NTCLE305E4…SB Vishay BCcomponents NTC Thermistors, 2-Point Micro Chip Sensor Insulated Leads FEATURES • Flexible insulated leads for special mounting or assembly • Miniature sized very fast reacting • Accurate over a wide temperature range • High stability over a long life • Exceptional withstanding in thermal shocks • AEC-Q200 qualified • Compliant to RoHS Directive 2002/95/EC and in accordance to WEEE 2002/96/EC VALUE 2060 to 10 000 ± 1.92; ± 2.19 3511 to 3984 ± 0.5 to ± 1 ± 0.5 between 25 and 85 - 40 to 125 50 0.8 3  0.7 40/125/56 UNIT  % K % °C °C mW mW/K QUICK REFERENCE DATA PARAMETER Resistance value at 25 C Tolerance on R25-value B25/85-value Tolerance on B25/85 Accuracy of temperature measurement Operating temperature range Maximum power dissipation at 55 °C Dissipation factor  (in still air) Response time (in stirred air) (in oil) Climatic category (LCT/UCT/days) Minimum dielectric withstanding voltage between leads termination and coated body Weight • Fulfils the ELV 2000/53/EC APPLICATIONS • Temperature measurement, sensing and control in automotive and industrial applications DESCRIPTION These negative temperature coefficient thermistors consist of a micro NTC chip with two insulated solid silver plated nickel wires and coated with a ochre-colored epoxy lacquer. PACKAGING The thermistors are packed in cardboard boxes; the smallest packing quantity is 1000 pieces. MARKING s The components are not marked. DESIGN-IN SUPPORT R(T) tables spreadsheet nlr@vishay.com. available on request at 100 VRMS MOUNTING By soldering or welding in any position. The parts can be potted in suitable resins.  0.05 g ELECTRICAL DATA AND ORDERING INFORMATION SAP PART AND ORDERING NUMBER NTCLE305E4202SB NTCLE305E4502SB NTCLE305E4103SB R25 (1) () 2060 5000 10 000  (25 °C) (%/K) - 3.85 - 4.39 - 4.39 R25 TOL. (%) 1.92 2.19 2.19 B25/85 (1) (K) 3511 3984 3984 B25/85 TOL. (%) 1.0 0.5 0.5 TMAX. (2) 25 TO 85 (°C) ± 0.5 ± 0.5 ± 0.5 Notes (1) Other R and B-values available on request 25 (2) T is the temperature measurement accuracy in the defined temperature range Document Number: 29076 Revision: 16-May-11 For technical questions, contact: nlr@vishay.com www.vishay.com 89 This document is subject to change without notice. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000 NTCLE305E4…SB Vishay BCcomponents DIMENSIONS in millimeters 5.0 ± 1.0 5.0 ± 1.0 NTC Thermistors, 2-Point Micro Chip Sensor Insulated Leads 1.6 max. 0.4 max. 0.2 ± 0.01 1.6 max. 41.0 ± 1.0 RESISTANCE VALUES AT INTERMEDIATE TEMPERATURES WITH R25 AT 2060  SAP PART AND ORDERING NUMBER: NTCLE305E4202SB TEMPERATURE (°C) - 40.0 - 35.0 - 30.0 - 25.0 - 20.0 - 15.0 - 10.0 - 5.0 0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0 55.0 60.0 65.0 70.0 75.0 80.0 85.0 90.0 95.0 100.0 105.0 110.0 115.0 120.0 125.0 RESISTANCE  47 326 35 203 26 473 20 115 15 435 11 954 9341.4 7361.4 5847.7 4680.9 3774.3 3064.4 2504.6 2060.0 1704.5 1418.6 1186.9 997.97 842.90 714.92 608.74 520.21 446.08 383.73 331.09 286.48 248.55 216.18 188.49 164.73 144.27 126.63 111.36 98.133 R/R25 22.974 17.089 12.851 9.7643 7.4925 5.8031 4.5347 3.5735 2.8387 2.2723 1.8322 1.4876 1.2158 1.0000 0.82744 0.68864 0.57618 0.48445 0.40917 0.34705 0.29550 0.25253 0.21654 0.18628 0.16072 0.13907 0.12065 0.10494 0.091501 0.079964 0.070036 0.061470 0.054061 0.047637 R/R (%) 5.27 4.95 4.64 4.34 4.06 3.78 3.52 3.27 3.02 2.79 2.56 2.34 2.13 1.92 1.86 1.81 1.76 1.71 1.67 1.63 1.59 1.55 1.52 1.49 1.46 1.43 1.57 1.70 1.83 1.96 2.08 2.20 2.32 2.43  (%/K) - 6.03 - 5.81 - 5.60 - 5.39 - 5.20 - 5.02 - 4.85 - 4.68 - 4.53 - 4.38 - 4.24 - 4.10 - 3.97 - 3.85 - 3.73 - 3.62 - 3.52 - 3.42 - 3.33 - 3.25 - 3.18 - 3.11 - 3.04 - 2.98 - 2.92 - 2.87 - 2.81 - 2.77 - 2.72 - 2.67 - 2.63 - 2.59 - 2.55 - 2.51 TMAX. (± °C) 0.87 0.85 0.83 0.81 0.78 0.75 0.73 0.70 0.67 0.64 0.60 0.57 0.54 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.56 0.62 0.67 0.73 0.79 0.85 0.91 0.97 RMIN. () 44 832 33 461 25 245 19 241 14 808 11 