VM-700
MEM’s Clock Oscillator
VM-700
Description
Vectron’s VM-700 Clock Oscillator is the next generation silicon MEMS based stabilized square wave generator with a CMOS output, operating off a 1.8, 2.5 or 3.3V supply. The VM-700 uses an internal compensation scheme to improve temperature stability which produces temperature performance equivalent to quartz based products.
Features
• • • • • • • • • • Short Lead Time Compact QFN Package Low Power +1.8V, +2.5V, or +3.3V Operation CMOS Output Output Frequencies to 150 MHz Enable/Disable for Board Test and Debug -20/70°C or –40/85°C Operating Temperature Industry Standard 7x5 SMD Footprint Product is Compliant to RoHS Directive and Fully Compatible with Lead Free Assembly • • • • • •
Applications
Portable Media Players Consumer Electronic Applications Printers Camera’s Low Profile Applications Computers & Peripherals
Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
Page1
Performance Specifications Specifications
Table 1. Electrical Performance Parameter
Frequency Stability1 (ordering option) Operating Temperature (ordering option) Operating Supply Voltage (ordering option)
2
Symbol
fO Δ f/fo TOP VDD
Min
1.000
Typical
±25, ±50, ±100 -20/70 or -40/85
Maximum
150.000
Units
MHz ppm °C
1.65 2.3 3.0
1.8 2.5 3.3 3 4 5 6
1.95 2.7 3.6 6 8 10 12 1
V V V mA mA mA mA uA V V ns ns % ps ps
Supply Current, Output Enabled 1 to 40MHz 40.01 to 80MHz 80.01 to 125MHz 125.01 to 150MHz Supply Current, Output Disabled Output Logic Levels Output Logic High3 Output Logic Low3 Output Load Output Rise/Fall Time Duty Cycle4 Period Jitter , RMS, 80MHz Output Peak-Peak Start-up Time Enable/Disable Output Enabled Output Disabled
1] 2] 3] 4] 5] 6]
6 5 3
IDD
IDD VOH VOL tR tF SYM 9 75 TSU VIH VIL 0.75*VDD 3 0.8*VDD
0.2*VDD ≥10Kohm II ≤15pf 1.3 1.3 3 3 45/55
10
ms V V
0.25*VDD
Stability includes initial accuracy, temperature and aging. A 0.01uF and a 0.1uF capacitor should be located as close to the supply as possible (to ground) is recommended. Figure 2 defines these parameters. Figure 1 illustrates the operating conditions under which these parameters are tested and specified. Duty Cycle is measured defined as On Time/Period. Measured using a Wavecrest SIA3300C, 90K samples Output will be active if Enable/Disable is left open.
Description
IDD 4 + VDD .1μF 1 3 2 15pF VOH 50% VOL On Time tR tF
Period
Fig 1: Test Circuit
Fig 2: Output Waveform
Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
Page2
Table 2. Absolute Maximum Ratings Parameter
Power Supply CMOS Input Voltage Junction Temperature Storage Temperature Soldering Temperature / Duration
Symbol
VDD E/D TJ TSTR TPEAK / tP
Ratings
-0.3 to +4.0 -0.3 to (VDD +0.3) 150 -55 to 125 260 / 40
Unit
V V °C °C °C / sec
Enable/Disable Functional Description
Under normal operation the E/D is set to a logic high state or logic low state. When E/D is set to a logic low, the oscillator stops and the output is in a high impedance state. This helps reduce power consumption as well as facilitating board testing and troubleshooting. When E/D is set to a logic high state, the oscillator produces an output. Leaving the Enable/Disable pin open results in an active state with an output frequency.
