MSP

MSP Vishay Dale Thick Film Resistor Networks Single-In-Line, Molded SIP; 01, 03, 05 Schematics 6, 8, 9 or 10 Pin “A” Profile and 6, 8 or 10 Pin “C” Profile FEATURES • 0.195" [4.95 mm] "A" or 0.350" [8.89 mm] "C" maximum seated height • Thick film resisitive elements • Low temperature coefficient (- 55 °C to + 125 °C) ± 100 ppm/°C • Rugged, molded case construction • Reduces total assembly costs • Compatible with automatic insertion equipment and reduces PC board space • Wide resistance range (10 Ω to 2.2 MΩ) • Available in tube pack or side-by-side pack • Lead (Pb)-free version is RoHS compliant Available e1 RoHS* COMPLIANT STANDARD ELECTRICAL SPECIFICATIONS GLOBAL MODEL/ SCHEMATIC MSPxxx01 MSPxxx03 MSPxxx05 PROFILE RESISTOR RESISTANCE POWER RATING RANGE Max. AT 70 °C W Ω 0.20 0.25 0.30 0.40 10 - 2.2M 10 - 2.2M 10 - 2.2M STANDARD TOLERANCE % ± 2 Standard (1, 5)** ± 2 Standard (1, 5)** ± 2 Standard (± 5 %)** TEMPERATURE TCR COEFFICIENT TRACKING* (- 55 °C to + 125 °C) (- 55 °C to + 125 °C) ppm/°C ppm/°C ± 100 ± 100 ± 100 ± 50 ppm/°C ± 50 ppm/°C ± 150 ppm/°C OPERATING VOLTAGE Max. VDC 100 100 100 A C A C A 0.20 C 0.25 * Tighter tracking available ** Tolerances in brackets available on request GLOBAL PART NUMBER INFORMATION New Global Part Numbering: MSP06A031K00GDA (preferred part numbering format) M GLOBAL MODEL MSP S P 0 6 A 0 3 1 K 0 0 G D A PACKAGING SPECIAL Blank = Standard (Dash Number) (up to 3 digits) From 1-999 as applicable RESISTANCE TOLERANCE VALUE CODE 06 = 6 Pin A = “A” Profile 01 = Bussed R = Decimal F=±1% 08 = 8 Pin C = “C” Profile 03 =Isolated K = Thousand G=±2% 09 = 9 Pin 00 = Special M = Million J=±5% 10 = 10 Pin 10R0 = 10 Ω S = Special 680K = 680 kΩ 1M00 = 1.0 MΩ Historical Part Number example: MSP06A03102G (will continue to be accepted) PIN COUNT PACKAGE HEIGHT SCHEMATIC EJ = Lead (Pb)-free, Tube DA = Tin/Lead, Tube MSP HISTORICAL MODEL 06 PIN COUNT A PACKAGE HEIGHT 03 SCHEMATIC 102 RESISTANCE VALUE G TOLERANCE CODE DO3 PACKAGING New Global Part Numbering: MSP08C05131AGDA (preferred part numbering format) M GLOBAL MODEL MSP S P 0 8 C 0 5 1 3 1 A G D A PACKAGING SPECIAL Blank = Standard (Dash Number) (up to 3 digits) From 1-999 as applicable RESISTANCE TOLERANCE VALUE CODE 06 = 6 Pin A = “A” Profile 05 = Dual 3 digit F=±1% 08 = 8 Pin C = “C” Profile Terminator Impedence code, G=±2% 09 = 9 Pin followed by J=±5% 10 = 10 Pin Alpha modifier (see Impedence codes table) Historical Part Number example: MSP08C05221331G (will continue to be accepted) PIN COUNT PACKAGE HEIGHT SCHEMATIC EJ = Lead (Pb)-free, Tube DA = Tin/Lead, Tube MSP HISTORICAL MODEL 08 PIN COUNT C PACKAGE HEIGHT 05 SCHEMATIC 221 RESISTANCE VALUE 1 331 RESISTANCE VALUE 2 G TOLERANCE DO3 PACKAGING * Pb containing terminations are not RoHS compliant, exemptions may apply www.vishay.com 1 For technical questions, contact: ff2aresistors@vishay.com Document Number: 31510 Revision: 28-Jul-06 MSP Thick Film Resistor Networks Single-In-Line, Molded SIP; 01, 03, 05 Schematics 6, 8, 9 or 10 Pin "A" Profile and 6, 8 or 10 Pin "C" Profile DIMENSIONS in inches [millimeters] Vishay Dale A Max. 0.015 [0.381] Min. 0.040 ± 