VL-821
CMOS Crystal Oscillator Previous Vectron Model VCS3
VL-821
Description
Vectron’s VL-821 Crystal Oscillator (XO) is a quartz stabilized square wave generator with a CMOS output, operating off either a 1.8, 2.5, or 3.3 volt supply. The VL-821 utilizes a high performance, low frequency quartz resonator followed by a custom ASIC to synthesize the output frequency.
Features
• • • • • • • •
•
Applications
• • • • • • SONET/SDH/DWDM Ethernet, GE, SynchE Storage Area Networking Digital Video Broadband Access Microprocessors/DSP/FPGA
Quick delivery CMOS Output 3.2mm x 2.5mm x 1.2mm Output frequencies to 200.00 MHz Tri-state output for the board test and debug -10/70°C or -40/85°C operating temperature Gold over nickel contact pads Hermetically Sealed SMD Package Product is compliant to RoHS directive and fully compatible with lead free assembly
Block Diagram
VDD
Crystal
Output
Osc
PLL
E/D
Gnd
Page1
Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
Performance Specifications
Table 1. Electrical Performance, 3.3V Option Parameter
Operating Supply Voltage
1
Symbol
VDD IDD
Min
Supply 2.97 -0.05
Typical
3.3
Maximum
3.63 5.0 10 15 20 25
Units
V V mA mA mA mA uA MHz ppm
Absolute Maximum Operating Voltage Supply Current, Output Enabled 10MHz Duty Cycle3 Output Enable/Disable Output Enable Output Disable Start-Up Time Operating Temp, (Ordering Option)
1] 2] 3] 4] 5]
5
VOH VOL IOH IOL tR/tF SYM
0.9*VDD 0.1*VDD 8 8 3 2 45 Enable/Disable 50 55
V V mA mA ns ns %
VIH VIL tSU TOP
0.7*VDD 0.3V*DD 100 2 -10/70 or -40/85
V V KΩ ms °C
Internal Pull-Up Resistor
A 0.01 uF and a 0.1uF capacitor should be located as close to the supply as possible (to ground). VDD supply ramp should be
