CRCW1206-HPe3

CRCW-HP e3 Vishay Pulse Proof, High Power Thick Film Chip Resistors FEATURES • • • • • Excellent pulse load capability Enhanced power rating Double side printed resistor element Protective overglaze Pure tin solder contacts on Ni barrier layer provides compatibility with lead (Pb)-free and lead containing soldering processes • Compliant to RoHS directive 2002/95/EC • Halogen-free according to IEC 61249-2-21 definition • AEC-Q200 qualified, rev. C compliant STANDARD ELECTRICAL SPECIFICATIONS SIZE MODEL INCH METRIC POWER RATING P70 W 0.125 (1) LIMITING ELEMENT VOLTAGE MAX. V 50 TEMPERATURE COEFFICIENT ppm/K TOLERANCE RESISTANCE RANGE E-SERIES % Ω ±1 ±5 ±1 ±5 ±1 ±5 ±1 ±5 ±1 ±5 ±1 ±5 ±1 ±5 ±1 ±5 1R to 1M E24 + E96 E24 E24 + E96 E24 E24 + E96 E24 E24 + E96 E24 E24 + E96 E24 E24 + E96 E24 E24 + E96 E24 E24 + E96 E24 CRCW0402-HP e3 0402 RR1005 CRCW0603-HP e3 0603 RR1608 CRCW0805-HP e3 0805 RR2012 CRCW1206-HP e3 1206 RR3216 CRCW1210-HP e3 1210 RR3225 CRCW1218-HP e3 1218 RR3246 CRCW2010-HP e3 2010 RR5025 CRCW2512-HP e3 2512 RR6332 ± 100 ± 200 Zero-Ohm-Resistor: Rmax. = 0.010 Ω, Imax. = 3 A ± 100 0.25 75 ± 200 Zero-Ohm-Resistor: Rmax. = 0.008 Ω, Imax. = 5 A ± 100 0.33 150 ± 200 Zero-Ohm-Resistor: Rmax. = 0.005 Ω, Imax. = 6 A ± 100 0.5 200 ± 200 Zero-Ohm-Resistor: Rmax. = 0.005 Ω, Imax. = 10 A ± 100 0.75 200 ± 200 Zero-Ohm-Resistor: Rmax. = 0.004 Ω, Imax. = 12 A ± 100 1.5 200 ± 200 Zero-Ohm-Resistor: Rmax. = 0.004 Ω, Imax. = 20 A ± 100 1.0 400 ± 200 Zero-Ohm-Resistor: Rmax. = 0.005 Ω, Imax. = 12 A ± 100 1.5 500 ± 200 Zero-Ohm-Resistor: Rmax. = 0.005 Ω, Imax. = 16 A 1R to 1M 1R to 1M 1R to 1M 1R to 1M 1R to 1M 1R to 1M 1R to 1M Notes (1) CRCW0402-HP resistors feature a single side printed resistive layer only • These resistors do not feature a limited lifetime when operated within the permissible limits. However, resistance value drift increasing over operating time may result in exceeding a limit acceptable to the specific application, thereby establishing a functional lifetime • Marking: See document “Surface Mount Resistor Marking” (document number 20020) • Power rating depends on the max. temperature at the solder point, the component placement density and the substrate material TECHNICAL SPECIFICATIONS PARAMETER Rated Dissipation P70 (1) Limiting Element Voltage Umax. AC/DC Insulation Voltage Uins. (1 min) Insulation Resistance Category Temperature Range Weight (1) UNIT W V V Ω °C mg CRCW CRCW CRCW CRCW CRCW CRCW CRCW CRCW 0402-HP 0603-HP 0805-HP 1206-HP 1210-HP 1218-HP 2010-HP 2512-HP 0.125 0.25 0.33 0.5 0.75 1.5 1.0 1.5 50 75 150 200 200 200 400 500 > 75 > 100 > 200 > 300 > 300 > 300 > 300 > 300 > 109 - 55 to + 155 0.65 2 5.5 10 18 31 25.5 42 Note The power dissipation on the resistors generates a temperature rise against the local ambient, depending on the heat flow support of the printed-circuit board (thermal resistance). The rated dissipation