601-10450003BO1E4

601-10450003BO1E4

  • 厂商:

    VISHAY

  • 封装:

  • 描述:

    601-10450003BO1E4 - Full 360° Smart Position Sensor - Vishay Siliconix

  • 数据手册
  • 价格&库存
601-10450003BO1E4 数据手册
Model 601-1045 Vishay Spectrol Full 360° Smart Position Sensor FEATURES • Ratiometric output over 360° range with no dead band • Self-contained package not requiring external electronic interface • Angular response 50 µs • Reverse polarity protection • Absolute and non volatile positioning output The model 601-1045 represents a new generation of Smart Sensors. This unique electronic device is a self-contained package which provides an analog electrical output over a full 360° without the need of external electronics. The low power consumption and non-volatile output makes this universal sensor the real cost-effective alternative to encoders. It’s versatile design makes it suitable for a variety of industries and applications, such as CCTVs, Medical Instruments, Robotic arm control, CNC machinery, Rotational control systems, Pick n’ place machines and Angular feedback applications. RoHS COMPLIANT STANDARD ELECTRICAL SPECIFICATIONS PARAMETER Supply Supply Current Absolute Maximum Supply Independent Lineaity Resolution Electrical Track Analog Voltage Output Output Ramp Slope Output Impedance Temperature Characteristic Insulation Resistance Dielectric Strength 4.5 to 5.5 VDC 20 mA max. 6V ± 1 % typical Resolves down to a min. of 0.5° 360° continuous Not less than 90 % of supply (ratiometric) see graphs on next page Electrically switchable see graphs 1 Ω typical ± 1° max. over - 40/+ 70 °C 1000 MΩ min. 1000 VRMS, 50/60 Hz MECHANICAL SPECIFICATIONS Rotation Rotational Speed Operating Torque Maximum Weight 360° continuous 5 max. revs/s (duration 60 s) 3.68 (0.5) mNm (oz. - in) 30 g ENVIRONMENTAL SPECIFICATIONS Operating Life Operating Temperature Range Storage Temperature Range Sealing 5 000 000 cycles - 40 °C to + 70 °C - 40 °C to + 105 °C IP54 ORDERING INFORMATION/DESCRIPTION 601-1045 MODEL XXXX STANDARD CONFIGURATION CODE PRODUCT NUMBER 0000 0001 0002 0003 Ø 1.57 PIN Yes Yes Ø 3.18 PIN Yes Yes BO1 PACKAGING e4 LEAD FINISH SAP PART NUMBERING GUIDELINES 601 MODEL 1045 STYLE 1045 or 1056 www.vishay.com 146 For technical questions, contact: sfer@vishay.com Document Number: 57000 Revision: 20-Mar-07 0001 PIN CONFIGURATION B01 PACKAGING Model 601-1045 Full 360° Smart Position Sensor Vishay Spectrol DIMENSIONS in inches (millimeters) 42 20 3/ 8 - 32 UNEF 2A 23.5 27.8 Ø 6.35 14.3 8.0 0.80 Ø 1.57 ANTI-ROTATION PIN OPTION TO BE SPECIFIED SEE ORDERING INFORMATION Ø 3.18 1.6 33 Spectrol PAT. APP. 99087991 1045-XXXX XXXX 1234 PIN CONNECTIONS 1 44 FUNCTION Supply O/P voltage Ramp polarity +5V 0V Output Direction 2 3 4 PRODUCT NO. DATE CODE AND TERMINAL I.D. LABEL MATERIAL SPECIFICATIONS Housing Bushing Shaft Pin Terminal Connector Plastic Brass, nickel plated Stainless steel Gold plated Pin header to suit IDC connectors. e.g. Panduit C100 - F22 and Molex 7880 Steel, nickel plated Brass, nickel plated SUPPLY (5 V NOM) Output Connection CABLE ASSEMBLY FOR CONNECTION Part Number Description 601-1056-0000 Molex KK 4-way crimp connector 4 wire (250 mm) SUPPLY (5 V NOM) Bushing Mount Hardware Lock Washer, Internal Tooth Panel Nut NOT LESS THAN 90 % OF SUPPLY VOLTAGE TRANSITION TIME 50 µs TYP. NOT LESS THAN 90 % OF SUPPLY VOLTAGE TRANSITION TIME 50 µs TYP. 0 360 CW SHAFT ROTATION (°) CW SHAFT ROTATION (°) DEFAULT OUTPUT [Terminal #4 Open-Circuit] REVERSE SLOPE [Terminal #4 Connected to OV] Document Number: 57000 Revision: 20-Mar-07 For technical questions, contact: sfer@vishay.com www.vishay.com 147 Legal Disclaimer Notice Vishay Disclaimer All product specifications and data are subject to change without notice. Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained herein or in any other disclosure relating to any product. Vishay disclaims any and all liability arising out of the use or application of any product described herein or of any information provided herein to the maximum extent permitted by law. The product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase, including but not limited to the warranty expressed therein, which apply to these products. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or by any conduct of Vishay. The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications unless otherwise expressly indicated. Customers using or selling Vishay products not expressly indicated for use in such applications do so entirely at their own risk and agree to fully indemnify Vishay for any damages arising or resulting from such use or sale. Please contact authorized Vishay personnel to obtain written terms and conditions regarding products designed for such applications. Product names and markings noted herein may be trademarks of their respective owners. Document Number: 91000 Revision: 18-Jul-08 www.vishay.com 1
