MSM (Military M83401) Vishay Dale Thick Film Resistor Networks Military, MIL-PRF-83401 Qualified, Type RZ, Single-In-Line, Molded SIP; 01, 03, 05 Schematics FEATURES • MIL-PRF-83401 qualified • 0.195" [4.95 mm] “A” and 0.350" [8.89 mm] “C” maximum seated heights • Thick film resistive elements • TCR available in “K” (± 100 ppm/°C) or “M” (± 300 ppm/°C) characteristic • All device leads are hot-solder dipped • Rugged molded case construction • Compatible with automatic insertion equipment • 100 % screen tested per Group A, Subgroup 1 of MIL-PRF-83401 • All devices are capable of passing the MIL-STD-202, Method 210, Condition D “Resistance to Soldering Heat” test • Available in tube pack STANDARD ELECTRICAL SPECIFICATIONS VISHAY DALE MODEL/ SCHEMATIC PIN NO/ PROFILE MSM06A 01 MSM08A 01 MSM10A 01 MSM06A 03 MSM08A 03 MSM10A 03 MSM06A 05 MSM08A 05 MSM10A 05 MSM06C 01 MSM08C 01 MSM10C 01 MSM06C 03 MSM08C 03 MSM10C 03 MSM06C 05 MSM08C 05 MSM10C 05 Notes (1) ± 1 % and ± 5 % available RESISTOR PACKAGE TEMPERATURE STANDARD WEIGHT POWER RATING POWER RATING RESISTANCE TOLERANCE (1) COEFFICIENT (2) RANGE g MAX. at 70 °C MAX. at 70 °C % (- 55 °C to + 125 °C) Ω W W 0.12 0.60 0.4 0.12 0.84 10 - 1M ±2 K, M 0.5 0.12 1.08 0.6 0.12 0.36 0.4 0.12 0.48 10 - 1M ±2 K, M 0.5 0.12 0.60 0.6 0.07 0.60 0.4 Consult 0.07 0.84 ±2 K, M 0.5 factory 0.07 1.08 0.6 0.20 1.00 0.7 0.20 1.40 10 - 1M ±2 K, M 0.9 0.20 1.80 1.1 0.20 0.60 0.7 0.20 0.80 10 - 1M ±2 K, M 0.9 0.20 1.00 1.1 0.11 0.88 0.7 Consult 0.9 0.11 1.32 ±2 K, M factory 1.1 0.11 1.80 (2) K = ± 100 ppm/°C; M = ± 300 ppm/°C GLOBAL PART NUMBER INFORMATION New Global Part Numbering: M8340107K1003GCD03 (preferred part numbering format) M MIL STYLE M83401 8 3 4 0 1 0 7 K 1 0 0 3 G C D 0 3 SPEC SHEET 04 = 6 Pin, “C” Profile 05 = 8 Pin, “C” Profile 06 = 10 Pin, “C” Profile 07 = 6 Pin, “A” Profile 08 = 8 Pin, “A” Profile 09 = 10 Pin, “A” Profile CHARACTERISTIC K = 100 ppm M = 300 ppm RESISTANCE VALUE 3 digit significant figure, followed by a multiplier 10R0 = 10 Ω 3302 = 33 kΩ 1004 = 1 MΩ TOLERANCE F=±1% G=±2% J=±5% SCHEMATIC C = Bussed G = Isolated PACKAGING D03 = Tin/Lead, Tube DSL = Tin/Lead, Tube, Single Lot Date Code Historical Part Number example: M8340107K1003GC (will continue to be accepted) M83401 07 K 1003 G C SCHEMATIC D03 PACKAGING MIL STYLE SPEC SHEET CHARACTERISTIC RESISTANCE VALUE TOLERANCE New Global Part Numbering: M8340104KA001GHD03 (preferred part numbering format) M MIL STYLE M83401 8 3 4 0 1 0 4 K A 0 0 1 G H D 0 3 SPEC SHEET 04 = 6 Pin, “C” Profile 05 = 8 Pin, “C” Profile 06 = 10 Pin, “C” Profile 07 = 6 Pin, “A” Profile 08 = 8 Pin, “A” Profile 09 = 10 Pin, “A” Profile CHARACTERISTIC K = 100 ppm M = 300 ppm RESISTANCE VALUE Per std. Mil. Spec (see Impedence Codes table) TOLERANCE F=±1% G=±2% J=±5% SCHEMATIC H = Dual Terminator PACKAGING D03 = Tin/Lead, Tube DSL = Tin/Lead, Tube, Single Lot Date Code Historical Part Number example: M8340104KA001GH (will continue to be accepted) M83401 MIL STYLE 04 SPEC SHEET K CHARACTERISTIC A001 RESISTANCE VALUE G TOLERANCE H SCHEMATIC D03 PACKAGING www.vishay.com 1 For technical questions, contact: ff2aresistors@vishay.com Document Number: 31514 Revision: 25-Jul-08 MSM (Military M83401) Thick Film Resistor Networks Military, MIL-PRF-83401 Qualified, Type RZ, Single-In-Line, Molded SIP; 01, 03, 05 Schematics DIMENSIONS in inches [millimeters] Vishay Dale "A" Profile 0.030 + 0.005 - 0.015 [0.762 + 0.127 - 0.381] Pin # 1 0.040 + 0.009 - 0.015 [1.02 + 0.229 - 0.381] 0.100 ± 0.005 [2.54 ± 0.127] Non-Accumulative A 0.187 + 0.008 - 0.010 [4.75 + 0.203 - 0.254] 0.135 + 0.015 - 0.010 [3.43 + 0.381 - 0.254] "C" Profile 0.030 + 