VC-710_06

Data Sheet VC-710 Voltage Controlled Crystal Oscillator Features • Small Industry Standard Package, 5.0 x 7.5 x 1.8 mm • Output Frequencies from 80 MHz to 200 MHz • 3.3 V Operation • HFF crystal for ultra low jitter • Complementary LVPECL Outputs • 0/70° C or –40/85° C operating temperature • Enable /Disable • Product is compliant to RoHS directive and fully compatible with lead free assembly Applications PLL circuits for Clock Smoothing and Frequency Translation • Fiber Channel • SONET • SDH, ITU-T G.709 • SONET, GR-253-CORE Issue3 Description The VC-710 is a voltage controlled crystal oscillator that operates at the fundamental frequency of the internal HFF crystal. The HFF crystal is a high-Q quartz device that enables the circuit to achieve low phase jitter performance over a wide operating temperature range. The oscillator is housed in an industry standard hermetically sealed leadless surface mount package and is available on tape and reel. Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: December 13, 2006 Page 1 of 6 VC-710 Voltage Controlled Crystal Oscillator Electrical Performance Parameter Frequency Supply Voltage (+3.3 V) Supply Current Output Logic Levels Output Logic High Output Logic Low Transition Times Rise Time Fall Time Symmetry or Duty Cycle Operating temperature (ordering option) Jitter (12 kHz – 20 MHz BW), 155.52 MHz Jitter (50 kHz – 80 MHz BW), 155.52 MHz Symbol fO VDD IDD Min 80 3.135 Typical 155.52 3.3 50 Maximum 200 3.465 90 Vcc -0.880 Vcc -1.620 Units MHz V mA V V +25 ºC +25 ºC VOH VOL Vcc -1.025 Vcc -1.810 Vcc -0.950 Vcc -1.700 tR tF SYM 45 0.5 0.5 50 0/70 or –40/85 0.3 0.5 -64 -95 -123 -143 -146 -146 -146 1 1 55 ns ns % °C ps (rms) ps (rms) dBc/Hz dBc/Hz dBc/Hz dBc/Hz dBc/Hz dBc/Hz dBc/Hz Phase Noise, f0 = 155.52 MHz 10 Hz offset 100 Hz offset 1 kHz offset 10 kHz offset 100 kHz offset 1 MHz offset 10 MHz offset Test Conditions for APR (+3.3V) Absolute Pull Range (APR) Gain Transfer Control Voltage Bandwidth (-3dB) Enable/Disable1 Output Enabled, F option Output Disabled, F option Output Enabled, B option Output Disabled, B option Package Size VC APR BW 0.3 + 50 20 VDD*0.7 3.0 Positive, 65 100 V ppm ppm/V kHz V V V V mm VDD*0.3 VDD*0.2 VDD*0.7 5.08 x 7.5 x 1.8 1. Output is enabled if the E/D, pin 2, is left open on F option. E/D must be terminated on B option. ( -1.3V to +2V) 1 6 ( +2V) >1.4V or Open 2 ( -1.3V) 5 COutput tR tF SYM = 100 x tA / tB VOH 80% 3 4 50Ω Output 5 0Ω 20% 50% T est Circuit Notes: Ω 1 ) To Permit 50 M easurement of Outputs, all DC Inputs are Biased Down 1.3V. 2) All Voltage Sources Contain Bypass Capacitors to Minimize Supply Noise. Ω T erminations are W ithin Test Equipment. 3) 50 tA tB VOL Figure 1. Test Circuit ( 3.3 V) Figure 2. PECL Waveform Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: December 13, 2006 Page 2 of 6 VC-710 Voltage Controlled Crystal Oscillator Outline Diagram 6 5 VDUGLA 35.328 VI YWW 1 2 3 4 Pad Layout Pin Out Pin 1 2 3 4 5 6 Symbol VC OE GND Output COutput VCC Function VCXO Control Voltage Enable / Disable Case and Electrical Ground Output Complementary Output Power Supply Voltage (3.3 V) Tape and Reel (EIA-481-2-A) Po ØDo W2 F W D C N A P1 W1 B Tape Dimensions (mm) Dimension Tolerance VC-710 Reel Dimensions (mm) F Do Typ 1.5 W Typ 16 Po Typ 4 P1 Typ 8 A Typ 178 B Min 1.5 C Typ 13 D Min 20.2 N Min 50 W1 Typ 16.4 W2 Max 22.4 Typ 7.5 # Per Reel 200 Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: December 13, 2006 Page 3 of 6 VC-710 Voltage Controlled Crystal Oscillator Absolute Maximum Ratings Parameter Power Supply Voltage Control Range Storage Temperature Symbol VDD VC TS Ratings 0 to 6 0 to VDD -55 to 125 Unit V V °C Stresses in excess of the absolute maximum ratings