BAT46W-V
Vishay Semiconductors
Small Signal Schottky Diode
Features
• For general purpose applications • This diode features very low turn-on voltage and fast switching. • This device is protected by a PN junction guard ring against excessive voltage, such as electrostatic discharges. • This diode is also available in the DO-35 case with the type designation BAT46 and in the MiniMELF case with the type designation LL46. • AEC-Q101 qualified • Compliant to RoHS directive 2002/95/EC and in accordance to WEEE 2002/96/EC
17431
Mechanical Data
Case: SOD-123 Weight: approx. 10.3 mg Packaging Codes/Options: GS18/10 k per 13" reel (8 mm tape), 10 k/box GS08/3 k per 7" reel (8 mm tape), 15 k/box
Parts Table
Part BAT46W-V Ordering code BAT46W-V-GS18 or BAT46W-V-GS08 Type Marking L6 Remarks Tape and Reel
Absolute Maximum Ratings
Tamb = 25 °C, unless otherwise specified
Parameter Repetitive peak reverse voltage Forward continuous current Repetitive peak forward current Surge forward current Power dissipation
1) 1)
Test condition
Symbol VRRM IF
Value 100 1501) 3501) 7501) 1501)
Unit V mA mA mA mW
tp < 1 s, δ < 0.5 tp < 10 ms Tamb = 65 °C
IFRM IFSM Ptot
Valid provided that electrodes are kept at ambient temperature
Document Number 85663 Rev. 1.4, 05-Aug-10
For technical questions within your region, please contact one of the following: DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
www.vishay.com 1
BAT46W-V
Vishay Semiconductors Thermal Characteristics
Tamb = 25 °C, unless otherwise specified
Parameter Thermal resistance junction to ambient air Junction temperature Ambient operating temperature range Storage temperature range
1)
Test condition
Symbol RthJA Tj Tamb Tstg
Value 3001) 125 - 55 to + 125 - 55 to + 150
Unit K/W °C °C °C
Valid provided that electrodes are kept at ambient temperature
Electrical Characteristics
Tamb = 25 °C, unless otherwise specified
Parameter Reverse breakdown voltage Test condition IR = 100 µA (pulsed) VR = 1.5 V VR = 1.5 V, Tj = 60 °C V R = 10 V Leakage current2) VR = 10 V, Tj = 60 °C V R = 50 V VR = 50 V, Tj = 60 °C V R = 75 V VR = 75 V, Tj = 60 °C IF = 0.1 mA Forward voltage2) IF = 10 mA IF = 250 mA Diode capacitance
2)
Symbol V(BR) IR IR IR IR IR IR IR IR VF VF VF CD CD
Min 100
Typ.
Max 0.5 5 0.8 7.5 2 15 5 20 250 450 1000
Unit V µA µA µA µA µA µA µA µA mV mV mV pF pF
VR = 0 V, f = 1 MHz VR = 1 V, f = 1 MHz
10 6
Pulse test tp < 300 µs, δ < 2 %
Typical Characteristics
Tamb = 25 °C, unless otherwise specified
IR - Reverse Leakage Current (µA) 1000 I F - Forward Current (mA) 100 T j = 60 °C
100
10
T j = 60 °C
10 25 °C 1
1
0.1
Tj = 25 °C
0.1 0.01
0.01
0
0.2
18546
0.4 0.6 0.8 1 VF - Forward Voltage (V)
1.2
18547
0
20
40
60
80
100
VR - Reverse Voltage (V)
Figure 1. Typical Instantaneous Forward Characteristics
Figure 2. Typical Reverse Characteristics
www.vishay.com 2
For technical questions within your region, please contact one of the following: Document Number 85663 DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com Rev. 1.4, 05-Aug-10
BAT46W-V
Vishay Semiconductors
250 Ptot - Power Dissipation (mW) 200 150 100 50 0 0
18548
200 50 100 150 Tamb - Ambient Temperature (°C)
Figure 3. Admissible Power Dissipation vs. Ambient Temperature
Package Dimensions in millimeters (inches): SOD-123
0.1 (0.004) max. 1.35 (0.053)
8°
0.45 (0.018) 0.25 (0.010)
0.5 (0.020) ref.
Cathode bar 2.85 (0.112) 2.55 (0.100)
0.15 (0.006)
0.10 (0.004)
1 (0.039)
0.2 (0.008)
0° to
Mounting Pad Layout
0.85 (0.033)
0.85 (0.033)
0.45 (0.018)
0.65 (0.026)
3.85 (0.152) 3.55 (0.140)
1.40 (0.055)
1.7 (0.067)
2.5 (0.098)
Rev. 4 - Date: 24. Sep. 2009 Document no.: S8-V-3910.01-001 (4)
17432
Document Number 85663 Rev. 1.4, 05-Aug-10
For technical questions within your region, please contact one of the following: DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
0.85 (0.033)
www.vishay.com 3