0.005 - 0.015 [0.762 + 0.127 - 0.381] 0.040 + 0.009 - 0.015 [1.02 + 0.229 - 0.381] 0.100 ± 0.005 [2.54 ± 0.127] Non-Accumulative A Pin # 1 0.342 + 0.008 - 0.010 [8.69 + 0.203 - 0.254] 0.017 ± 0.004 [0.432 ± 0.102] B C Equal Space 0.017 ± 0.004 [0.432 ± 0.102] B C Equals Spaces 0.135 + 0.015 - 0.010 [3.43 + 0.381 - 0.254] 0.098 max. [2.49 max.] 0.098 max. [2.49 max.] VISHAY DALE MODEL MSM06 MSM08 MSM10 A 0.583 ± 0.015 [14.81 ± 0.381] 0.783 ± 0.015 [19.89 ± 0.381] 0.983 ± 0.015 [24.97 ± 0.381] B 0.500 [12.70] 0.700 [17.78] 0.900 [22.86] C 5 7 9 0.012 ± 0.004 [0.305 ± 0.102] 0.012 ± 0.004 [0.305 ± 0.102] TECHNICAL SPECIFICATIONS PARAMETER Maximum Operating Voltage Voltage Coefficient of Resistance Dielectric Strength Insulation Resistance Operating Temperature Range Storage Temperature Range UNIT VDC Veff VAC Ω °C °C MSM SERIES 50 < 50 ppm 200 min. 10 000 M - 55 to + 125 - 55 to + 150 MECHANICAL SPECIFICATIONS Body: Molded epoxy Terminals: Copper alloy, hot-solder dipped Solderability: Per MIL-PRF-83401 CAGE CODE: 91637 and SH903 MILITARY IMPEDANCE CODES CODE A001 A002 A003 A004 A005 A006 A007 A008 A009 R1 (Ω) 82 120 130 160 180 180 220 220 330 R2 (Ω) 130 200 210 260 240 390 270 330 390 CODE A010 A011 A012 A013 A014 A015 A016 A017 A018 R1 (Ω) 330 330 1.5K 3K 180 270 560 560 620 R2 (Ω) 470 680 3.3K 6.2K 270 270 560 1.2K 2.7K Document Number: 31514 Revision: 25-Jul-08 For technical questions, contact: ff2aresistors@vishay.com www.vishay.com 2 MSM (Military M83401) Vishay Dale DERATING 01 Schematic “A” Profile 1.08 MSM10A Package 1.80 MSM10C Package Power Rating (W) Thick Film Resistor Networks Military, MIL-PRF-83401 Qualified, Type RZ, Single-In-Line, Molded SIP; 01, 03, 05 Schematics “C” Profile Power Rating (W) 0.84 MSM08A Package 1.40 MSM08C Package 0.60 MSM06A Package 1.00 MSM06C Package 0.12 - 55 Single Resistor 0.20 Single Resistor 0 + 25 + 70 + 125 + 150 Ambient Temperature °C - 55 0 + 25 + 70 + 125 + 150 Ambient Temperature °C 03 Schematic “A” Profile Power Rating (W) “C” Profile 1.00 MSM10C Package Power Rating (W) 0.60 0.48 MSM10A Package MSM08A Package 0.80 MSM08C Package 0.60 MSM06C Package 0.36 MSM06A Package 0.20 Single Resistor 0.12 - 55 Single Resistor 0 + 25 + 70 + 125 + 150 - 55 0 + 25 Ambient Temperature °C + 70 + 125 + 150 Ambient Temperature °C 05 Schematic “A” Profile Power Rating (W) Power Rating (W) “C” Profile 1.80 MSM10C Package 1.08 0.84 MSM10A Package MSM08A Package 1.32 MSM08C Package 0.60 MSM06A Package 0.88 MSM06C Package 0.07 - 55 Single Resistor 0 + 25 + 70 + 125 + 150 0.11 - 55 Single Resistor 0 + 25 Ambient Temperature °C + 70 + 125 + 150 Ambient Temperature °C www.vishay.com 3 For technical questions, contact: ff2aresistors@vishay.com Document Number: 31514 Revision: 25-Jul-08 MSM (Military M83401) Thick Film Resistor Networks Military, MIL-PRF-83401 Qualified, Type RZ, Single-In-Line, Molded SIP; 01, 03, 05 Schematics CIRCUIT APPLICATIONS 01 Schematic 5, 7 or 9 resistors with one pin common “A” Profile MSM06A01 (M8340107xxxxxxC) MSM08A01 (M8340108xxxxxxC) MSM10A01 (M8340109xxxxxxC) “C” Profile MSM06C01 (M8340104xxxxxxC) MSM08C01 (M8340105xxxxxxC) MSM10C01 (M8340106xxxxxxC) Vishay Dale 1 2 3 n-1 n The MSM06A01, MSM08A01, MSM10A01, MSM06C01, MSM08C01 and MSM10C01 molded single-in-line resistor networks provide the user with a choice of 5, 7 or 9 nominally equal resistors, each connected to a common pin (Pin No. 1). Commonly used in the following applications: • “Wired OR” Pull-up • Power Gate Pull-up • MOS/ROM Pull-up/Pull-down • Open Collector Pull-up • TTL Input Pull-down • TTL Unused Gate Pull-up “C” Profile MSM06C03 (M8340104xxxxxxG) MSM08C03 (M8340105xxxxxxG) MSM10C03 (M8340106xxxxxxG) 03 Schematic 3, 4 or 5 isolated resistors “A” Profile MSM06A03 (M8340107xxxxxxG) MSM08A03 (M8340108xxxxxxG) MSM10A03 (M8340109xxxxxxG) The MSM06A03, MSM08A03, MSM10A03, MSM06C03, MSM08C03 and MSM10C03 molded single-in-line resistor networks provide the user with a choice of 3, 4 or 5 nominally equal resistors. Each resistor is isolated from all others. Commonly used in the following applications: 1 23 4 n-1 n • “Wired OR” Pull-up • Power Driven Pull-up • Power Gate Pull-up • Line Termination • Long-Line Impedance Balance • LED Current Limiting • ECL Output Pull-down • TTL Input Pull-down 05 Schematic R2 R1 4, 6 or 8 isolated resistors “A” Profile MSM06A05 (M8340107xxxxxxH) MSM08A05 (M8340108xxxxxxH) MSM10A05 (M8340109xxxxxxH) “C” Profile MSM06C05 (M8340104xxxxxxH) MSM08C05 (M8340105xxxxxxH) MSM10C05 (M8340106xxxxxxH) 1 2 3 n-1 n The MSM06A05, MSM08A05, MSM10A05, MSM06C05, MSM08C05 and MSM10C05 molded single-in-line resistor networks provide the user with a choice of 4, 6 or 8 pair of R1/R2 resistor values for pulse squaring and TTL dual-line terminating requirements. PERFORMANCE TEST Power Conditioning Thermal Shock Short Time Overload Low Temperature Operation Moisture Resistance Resistance to Soldering Heat Shock Vibration Load Life Terminal Strength Insulation Resistance Dielectric Withstanding Document Number: 31514 Revision: 25-Jul-08 CONDITIONS 1.5 x rated power, applied 1.5 h “ON” and 0.5 h “OFF” for 100 h ± 4 h at + 25 °C ambient temperature 5 cycles between - 65 °C and + 125 °C 2.5 x rated working voltage for 5 s 45 min at full rated working voltage at - 65 °C 240 h with humidity ranging from 80 % RH to 98 % RH Leads immersed in + 260 °C solder to within 1/16" of body for 10 s Total of 18 shocks at 100 G's 12 h at maximum of 20 G's between 10 and 2000 Hz 1000 h at + 70 °C, rated power applied 1.5 h “ON”, 0.5 h “OFF” for full 1000 h period 4 1/2 pound pull for 30 s 10 000 MΩ (minimum) No evidence of arcing or damage (200 VRMS for 1 min) For technical questions, contact: ff2aresistors@vishay.com MAX. ΔR (Typical Test Lots) ± 0.50 % ΔR ± 0.50 % ΔR ± 0.25 % ΔR (Characteristic K) ± 0.50 % ΔR (Characteristic M) ± 0.25 % ΔR (Characteristic K) ± 0.50 % ΔR (Characteristic M) ± 0.50 % ΔR ± 0.25 % ΔR ± 0.25 % ΔR ± 0.25 % ΔR ± 0.50 % ΔR (Characteristic K) ± 2.00 % ΔR (Characteristic M) ± 0.25 % ΔR www.vishay.com 4 Legal Disclaimer Notice Vishay Disclaimer All product specifications and data are subject to change without notice. Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained herein or in any other disclosure relating to any product. Vishay disclaims any and all liability arising out of the use or application of any product described herein or of any information provided herein to the maximum extent permitted by law. The product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase, including but not limited to the warranty expressed therein, which apply to these products. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or by any conduct of Vishay. The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications unless otherwise expressly indicated. Customers using or selling Vishay products not expressly indicated for use in such applications do so entirely at their own risk and agree to fully indemnify Vishay for any damages arising or resulting from such use or sale. Please contact authorized Vishay personnel to obtain written terms and conditions regarding products designed for such applications. Product names and markings noted herein may be trademarks of their respective owners. Document Number: 91000 Revision: 18-Jul-08 www.vishay.com 1
