VC-820_12

VC-820 CMOS Crystal Oscillator VC-820 Description Vectron’s VC-820 Crystal Oscillator (XO) is a quartz stabilized square wave generator with a CMOS output. The VC-820 uses a fundamental or a 3rd overtone crystal, oscillating in a fundamental tone, resulting in very low jitter performance, and a monolithic IC which improves reliability and reduces cost. Features • • • • • • • • CMOS output XO Output Frequencies from 625kHz to 133.000 MHz 3.3V, 2.5 V and 1.8V Operation Fundamental Oscillator with Low Jitter Performance Output Disable Feature -10/70°C or -40/85°C operating temperature Small Industry Standard Package, 2.5x3.2.x1.0mm Product is compliant to RoHS directive and fully compatible with lead free assembly • • • • • • • Applications SONET/SDH/DWDM Ethernet, GE, SynchE Storage Area Networking Fiber Channel Digital Video Broadband Access Base Stations, Picocells Block Diagram VDD Output Crystal Oscillator E/D Page1 Gnd Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com Specifications Performance Specifications Table 1. Electrical Performance, 3.3V Option Parameter Voltage1 Maximum Voltage Current ≤20.000MHz 20.000 to 39.999MHz 40.000 to 49.999MHz 50.000 to 79.999MHz 80.000 to 99.999MHz 100.000 to 133.000MHz Current, Output Disabled Frequency Nominal Frequency 4 3 2 Symbol VDD IDD Min Supply 3.15 -0.5 Typical 3.3 Maximum 3.45 5 6 7 8 9 10 40 5 Units V V mA uA MHz ppm fN 0.625 ±20, ±25, ±50, ±100 Outputs 133.000 Stability , (Ordering Option) Output Logic Levels2,
