VS-550_06

VS-550_06

  • 厂商:

    VECTRON

  • 封装:

  • 描述:

    VS-550_06 - Dual Frequency VCSO - Vectron International, Inc

  • 数据手册
  • 价格&库存
VS-550_06 数据手册
VS-550 Dual Frequency VCSO Features • 9 x 14 x 3.5 mm Package • Output Frequencies from 500 MHz to 850 MHz • 3.3 V Operation • Low Jitter < 0.25 ps-rms across 50 kHz to 80 MHz • LV-PECL Configuration with Fast Transition Times • Complementary Outputs • Frequency Select Feature Product is free of lead and compliant to EC RoHS Directive Applications PLL circuits for Clock Smoothing and Frequency Translation Description • 10G Fibre Channel • 10GbE LAN / WAN • OC-192 • SONET / SDH Vcc COutput Output Standard INCITS 364-2003 IEEE 802.3ae ITU-T G.709 GR-253-CORE Issue3 Description SAW 1 SAW 2 The VS-550 is a SAW based voltage controlled oscillator that operates at the fundamental frequencies of the internal SAW filters. These SAW filters are high-Q quartz devices that enable the circuit to achieve low phase jitter performance over a wide operating temperature range. The dual oscillator is housed in a hermetically sealed J-lead surface mount package offered on tape and reel. It has a frequency select function that enables either “Frequency 1” or “Frequency 2.” FS Gnd Vc Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 Page 1 of 7 Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: 11Apr06 VS-550 Voltage Controlled SAW Oscillator Electrical Performance Parameter Frequency Nominal Frequency Absolute Pull Range Linearity Gain Transfer (See Pg 5) Temperature Stability Transition Time Supply Voltage Current (No Load) Outputs Mid Level Swing Current Rise Time Fall Time Symmetry Spurious Suppression Jitter (See Pg 5) Control Voltage Input Impedance Modulation Bandwidth Operating Temperature Package Size 1. 2. 3. 4. 5. 6. 7. 8. Symbol fN APR Lin KV fSTAB Minimum Typical 500 - 850 Maximum Units MHz ppm % ppm/V ppm µsec Notes 1,2,3 1,2,3,8 2,4,8 2,8 1,6 6 2,3 3 2,3 2,3 6 5,6 5,6 2,3 6 6,7 6 6 1,3 ±50 ±5 +385 ±100 4 2.97 3.3 55 VCC-1.3 650 250 250 50 60 0.135 100 500 -40 9.0 x 14.0 x 3.5 85 3.63 70 VCC-1.2 950 20 400 400 55 0.250 VCC ICC V mA V mV-pp mA ps ps % dBc ps-rms kΩ kHz °C mm VCC-1.4 550 IOUT tR tF SYM φJ Zc BW TOP 45 50 See Standard Frequencies and Ordering Information (Pg 7). Parameters are tested with production test circuit below (Fig 1). Parameters are tested at ambient temperature with test limits guardbanded for specified operating temperature. Measured as the maximum deviation from the best straight-line fit, per MIL-0-55310. Measured from 20% to 80% of a full output swing (Fig 2). Not tested in production, guaranteed by design, verified at qualification. Integrated across 50 kHz to 80 MHz, per GR-253-CORE Issue3. Tested with Vc = 0.3V to 3.0V. Vc (-1.0V to +1.7V) 1 F1 (-0.58V), F2 (+0.59V) 2 Vee (-1.3V) 3 5 4 6 Vcc (+2V) COutput tR Output 80% tF SYM = 100 x tA / tB Vcc - 1.0V Vcc - 1.3V 50Ω 50Ω 20% Vcc - 1.6V Test Circuit Notes: 1) To Permit 50Ω Measurement of Outputs, all DC Inputs are Biased Down 1.3V. 2) All Voltage Sources Contain Bypass Capacitors to Minimize Supply Noise. 3) 50Ω Terminations are Within Test Equipment. tA tB Figure 1. Test Circuit Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 Page 2 of 7 Figure 2. 