BA-22

VESTAL PART NUMBER WIRE AWG DIAMETER (WD) PITCH (P) TAPE WIDTH (T) BETWEEN TAPE (BT) MATERIAL PLATING QTY PER 10" REEL WEIGHT PER REEL BA-18 BA-20 BA-22 BA-24 BA-26 BA-22-SEQ 18 20 22 24 26 22 .040" .030" .025" .020" .015" .025" .200" .200" .200" .200" .200" .200" .250" .250" .250" .250" .250" .250" 2.062" 2.062" 2.062" 2.062" 2.062" 1.700" SOLID COPPER SOLID COPPER SOLID COPPER SOLID COPPER SOLID COPPER SOLID COPPER TIN TIN TIN TIN TIN TIN 8,000 8,000 10,000 10,000 10,000 10,000 8.75 lbs 5.80 lbs 4.70 lbs 3.25 lbs 2.30 lbs 4.05 lbs BT NOTES : WD 1. All products are RoHS compliant 2. All taping dimensions and tolerances conform to EIA-296F unless otherwise noted 3. All wire meets ASTM-B33 for solderability P T Title: Bare Axial Jumper Wire Drawing No. : VED002 Rev: C Revision Date: 01.02.06 Approval: WHK VESTAL Vestal Electronic Devices, LLC 635 Dickson Street Endicott, NY 13760 Phone: 607-773-8461 ~ Fax: 607-772-8184 Email: vedsales@vestalelectronics.com