0.010 [1.02 ± 0.254] 0.100 ± 0.010 [2.54 ± 0.254] Non-Accumulative PIN #1 D Max. 0.090 [2.29] Max. 0.016 ± 0.003 [0.406 ± 0.076] B C Equal Space 0.135 + 0.015 - 0.010 [3.43 + 0.381 - 0.254] 0.012 ± 0.003 [0.305 ± 0.076] GLOBAL MODEL MSP06 MSP08 MSP10 MSP09 A (Max.) 0.590 [14.99] 0.790 [20.07] 0.990 [25.15] 0.890 [22.61] B 0.500 [12.70] 0.700 [17.78] 0.900 [22.86] 0.800 [20.32] C 5 7 9 8 D (Max.) MSPxxA = 0.195 [4.95] MSPxxC = 0.350 [8.89] 0.195 [4.95] ONLY TECCHNICAL SPECIFICATIONS PARAMETER Package Power Rating Maximum at + 25 °C and + 70 °C Voltage Coefficient of Resistance Dielectric Strength Isolation Resistance (03 Schematic) Operating Temperature Range Storage Temperature Range Veff VAC Ω °C °C UNIT MSP SERIES See Derating Curves < 50 ppm typical 200 > 100M - 55 to + 125 - 55 to + 150 MECHANICAL SPECIFICATIONS Marking Resistance to Solvents: Solderability: Body: Terminals: Weight: Permanency testing per MIL-STD-202, Method 215 Per MIL-STD-202, Method 208E, RMA flux Molded epoxy Copper alloy, solder plated MSP06A = 0.4 gram MSP08A = 0.5 gram MSP09A = 0.55 gram MSP10A = 0.6 gram MSP06C = 0.7 gram MSP08C = 0.9 gram MSP10C = 1.1 gram Document Number: 31510 Revision: 28-Jul-06 For technical questions, contact: ff2aresistors@vishay.com www.vishay.com 2 MSP Vishay Dale Thick Film Resistor Networks Single-In-Line, Molded SIP; 01, 03, 05 Schematics 6, 8, 9 or 10 Pin "A" Profile and 6, 8 or 10 Pin "C" Profile IMPEDANCE CODES CODE 500B 750B 800C 990A 101C 111C 121B 121C 131A R1(Ω) 82 120 130 160 180 180 180 220 220 R2(Ω) 130 200 210 260 240 270 390 270 330 CODE 141A 181A 191A 221B 281B 381B 501C 102A 202B R1(Ω) 270 330 330 330 560 560 620 1.5K 3K R2(Ω) 270 390 470 680 560 1.2K 2.7K 3.3K 6.2K CIRCUIT APPLICATIONS 01 Schematic 5, 7, 8* or 9 resistors with one pin common The MSPxxx01 circuit contains 5, 7, 8* or 9 nominally equal resistors, each connected between a common pin (Pin No. 1) and a discrete PC board pin. Commonly used in the following applications: • "Wired OR" Pull-up • MOS/ROM Pull-up/Pull-down • Power Gate Pull-up • Open Collector Pull-up • TTL Input Pull-down • TTL Unused Gate Pull-up * Available in "A" Profile only Standard E-24 resistance values stocked. Consult factory. 03 Schematic 3, 4 or 5 isolated resistors The MSPxxx03 circuit contains 3, 4 or 5 resistors of nominally equal value in a compact package. Each resistor is connected to two discrete PC pins. Standard E-24 resistance values stocked. Consult factory. 1 23 4 n-1 n 1 2 3 n-1 n 05 Schematic Pulse squaring and TTL dual-line terminators R2 R1 The MSPxxx05 circuits contain 4, 6, 7* or 8 series pair of resistors. Each series pair is connected between two common lines. The junction of these resistor pairs is connected to the input terminals. The 05 circuits are designed for TTL dual-line termination and pulse squaring. * Available in "A" Profile only Many dual terminator resistance values stocked. Consult factory. 