Outline Drawing
Units: mm (inches)
Suggested Pad Layout
Contact Pads are Gold flash (0.003 um min ) over Palladium (0.01-0.15um) over Nickel (0.508-2.032um) Figure 3 Table 3. Pin Out Pin
1 2 3 4
Symbol E/D
GND fO VDD
Function
Enable/Disable Electrical Ground Output Frequency Supply Voltage
Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
Page3
Reliability
Table 4. Environmental Compliance Parameter
Mechanical Shock Mechanical Vibration Temperature Cycle Gross and Fine Leak Resistance to Solvents Moisture Sensitivity Level
Conditions
MIL-STD-202, Method 2002 MIL-STD-883, Method 2007 MIL-STD-883, Method 1010 MIL-STD-883, Method 1014 MIL-STD-202, Method 215 MSL2
Handling Precautions
Although ESD protection circuitry has been designed into the VM-700, proper precautions should be taken when handling and mounting. VI employs a Human Body Model and a Charged-Device Model (CDM) for ESD susceptibility testing and design protection evaluation. ESD thresholds are dependent on the circuit parameters used to define the model. Table 5. ESD Ratings Model
Human Body Model Charged Device Model Machine Model
Minimum
2000V 500V 200 V
Suggested IR Profile
Devices are built using lead free epoxy and can also be subjected to standard lead free IR reflow conditions. Figure 6 shows max temperatures and lower temperatures can also be used e.g. peak temperature of 220C.
Table 6. Reflow Profile Parameter
PreHeat Time Ts-min Ts-max Ramp Up Time Above 217 °C Peak Temperature Time To Peak Temperature Time at Peak Temperature Ramp Down
Symbol
tS
Value
60 sec Min, 260 sec Max 150°C 200°C 3 °C/sec Max 60 sec Min, 150 sec Max 255-260°C 480 sec Max 20 sec Max 6 °C/sec Max
RUP tL tP T25C to Peak tP RDN
Figure 4
Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
Page4
Ordering Information
Standard Frequencies (MHz)
2.000 9.216 17.000 29.4912 48.000 75.000 116.640 3.686 9.600 20.000 30.000 50.000 80.000 125.000 4.000 10.000 21.000 32.000 55.000 83.333 127.872 4.032 12.000 21.500 33.000 56.448 84.000 4.9152 12.500 22.000 33.333 58.320 95.000 5.000 12.729 23.000 36.000 60.000 100.000 6.000 14.31818 24.000 37.500 64.000 110.000 7.3728 14.746 25.000 40.000 66.000 112.500 7.680 16.000 26.000 42.500 66.666 114.000 8.000 16.128 27.000 45.000 72.000 115.200
Other Frequencies Available Upon Request.
VM-700-EAE-KANN- xxMxxxxxxx
Product Family MEM’s Oscillator Package Size 7.0x5.0x0.9mm Supply Voltage E: +3.3Vdc H: +2.5Vdc J: +1.8Vdc Output A: LVCMOS Operating Temperature J: -20/70°C E: -40/85°C Frequency (See Above) In MHz Other N: Standard Other N: Standard Enable/Disable Options A: Enable High Stability Options S: ±100ppm K: ±50ppm F: ±25ppm
Example: VM-700-EAE-KANN-125M000000 = 7.0x5.0, +3.3V, LVCMOS output, ±50ppm over -40/85°C with a 125.000MHz output
For Additional Information, Please Contact
USA:
Vectron International 267 Lowell Road Hudson, NH 03051 Tel: 1.888.328.7661 Fax: 1.888.329.8328
Europe:
Vectron International Landstrasse, D-74924 Neckarbischofsheim, Germany Tel: +49 (0) 3328.4784.17 Fax: +49 (0) 3328.4784.30
Asia:
Vectron International 1F-2F, No 8 Workshop, No 308 Fenju Road WaiGaoQiao Free Trade Zone Pudong, Shanghai, China 200131 Tel: 86.21.5048.0777 Fax: 86.21.5048.1881
Disclaimer
Vectron International reserves the right to make changes to the product(s) and or information contained herein without notice. No liability is assumed as a result of their use or application. No rights under any patent accompany the sale of any such product(s) or information. Rev: 9/22/2009
