APD-192G064-1

APD-192G064-1 Vishay Dale Plasma Panel Display Modules 192 x 64 Graphics Display with Drive Electronics TTL Level Data Interface and Integrated DC Converter FEATURES • TTL level video interface. • On board DC converter. • Slim profile. • Large, bright characters and graphics. • Highly visible for long distance viewing. The APD-192G064-1 has been designed to offer high brightness and superior viewing aesthetics in a package that is very affordable. This display is ideal for low to medium level information content messages and would be ideal for applications such as arcade games, process control, POS terminals, medical equipment, message centers and ATM machines. ELECTRICAL SPECIFICATIONS Voltages Required: VDC: + 12 to + 24 VDC. Power Required: Typical = 12 watts. Maximum = 55 watts. OPTICAL SPECIFICATIONS Viewing Area: 15.33" [389.38] W x 5.09" [129.29] H. Pixel Pitch: 0.080" [2.032]. Pixel Size: 0.050" [1.27]. Color: Neon orange. Character Array: 8 x 8: 24 x 16. 6 x 8: 32 x 16. Character Size: 0.48" [12.19] W x 0.64" [16.26] H . Luminance: 50 foot lamberts minimum. STANDARD ELECTRICAL SPECIFICATIONS* DESCRIPTION DC converter input DC converter power @ + 12 V Logic 1 Input Logic 0 Input SYMBOL VDC Amps Vih Vil MIN. + 10.0 TYP. + 24.0 MAX. + 28.0 UNITS VDC — VDC VDC Screen Clear 50% Lit 100% Lit 0.100 1.7 3.5 2.0 — — — — 0.8 *Recommended operating voltages. All maximums are absolute maximum. ENVIRONMENTAL SPECIFICATIONS Operating Temperature: 0°C to + 70°C. Storage Temperature: - 40°C to + 85°C. Relative Operating Humidity: To 95% non-condensing. Mechanical Shock: 30 G. Vibration: 3 G. Operating Altitude: 10,000 feet. DIMENSIONS in inches [millimeters] 192 x 64 Full Field Pixel Pitch: 0.080 [2.03] Pixel Size: 0.050 [1.27] 17.055 [433.20] 6.975 ± 0.010 [177.17 ± 0.254] 6.663 [169.24] 8.527 [216.59] 0.156 [3.96] 15.330 [389.38] 16.68 [423.67] 17.367 ± 0.010 [441.12 ± 0.254] Center of Active Area 0.156 [3.96] GENERAL DESCRIPTION The APD-192G064-1 DC Plasma display offers viewing qualities designers seek such as high contrast, viewing angle of 150° minimum, and long distance readability. It is bright (50 foot lamberts minimum) with characters and graphics figures presented in a pleasing neon orange color against a black background. Plasma is much more readable and eye-pleasing than liquid crystal or vacuum fluorescent displays and is filterable to red, amber, or neutral density. These plasma display panels are driven in a standard row - column refresh method much like a CRT display. The designer need only supply TTL level signals for SERIAL DATA, DOT CLOCK, COLUMN LATCH, ROW DATA, ROW CLOCK and DISPLAY ENABLE. The SERIAL DATA is entered with the DOT CLOCK up to frequencies as high as 8mHz. After a row of 192 pixels is clocked in, the COLUMN LATCH signal is toggled and the data is latched. At the time the data is latched, the display is briefly disabled using the DISPLAY ENABLE signal, then the row pointer is advanced with the ROW CLOCK signal. Once each frame the ROW DATA must be asserted to synchronize the column serial data with the beginning row. The recommended scanning frequency is approximately 70 Hz but may be as high as 200 Hz. The high clock rate on the data clock allows for rapid refresh and maximum access time to the refresh ram. Document Number: 37013 Revision 05-Dec-00 5.090 [129.29] 6.19 [157.23] 3.217 [81.71] 0.403 [10.24] 0.840 [21.34] 0.447 ± 0.025 [11.35 ± 0.635] 1.10 [27.94] Max. Component Height ....... ....... Pin 1 of P1 10.135 [257.43] Ref. 11.86 [301.24] Ref. Pin 1 of P2 www.vishay.com 2 APD-192G064-1 Vishay Dale PIN DESCRIPTION P3, POWER CONNECTOR AMP #641737-1 or equivalent. (Mates with AMP 1-480424-0 or equivalent.) PIN 4 3 2 1 SIGNAL N/C GND GND VDC DESCRIPTION Reserved Ground Ground DC Converter Supply t4 Row Data t2 t1 Row Clock 0 Display Enable 0 1 1 2 2 62 62 63 63 0 0 1 1 t3 ROW CLOCK - This signal clocks ROW DATA on the falling edge. The ROW CLOCK signal is repetitive and must be present for proper scanning of the display module. The APD-192G064-1 has a unique input protection circuit that assures the column drivers stay blanked on power up. The protection circuit unblanks the column drivers when the ROW CLOCK signal begins (i.e. the display