can permanently damage the device. Functional operation is not implied at these or any other conditions in excess of conditions represented in the operational sections of this data sheet. Exposure to absolute maximum ratings for extended periods may adversely affect device reliability. Reliability The VC-710 family is capable of meeting the following qualification tests: Environmental Compliance Parameter Mechanical Shock Mechanical Vibration Solderability Gross and Fine Leak Resistance to Solvents Moisture Sensitivity Conditions MIL-STD-883, Method 2002 MIL-STD-883, Method 2007 MIL-STD-883, Method 2003 MIL-STD-883, Method 1014 MIL-STD-883, Method 2015 MSL1 Handling Precautions Although ESD protection circuitry has been designed into the VC-710 proper precautions should be taken when handling and mounting. VI employs a human body model and a charged-device model (CDM) for ESD susceptibility testing and design protection evaluation. ESD Ratings Model Human Body Model Charged Device Model Minimum 500 500 Conditions MIL-STD 883, Method 3015 JESD 22-C101 Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: December 13, 2006 Page 4 of 6 VC-710 Voltage Controlled Crystal Oscillator Suggested IR profile The VC-710 is qualified to meet the JEDEC standard for Pb-Free assembly. The temperatures and time intervals listed are based on the Pb-Free small body requirements and parameters are listed in the table below. The contact pads are gold over nickel so lower IR reflow temperatures such as 220°C can be used (device is backwards compatible with a lead solder assembly). The VC-710 is hermetically sealed so an aqueous wash is not an issue. Reflow Profile (IPC/JEDEC J-STD-020C) Parameter PreHeat Time Ramp Up Time Above 217 oC Time To Peak Temperature Time At 260 oC Ramp Down Symbol tS R UP tL t AMB-P tP R DN Value 60 sec Min, 180 sec Max 3 oC/sec Max 60 sec Min, 150 sec Max 480 sec Max 20 sec Min, 40 sec Max 6 oC/sec Max tL 260 R UP tP Temperature (DegC) 217 200 R DN 150 tS t AMB-P 25 Time (sec) Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: December 13, 2006 Page 5 of 6 VC-710 Voltage Controlled Crystal Oscillator Standard Frequencies (MHz) 80.000 88.4736 89.600 110.000 112.640 120.000 139.264 144.000 155.520 167.3316 175.000 184.000 Other frequencies available upon request 91.080 122.880 156.250 184.320 93.312 124.416 157.500 187.500 96.000 125.000 161.1328 192.000 100.000 128.000 166.627 192.456 101.992 133.330 166.6286 200.000 Ordering Information VC - 710 - D F F - G F A - xxx.xxx Product Family VC: VCXO Frequency 80 - 200 MHz Linearity, Temp. Stability Package 710: 5.0 x 7.5 x 1.8 mm A: N/A L: + 10 % linearity M: + 20 ppm temp. stability Input D: 3.3 Vdc ± 5% Enable - Disable) F: Pin 2, Output is enabled high B: Pin 2, Output is enabled low Output F: Complementary LVPECL Absolute Pull Range G: + 50 ppm Operating Temperature C: 0 to 70 °C F: -40 to 85 °C 1. Not all combinations are possible. 2. ± 10% linearity available at certain frequencies. Consult factory. For Additional Information, Please Contact: USA: Vectron International, 267 Lowell Rd, Hudson, NH 03051 . . . . . . . Tel: 1-88-VECTRON-1 EUROPE: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Tel: 49 (0) 7268 8010 ASIA: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Tel: 86 21 5048 0777 Fax: 1-888-FAX-VECTRON Fax: 49 (0) 7268 801281 Fax: 86 21 5048 1881 Vectron International reserves the right to make changes to the product(s) and or information contained herein without notice. No liability is assumed as a result of their use or application. No rights under any patent accompany the sale of any such product(s) or information. Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: December 13, 2006 Page 6 of 6
