MI-26M-IX

MI-200 Features TM Military DC-DC Converters 50 to 100W Inputs: 28Vdc per MIL-STD-704D/E 155Vdc per MIL-STD-1399A 270Vdc per MIL-STD-704D/E Single output: 2 – 48Vdc Up to 23W/in3 MIL-STD-810 environments Current limit OVP and thermal shutdown Power boosters for higher power outputs ZVS/ZCS power architecture Low noise FM control Size: 4.6" x 2.4" x 0.5" (116,8 x 61,0 x 12,7mm) Product Highlights The MI-Series is designed for military applications and is based on Vicor’s 1st Generation family of zero-current/zero-voltage switching, component level DC-DC converters. Operating at frequencies in excess of 1MHz, the MI-Series offers state-of-the-art performance in terms of power density, efficiency, noise, ease of use, and reliability. All units are manufactured in ISO 9001-registered facilities. Full epoxy encapsulation in Vicor’s industry standard package enables the MI-Series to meet MIL-STD-810 environmental requirements for humidity, fungus, salt, fog, explosive atmosphere, acceleration, vibration, and shock. (See page 32.) Standard features such as wide output trimming/programming, current limiting, remote sense, output inhibit, and latching OVP and OTP combine to offer a high degree of protection, versatility, and reliability for military power systems. Up to 90% efficiency Remote sense Converter/Booster Specifications (At TBP = 25°C, nominal line and 75% load, unless otherwise specified) PARAMETER Input Characteristics Input voltage range No load power dissipation Output Characteristics Set point accuracy Load/line regulation Output temperature drift Output noise - pp Output voltage trimming (1) Remote sense compensation OVP set point (2) Current limit Short circuit current (3) Control Pin Characteristics Gate-in high threshold Gate-in low threshold Gate-in low current Power sharing accuracy Isolation Characteristics Isolation (input to output) Isolation (output to baseplate) Isolation (input to baseplate) Input/output capacitance Environmental (MIL-STD-810) Altitude - method 500.2 Humidity - method 507.2 Acceleration - method 513.3 Vibration - method 514.3 Shock - method 516.3 50 0.5 115 105 20 MIN TYP MAX UNITS TEST CONDITIONS See input voltage chart 1.35 2.0 0.5 0.05 0.2 0.01 1.0 100 1.0 0.2 0.5 0.02 1.5 150 110 135 125 130 Watts % Vnom % Vnom % Vnom %/°C % Vnom mV % Vnom Vdc % Vnom % Inom % Inom Vdc Vdc mA LL to HL, 10% to FL LL to HL, NL to 10% } Whichever is greater 20MHz BW 125 Latching Auto restart 6 0.65 0.95 3,000 500 1,500 50 70,000 86 / 240 9 20 40 2,478,477 584,920 483,303 80-90 0.07 95 75 6 1.05 Vrms Vrms Vrms pF feet % / hours g's g's g's hours hours hours % °C/W °C °C °C ounces (grams) Procedure II Procedure 1, cycle 1 Procedure 2 Procedure 1, category 6 Procedure 1 Reliability (MIL-HDBK-217F) 25°C Ground Benign: G.B. 50°C Naval Sheltered: N.S. 65°C Airborne Inhabited Cargo: A.I.C. Thermal Characteristics Efficiency Baseplate to sink Thermal shutdown 90 Baseplate operating temperature Storage temperature M echanical Specifications Weight (1) (2) 105 +85 +100 With thermal pads Latching See product grade See product grade 6.0 (170) MI-200 10/02 1 of 2 10V, 12V, and 15V outputs, standard trim range ±10%. Consult factory for wider trim range. No over temperature or voltage protection in booster modules. (3) Output voltages of 5V or less incorporate foldback current limiting; outputs of 10V and above provide constant current limiting. Configuration Chart MI - 2 Nominal 2 5 6 7 = 28V = 155V = 270V = 165V Semi-custom driver and booster modules available: Consult factory. (1) 16V operation at 75% load. (2) These units rated at 75% load from 125-150Vin: MI-26Z-xV MI-26Y-xV MI-260-xW 28Vdc input per MIL-STD 704D/E 155Vdc input per DOD-STD-1399A 270Vdc input per MIL-STD-704D/E Input Voltage Range 18 – 50V 100 – 210V (2) 125 – 400V 100 – 310V (1) Output Voltage Transient 60V 230V 475V Z = 2V Y = 3.3V 0 = 5V X = 5.2V W= 5.5V V = 5.8V T = 6.5V R = 7.5V M= 10V 1 = 12V P = 13.8V 2 = 15V N = 18.5V 3 = 24V L = 28V J = 36V K = 40V 4 = 48V Product Grade I M = = Operating Temp. -40°C to +85°C -55°C to +85°C Output Power/Current ≥5V