begins scanning). LOGIC AND DATA TIMING P2, DATA CONNECTOR AMP #103309-2 or equivalent. (Mates with AMP 746195-2, MOLEX 39-27-1146 or equivalent.) PIN 1 3 5 7 9 11 13 DESCRIPTION DISPLAY ENABLE ROW DATA ROW CLOCK COLUMN LATCH DOT CLOCK SERIAL DATA No connect PIN 2 4 6 8 10 12 14 DESCRIPTION GROUND GROUND GROUND GROUND GROUND GROUND GROUND Row Clock Column Latch Display Enable DESCRIPTION OF INPUT SIGNALS DOT CLOCK - This signal enters the SERIAL DATA on each low to high transition. A total of 192 DOT CLOCK transitions must be present for each line of column/anode data. SERIAL DATA - This signal presents the pixel data in positive logic format. A logic one represents a lit pixel and a logic zero represents an extinguished pixel. Data is entered from right to left. The first pixel data entered will represent the leftmost pixel in the row. COLUMN LATCH - This signal latches the pixel data into the driver outputs. When the COLUMN LATCH signal goes to logic one the data entered previously will fall through to the driver outputs. When the signal returns to a logic zero, the data is latched and the shift register is now ready to accept the next row of data. Must be held low while entering new SERIAL DATA. DISPLAY ENABLE - This signal enables the output drivers. Using a duty cycle control, this signal may also be used for intensity control. The DISPLAY ENABLE must be at logic zero before the COLUMN LATCH signal transitions. To avoid display blurring, the ROW CLOCK signal should also transition while DISPLAY ENABLE is a logic zero. It is recommended that this signal remain low for 10µS min. ROW DATA - This signal is the first line marker for the scan. This input should be held high to correspond to the first row of pixel data. 1st Bit of Row Will Appear in Leftmost Column Serial Data 0 1 2 190 191 t5 Dot Clock t6 Positive Edge x 192 t7 PARAMETER t1 t2 t3 t4 t5 t6 t7 MINIMUM 100 5 1 — 25 75 75 TYPICAL — — — 70 — — — MAXIMUM — — — 200 — — — UNITS nS uS uS Hz nS nS nS ORDERING INFORMATION Display Module with Drivers, TTL Interface and On Board DC Converter ...................................................................... APD-192G064-1 Data Connector Kit ................................................................................................................................................................... 280105-05 Power Connector Kit ................................................................................................................................................................. 280108-13 Video Controller (+5V) ........................................................................................................................................... .................. PDS-500 Video Contoller (+ 12V)............................................................................................................................................. ............ PDS-500-1 Document Number: 37013 Revision 05-Dec-00 www.vishay.com 3 Legal Disclaimer Notice Vishay Disclaimer All product specifications and data are subject to change without notice. Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained herein or in any other disclosure relating to any product. Vishay disclaims any and all liability arising out of the use or application of any product described herein or of any information provided herein to the maximum extent permitted by law. The product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase, including but not limited to the warranty expressed therein, which apply to these products. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or by any conduct of Vishay. The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications unless otherwise expressly indicated. Customers using or selling Vishay products not expressly indicated for use in such applications do so entirely at their own risk and agree to fully indemnify Vishay for any damages arising or resulting from such use or sale. Please contact authorized Vishay personnel to obtain written terms and conditions regarding products designed for such applications. Product names and markings noted herein may be trademarks of their respective owners. Document Number: 91000 Revision: 18-Jul-08 www.vishay.com 1
