VC-700-CFC-GAA

10188_VECTRON 05/21/03 3:14 PM Page 1 VC-700 Voltage Controlled Crystal Oscillator Features • • • • • • • • Small Industry Standard Package, 5.0 x 7.5 x 2.8 mm Output Frequencies from 77.76 MHz to 180 MHz 3.3 V or 5 V Operation HFF crystal for ultra low jitter Complementary PECL Outputs Low phase noise and custom options 0/70 ºC or –40/85 ºC operating temperature Enable /Disable (PECL) Applications PLL circuits for Clock Smoothing and Frequency Translation • • • • Fiber Channel SONET SDH, ITU-T G.709 SONET, GR-253-CORE Issue3 Description The VC-700 is a voltage controlled crystal oscillator that operates at the fundamental frequency of the internal HFF crystal. The HFF crystal is a high-Q quartz device that enables the circuit to achieve low phase jitter performance over a wide operating temperature range. The oscillator is housed in an industry standard hermetically sealed leadless surface mount package and is available on tape and reel. 10188_VECTRON 05/21/03 3:14 PM Page 2 VC-700 Voltage Controlled Crystal Oscillator Electrical Performance Parameter Frequency Supply Voltage Supply Current Output Logic Levels Output Logic High Output Logic low Output Logic High Output Logic low Transition Times Rise Time Fall Time Symmetry or Duty Cycle Operating Temperature ordering option Symbol fO (+3.3V) (+5.0V) VDD VDD IDD 0/70 ˚C 0/70 ˚C -40/85 ˚C -40/85 ˚C VOH VOL VOH VOL tR tF SYM Minimum 77.76 3.15 4.75 Typical 3.3 5.0 Maximum 180 3.45 5.25