10K LV-PECL Waveform Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: 11Apr06 VS-550 Voltage Controlled SAW Oscillator Outline Diagram 6 5 4 Pad Layout VS-550-LFF-GNN XXX.XXX-XXX.XXX VI YWW 8.89±0.15 [0.350±0.006] ( 7.63 [0.300]) 1.27 [0.050] 1 2 3 13.97±0.20 [0.550±0.008] 0.46±0.05 [0.018±0.002] [ 3.42+0.20 -0.30 0.135+0.008 -0.012 8.80 [0.346] ] 3.00 [0.118] 2.54 [0.100] 5.08 [0.200] mm [inch] 5.08±0.13 [0.200±0.005] 2.54±0.13 [0.100±0.005] mm [inch] Pin Out Pin 1 2 3 4 5 6 Control Logic (LV-CMOS) Function VCSO Control Voltage Frequency Select (See Control Logic) Case and Electrical Ground VCSO Output VCSO Complementary Output Power Supply Voltage (3.3 V ±10%) Symbol VC FS GND Output COutput VCC FS 0 1 Operation F1 F2 Tape and Reel (EIA-481-2-A) Po ØDo W2 F W D C N A P1 W1 B Tape Dimensions (mm) Dimension Tolerance VS-550 Reel Dimensions (mm) F Do Typ 1.5 W Typ 24 Po Typ 4 P1 Typ 12 A Typ 330 B Min 1.5 C Typ 13 D Min 20.2 N Min 100 W1 Typ 24.4 W2 Max 30.4 Typ 11.5 # Per Reel 200 Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 Page 3 of 7 Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: 11Apr06 VS-550 Voltage Controlled SAW Oscillator Absolute Maximum Ratings Parameter Power Supply Input Current Output Current Voltage Control Range Storage Temperature Solder Temperature / Duration Symbol VCC IIN IOUT VC TSTR TPEAK / tP Ratings 0 to 6 100 25 0 to VCC -55 to 125 260 / 40 Unit V mA mA V °C °C / sec Stresses in excess of the absolute maximum ratings can permanently damage the device. Also, exposure to these absolute maximum ratings for extended periods may adversely affect device reliability. Functional operation is not implied at these or any other conditions in excess of those represented in the operational sections of this datasheet. Permanent damage is also possible if any device input (Vc or FS) draws greater than 100mA. Suggested Output Load Configurations +3.3V 0.10 µF 0.01 µF 0.10 µF 0.01 µF 150Ω 150Ω +3.3V +3.3V Vc FS Gnd 1 2 3 6 5 4 Vcc COutput Output Z = 50Ω Z = 50Ω 240Ω 100Ω Vc FS Gnd 1 2 3 6 5 4 Vcc COutput Z = 50Ω Output Z = 50Ω 40Ω 40Ω 49Ω 49Ω 240Ω LV-PECL to LV-PECL: For short transmission lengths, the power consumption could be reduced by removing the 100Ω resistor and doubling the value of the pull down resistors. LV-PECL to LVDS: Restricted for short transmission lengths. Configuration may require modification depending on LVDS receiver. +3.3V 0.10 µF 0.01 µF 0.10 µF 0.01 µF +2.0V Vc FS Gnd 1 2 3 6 5 4 Vcc COutput Output 0.01 µF Vc FS -1.3V 1 2 3 6 5 4 Vcc COutput Output 0.01 µF 240Ω 240Ω Functional Test: Allows standard power supply configuration. Since AC coupled, the LV-PECL levels cannot be measured. Production Test: Allows direct DC coupling into 50Ω measurement equipment. Must bias the power supplies as shown. Similar to Figure 1. Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 Page 4 of 7 Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: 11Apr06 VS-550 Voltage Controlled SAW Oscillator Typical Characteristics 800 600 400 At Ambient (22.5°C) Typical Gain Transfer @ 622.0800 = +393 ppm/V Typical Gain Transfer @ 644.5313 = +372 ppm/V Frequency (PPM) 200 0 -200 622 Vc Pull -400 y = 393.01x - 555.91 y = 371.69x - 531.82 -600 -800 0.3 0.6 0.9 1.2 1.5 1.8 2.1 2.4 2.7 3 644 Vc Pull Linear (622 Vc Pull) Linear (644 Vc Pull) Control Voltage (V) -95 -100 -105 -110 1/f -115 Typical Calculated Jitter @ Vc = 1.65V SONET OC-48 (12kHz-20MHz) = 0.239 ps-rms; 1.67 ps-pp SONET OC-192 (50kHz-80MHz) = 0.135 ps-rms; 0.95 ps-pp 3 OC-192 Spec F1 = 622.0800 F2 = 644.5313 L(f) (dBc/Hz) -120 1/f -125 -130 -135 -140 -145 -150 -155 