PX-700
Crystal Oscillator
PX-700
Features
• • • • • • • 5X7 Surface Mount Package Re ow Process Compatible ACMOS, TTL, LVPECL and LVDS MIL-PRF-55310 Class B Screening (optional) Frequency Range: 1 MHZ to 800 MHZ Previous Model: C1250 EAR99 • • • •
Applications
Military Systems Avionics and Instrumentation Test Equipment Medical Equipment
Performance Speci cations
Parameter
vs. operating temperature range (referenced to +25°C)
Min
-15 -25 -50 -100 -25 -50 -100 -65 -100 -15 -25 -50 -100 -25 -50 -100 -50 -100 -80 -100
Typ
Max
+15 +25 +50 +100 +25 +50 +100 +65 +100 +15 +25 +50 +100 +25 +50 +100 +50 +100 +80 +100
Units
1
Condition
0… +70°C 0… +70°C 0… +70°C 0… +70°C -40… +85°C -40… +85°C -40… +85°C -55...+125°C -55...+125°C @+25°C @+25°C @+25°C @+25°C 0… +70°C 0… +70°C 0… +70°C -40… +85°C -40… +85°C -55… +125°C -55… +125°C
Frequency Stabilities
ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm ppm
Initial tolerance
Overall tolerance (Referenced to +25°C) (includes operating temperature and initial accuracy)
Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
Performance Speci cations
Parameter
vs. supply voltage change vs. load change vs. aging / 1 year vs. aging / year (following years)
Min
-2 -1 -3 -1
Typ
Max
+2 +1 +3 +1
Units
ppm ppm ppm ppm
Condition
VS ± 5% Load ± 5% after 30 days of operation
Supply Voltage (Vs)
Supply voltage Supply voltage Supply voltage Current consumption (+5 VDC) Current consumption (+3.3 VDC or +2.5 VDC) 4.75 3.135 2.375 5.0 3.3 2.5 5.25 3.465 2.625 15 20 40 6 8 16 20 40 75 100 VDC VDC VDC mA mA mA mA mA mA mA mA mA mA ACMOS or TTL 1.0 to 23.9 MHz ACMOS or TTL 24 to 49.9 MHz ACMOS or TTL 50 to 125.00 MHz ACMOS 1.0 to 14.9 MHZ ACMOS 15.0 to 39.9 MHZ ACMOS 40.0 to 59.9 MHZ ACMOS 60.0 to 84.9 MHZ ACMOS 85.0 to 125.0 MHZ LVPECL or LVDS No load 200 MHz
RF Output
Signal Load Signal Level (Vol) 4.5 3.0 2.25 10 6 3 45 40 55 60 TTL 10 0.4 2.4 5 3 45 40 55 60 LVPECL 50 Vs -1.62 Vs1.025 1000 600 45 55 ohm VDC VDC ps ps % into Vcc-2V or Thevenin Equivalent -40....+85°C operating temp -40....+85°C operating temp < 100 MHz >= 100 MHz @ 50% Vdd pF VDC VDC ns ns % % with Vs=5.0V and 15pF load with Vs=5.0V and 15pF load 1.0 to 23.9 MHz 24.0 to 125 MHz @ 1.4V < 15 MHz @ 1.4V >= 15 MHz 15 ACMOS 50 0.5 0.3 0.25 pF VDC VDC VDC VDC VDC VDC ns ns ns % % with Vs=5.0V and 15pF load with Vs=3.3V and 15pF load with Vs= 2.5V and 15pF load with Vs=5.0V and 15pF load with Vs=3.3V and 15pF load with Vs=2.5V and 15pF load 1.0 to 23.9 MHz 24.0 to 79.9 MHz 80.0 to 125.0 MHz @ 50% Vs< 15 MHz @ 50% Vs=> 15 MHz
Signal Level (Voh) Rise and fall times for ACMOS (measured 10% to 90%) Duty cycle Signal Load Signal Level (Vol) Signal Level (Voh) Rise and fall times for ACMOS (measured 20% to 80%) Duty cycle Signal Load Signal Level (Vol) Signal Level (Voh) Rise and fall times for ACMOS (measured 20% to 80%) Duty cycle
Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
Parameter
Jitter (rms) Period Jitter (pk-pk) Signal Load Signal Level (Vol) Signal Level (Voh) Di erential Voltage (Vod) Common Mode (O set) Voltage (Vos) Start-up Time Rise \ Fall Time Duty cycle Jitter (rms) Period Jitter (pk-pk)
Min
Typ
Max
10 0.5 40 LVDS
Units
ps ps ps
Condition
BW = 10Hz to 20 MHz BW = 12KHz to 20 MHz 10,000 Samples - Rising edge
60
100 1.2 1.4
140
ohm VDC VDC
Between outputs
240 1.125
330 1.2
460 1.375 10
mVpeak V ms ps % ps ps ps measured @ 20% to 80% of Vod @ 50% of Vod BW = 10Hz to 20 MHz BW = 12KHz to 20 MHz 10,000 Samples - Rising edge
600 45
1000 55 5 1 40
Absolute Maximum Ratings