applies only if the permitted film temperature of 155 °C is not exceeded. For technical questions, contact: thickfilmchip@vishay.com www.vishay.com 171 Document Number: 20043 Revision: 26-Mar-10 CRCW-HP e3 Vishay Pulse Proof, High Power Thick Film Chip Resistors PART NUMBER AND PRODUCT DESCRIPTION PART NUMBER: CRCW0603562RFKEAHP (1) C R C W 0 6 0 3 5 6 2 R F K E A H P MODEL/SIZE CRCW0402 CRCW0603 CRCW0805 CRCW1206 CRCW1210 CRCW1218 CRCW2010 CRCW2512 VALUE R = Decimal K = Thousand M = Million 0000 = Jumper TOLERANCE F=±1% J=±5% Z = Jumper TCR K = ± 100 ppm/K N = ± 200 ppm/K 0 = Jumper PACKAGING (2) EA EB EC ED EE EI EL EF EG EH EK SPECIAL Up to 2 digits HP = Pulse proof, High Power PRODUCT DESCRIPTION: CRCW0603-HP 100 562R 1 % ET1 e3 CRCW0603-HP MODEL CRCW0402-HP CRCW0603-HP CRCW0805-HP CRCW1206-HP CRCW1210-HP CRCW1218-HP CRCW2010-HP CRCW2512-HP 100 TCR ± 100 ppm/K ± 200 ppm/K 562R RESISTANCE VALUE 10R = 10 Ω 562R = 562 Ω 10K = 10 kΩ 1M = 1 MΩ 0R0 = Jumper 1% TOLERANCE ±1% ±5% ET1 PACKAGING (2) ET1 ET5 ET6 ET7 EF4 EG1 E20 E02 E67 E82 ET9 e3 LEAD (Pb)-FREE e3 = Pure tin termination finish Notes (1) Preferred way for ordering products is by use of the PART NUMBER (2) Please refer to table PACKAGING, see below PACKAGING REEL MODEL PACKAGING CODE TAPE WIDTH 8 mm 8 mm DIAMETER 180 mm/7" 330 mm/13" 180 mm/7" 285 mm/11.25" 330 mm/13" 180 mm/7" 285 mm/11.25" 330 mm/13" 180 mm/7" 285 mm/11.25" 330 mm/13" 180 mm/7" 285 mm/11.25" 330 mm/13" 180 mm/7" 180 mm/7" 180 mm/7" PITCH 2 mm 2 mm 4 mm 4 mm 4 mm 4 mm 4 mm 4 mm 4 mm 4 mm 4 mm 4 mm 4 mm 4 mm 4 mm 4 mm 8 mm 4 mm PIECES/ REEL 10 000 50 000 5000 10 000 20 000 5000 10 000 20 000 5000 10 000 20 000 5000 10 000 20 000 4000 4000 2000 4000 PART NUMBER PAPER CRCW0402-HP CRCW0603-HP ED EE EA EB EC EA EB EC EA EB EC EA EB EC EK EF EG EH BLISTER PRODUCT DESC. PAPER ET7 EF4 ET1 ET5 ET6 ET1 ET5 ET6 ET1 ET5 ET6 ET1 ET5 ET6 ET9 E02 E67 E82 Document Number: 20043 Revision: 26-Mar-10 BLISTER CRCW0805-HP 8 mm CRCW1206-HP 8 mm CRCW1210-HP CRCW1218-HP CRCW2010-HP CRCW2512-HP 8 mm 12 mm 12 mm 12 mm www.vishay.com 172 For technical questions, contact: thickfilmchip@vishay.com CRCW-HP e3 Pulse Proof, High Power Thick Film Chip Resistors Vishay DIMENSIONS in millimeters l a b SIZE INCH 0402 0603 0805 1206 1210 1218 2010 2512 METRIC 1005 1608 2012 3216 3225 3246 5025 6332 L 1.0 ± 0.05 1.6 ± 0.1 2.0 ± 0.15 3.1 ± 0.2 3.2 ± 0.2 3.1 ± 0.2 5.0 ± 0.15 6.3 ± 0.2 W 0.5 ± 0.05 0.85 ± 0.1 1.25 ± 0.15 1.6 ± 0.15 2.5 ± 0.2 4.6 ± 0.2 2.5 ± 0.15 3.15 ± 0.15 DIMENSIONS H 0.3 ± 0.1 0.45 ± 0.1 0.50 ± 0.1 0.50 ± 0.15 0.6 ± 0.1 0.6 ± 0.1 0.6 ± 0.1 0.6 ± 0.1 T1 0.25 ± 0.1 0.3 ± 0.2 0.4 ± 0.2 0.5 ± 0.2 0.45 ± 0.2 0.45 ± 0.2 0.6 ± 0.2 0.6 ± 0.2 T2 0.2 ± 0.1 0.3 ± 0.2 0.35 ± 0.2 0.45 ± 0.2 0.4 ± 0.2 0.4 ± 0.2 0.6 ± 0.2 0.6 ± 0.2 SOLDER PAD DIMENSIONS REFLOW SOLDERING WAVE SOLDERING a b l a b l 0.4 0.6 0.5 0.5 0.9 1.0 0.9 0.9 1.0 0.7 1.3 1.2 0.9 1.3 1.3 0.9 1.7 2.0 1.1 1.7 2.3 0.9 2.5 2.0 1.1 2.5 2.2 1.05 4.9 1.9 1.25 4.8 1.9 1.0 2.5 3.9 1.2 2.5 3.9 1.0 3.2 5.2 1.2 3.2 5.2 FUNCTIONAL PERFORMANCE Single Pulse Pulse Load Pmax. (W) 10 000 1000 100 2512 1218 2010 1210 1206 0805 0603 0402 10 1 0.1 0.01 0.000001 0.00001 0.0001 0.001 0.01 0.1 100 1 10 Pulse Duration ti (s) Maximum pulse dissipation as a function of the pulse duration, single pulse for CRCW...