VS-705

VS-705 Single Frequency VCSO Features • Industry Standard Package, 5.0 x 7.5 x 2.5 mm • 5th Generation ASIC Technology for Ultra Low Jitter 120 fs-rms (fN = 622.08 MHz, 12 kHz to 20 MHz) 105 fs-rms (fN = 622.08 MHz, 50 kHz to 80 MHz) • Output Frequencies from 122.88 MHz to 1.00 GHz • Spurious Suppression, 90 dBc Typical • 2.5V or 3.3V Supply Voltage • LVPECL or LVDS Output Configurations • Tri-State Output Select (OD, OS, OE) • Compliant to EC RoHS Directive Pb Applications PLL circuits for Clock Smoothing and Frequency Translation Description • SONET / SDH • OTN (Optical Transport Network) • 10 GbE (Gigabit Ethernet) • 10 GFC (Gigabit Fibre Channel) • 40 GbE & 100 GbE • Synchronous Ethernet • WiMax Standard GR-253-CORE ITU-T G.709/Y.1331 IEEE 802.3ae INCITS 364-2003 IEEE 802.3ba ITU-T G.8261 IEEE 802.16 Vcc COutput Output Description The VS-705 is a Voltage Controlled SAW Oscillator that operates at the fundamental frequency of the internal SAW filter. The SAW filter is a high-Q Quartz device that enables the circuit to achieve low phase jitter performance over a wide operating temperature range. A divider circuit is deployed for output frequencies less than 491.52 MHz. The oscillator is housed in a hermetically sealed leadless surface mount package and offered on tape and reel. It has a tri-state Output Select function that provides one of three conditions: Output Disable, Output Set, or Output Enable. SAW LVPECL LVDS 1 X X=1,2,4 Vc OSelect Gnd Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 1 of 9 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 23Jul2010 VS-705 Single Frequency VCSO Electrical Performance: 3.3V LV-PECL Parameter Frequency Nominal Frequency Absolute Pull Range Linearity Gain Transfer Temperature Stability fN APR Lin KV fSTAB VCC ICC ICC 120 ±50 ±7 +445 ±100 2.97 3.3 73 60 VCC-1.3 750 1.5 180 180 50 90 150 190 280 123 472 200 -40 5.0 x 7.5 x 2.5 +85 3.63 75 VCC-1.1 1000 MHz ppm % ppm/V ppm V mA mA mV mV-pp V-pp mA ps-pp ps-pp % dBc fs-rms fs-rms fs-rms kΩ kΩ kHz °C mm 1,2,3 1,2,3,9 2,4,9 2,9 1,7 2,3 3 3 2,3 2,3 2,3 7 6,7 6,7 2,3 7 7,8 7,8 7,8 7 7 7 1,3 Symbol Minimum Typical Maximum Units Notes Supply Voltage (± 10%) Current (Typical 50Ω Load) Current (No Load) Outputs Mid Level Single Ended Swing Differential Swing Current Rise Time Fall Time Symmetry Spurious Suppression Jitter (>491.52 MHz to 245.76 MHz to 122.88 MHz to 491.52 MHz, Jitter is Integrated across 50 kHz to 80 MHz. For Frequencies 100 mA. Test Circuits & Output Load Configurations +3.3V Vc (-3.00V to -0.30V) 0.10 μF OSelect 0.01 μF Vc OSelect Gnd Vcc COutput Output 0.01 μF 0.01 μF + + H (-0.55V to 0.00V) M (-1.90V to -1.40V) L (-3.30V to -2.75V) +2.0V 0.10 μF 0.01 μF Vcc COutput Output Or 0.01 μF 0.01 μF 10KΩ 1 2 3 6 5 4 Vc 1 2 3 6 5 4 OSelect Vee -1.3V 240Ω 240Ω 10KΩ Functional Test: Allows use of standard power supply biasing configuration. Pull down resistors are used for LV-PECL outputs and are removed for with LVDS outputs. Since the LVDS outputs are AC coupled, the output DC levels cannot be measured. V DMV Production Test: DC levels shown for Vee, OSelect, & Vc are for devices configured for 3.3V operation. Vee LV-PECL outputs are DC coupled to 50Ω test equipment. LVDS outputs are connected to a digital volt meter, then AC coupled to the test equipment. The digitial volt meter allows for Mid Level & Swing measurements. +3.3V 0.10 μF 0.01 μF Vc OSelect Gnd Vcc COutput Output Z = 50Ω Z = 50Ω 100Ω Vc OSelect Gnd +3.3V 0.10 μF 0.01 μF Vcc COutput Output Z = 50Ω Z = 50Ω 100Ω 1 2 3 6 5 4 1 2 3 6 5 4 240Ω 240Ω LV-PECL to LV-PECL: For short transmission lengths, the pull down resistor values shown provide reasonable power consumption and waveform performance. LVDS to LVDS: The 100Ω resistor should be removed if this load is provided internally within the LVDS receiver. Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 3 of 9 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 23Jul2010 VS-705 Single Frequency VCSO Typical Characteristics: Vc Pull & Vc Pull Linearity 900 800 700 600 500 400 850.00 622.08 491.52 425.00 311.04 245.76 212.50 155.52 122.88 Kv = 459 ppm/V Kv = 443 ppm/V Kv = 458 ppm/V Vc Pull Frequency (ppm) 300 200 100 0 -100 -200 -300 -400 -500 -600 -700 0.00 TPull = 1240 ppm TPull = 1150 ppm TPull = 1258 ppm 0.30 0.60 0.90 1.20 1.50 1.80 2.10 2.40 2.70 3.00 3.30 Control Voltage (V) 10% 8% 6% 4% Vc Linearity (%) 2% 0% -2% -4% -6% -8% -10% 0.30 850.00 622.08 491.52 425.00 311.04 245.76 212.50 155.52 122.88 Vc Pull Linearity Max (0.3V to 3.0V) = 3.32% Min (0.3V to 3.0V) = -6.19% 0.60 0.90 1.20 1.50 1.80 2.10 2.40 2.70 3.00 Control Voltage (V) Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 4 of 9 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 23Jul2010 VS-705 Single Frequency VCSO Typical Characteristics: Phase Noise & Jitter -20 -30 -40 -50 -60 -70 Jitter (fs-rms) Frequency 12K-20M 850.00 104.7 622.08 116.3 491.25 128.8 425.00 142.9 311.04 169.2 245.76 185.1 212.50 205.0 155.52 235.3 122.88 275.1 Agilent E5052B 50K-40M 50K-80M 67.3 83.7 79.0 100.5 106.3 140.6 160.0 217.8 183.7 255.0 218.9 258.4 300.5 360.5 850.00 Fund 622.08 491.52 425.00 Div2 311.04 245.76 212.50 Div4 155.52 122.88 12K - 20M 50K - 80M L(f) (dBc/Hz) -80 -90 -100 -110 -120 -130 -140 -150 -160 10 100 1,000 10,000 100,000 1,000,000 10,000,000 100,000,000 Offset (Hz) Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 5 of 9 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 23Jul2010 VS-705 Single Frequency VCSO Reliability VI qualification includes aging at various extreme temperatures, shock and vibration, temperature cycling, and IR reflow simulation. The VS-705 family is capable of meeting the following qualification tests: Environmental Compliance Parameter Mechanical Shock Mechanical Vibration Solderability Gross and Fine Leak Resistance to Solvents Moisture Sensitivity Level Conditions MIL-STD-883, Method 2002 B MIL-STD-883, Method 2007 A MIL-STD-883, Method 2003 MIL-STD-883, Method 1014 MIL-STD-883, Method 2016 IPC/JEDEC J-STD-020, MSL1 Handling Precautions Although ESD protection circuitry has been designed into the VS-705 proper precautions should be taken when handling and mounting. VI employs a human body model (HBM) and a charged-device model (CDM) for ESD susceptibility testing and design protection evaluation. ESD Ratings Model Human Body Model Charged Device Model Machine Model Minimum 2000 V 1000 V 200 V Conditions MIL-STD 883, Method 3015 JEDEC, JESD22-C101 JEDEC, JESD22-A115-A Reflow Profile (IPC/JEDEC J-STD-020) Parameter PreHeat Time Ramp Up Time Above 217 oC Time To Peak Temperature Time At 260 oC Ramp Down Symbol tS R UP tL t AMB-P tP R DN 260 Value 60 sec Min, 180 sec Max 3 oC/sec Max 60 sec Min, 150 sec Max 480 sec Max 20 sec Min, 40 sec Max 6 oC/sec Max tL R UP Temperature (DegC) 217 200 150 The VS-705 is qualified to meet the JEDEC standard for Pb-Free assembly. The temperatures and time intervals listed are based on the Pb-Free small body requirements. The temperatures refer to the topside of the package, measured on the package body surface. The VS-705 device is hermetically sealed so an aqueous wash is not an issue. Terminal Plating: Electroless Ni > 1.90 μm Electroless Au > 1.50 μm tP R DN tS t AMB-P 25 Time (sec) Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 6 of 9 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 23Jul2010 VS-705 Single Frequency VCSO Outline & Marking Diagram 6 5 4 6.76 [0.266] 0.86 [0.034] 1.68 [0.066] Suggested Pad Layout VS705 YWW