1 2 3 n-1 n www.vishay.com 3 For technical questions, contact: ff2aresistors@vishay.com Document Number: 31510 Revision: 28-Jul-06 MSP Thick Film Resistor Networks Single-In-Line, Molded SIP; 01, 03, 05 Schematics 6, 8, 9 or 10 Pin "A" Profile and 6, 8 or 10 Pin "C" Profile Vishay Dale “A” Profile Power Rating (Watts) 1.90 “C” Profile Power Rating (Watts) 3.00 MSP10C Package 2.50 MSP08C Package 2.00 MSP06C Package MSP10A Package 1.50 MSP08A Package 1.15 MSP06A Package 1.50 0.45 0.30 Single Resistor 03 01 and 05 0.60 0.38 Single Resistor 03 01 and 05 - 50 + 25 + 70 + 125 + 150 - 50 + 25 + 70 + 125 + 150 Derating Ambient Temperature °C Derating Ambient Temperature °C "A" PROFILE + 70 °C PACKAGE RATINGS MSP10A MSP09A MSP08A MSP06A 1.25 watts 1.12 watts 1.00 watts 0.75 watts "C" PROFILE + 70 °C PACKAGE RATINGS MSP10C MSP08C MSP06C 1.60 watts 1.30 watts 1.00 watts Higher power ratings available. Contact factory. PERFORMANCE TEST Power Conditioning Thermal Shock Short Time Overload Low Temperature Operation Moisture Resistance Resistance to Soldering Heat Shock Vibration Load Life Terminal Strength Insulation Resistance Dielectric Withstanding Voltage CONDITIONS 1.5 x rated power, applied 1.5 hours “ON” and 0.5 hour “OFF” for 100 hrs. ± 4 hrs. at + 25 °C ambient temperature 5 cycles between - 65 °C and + 125 °C 2.5 x rated working voltage 5 seconds 45 minutes at full rated working voltage at - 65 °C 240 hrs. with humidity ranging from 80 % RH to 98 % RH Leads immersed in + 260 °C solder to within 1/16" of device body for 10 seconds Total of 18 shocks at 100 G's 12 hours at maximum of 20 G's between 10 and 2000 Hz 1000 hrs. at + 70 °C, rated power applied 1.5 hours “ON”, 0.5 hour “OFF” for full 1000 hour period. Derated according to the curve. 4.5 pound pull for 30 seconds 10 000 Megohm (minimum) MAX. ΔR (Typical Test Lots) ± 0.50 % ΔR ± 0.50 % ΔR ± 0.25 % ΔR ± 0.25 % ΔR ± 0.50 % ΔR ± 0.25 % ΔR ± 0.25 % ΔR ± 0.25 % ΔR ± 1.00 % ΔR ± 0.25 % ΔR - Document Number: 31510 Revision: 28-Jul-06 For technical questions, contact: ff2aresistors@vishay.com www.vishay.com 4 Legal Disclaimer Notice Vishay Disclaimer All product specifications and data are subject to change without notice. Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained herein or in any other disclosure relating to any product. Vishay disclaims any and all liability arising out of the use or application of any product described herein or of any information provided herein to the maximum extent permitted by law. The product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase, including but not limited to the warranty expressed therein, which apply to these products. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or by any conduct of Vishay. The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications unless otherwise expressly indicated. Customers using or selling Vishay products not expressly indicated for use in such applications do so entirely at their own risk and agree to fully indemnify Vishay for any damages arising or resulting from such use or sale. Please contact authorized Vishay personnel to obtain written terms and conditions regarding products designed for such applications. Product names and markings noted herein may be trademarks of their respective owners. Document Number: 91000 Revision: 18-Jul-08 www.vishay.com 1
