1N4148WS-V-GS18

1N4148WS-V Vishay Semiconductors Small Signal Fast Switching Diode Features • These diodes are also available in other case styles including the DO35 case e3 with the type designation 1N4148, the MiniMELF case with the type designation LL4148, and the SOT23 case with the type designation IMBD4148-V • Silicon epitaxial planar diode • Fast switching diodes • Lead (Pb)-free component • Component in accordance to RoHS 2002/95/EC and WEEE 2002/96/EC 20145 Mechanical Data Case: SOD323 plastic case Weight: approx. 4.3 mg Packaging Codes/Options: GS18/10 k per 13" reel (8 mm tape), 10 k/box GS08/3 k per 7" reel (8 mm tape), 15 k/box Parts Table Part 1N4148WS-V Ordering code 1N4148WS-V-GS18 or 1N4148WS-V-GS08 Type Marking A2 Remarks Tape and Reel Absolute Maximum Ratings Tamb = 25 °C, unless otherwise specified Parameter Reverse voltage Repetitive peak reverse voltage Average rectified current half wave rectification with resistive load Surge forward current Power dissipation Note: 1) Valid provided that electrodes are kept at ambient temperature. f ≥ 50 Hz t < 1 s and Tj = 25 °C Test condition Symbol VR VRRM IF(AV) IFSM Ptot Value 75 100 1501) 350 2001) Unit V V mA mA mW Document Number 85751 Rev. 1.7, 14-Sep-07 www.vishay.com 1 1N4148WS-V Vishay Semiconductors Thermal Characteristics Tamb = 25 °C, unless otherwise specified Parameter Thermal resistance junction to ambient air Junction temperature Storage temperature Note: 1) Valid provided that electrodes are kept at ambient temperature. Test condition Symbol RthJA Tj Tstg Value 6501) 150 - 65 to + 150 Unit K/W °C °C Electrical Characteristics Tamb = 25 °C, unless otherwise specified Parameter Forward voltage Test condition IF = 10 mA IF = 100 mA V R = 20 V Leakage current V R = 75 V VR = 100 V VR = 20 V, Tj = 150 °C Diode capacitance Voltage rise when switching ON (tested with 50 mA pulses) Reverse recovery time Rectification efficiency VF = VR = 0 V tested with 50 mA pulses, tp = 0.1 µs, rise time < 30 ns, fp = (5 to 100) kHz IF = 10 mA, IR = 1 mA, VR = 6 V, RL = 100 Ω f = 100 MHz, VRF = 2 V Symbol VF VF IR IR IR IR CD Vfr Min Typ. Max 1000 1200 25 5 100 50 4 2.5 Unit mV mV nA µA µA µA pF V trr ην 0.45 4 ns Rectification Efficiency Measurement Circuit 60 Ω VRF = 2 V 2 nF 5 kΩ VO 17436 www.vishay.com 2 Document Number 85751 Rev. 1.7, 14-Sep-07 1N4148WS-V Vishay Semiconductors Typical Characteristics Tamb = 25 °C, unless otherwise specified 103 1.1 Tj = 25 °C f = 1 MHz 102 Tj = 100 °C Tj = 25 °C 1.0 CD (0 V) IF (mA) CD (VR) 10 0.9 1 0.8 10 -1 0.7 10-2 17437 0 1 2 17440 0 2 4 6 8 10 VF (V) VR (V) Figure 1. Forward characteristics Figure 4. Relative Capacitance vs. Reverse Voltage 104 5 2 Tj = 25 °C f = 1 kHz 104 5 2 103 5 103 5 IR (nA) rf (Ω) 2 2 102 5 2 102 5 2 10 5 2 10 5 2 VR = 20 V 1 10-2 17438 10-1 1 10 102 17441 0 100 200 IF (mA) Tj (°C) Figure 2. Dynamic Forward Resistance vs. Forward Current Figure 5. Leakage Current vs. Junction Temperature 250 Ptot - Power Dissipation (mW) 200 150 100 50 0 0 20324 50 100 150 200 Tamb - Ambient Temperature (°C) Figure 3. Admissible Power Dissipation vs. Ambient Temperature Document Number 85751 Rev. 1.7, 14-Sep-07 www.vishay.com 3 1N4148WS-V Vishay Semiconductors 100 5 4 3 2 I v = tP/T IFRM V=0 tP T t T = 1/fP 10 IFRM (A) 5 4 3 2 0.1 0.2 0.5 1 5 4 3 2 0.1 10-5 17442 2 5 10-4 2 5 10-3 2 5 10-2 2 5 10-1 2 5 1 2 5 10 tP (s) Figure 6. Admissible Repetitive Peak Forward Current vs. Pulse Duration Package Dimensions in millimeters (inches): SOD323 17443 www.vishay.com 4 Document Number 85751 Rev. 1.7, 14-Sep-07 1N4148WS-V Vishay Semiconductors Ozone Depleting Substances Policy Statement It is the policy of Vishay Semiconductor GmbH to 1. Meet all present and future national and international statutory requirements. 2. Regularly and continuously improve the performance of our products, processes, distribution and operating systems with respect to their impact on the health and safety of our employees and the public, as well as their impact on the environment. It is particular concern to control or eliminate releases of those substances into the atmosphere which are known as ozone depleting substances (ODSs). The Montreal Protocol (1987) and its London Amendments (1990) intend to severely restrict the use of ODSs and forbid their use within the next ten years. Various national and international initiatives are pressing for an earlier ban on these substances. Vishay Semiconductor GmbH has been able to use its policy of continuous improvements to eliminate the use of ODSs listed in the following documents. 1. Annex A, B and list of transitional substances of the Montreal Protocol and the London Amendments respectively 2. Class I and II ozone depleting substances in the Clean Air Act Amendments of 1990 by the Environmental Protection Agency (EPA) in the USA 3. Council Decision 88/540/EEC and 91/690/EEC Annex A, B and C (transitional substances) respectively. Vishay Semiconductor GmbH can certify that our semiconductors are not manufactured with ozone depleting substances and do not contain such substances. We reserve the right to make changes to improve technical design and may do so without further notice. Parameters can vary in different applications. All operating parameters must be validated for each customer application by the customer. Should the buyer use Vishay Semiconductors products for any unintended or unauthorized application, the buyer shall indemnify Vishay Semiconductors against all claims, costs, damages, and expenses, arising out of, directly or indirectly, any claim of personal damage, injury or death associated with such unintended or unauthorized use. Vishay Semiconductor GmbH, P.O.B. 3535, D-74025 Heilbronn, Germany Document Number 85751 Rev. 1.7, 14-Sep-07 www.vishay.com 5 Legal Disclaimer Notice Vishay Disclaimer All product specifications and data are subject to change without notice. Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained herein or in any other disclosure relating to any product. Vishay disclaims any and all liability arising out of the use or application of any product described herein or of any information provided herein to the maximum extent permitted by law. The product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase, including but not limited to the warranty expressed therein, which apply to these products. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or by any conduct of Vishay. The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications unless otherwise expressly indicated. Customers using or selling Vishay products not expressly indicated for use in such applications do so entirely at their own risk and agree to fully indemnify Vishay for any damages arising or resulting from such use or sale. Please contact authorized Vishay personnel to obtain written terms and conditions regarding products designed for such applications. Product names and markings noted herein may be trademarks of their respective owners. Document Number: 91000 Revision: 18-Jul-08 www.vishay.com 1