-HP Continuous Pulse Continuous Pulse Load Pmax. (W) 10 000 1000 100 2512 1218 2010 1210 1206 0805 0603 0402 10 1 0.1 0.01 0.000001 0.00001 0.0001 0.001 0.01 0.1 1 10 100 Pulse Duration ti (s) Maximum pulse dissipation as a function of the pulse duration, continuous pulse for CRCW...-HP Document Number: 20043 Revision: 26-Mar-10 For technical questions, contact: thickfilmchip@vishay.com www.vishay.com 173 CRCW-HP e3 Vishay Pulse Proof, High Power Thick Film Chip Resistors Pulse Voltage Pulse Voltage Ûmax. (V) 2000 1800 1600 1400 1200 1000 800 600 400 200 0402 0 0.000001 0.00001 0.0001 0.001 0.01 0.1 1 10 Pulse Duration ti (s) 0805 0603 1206/1210/1218 2010 2512 Maximum pulse voltage, single and continuous pulses; applicable if P ≤ Pmax.; for permissible resistance change equivalent to 8000 h operation Derating Rated Power in % 120 100 80 60 40 20 0 - 55 - 25 0 25 50 75 70 100 125 155 175 Ambient Temperature in °C www.vishay.com 174 For technical questions, contact: thickfilmchip@vishay.com Document Number: 20043 Revision: 26-Mar-10 CRCW-HP e3 Pulse Proof, High Power Thick Film Chip Resistors Vishay TEST PROCEDURES AND REQUIREMENTS EN 60115-1 CLAUSE IEC 60068-2 TEST METHOD TEST PROCEDURE Stability for product types: CRCW-HP e3 4.5 4.7 4.13 Resistance Voltage proof Short time overload U = 1.4 x Uins; 60 s U = 2.5 x P 70 x R ≤ 2 × Umax.; Duration according to style Solder bath method; Sn60Pb40; non-activated flux; (235 ± 5) °C; (2 ± 0.2) s Solder bath method; Sn96.5Ag3Cu0.5; non-activated flux; (245 ± 5) °C; (3 ± 0.3) s (20/- 55/20) °C and (20/125/20) °C 45 N Depth 2 mm; 3 times 30 min. at - 55 °C; 30 min at 125 °C 5 cycles 1000 cycles 125 °C; 16 h 55 °C; ≥ 90 % RH; 24 h; 1 cycle - 55 °C; 2 h 1 kPa; (25 ± 10) °C; 1 h 55 °C; ≥ 90 % RH; 24 h; 5 cycle U= P 70 x R ± (2 % R + 0.1 Ω) ± (4 % R + 0.1 Ω) ± (0.5 % R + 0.05 Ω) No burning after 30 s ± (1 % R + 0.05 Ω) ± (2 % R + 0.1 Ω) ± (1 % R + 0.05 Ω) No visible damage Marking legible, no visible damage ± (0.5 % R + 0.05 Ω) ± (1 % R + 0.05 Ω) ± (1 % R + 0.05 Ω) U = P 70 x R ≤ U max. 1.5 h on; 0.5 h off; 70 °C; 1000 h 70 °C; 8000 h Solder bath method; (260 ± 5) °C; (10 ± 1) s IEC 60695-15-5; 10 s (40 ± 2) °C; (93 ± 3) % RH; 56 days 155 °C; 1000 h IEC 61340-3-1; 3 positive and 3 negative discharges; ESD voltage according to size Isopropyl alcohol; 50 °C; method 2 Isopropyl alcohol; 50 °C; method 1; toothbrush f = 10 Hz to 2000 Hz; x, y, z ≤ 1.5 mm; A ≤ 200 m/s2; 10 sweeps per axis U = 15 x P 70 x R ≤ 2 x U max. 0.1 s on; 2.5 s off; 1000 cycles