VI-ARM-H2S

45 Features • Autoranging input • Microprocessor controlled • VI-ARM-1 500 Watts @ 90-132Vac 750 Watts @ 180-264Vac • VI-ARM-2 1000 Watts @ 90-132Vac 1500 Watts @ 180-264Vac • 96-98% Efficiency • 100˚C baseplate (no derating) • UL, CSA, TÜV, VDE, BABT • AC Bus OK, module enable • Inrush limiting (no external circuitry) • CE Marked Typical Applications: systems requiring a rugged, full featured interface to the AC mains in the smallest possible package. VI-ARM TM Autoranging Rectifier Modules Up to 1500 Watts Actual size: 2.28 x 1.45 x 0.5 in 57,9 x 36,8 x 12,7 mm Absolute Maximum Ratings Parameter Rating VI-ARM-1/VI-ARM-2 Unit L to N 264 Vac L to N 280 Vac +Out to –Out 400 Vdc B OK to –Out 16 Vdc EN to –Out 16 Vdc Output power 500/1000 Watts 750/1500 Watts Mounting torque 4 - 6 (0.45 - 0.68) in- lbs (N-m) Pin soldering temperature 500 (260) °F (°C) Pin soldering temperature 750 (390) °F (°C) Storage temperature, C–,& T– Grade –40 to +125 °C Operating temperature, C– Grade –20 to +100 °C Operating temperature, T– Grade –40 to +100 °C Notes 100ms Product Highlights The ARM (Autoranging Rectifier Module) is an AC front end module which provides autoranging line rectification and inrush current limiting. The ARM is available in either 500/750W or 750/1000W models in a mini sized package measuring only 2.28" x 1.45" x 0.5". The ARM interfaces directly with worldwide AC mains and may be used with Vicor 1st or 2nd Generation 300V input DC-DC converters to realize an autoranging, high density, low profile switching power supply. The ARM includes a microcontroller that continuously monitors the AC line to control bridge/doubler operation. The user need only provide external capacitance to satisfy system hold-up requirements. Vicor 2nd Generation packaging technology offers flexible mounting options for various manufacturing processes. The ARM may be installed as a conventional leaded device for on-board applications, in-board for low profile, height restricted applications, socketed or surface mounted with optional ModuMate interconnect products. 90-132Vac 180-264Vac 6 each, 4-40 screw
