VS-4010-DEX-205X

Voltage Controlled SAW Oscillator High Frequency VS-401 VS-401 Description The VS-401 VCSO (Voltage Controlled Saw Oscillator) from Vectron is a high frequency, ultra low phase noise oscillator designed to support high speed data converters and 100G coherent optical receivers. The VS-401 provides 12fs rms jitter in the 12kHz to 20MHz integration bandwidth and is available from 1.3GHz to 2.1GHz. Features • • • • • • • Frequency Range 1.3 to 2.1 GHz Ultra low jitter performance Typical Jitter: 12fsec rms, 12kHz to 20MHz 5V supply voltage Output sinewave + balanced sinewave 13x20 mm SMD package See table on Page 5 for standard frequencies • • • Applications High Speed ADCs 40G & 100G Coherent Receivers Test & Measurement Performance Specifications Pulling Characteristics Parameter Absolute Pull Range (APR) Min ±20 Typ Max Units Notes Includes df vs: •Operating temperature range +10 .. 85°C •Aging 10 years •Supply Voltage Change 5% •Load change 10% Tuning Slope Control Voltage Range Frequency control input impedance Supply voltage (standard) Current consumption 0.5 10 2.5 Positive 4.5 V DC kΩ with VS = 5V Supply Voltage (Vs) 4.75 5.00 5.25 150 V DC mA @ Sinewave / Balanced Sinewave Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com 1 of 5 Performance Specifications (Continued) RF Output Parameter Signal Load Output Power Signal Load Output Power Phase difference between output signal pairs Phase Noise: 100Hz offset Phase Noise: 1kHz offset Phase Noise: 10kHz offset Phase Noise: 100kHz offset Phase Noise: 1MHz offset Phase Noise: 10MHz offset Jitter: 12kHz to 20MHz offset Phase Noise: 100Hz offset Phase Noise: 1kHz offset Phase Noise: 10kHz offset Phase Noise: 100kHz offset Phase Noise: 1MHz offset Phase Noise 10MHz offset Jitter: 12kHz to 20MHz offset Subharmonics -75 -101 -129 -146 -155 -160 12 -62 -90 -118 -139 -151 -158 14 -30 45 0 45 7 50 8.5 50 3 Min Typ Max Sinewave 55 12 55 6 ±10 Units Ω dBm Ω dBm 0 dBc/Hz dBc/Hz dBc/Hz dBc/Hz dBc/Hz dBc/Hz fs rms dBc/Hz dBc/Hz dBc/Hz dBc/Hz dBc/Hz dBc/Hz fs rms dBc Notes Balanced Sinewave @ 1.75GHz Sinewave 5V @ 1.97GHz Sinewave 5V For > 1.8GHz Additional Parameters Weight Processing and Packing 2.0g Handling and Processing Note Absolute Maximum Ratings Parameter Supply Voltage (VS) Operating Temperature Range Storage Temperature Range -40 -55 Min Max 6.0 +85 +125 Units V 0C 0C Notes Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com 2 of 5 Typical Performance Phase Noise VS-401 @ 1.75GHz Sinewave Phase Noise VS-401 @ 1.97GHz Sinewave Outline Drawing / Enclosure Package Codes Code G239 Height “H” 5.9 Pin Length “L” NA Dimensions in mm 1 6 7 8 9 14 Pin Assignment Control Voltage (VC) GND GND RF Out GND (Sinewave) RF Out compl. (Balanced Sinewave) Supply Voltage Input (VS) Marking VS-401-xxxx Frequency •AYYWW Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com 3 of 5 Standard Shipping Method Enclosure Type G239 Tape Width W (mm) 24 Quantity per meter Quantity per reel 500 Dimension P 12 Recommended Reflow Profile Profile Feature Average ramp-up rate (TL to TP) Preheat - Temperature Min TSmin -Temperature Min TSma -Time (min to max) tS TSmax to TL -Ramp-up Rate Time maintained above -Temperature (TL) -Time (tL) Peak Temperature (TP) Pb-Free Assembly/Sn-Pb Assembly 3°C/second max. 150°C 200°C 60-180 seconds 3°C/second max 217°C 60-150 seconds max 260°C Profile Feature Time 25°C to Peak Temperature Time maintained above -Temperature (TL) -Time (tL) Time within 5°C of actual PeakTemperature (tP) Ramp-down Rate Pb-Free Assembly/Sn-Pb Assembly 8 minutes max. 217°C 60-150 seconds 20-40 seconds 6°C/ second max Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com 4 of 5 Ordering Information VS - 401 0 - D E X - 205 X - 1747M03083 Product Family VS: VCSO Package 13x20mm SMT Height 0: 5.9 mm (G239) Supply Voltage D: +5.0V RF Output Code E: Sinewave F: Balanced Sinewave Temperature Range X: +10°C to +85°C APR Code 205: ±20ppm Frequency Enable X: No Enable Standard Frequencies (MHz) 1701.32 1769.18 1707.08 1968.75 1747.030837 1980.022 1747.62305 1986.819383 1748.366885 2031.25 1748.793733 1769.145 Other Frequencies Available Upon Request Notes: 1. Contact factory for improved stabilities or additional product options. Not all options and codes are available at all frequencies. 2. Unless other stated all values are valid after warm-up time and refer to typical conditions for supply voltage, frequency control voltage, load, temperature (25°C). 3. Phase noise degrades with increasing output frequency. 4. Subject to technical modification. 5. Contact factory for availability. For Additional Information, Please Contact Vectron International 267 Lowell Road Hudson, NH 03051 Tel: 1.888.328.7661 Fax: 1.888.329.8328 USA: Vectron International Landstrasse, D-74924 Neckarbischofsheim, Germany Tel: +49 (0) 3328.4784.17 Fax: +49 (0) 3328.4784.30 Europe: Vectron International 1F-2F, No 8 Workshop, No 308 Fenju Road WaiGaoQiao Free Trade Zone Pudong, Shanghai, China 200131 Tel: 86.21.5048.0777 Fax: 86.21.5048.1881 Asia: Disclaimer Vectron International reserves the right to make changes to the product(s) and or information contained herein without notice. No liability is assumed as a result of their use or application. No rights under any patent accompany the sale of any such product(s) or information. Rev: 06/2011 Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com 5 of 5