Supply voltage (Vs) Operable temperature range Storage temperature range -55 -62 7.0 +125 +125 V °C °C with Vs=5.0VDC and 3.3 VDC
Additional Parameters
Screening Vectron Veri cation Class B, MIL-PRF-55310, Rev.E Logic “0“ input = Outputs disabled (Tri-state) Logic “1“ or oating input = Outputs enabled) Logic “0“ or oating input = Outputs enabled Logic “1“ input = Outputs disabled (Tri-state) < 2 grams Handling & processing note Standard (ACMOS, TTL and LVDS) Standard (LVPECL)
Output Enable
Weight Processing & Packing
Standard Environmentals
Vibration Shock Acceleration Temperature Cycling Thermal Shock Solderability MIL-STD-202, Method 204, Condition G (30 G, 10Hz-2000Hz) MIL-STD-202, Method 213, Condition I (100 G, 6ms, Sawtooth) MIL-STD-883, Method 2001, Condition A (5000 G, Y1 Plane) MIL-STD-883, Method 1010, Condition B MIL-STD-883, Method 107, Condition B MIL-STD-202, Method 208
Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
Outline Drawing / Enclosure
Type LCC (ACMOS or TTL)
Package Code 0 Height “H” 1.88mm
Pin Connections
1 2 3 4 Enable/Disable or N/C Ground (Case) Output Supply
Type LCC (LVPECL or LVDS)
Package Code 1 Height “H” 1.88mm
Pin Connections
1 2 3 4 5 6 Enable/Disable or N/C Enable/Disable or N/C (custom number required) Ground (Case) Output Complementary Output Supply
Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
Outline Drawing / Enclosure
J leads are tinned with Alpha Pb/Sn 63/37 solder.
Type J LEAD (ACMOS or TTL)
Package Code 2 Height “H” 3.40 mm 1 2 3 4
Pin Connections
Enable/Disable or N/C Ground (Case) RF Output Supply Voltage
J leads are tinned with Alpha Pb/Sn 63/37 solder.
Pin Connections
1 2 3 4 5 6 Enable/Disable or N/C N/C Ground (Case) RF Output Complementary Output Supply Voltage
Type J LEAD (LVPECL or LVDS)
Package Code 3 Height “H” 3.40 mm
Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
Ordering Information
PX - 700 0 - D A T - F K X B - 10M0000000
Frequency Product Family PX: PXO Package 5 x 7 mm Package Code 0: 4 pad LCC 1: 6 pad LCC 2: 4 J Lead 3: 6 J Lead Supply Voltage D: 5 Vdc E: 3.3 Vdc H: 2.5 Vdc RF Output Code A: ACMOS B: TTL C: LVPECL D: LVDS Temperature Range C: -55°C to +125°C E: -40°C to +85°C T: 0°C to +70°C Screening Option B: “B” Level screening X: No Screening Enable Code 5 A: Enable Hi, Tristate C: Enable Lo, Tristate X: No Enable Temp. Stability Code D: ±15ppm F: ±25ppm K: ±50ppm S: ±100ppm X: Use with Overall Tolerance Code Accuracy Code @ 25°C OR Overall Tolerance Code D: ±15ppm F: ±25ppm K: ±50ppm P: ±80ppm S: ±100ppm
Notes: 1. Contact factory for improved stabilities or additional product options. Not all options and codes are available at all frequencies or operating temperature ranges. 2. Unless other stated all values are valid after warm-up time and refer to typical conditions for supply voltage, frequency control voltage, load, temperature (25°C). 3. Subject to technical modi cation. 4. Contact factory for availability. 5. Enable Codes: Option A is standard for ACMOS, TTL and LVDS; Option C is standard for LVPECL. Contact facory for custom options.
For Additional Information, Please Contact
USA:
Vectron International 267 Lowell Road Hudson, NH 03051 Tel: 1.888.328.7661 Fax: 1.888.329.8328
Europe:
Vectron International Landstrasse, D-74924 Neckarbischofsheim, Germany Tel: +49 (0) 3328.4784.17 Fax: +49 (0) 3328.4784.30
Asia:
Vectron International 1589 Century Avenue, the 19th Floor Chamtime International Financial Center Shanghai, China Tel: 86.21.60812888 Fax: 86.21.61633598
