VC-800_1

VC-800 Voltage Controlled Crystal Oscillator Features • Worlds Smallest VCXO, 5.0 X 3.2 X 1.5 mm • High Frequencies to 74.250 MHz • 5.0 or 3.3 V operation • Linearity ≤ 10% • Tri-State Output • Low jitter < 6ps rms • VCXO with CMOS outputs • 0/70 or –40/85 °C temperature range • Hermetically sealed ceramic SMD package The VC-800 Voltage Controlled Crystal Oscillator Product is compliant to RoHS directive and fully compatible with lead free assembly Applications • SONET/SDH • DWDM ESD Diodes • xDSL/PCMCIA cards • Digital Video Vc Input Buffer Output Buffer / Tri-state fO Description Vectron’s VC-800 Voltage Controlled Crystal Oscillator (VCXO) is a quartz stabilized square wave generator with a CMOS output and is tested at CMOS and TTL (5.0 volt operation) logic levels. The VC-800 is the smallest available VCXO making it ideally suitable for PCMCIA applications as well as any other where size is limited but performance is required. Vectron International 267 Lowell Road, Hudson NH 03051 Tel:1-88-VECTRON-1 e-mail: vectron@vectron.com VC-800 Voltage Controlled Crystal Oscillator Performance Characteristics Table 1. Electrical Performance Parameter Frequency Supply Voltage 1 (+3.3 V) (+5.0 V) Supply Current Output Logic Levels Output Logic High2 Output Logic Low2 Transition Times Rise Time2 Fall Time2 Tristate Output Enabled Output Disabled Symmetry or Duty Cycle3 (ordering option) Operating temperature (ordering option) Test Conditions for APR (+5V option) Test Conditions for APR (+3.3V option) Absolute Pull Range (ordering option) Symbol fO VDD IDD VOH VOL tR tF VIN VIL SYM Min 1.544 2.97 4.5 Typical 3.3 5.0 12 Maximum 75.000 3.63 5.5 25 Units MHz V mA V V ns ns V V % °C V V ppm 0.9*VDD 0.1VDD 1 1 2.5 40 50 0/70 or –40/85 0.7 60 3 3 VC VC APR 0.5 0.3 ±50 ±70 ±80 Positive 4.5 3.0 Gain Transfer (See Figure 3) Control Voltage Leakage Current Control Voltage Bandwidth (-3dB) Phase Noise 10 Hz Offset 100 Hz Offset 1 KHz Offset 10 KHz Offset 100 KHz Offset 1 MHz Offset Package Size IVCXO BW ±1 10 -58 -88 -118 -143 -151 -151 5.0 x 3.2 x 1.5 ppm/V uA kHz dBc/Hz dBc/Hz dBc/Hz dBc/Hz dBc/Hz dBc/Hz mm 1. A 0.01uF and a 0.1uF capacitor should be located as close to the supply as possible (to ground) is recommended. 2. Figure 1 defines these parameters. Figure 2 illustrates the equivalent five gate TTL load and operating conditions under which these parameters are tested and specified. 3. Symmetry is defined as (ON TIME/PERIOD with Vs= 1.4 V for TTL and Vs=2.5 V for CMOS, 5 volt operation, and Vs=1.65V for 3.3 Volt operation. tR 80% tF IDD 6 V DD + 2 5 3 650 Ω Vs 20 % On Time Period .1 µF .01 µ F IC VC 1 + - 4 15pF 1.8k Figure 1. Output Waveform Figure 2. Typical Output Test Conditions (25±5°C) Vectron International 267 Lowell Road, Hudson NH 03051 Tel:1-88-VECTRON-1 e-mail: vectron@vectron.com VC-800 Voltage Controlled Crystal Oscillator Outline Diagram, Pad Layout and Pin Out 6 5 4 1 2 3 Pin # 1 2 3 4 5 6 Symbol VC Tri-state GND fO CMOS/TTL VDD Function Control Voltage Logic low disables output Logic high or no connection enables output waveform Ground Output Frequency Logic low for CMOS optimized symmetry Logic high or no connection for TTL optimized symmetry Supply Voltage Tape and Reel J F D A E C G B L I H K Tape and Reel Dimensions (mm) Tape Dimensions Product A B C D E VC-800 12 5.5 1.5 4 8 Reel Dimensions F G H 1.78 20.6 13 I 55 J 6 K 12.4 L 178 # Per Reel 500 Vectron International 267 Lowell Road, Hudson NH 03051 Tel:1-88-VECTRON-1 e-mail: vectron@vectron.com VC-800 Voltage Controlled Crystal Oscillator Absolute Maximum Ratings Stresses in excess of the absolute maximum ratings can permanently damage the device. Functional operation is not implied at these or any other conditions in excess of conditions represented in the operational sections of this data sheet. Exposure to absolute maximum ratings for extended periods may adversely affect device reliability. Table 