noise degrades with increasing output frequency. 4. Subject to technical modi cation. 5. Contact factory for availability. For Additional Information, Please Contact USA: Vectron International 267 Lowell Road Hudson, NH 03051 Tel: 1.888.328.7661 Fax: 1.888.329.8328 Europe: Vectron International Landstrasse, D-74924 Neckarbischofsheim, Germany Tel: +49 (0) 3328.4784.17 Fax: +49 (0) 3328.4784.30 Asia: Vectron International 1F-2F, No 8 Workshop, No 308 Fenju Road WaiGaoQiao Free Trade Zone Pudong, Shanghai, China 200131 Tel: 86.21.5048.0777 Fax: 86.21.5048.1881 Disclaimer Vectron International reserves the right to make changes to the product(s) and or information contained herein without notice. No liability is assumed as a result of their use or application. No rights under any patent accompany the sale of any such product(s) or information. Rev: 2/5/2009 daf Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