502 9012.6 7120.9 5671.0 4550.5 3677.7 2992.7 2451.3 2020.4 1672.7 1392.9 1166.1 980.90 828.85 703.29 599.06 512.13 439.29 378.01 326.25 282.37 244.64 212.50 185.04 161.50 141.27 123.84 108.78 95.746 RMAX. () 49 820 36 945 27 700 20 988 16 061 12 407 9670.2 7601.8 6024.5 4811.4 3870.9 3136.2 2557.9 2099.6 1736.3 1444.3 1207.8 1015.0 856.95 726.55 618.41 528.30 452.86 389.45 335.93 290.59 252.45 219.87 191.95 167.95 147.28 129.42 113.95 100.52 Note • R(T) table spreadsheet available on request at nlr@vishay.com www.vishay.com 90 For technical questions, contact: nlr@vishay.com Document Number: 29076 Revision: 16-May-11 This document is subject to change without notice. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000 NTCLE305E4…SB NTC Thermistors, 2-Point Micro Chip Sensor Insulated Leads Vishay BCcomponents RESISTANCE VALUES AT INTERMEDIATE TEMPERATURES WITH R25 AT 5 k SAP PART AND ORDERING NUMBER: NTCLE305E4502SB TEMPERATURE (°C) - 40 - 35 - 30 - 25 - 20 - 15 - 10 -5 0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 RESISTANCE  167 137 120 661 88 066 64 950 48 381 36 382 27 609 21 134 16 312 12 691 9948.4 7855.6 6246.4 5000.0 4028.0 3264.9 2661.9 2182.6 1799.4 1491.1 1241.9 1039.3 873.83 737.96 625.90 533.05 455.79 391.23 337.06 291.42 252.84 220.09 192.21 168.37 R/R25 33.427 24.132 17.613 12.990 9.6761 7.2765 5.5218 4.2268 3.2624 2.5381 1.9897 1.5711 1.2493 1.0000 0.80560 0.65297 0.53239 0.43653 0.35987 0.29823 0.24838 0.20787 0.17477 0.14759 0.12518 0.10661 0.091159 0.078246 0.067411 0.058284 0.050568 0.044019 0.038441 0.033675 R/R (%) 4.10 3.91 3.74 3.57 3.41 3.25 3.10 2.96 2.82 2.68 2.55 2.43 2.31 2.19 2.13 2.07 2.01 1.96 1.90 1.85 1.80 1.76 1.71 1.67 1.63 1.59 1.66 1.74 1.81 1.88 1.95 2.02 2.09 2.15  (%/K) - 6.63 - 6.41 - 6.19 - 5.99 - 5.79 - 5.61 - 5.43 - 5.26 - 5.10 - 4.94 - 4.80 - 4.65 - 4.52 - 4.39 - 4.26 - 4.14 - 4.03 - 3.92 - 3.81 - 3.71 - 3.61 - 3.51 - 3.42 - 3.34 - 3.25 - 3.17 - 3.09 - 3.02 - 2.94 - 2.87 - 2.81 - 2.74 - 2.68 - 2.62 TMAX. (± °C) 0.62 0.61 0.60 0.60 0.59 0.58 0.57 0.56 0.55 0.54 0.53 0.52 0.51 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.54 0.58 0.62 0.66 0.70 0.74 0.78 0.82 RMIN. () 160 290 115 939 84 775 62 632 46 732 35 199 26 753 20 509 15 852 12 350 9694.3 7664.7 6102.1 4890.3 3942.2 3197.3 2608.4 2139.9 1765.1 1463.5 1219.5 1021.1 858.87 725.65 615.72 524.60 448.21 384.43 330.95 285.93 247.90 215.64 188.19 164.75 RMAX. () 173 984 125 383 91 358 67 268 50 029 37 565 28 465 21 759 16 772 13 031 10 203 8046.5 6390.6 5109.7 4113.8 3332.5 2715.5 2225.4 1833.6 1518.8 1264.3 1057.6 888.79 750.27 636.08 541.51 463.37 398.03 343.16 296.91 257.78 224.54 196.22 172.00 Note • R(T) table spreadsheet available on request at nlr@vishay.com Document Number: 29076 Revision: 16-May-11 For technical questions, contact: nlr@vishay.com www.vishay.com 91 This document is subject to change without notice. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000 NTCLE305E4…SB Vishay BCcomponents NTC Thermistors, 2-Point Micro Chip Sensor Insulated Leads RESISTANCE VALUES AT INTERMEDIATE TEMPERATURES WITH R25 AT 10 k SAP PART AND ORDERING NUMBER: NTCLE305E4103SB TEMPERATURE (°C) - 40 - 35 - 30 - 25 - 20 - 15 - 10 -5 0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 RESISTANCE  334 274 241 323 176 133 129 900 96 761 72 765 55 218 42 268 32 624 25 381 19 897 15 711 12 493 10 000 8056.0 6529.7 5323.9 4365.3 3598.7 2982.3 2483.8 2078.7 1747.7 1475.9 1251.8 1066.1 911.59 782.46 674.11 582.84 505.68 440.19 384.41 336.75 R/R25 33.427 24.132 17.613 12.990 9.6761 7.2765 5.5218 4.2268 3.2624 2.5381 1.9897 1.5711 1.2493 1.0000 0.80560 0.65297 0.53239 0.43653 0.35987 0.29823 0.24838 0.20787 0.17477 0.14759 0.12518 0.10661 0.091159 0.078246 0.067411 0.058284 0.050568 0.044019 0.038441 0.033675 R/R (%) 4.10 3.91 3.74 3.57 3.41 3.25 3.10 2.96 2.82 2.68 2.55 2.43 2.31 2.19 2.13 2.07 2.01 1.96 1.90 1.85 1.80 1.76 1.71 1.67 1.63 1.59 1.66 1.74 1.81 1.88 1.95 2.02 2.09 