CCC-CCCC XXXMXXX 1 2 7.49±0.15 [0.295±0.006] 1.91 [0.075] 3 5.08±0.15 [0.200±0.006] 2.49±0.18 [0.098±0.007] 1.27 [0.050] Y = Year WW = Week C = Option Codes XXXMXXX = Frequency (See Ordering Info) 1.70 [0.067] 3.83 5.54 [0.151] [0.218] 2.34 [0.092] 2.54 [0.100] 5.08 [0.200] mm [inch] 1.27 [0.050] R0.64 [0.025] 2.54 [0.100] 5.08 [0.200] mm [inch] Pin Out Pin Symbol Function Control Voltage 1 VC 2 OSelect Output Select 3 GND Case and Electrical Ground 4 Output Output 5 COutput Complementary Output Power Supply Voltage 6 VCC Floating OSelect Always Results In OE Output Select (Tri-State LV-CMOS) Option A OS Voltage Range Result OE OS OD OD OS OE H (5VCC / 6) to VCC M (VCC / 2) ± 15%(VCC / 2) L Gnd to (VCC / 6) H (5VCC / 6) to VCC M C (VCC / 2) ± 15%(VCC / 2) L Gnd to (VCC / 6) OD = Outputs Disabled OS = Outputs Set (Output = H, COutput = L) OE = Outputs Enabled Tape and Reel (EIA-481-2-A) D Pin ID W2 F A C W1 N W Pull Off Direction Po ØDo P1 B Tape Dimensions (mm) Dimension Tolerance VS-705 Reel Dimensions (mm) F Do Typ 1.5 W Typ 16 Po Typ 4 P1 Typ 8 A Typ 178 B Min 1.5 C Typ 13 D Min 20.2 N Min 50 W1 Typ 16.4 W2 Max 22.4 Typ 7.5 # Per Reel 200 Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 7 of 9 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 23Jul2010 VS-705 Single Frequency VCSO Standard Frequencies (MHz) 122.880000 167.331646 245.760000 491.520000 644.531250 716.800000 819.200000 125.000000 168.040678 307.200000 500.000000 657.421875 718.863800 834.640000 155.520000 173.370748 315.000000 531.250000 666.514286 737.280000 877.968756 156.250000 173.437500 320.000000 614.400000 669.326582 739.200000 983.040000 160.000000 184.320000 368.640000 622.080000 672.000000 768.000000 1000.00000 161.132813 200.000000 400.000000 625.000000 699.517493 777.600000 166.628572 212.500000 425.000000 627.329620 715.538900 800.000000 Other Frequencies Available Upon Request. Ordering Information VS - 705 - E C E - K A A N – xxxMxxxxxx Product Family VS: VCSO Frequency (See Above) 122M880000 – 1G00000000 Package 705: 5.1 x 7.5 x 2.5 mm Other (Future Use) N: N/A Supply Voltage E: 3.3V H: 2.5V Oscillator Gain A: Standard B: Low Output Type C: LVPECL D: LVDS Control Logic (Tri-State) A: L = OD, M = OS, H = OE C: L = OE, M = OS, H = OD Operating Temperature E: -40oC to 85oC Absolute Pull Range K: ± 50 ppm S: ± 100 ppm Example: VS-705-ECE-KAAN-983M040000 Contact Information: USA: Vectron International • 267 Lowell Rd. Hudson, NH 03051 Tel: 1-88-VECTRON-1 • Fax: 1-888-FAX-VECTRON EUROPE: Landstrasse, D-74924, Neckarbischofsheim, Germany Tel: 49 (0) 7268 8010 • Fax: 49 (0) 7268 801281 ASIA: 1F-2F, No 8 Workshop, No. 308 Fenju Road, WaiGaoQiao Free Trade Zone, Pudong, Shanghai, China 200131 Tel: 86 21 5048 0777 • Fax: 86 21 5048 1881 Vectron International reserves the right to make changes to the product(s) and or information contained herein without notice. No liability is assumed as a result of their use or application. No rights under any patent accompany the sale of any such product(s) or information. Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 8 of 9 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 23Jul2010 VS-705 Single Frequency VCSO Revision History Date 15Apr2008 30May2008 29July2008 23Oct2008 08Mar2010 23Jul2010 Approved JM, BW JM, BW JM, BW JM,BW JM CH Description Release Corrected Production Test Circuit on Pg3. Max Operating Frequency extended to 985 MHz. Standard Frequency List updated. Standard Frequency List updated. Updated rendering, application section, frequency range, environmental compliance, frequencies, and ordering codes. Standard Frequency List updated. Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 9 of 9 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 23Jul2010
