MI-LC6V-MY

MI-ComPAC Military DC-DC Power Supplies Features Inputs: 28Vdc per MIL-STD-704A, MIL-STD-1275A 270Vdc per MIL-STD-704D/E Outputs: 1 to 3, 2 to 48Vdc Up to 5W/in3 MIL-STD-461C/D/E EMI compliance High efficiency TM Low noise FM control Reverse polarity protection Size — 1- up: 8.6" x 2.5" x 0.99" (219,2 x 64,5 x 25,1mm) Size — 2- up: 8.6" x 4.9" x 0.99" (219,2 x 126,0 x 25,1mm) Size — 3- up: 8.6" x 7.3" x 0.99" (219,2 x 187,45 x 25,1mm) Product Highlights The MI-ComPAC is a complete single, dual, or triple output DC-DC power supply that delivers up to 300W from inputs of 28Vdc or 270Vdc. The MI-ComPAC meets the conducted emissions and conducted susceptibility specifications of MIL-STD-461C/D/E and offers complete input transient, surge, and spike protection to the most severe levels of MIL-STD-1275A, 704A. Reverse polarity protection and over/undervoltage lockout provide additional safeguards against potentially damaging line conditions. The MI-ComPAC also features a master disable. Remote sense ZVS/ZCS power architecture Configuration Chart Number of Modules 1 2 3 Single Output MI-LC MI-MC MI-NC Dual Output MI-PC MI-QC Triple Output MI-RC – – – 50 – 100W 150 – 200W 300W 8.6" x 2.5" x 0.99" 8.6" x 4.9" x 0.99" 8.6" x 7.3" x 0.99" – – 100 – 200W 200 – 300W 8.6" x 4.9" x 0.99" 8.6" x 7.3" x 0.99" 2 3 – 150 – 300W 8.6" x 7.3" x 0.99" 3 Conduction Cooled Models Available Add "-CC" to the end of the part number. (Consult factory for details.) Input Voltage Nominal Range 2 =28Vdc 18 – 50V 6 =270Vdc 125 – 400V (1) Output Voltage Z = 2V Y = 3.3V 0 = 5V X = 5.2V W= 5.5V V = 5.8V T = 6.5V R = 7.5V M = 10V 1 = 12V P = 13.8V 2 = 15V N = 18.5V 3 = 24V L = 28V J = 36V K = 40V 4 = 48V Product Grade I = –40°C to +85°C M = –55°C to +85°C Output Power/Current ≥5V
