www.we-online.com Modular Jack Connector WR-MJ 12 09/08 12-1 www.we-online.com Modular Jack Connector WR-MJ Würth Elektronik is a leader for filtered connectivity solutions thanks to WE Midcom Inc. USA it’s US branch office, well known for Modular Jack with transformer. After primarily focused on RJ with magnetic Würth Elektronik decided to offer a wide range of non filtered Modular Jack too. This range consists in single or multi-port jacks, stacked or not, with possible LEDs (eventually bipolar), in surface mount or through hole pc board mount, shielded or unshielded. 12 Performance level 3 Performance level 2 as per CECC 75 301-802 Performance level 1 as per CECC 75 301-802 50 mating cycles, no gaz test 250 mating cycles, 4 days 4 mixed gaz test - IEC 60 512 500 mating cycles, 10 days 4 mixed gaz test - IEC 60 512 xPyC means x Poles/y Contacts ex: 6P4C means 6Poles/4Contacts 12-2 09/08 www.we-online.com Modular Jack Connector WR-MJ NEW Horizontal Shielded Modular Jack 12-5 to 12-18 NEW Horizontal Half Shielded Modular Jack 12-19 & 12-20 NEW Horizontal Plastic Modular Jack 12-21 to 12-29 NEW Vertical Shielded Modular Jack 12-30 to 12-32 NEW Vertical Plastic Modular Jack 12-33 to 12-38 NEW 45° Plastic Modular Jack 12-39 NEW Design Kit 12-40 Würth Elektronik has understood the requirements of design engineers offering also ESD and EMI suppression parts for its communication connectors. In the EMC labs customers are often faced with unsatisfied protection of its designs due to the rigorous tests against ESD and EMI. Related Products WESURGE ESD Protection WERI Shielding Connector 09/08 Varistor or TVS eiSos EMI Filter Ferrite bead or Suppression Choke I/O IC Driver • Recommended parts for LAN transforming LAN Transformer 10/100 BaseT WE-LAN e.g. 749 010 012 LAN Transformer Gigabit WE-LAN e.g. 749 020 010 • Recommended parts for EMI suppression Chip Bead Ferrites WE-CBF e.g. 742 792 040 with 600Ohm in size 0805 Common Mode Chokes WE-CNSW e.g. 744 232 222 with 2200Ohm • Recommended parts for ESD suppression ESD Suppressor WE-VE “ULC” e.g. 823 07 050 029 with 0.2pF in size 0402 TVS Diodes WE-TVS e.g. 824 015 with 4 I/O lines + VDD protection 12-3 12 www.we-online.com Modular Jack Connector WR-MJ Entrance Shielding Port TH/SMT LED EMI xPxC Tab Order Code Page 6P6C Up 615 006 143 221 12-5 NEW 8P8C Down 615 008 140 121 12-6 NEW 8P8C Down 615 008 142 21 12-7 8P8C Down 615 008 142 621 12-8 NEW 12-9 NEW No No THT 1x1 Yes 8P8C Up 615 008 140 621 Yellow/Green Yes 8P8C Up 615 008 137 421 8P8C Up 615 008 141 321 2x Bipolar G/Y Yes 8P8C Up 615 008 142 121 NEW 12-10 NEW Shielded SMT Yellow/Green Yes 8P8C Up 634 008 137 521 12-11 No No 8P8C Down 615 016 137 621 12-12 Yellow/Green Yes 8P8C Up 615 016 137 721 12-13 No No 8P8C Down 615 032 137 821 12-14 Yellow/Green Yes 8P8C Up 615 032 137 921 12-15 8P8C Down & Up 615 016 240 521 12-16 8P8C Down & Up 615 032 243 321 12-17 NEW 8P8C Down & Up 615 064 243 321 12-18 NEW 6P6C Down 615 006 143 421 12-19 NEW 8P8C Down 615 008 143 521 12-20 NEW 6P6C Down 615 006 143 621 12-21 NEW 8P8C Down 615 008 143 721 12-22 NEW 6P4C Down 615 004 141 121 6P6C Down 615 006 141 121 6P2C Up 615 002 138 421 6P4C Up 615 004 138 421 6P6C Up 615 006 138 421 4P4C Up 615 004 143 821 12-25 8P8C Down 615 008 137 121 12-26 8P8C Down 634 008 137 221 12-27 6P6C Up 615 012 143 921 12-28 NEW 6P6C Up 615 024 143 921 12-29 NEW 615 008 138 221 12-30 615 008 140 421 12-31 8P8C 615 008 138 321 12-32 6P6C 615 006 138 521 12-33 4P4C 615 004 144 021 12-34 6P4C 615 004 144 121 1x2 1x4 THT 2x1 2x2 No Yes Horizontal 2x4 Half-shielded 1x1 THT No No NEW NEW 12-23 THT NEW 1x1 Plastic No 12-24 Nc SMT 1x2 