2. Absolute Maximum Ratings Parameter Symbol Power Supply VDD Storage Temperature Tstorage Voltage Control Range VC Ratings 6 -55/125 0 to VDD Unit Vdc °C V 200.0 150.0 100.0 Frequency Pull (ppm) 50.0 0.0 -50.0 -100.0 -150.0 -200.0 0.30 0.60 0.90 1.20 1.50 1.80 2.10 2.40 2.70 3.00 Control Voltage (volts) Figure 3. Typical Frequency Pull Versus Control Voltage, 35.328MHz Output, 3.3 Volt Supply Vectron International 267 Lowell Road, Hudson NH 03051 Tel:1-88-VECTRON-1 e-mail: vectron@vectron.com VC-800 Voltage Controlled Crystal Oscillator Reliability The VC-800 is capable of meeting the following qualification tests. Table 3. Environmental Compliance Parameter Mechanical Shock Mechanical Vibration Solderability Gross and Fine Leak Resistance to Solvents MIL-STD-883 MIL-STD-883 MIL-STD-883 MIL-STD-883 MIL-STD-883 Conditions Method 2002 Method 2007 Method 2003 Method 1014 Method 2016 Handling Precautions Although ESD protection circuitry has been designed into the the VC-800, proper precautions should be taken when handling and mounting. VI employs a Human Body Model and a Charged-Device Model (CDM) for ESD susceptibility testing and design protection evaluation. ESD thresholds are dependent on the circuit parameters used to define the model. Although no industry wide standard has been adopted for the CDM, a standard HBM of resistance = 1.5kohms and capacitance = 100pF is widely used and therefore can be used for comparison purposes. Table 4. ESD Ratings Model Human Body Model Charged Device Model Minimum 1500 1000 Conditions MIL-STD-883 Method 3115 JESD 22-C101 The VC-800 is qualified to meet the JEDEC standard for Pb-Free assembly. The temperatures and time intervals listed are based on the Pb-Free small body requirements and parameters are listed in the table below. The contact pads are gold over nickel so lower IR reflow temperatures such as 220°C can be used (device is backwards compatible with a lead solder assembly). The VC-800 is hermetically sealed so an aqueous wash is not an issue. Table 5. Reflow Profile (IPC/JEDEC J-STD-020C) Parameter Symbol PreHeat Time Ramp Up Time Above 217 C Time To Peak Temperature Time At 260 C Ramp Down o o Value 60 sec Min, 180 sec Max 3 C/sec Max 60 sec Min, 150 sec Max 480 sec Max 20 sec Min, 40 sec Max 6 C/sec Max o o tS R UP tL t AMB-P tP R DN 260 tL R UP tP R DN Temperature (DegC) 217 200 150 tS t AMB-P 25 Time (sec) Vectron International 267 Lowell Road, Hudson NH 03051 Tel:1-88-VECTRON-1 e-mail: vectron@vectron.com VC-800 Voltage Controlled Crystal Oscillator Standard Frequencies (MHz) 3.600 13.500 32.768 74.1758 4.096 16.384 34.560 74.250 8.192 19.440 38.785 10.000 27.000 44.736 12.960 28.375 51.840 Other frequencies may be available upon request Ordering Information VC - 800 - K A C - G T J – XX.XX Product Family VC = VCXO Frequency (MHz) Package 800= 5.0x3.2x1.5 mm Symmetry J = 50±5% K= 50±10% Input K = 5.0 Vdc ± 10% L = 3.3 Vdc ± 10% Tristate T = Pin 2: Enable High (or Float) / Disable Low Output A = CMOS Absolute Pull Range G = ± 50 ppm minimum M = ± 70 ppm minimum N = ± 80 ppm minimum Operating Temperature C = 0°C to 70°C F = -40°C to 85°C NOTE: Not all combinations of options are available. For Additional Information, Please Contact: USA: Vectron International, 267 Lowell Rd, Hudson, NH 03051 . . . . . . . EUROPE: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ASIA: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Tel: 1-88-VECTRON-1 Tel: 49 (0) 7268 8010 Tel: 86 21 5048 0777 Fax: 1-888-FAX-VECTRON Fax: 49 (0) 7268 801281 Fax: 86 21 5048 1881 Vectron International reserves the right to make changes to the product(s) and or information contained herein without notice. No liability is assumed as a result of their use or application. No rights under any patent accompany the sale of any such product(s) or information. Vectron International 267 Lowell Road, Hudson NH 03051 Tel:1-88-VECTRON-1 e-mail: vectron@vectron.com