10 100 2 1/f 1 OC-192 Spec Equivalent to 0.25 ps-rms @ 500 MHz 1,000 10,000 100,000 Offset (kHz) Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 Page 5 of 7 Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: 11Apr06 VS-550 Voltage Controlled SAW Oscillator Reliability VI qualification includes aging at various extreme temperatures, shock and vibration, temperature cycling, and IR reflow simulation. The VS-550 family is capable of meeting the following qualification tests: Environmental Compliance Parameter Mechanical Shock Mechanical Vibration Solderability Gross and Fine Leak Resistance to Solvents Conditions MIL-STD-883, Method 2002 MIL-STD-883, Method 2007 MIL-STD-883, Method 2003 MIL-STD-883, Method 1014 MIL-STD-883, Method 2016 Handling Precautions Although ESD protection circuitry has been designed into the VS-550 proper precautions should be taken when handling and mounting. VI employs a human body model (HBM) and a charged-device model (CDM) for ESD susceptibility testing and design protection evaluation. ESD Ratings Model Human Body Model Charged Device Model Minimum 1500 V 1000 V Conditions MIL-STD 883, Method 3015 JEDEC, JESD22-C101 Reflow Profile (IPC/JEDEC J-STD-020C) Parameter PreHeat Time Ramp Up Time Above 217 oC Time To Peak Temperature Time At 260 oC Ramp Down Symbol tS R UP tL t AMB-P tP R DN 260 Value 60 sec Min, 180 sec Max 3 oC/sec Max 60 sec Min, 150 sec Max 480 sec Max 20 sec Min, 40 sec Max 6 oC/sec Max tL R UP tP R DN Temperature (DegC) The device has been qualified to meet the JEDEC standard for Pb-Free assembly. The temperatures and time intervals listed are based on the Pb-Free small body requirements. The temperatures refer to the topside of the package, measured on the package body surface. The VS-550 device is hermetically sealed so an aqueous wash is not an issue. 217 200 150 tS t AMB-P 25 Time (sec) Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 Page 6 of 7 Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: 11Apr06 VS-550 Voltage Controlled SAW Oscillator Standard Frequencies (MHz) 622.0800 P2 672.1627 R5 625.0000 P3 690.5692 R4 644.5313 P4 693.4830 R6 657.4219 PB 666.5143 P5 669.3266 R3 1. For other frequencies, we recommend the VS-751, please contact VI for details. 2. Frequency 1 must be lower than Frequency 2. Not all combinations are available. Ordering Information VS - 550 - L F F - H N N – P2 – P4 Product Family VS: VCSO Frequency 2 P3 – R6 Package 550: 9 x 14 x 3.5 mm Frequency 1 P2 – R3 Input L: 3.3 V Other (Future Use) N: N/A Output F: LV-PECL Other (Future Use) N: N/A Operating Temperature F: -40 to 85 °C Absolute Pull Range G: +/- 50 ppm H: +/- 100 ppm For Additional Information, Please Contact: USA: Vectron International, 267 Lowell Rd, Hudson, NH 03051 . . . . Tel: 1-88-VECTRON-1 EUROPE: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Tel: +49 (0) 3328-4784-17 ASIA: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Tel: +86-21-28909740 Fax: 1-888-FAX-VECTRON Fax: +49 (0) 3328-4784-30 Fax: +86-21-28909240 Vectron International reserves the right to make changes to the product(s) and or information contained herein without notice. No liability is assumed as a result of their use or application. No rights under any patent accompany the sale of any such product(s) or information. Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 Page 7 of 7 Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: 11Apr06