NEW THT 1x4 8P8C 12 No Shielded 1x1 THT No Yellow/Green 8P8C - NEW NEW Vertical 1x1 THT No No Plastic 12-35 6P6C NEW 615 006 144 121 - 45° Plastic 8P8C 615 008 144 221 12-36 NEW 8P8C 615 008 138 021 12-37 1x1 SMT No No 8P8C 634 008 138 121 12-38 1x1 THT No No 8P8C 615 008 142 521 12-39 NEW 615 001 12-40 NEW Design Kit 12-4 NEW 09/08 www.we-online.com NEW Horizontal Shielded 6P6C Modular Jack Tab Up WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max JEDEC lead free wave soldering PACKAGING • Tray 12 09/08 Order Code Pins Description 615 006 143 221 6P6C Modular Jack Horizontal Shielded Tab Up 12-5 www.we-online.com NEW Horizontal Shielded 8P8C Modular Jack Tab Down WR-MJ PCB LAYOUT - COMPONENT VIEW MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: • System application: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max CAT 5 Compatible JEDEC lead free wave soldering PACKAGING • Tray 12 Order Code Pins Description 615 008 140 121 8P8C Modular Jack Horizontal Shielded Tab Down 12-6 09/08 www.we-online.com Horizontal Shielded 8P8C Modular Jack Tab Down WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: • System application: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max CAT 5 Compatible JEDEC lead free wave soldering PACKAGING • Tray 12 09/08 Order Code Pins Description 615 008 142 21 8P8C Modular Jack Horizontal Shielded Tab Down 12-7 www.we-online.com NEW Horizontal Shielded 3.05mm Rear Grounding Post 8P8C Modular Jack Tab Down WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: • System application: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max CAT 5 Compatible JEDEC lead free wave soldering PACKAGING • Tray 12 Order Code Pins Description 615 008 142 621 8P8C Modular Jack Horizontal Shielded 3.05 mm Rear Grounding Post Tab Down 12-8 09/08 www.we-online.com NEW Horizontal Shielded with EMI Panel Finger 8P8C Modular Jack Tab Up WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: • System application: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max CAT 5 Compatible JEDEC lead free wave soldering PACKAGING • Tray 12 09/08 Order Code Pins Description 615 008 140 621 8P8C Modular Jack Horizontal Shielded With EMI Panel Finger Tab Up 12-9 www.we-online.com Horizontal Shielded with LED and EMI Panel Finger 8P8C Modular Jack Tab Up WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: • System application: PBT UL94-V0 Black Copper alloy Stamped Selective gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: SOLDERING • Solder temperature: –25 °C up to 85 °C Lead free and RoHS 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max CAT 5 Compatible JEDEC lead free wave soldering PACKAGING • Tray 12 Order Code Pins 615 008 137 421 8P8C Green 615 008 141 321 8P8C Bipolar G/Y 615 008 142 121 8P8C Bipolar Y/G Bipolar Y/G 12-10 LED 1 LED 2 LED Colour Status Description Yellow - Modular Jack Horizontal Shielded with LED & EMI Panel Finger Bipolar G/Y See Drawing MJ Horizontal Shielded with Bipolar LED & EMI Panel Finger See Drawing MJ Horizontal Shielded with Bipolar LED & Panel EMI Finger 09/08 www.we-online.com Horizontal Shielded SMT with LED and EMI Panel Finger 8P8C Modular Jack Tab Up WR-MJ (YELLOW) (GREEN) HIGH TEMPERATURE MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: • System application: Nylon 6T UL94-V0 Black Copper alloy Stamped Selective gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: SOLDERING • Solder temperature: –25 °C up to 85 °C Lead free and RoHS 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max CAT 5 Compatible JEDEC lead free reflow soldering PACKAGING • Tape & Reel 12 Order Code Pins LED 1 LED 