2.15  (%/K) - 6.63 - 6.41 - 6.19 - 5.99 - 5.79 - 5.61 - 5.43 - 5.26 - 5.10 - 4.94 - 4.80 - 4.65 - 4.52 - 4.39 - 4.26 - 4.14 - 4.03 - 3.92 - 3.81 - 3.71 - 3.61 - 3.51 - 3.42 - 3.34 - 3.25 - 3.17 - 3.09 - 3.02 - 2.94 - 2.87 - 2.81 - 2.74 - 2.68 - 2.62 TMAX. (± °C) 0.62 0.61 0.60 0.60 0.59 0.58 0.57 0.56 0.55 0.54 0.53 0.52 0.51 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.54 0.58 0.62 0.66 0.70 0.74 0.78 0.82 RMIN. () 320 580 231 879 169 549 125 264 93 465 70 399 53 506 41 018 31 705 24 700 19 389 15 329 12 204 9780.7 7884.3 6394.5 5216.7 4279.8 3530.2 2927.0 2439.0 2042.1 1717.7 1451.3 1231.4 1049.2 896.42 768.85 661.89 571.86 495.79 431.28 376.38 329.50 RMAX. () 347 969 250 767 182 716 134 536 100 058 75 130 56 931 43 518 33 544 26 063 20 405 16 093 12 781 10 219 8227.6 6664.9 5431.1 4450.7 3667.3 3037.6 2528.6 2115.2 1777.6 1500.5 1272.2 1083.0 926.75 796.06 686.33 593.83 515.56 449.09 392.44 344.00 Note • R(T) table spreadsheet available on request at nlr@vishay.com www.vishay.com 92 For technical questions, contact: nlr@vishay.com Document Number: 29076 Revision: 16-May-11 This document is subject to change without notice. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000 Legal Disclaimer Notice Vishay Disclaimer ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE. Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained in any datasheet or in any other disclosure relating to any product. Vishay makes no warranty, representation or guarantee regarding the suitability of the products for any particular purpose or the continuing production of any product. To the maximum extent permitted by applicable law, Vishay disclaims (i) any and all liability arising out of the application or use of any product, (ii) any and all liability, including without limitation special, consequential or incidental damages, and (iii) any and all implied warranties, including warranties of fitness for particular purpose, non-infringement and merchantability. Statements regarding the suitability of products for certain types of applications are based on Vishay’s knowledge of typical requirements that are often placed on Vishay products in generic applications. Such statements are not binding statements about the suitability of products for a particular application. It is the customer’s responsibility to validate that a particular product with the properties described in the product specification is suitable for use in a particular application. Parameters provided in datasheets and/or specifications may vary in different applications and performance may vary over time. All operating parameters, including typical parameters, must be validated for each customer application by the customer’s technical experts. Product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase, including but not limited to the warranty expressed therein. Except as expressly indicated in writing, Vishay products are not designed for use in medical, life-saving, or life-sustaining applications or for any other application in which the failure of the Vishay product could result in personal injury or death. Customers using or selling Vishay products not expressly indicated for use in such applications do so at their own risk and agree to fully indemnify and hold Vishay and its distributors harmless from and against any and all claims, liabilities, expenses and damages arising or resulting in connection with such use or sale, including attorneys fees, even if such claim alleges that Vishay or its distributor was negligent regarding the design or manufacture of the part. Please contact authorized Vishay personnel to obtain written terms and conditions regarding products designed for such applications. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or by any conduct of Vishay. Product names and markings noted herein may be trademarks of their respective owners. Document Number: 91000 Revision: 11-Mar-11 www.vishay.com 1