Û = 10 x P 70 x R ≤ 2 x U max. 10 pulses ± (2 % R + 0.1 Ω) REQUIREMENTS PERMISSIBLE CHANGE (ΔR) STABILITY CLASS 2 OR BETTER 1 Ω to 1 M Ω ± 1 %, ± 5 % ± (0.5 % R + 0.05 Ω) Good tinning (≥ 95 % covered) no visible damage Good tinning (≥ 95 % covered) no visible damage ± 100 ppm/K, ± 200 ppm/K No visible damage No visible damage, no open circuit in bent position ± (0.25 % R + 0.05 Ω) ± (0.5 % R + 0.05 Ω) ± (1 % R + 0.05 Ω) 4.17.2 4.8.4.2 4.32 4.33 58 (Td) 21 (UU3) 21 (UU1) Solderability Temperature coefficient Shear (adhesion) Substrate bending 4.19 4.23 4.23.2 4.23.3 4.23.4 4.23.5 4.23.6 4.23.7 4.25.1 4.18.2 4.35 4.24 4.25.3 4.40 4.29 4.30 4.22 4.37 4.27 14 (Na) 2 (Ba) 30 (Db) 1 (Aa) 13 (M) 30 (Db) 58 (Td) 78 (Cab) 45 (XA) 45 (XA) 6 (Fc) - Rapid change of temperature Dry heat Damp heat, cyclic cold Low air pressure Damp heat, cyclic D.C. load Endurance at 70 °C Resistance to soldering heat Flammability, needle flame test Damp heat, steady state Endurance at upper category temperature Electrostatic discharge (human body model) Component solvent resistance Solvent resistance of marking Vibration, endurance by sweeping Periodic electric overload Single pulse high voltage overload, 10 µs/700 µs All tests are carried out in accordance with the following specifications: • EN 60115-1, generic specification • EN 140400, sectional specification • EN 140401-802, detail specification • IEC 60068-2 environmental test procedures Packaging of components is done in paper or blister tapes according to IEC 60286-3 Document Number: 20043 Revision: 26-Mar-10 For technical questions, contact: thickfilmchip@vishay.com www.vishay.com 175 Legal Disclaimer Notice Vishay Disclaimer All product specifications and data are subject to change without notice. Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained herein or in any other disclosure relating to any product. Vishay disclaims any and all liability arising out of the use or application of any product described herein or of any information provided herein to the maximum extent permitted by law. The product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase, including but not limited to the warranty expressed therein, which apply to these products. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or by any conduct of Vishay. The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications unless otherwise expressly indicated. Customers using or selling Vishay products not expressly indicated for use in such applications do so entirely at their own risk and agree to fully indemnify Vishay for any damages arising or resulting from such use or sale. Please contact authorized Vishay personnel to obtain written terms and conditions regarding products designed for such applications. Product names and markings noted herein may be trademarks of their respective owners. Document Number: 91000 Revision: 18-Jul-08 www.vishay.com 1
