BAT54 Vishay High Power Products Schottky Diode, 0.2 A FEATURES • Small foot print, surface mountable • Very low forward voltage drop • Extremely fast switching speed for high frequency operation (K) 1 • Guard ring for enhanced ruggedness and long term reliability 3 (nc) 2 (A) • Designed and qualified for industrial level SOT-23 DESCRIPTION This Schottky barrier diode is designed for high speed switching applications, voltage clamping and circuit protection. Miniature surface mount packages with reduced foot print are excellent for portable applications where space is limited. PRODUCT SUMMARY IF(AV) VR 0.2 A 30 V MAJOR RATINGS AND CHARACTERISTICS SYMBOL IF VRRM IFSM VF Pd TJ tp = 10 ms sine 30 mA DC, TJ = 25 °C Power dissipation at TA = 25 °C Range DC CHARACTERISTICS VALUES 0.2 30 1.0 0.5 200 - 65 to 150 UNITS A V A V mW °C VOLTAGE RATINGS PARAMETER Maximum DC reverse voltage Maximum working peak reverse voltage SYMBOL VR VRWM BAT54 30 UNITS V ABSOLUTE MAXIMUM RATINGS PARAMETER Forward current Maximum peak one cycle non-repetitive surge current at TJ = 25 °C SYMBOL IF IFSM 10 ms sine or 6 ms rect. pulse DC 5 µs sine or 3 µs rect. pulse Following any rated load condition and with rated VRRM applied TEST CONDITIONS VALUES 0.2 8.4 1.0 A UNITS Document Number: 93420 Revision: 18-Jun-08 For technical questions, contact: diodes-tech@vishay.com www.vishay.com 1 BAT54 Vishay High Power Products ELECTRICAL SPECIFICATIONS PARAMETER SYMBOL 0.1 A 30 mA Maximum forward voltage drop VFM (1) 10 mA 1 mA 0.1 mA Maximum reverse leakage current Maximum junction capacitance Maximum voltage rate of change Note (1) Pulse width < 300 µs, duty cycle < 2 % IRM (1) CT dV/dt V R = 25 V V R = 30 V VR = 1 VDC (test signal range 100 kHz to 1 MHz), TJ = 25 °C Rated VR TJ = 25 °C TEST CONDITIONS VALUES 0.65 0.50 0.40 0.32 0.24 2 3 10 10 000 µA pF V/µs V UNITS Schottky Diode, 0.2 A THERMAL - MECHANICAL SPECIFICATIONS PARAMETER Maximum junction and storage temperature range Maximum thermal resistance, junction to ambient Approximate weight Marking device Note (1) SYMBOL TJ (1), TStg RthJA TEST CONDITIONS VALUES - 65 to 150 UNITS °C °C/W g Mounted on PC board FR4 with minimum pad size 500 0.008 Case style SOT-23 EYWLC dP tot 1 ------------ < ------------- thermal runaway condition for a diode on its own heatsink dT J R thJA www.vishay.com 2 For technical questions, contact: diodes-tech@vishay.com Document Number: 93420 Revision: 18-Jun-08 BAT54 Schottky Diode, 0.2 A Vishay High Power Products 1 10 0.1 CT - Junction Capacitance (pF) IF - Instantaneous Forward Current (A) TJ = 25 °C 0.01 0.001 TJ = 150 °C TJ = 125 °C TJ = 25 °C 0.0001 0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1 0 5 10 15 20 25 30 VFM - Forward Voltage Drop (V) Fig. 1 - Maximum Forward Voltage Drop Characteristics (Per Leg) VR - Reverse Voltage (V) Fig. 3 - Typical Junction Capacitance vs. Reverse Voltage (Per Leg) 1 0.4 TJ = 150 °C IR - Reverse Current (mA) 0.1 TJ = 125 °C TJ = 100 °C TJ = 75 °C Average Power Loss (W) 0.3 D = 0.20 D = 0.25 D = 0.33 D = 0.50 D = 0.75 0.01 0.2 0.001 RMS limit DC TJ = 50 °C 0.0001 0.1 TJ = 25 °C 0.00001 0 0 5 10 15 20 25 30 0 0.1 0.2 0.3 VR - Reverse Voltage (V) Fig. 2 - Typical Values of Reverse Current vs. Reverse Voltage (Per Leg) IF(AV) - Average Forward Current (A) Fig. 4 - Forward Power Loss Characteristics IFSM - Non-Repetitive Surge Current (A) 10 1 At any rated load condition and with rated VRRM applied following surge 0.1 10 100 1000 10 000 tp - Square Wave Pulse Duration (µs) Fig. 5 - Maximum Non-Repetitive Surge Current Document Number: 93420 Revision: 18-Jun-08 For technical questions, contact: diodes-tech@vishay.com www.vishay.com 3 BAT54 Vishay High Power Products Schottky Diode, 0.2 A ORDERING INFORMATION TABLE DEVICE BAT54 PACKAGE SOT-23 MARKING EYWLC CONFIGURATION Single BASE QUANTITY 3000 DELIVERY MODE Tape and reel LINKS TO RELATED DOCUMENTS Dimensions Packaging information http://www.vishay.com/doc?95048 http://www.vishay.com/doc?95061 www.vishay.com 4 For technical questions, contact: diodes-tech@vishay.com Document Number: 93420 Revision: 18-Jun-08 Legal Disclaimer Notice Vishay Disclaimer All product specifications and data are subject to change without notice. Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained herein or in any other disclosure relating to any product. Vishay disclaims any and all liability arising out of the use or application of any product described herein or of any information provided herein to the maximum extent permitted by law. The product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase, including but not limited to the warranty expressed therein, which apply to these products. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or by any conduct of Vishay. The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications unless otherwise expressly indicated. Customers using or selling Vishay products not expressly indicated for use in such applications do so entirely at their own risk and agree to fully indemnify Vishay for any damages arising or resulting from such use or sale. Please contact authorized Vishay personnel to obtain written terms and conditions regarding products designed for such applications. Product names and markings noted herein may be trademarks of their respective owners. Document Number: 91000 Revision: 18-Jul-08 www.vishay.com 1
