10A8-T3

WTE POWER SEMICONDUCTORS 10A05 – 10A10 Pb 10A STANDARD DIODE Features ! ! ! ! ! Diffused Junction Low Forward Voltage Drop High Current Capability High Reliability High Surge Current Capability A B A Mechanical Data ! ! ! ! ! ! ! Case: P-600, Molded Plastic Terminals: Plated Leads Solderable per MIL-STD-202, Method 208 Polarity: Cathode Band Weight: 2.1 grams (approx.) Mounting Position: Any Marking: Type Number Lead Free: For RoHS / Lead Free Version, Add “-LF” Suffix to Part Number, See Page 4 D P-600 Dim Min Max 25.4 — A 8.60 9.10 B 1.20 1.30 C 8.60 9.10 D All Dimensions in mm C Maximum Ratings and Electrical Characteristics Single Phase, half wave, 60Hz, resistive or inductive load. For capacitive load, derate current by 20%. @TA=25°C unless otherwise specified Characteristic Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Average Rectified Output Current (Note 1) @TA = 50°C Non-Repetitive Peak Forward Surge Current 8.3ms Single half sine-wave superimposed on rated load (JEDEC Method) Forward Voltage Peak Reverse Current At Rated DC Blocking Voltage @IF = 10A @TA = 25°C @TA = 100°C Symbol VRRM VRWM VR VR(RMS) IO 10A05 10A1 10A2 10A4 10A6 10A8 10A10 Unit 50 35 100 70 200 140 400 280 10 600 420 800 560 1000 700 V V A IFSM VFM IRM Cj R
JA Tj TSTG 150 600 1.0 10 100 80 10 -50 to +150 -50 to +150 A V µA pF °C/W °C °C Typical Junction Capacitance (Note 2) Typical Thermal Resistance Junction to Ambient (Note 1) Operating Temperature Range Storage Temperature Range Note: 1. Leads maintained at ambient temperature at a distance of 9.5mm from the case 2. Measured at 1.0 MHz and applied reverse voltage of 4.0V D.C. 10A05 – 10A10 1 of 4 © 2006 Won-Top Electronics 

I(AV), AVERAGE RECTIFIED CURRENT (A) 12 10 8.0 IF, INSTANTANEOUS FORWARD CURRENT (A) 100 10 6.0 4.0 2.0 0 0 50 100 150 200 1.0 Tj = 25ºC Pulse Width = 300 ms 2% Duty Cycle 0.1 0 0.4 0.8 1.2 1.6 TA, AMBIENT TEMPERATURE (ºC) Fig. 1 Forward Current Derating Curve 1000 IFSM, PEAK FORWARD SURGE CURRENT (A) Cj, JUNCTION CAPACITANCE (pF) 1000 VF, INSTANTANEOUS FORWARD VOLTAGE (V) Fig. 2 Typical Forward Characteristics Tj = 25°C f = 1MHz 800 10A05 - 10A4 100 600 10A6 - 10A10 400 10 200 8.3ms Single Half Sine-Wave JEDEC Method 0 1 10 100 1.0 1 10 VR, REVERSE VOLTAGE (V) Fig. 4 Typical Junction Capacitance 100 NUMBER OF CYCLES AT 60 Hz Fig. 3 Maximum Non-Repetitive Peak Forward Surge Current 10A05 – 10A10 2 of 4 © 2006 Won-Top Electronics MARKING INFORMATION TAPING SPECIFICATIONS 0.8mm MAX 10mm 10 Ax WTE Cathode 10Ax x WTE = Polarity Band = Device Number = 05, 1, 2, 4, 6, 8 or 10 = Manufacturer’s Logo 1.2mm MAX 6mm 52.4mm Cathode Tape: Red Anode Tape: White 0.8mm MAX PACKAGING INFORMATION TAPE & REEL BULK 330mm 50mm 210mm 85mm Product ID Label 80±5mm Packaging TAPE & REEL BULK Reel Diameter / Box Size (mm) 330 210 x 85 x 50 Quantity (PCS) 800 250 Carton Size (mm) 370 x 370 x 420 500 x 255 x 275 Quantity (PCS) 4,000 7,000 Approx. Gross Weight (KG) 12.0 17.0 Note: 1. Paper reel, white or gray color. Core material: plastic or metal. 2. Components are packed in accordance with EIA standard RS-296-E. 10A05 – 10A10 3 of 4 © 2006 Won-Top Electronics ORDERING INFORMATION Product No. 10A05-T3 10A05 10A1-T3 10A1 10A2-T3 10A2 10A4-T3 10A4 10A6-T3 10A6 10A8-T3 10A8 10A10-T3 10A10 1. 2. 3. Package Type P-600 P-600 P-600 P-600 P-600 P-600 P-600 P-600 P-600 P-600 P-600 P-600 P-600 P-600 Shipping Quantity 800/Tape & Reel 250 Units/Box 800/Tape & Reel 250 Units/Box 800/Tape & Reel 250 Units/Box 800/Tape & Reel 250 Units/Box 800/Tape & Reel 250 Units/Box 800/Tape & Reel 250 Units/Box 800/Tape & Reel 250 Units/Box Products listed in bold are WTE Preferred devices. Shipping quantity given is for minimum packing quantity only. For minimum order quantity, please consult the Sales Department. To order RoHS / Lead Free version (with Lead Free finish), add “-LF” suffix to part number above. For example, 10A05-T3-LF. Won-Top Electronics Co., Ltd (WTE) has checked all information carefully and believes it to be correct and accurate. However, WTE cannot assume any responsibility for inaccuracies. Furthermore, this information does not give the purchaser of semiconductor devices any license under patent rights to manufacturer. WTE reserves the right to change any or all information herein without further notice. WARNING: DO NOT USE IN LIFE SUPPORT EQUIPMENT. WTE power semiconductor products are not authorized for use as critical components in life support devices or systems without the express written approval. Won-Top Electronics Co., Ltd. No. 44 Yu Kang North 3rd Road, Chine Chen Dist., Kaohsiung, Taiwan Phone: 886-7-822-5408 or 886-7-822-5410 Fax: 886-7-822-5417 Email: sales@wontop.com Internet: http://www.wontop.com We power your everyday. 10A05 – 10A10 4 of 4 © 2006 Won-Top Electronics