2 LED Colour Status Description 634 008 137 521 8P8C Green Yellow - Modular Jack Horizontal Shielded with LED & EMI Panel Finger 09/08 12-11 www.we-online.com Horizontal Shielded Dual Port 8P8C Modular Jack Tab Down WR-MJ 12 MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: • System application: SOLDERING • Solder temperature: JEDEC lead free wave soldering PACKAGING • Tray Order Code Pins Description 615 016 137 621 2 x 8P8C 2 x Modular Jack Horizontal Dual Port Shielded Tab Down 12-12 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max CAT 5 Compatible 09/08 www.we-online.com Horizontal Shielded Dual Port with LED and EMI Panel Finger 8P8C Modular Jack Tab Up WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: 09/08 –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: • System application: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max CAT 5 Compatible JEDEC lead free wave soldering PACKAGING • Tray Order Code Pins Description 615 016 137 721 2 x 8P8C 2 x Modular Jack Horizontal Shielded with LED 1 (Green) / LED 2 (Yellow) & EMI Panel Fingers 12-13 12 www.we-online.com Horizontal Shielded Ganged 4 Ports 8P8C Modular Jack Tab Down WR-MJ 12 MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: • System application: SOLDERING • Solder temperature: JEDEC lead free wave soldering PACKAGING • Tray Order Code Pins Description 615 032 137 821 4 x 8P8C 4 x Modular Jack Horizontal Shielded Tab Down 12-14 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max CAT 5 Compatible 09/08 www.we-online.com Horizontal Shielded Ganged 4 Ports with LED & EMI Panel Finger 8P8C Modular Jack Tab Up WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: • System application: PBT UL94-V0 Black Copper alloy Stamped Selective gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max CAT 5 Compatible JEDEC lead free wave soldering PACKAGING • Tray –25 °C up to 85 °C Lead free and RoHS Order Code Pins LED 1 LED 2 LED Colour Status Description 615 032 137 921 4 x 8P8C Green Yellow - 4 x M.Jack Horizontal Shielded with LED & EMI Panel Finger 09/08 12-15 12 www.we-online.com NEW Horizontal Shielded Dual Stacked Port with EMI Panel Finger 8P8C Modular Jack Tab Up & Down WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: • System application: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max CAT 5 Compatible JEDEC lead free wave soldering PACKAGING • Tray 12 Order Code Pins Description 615 016 240 521 2 x 8P8C Modular Jack Horizontal Dual Stacked Port Shielded with EMI Panel Finger Tab Up & Down 12-16 09/08 www.we-online.com NEW Horizontal Shielded 2 x Dual Stacked Port with EMI Panel Finger 8P8C M. Jack Tab Up & Down WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: PBT / PA66 UL94-V0 Black Copper alloy Stamped Gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: 09/08 –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: • System application: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max CAT 5 Compatible JEDEC lead free wave soldering PACKAGING • Tray Order Code Pins Description 615 032 243 321 2 x 2 x 8P8C Modular Jack Horizontal 2 x Dual Stacked Port Shielded with EMI Panel Finger Tab Up & Down 12-17 12 www.we-online.com NEW Horizontal Shielded 2 x 4 Stacked Port with EMI Panel Finger 8P8C Modular Jack Tab Up & Down WR-MJ 12 MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: • System application: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max CAT 5 Compatible JEDEC lead free wave soldering PACKAGING • Tray Order Code Pins Description 615 064 243 321 2 x 4 x 8P8C Modular Jack Horizontal 2 x Four Stacked Port Shielded with EMI Panel Finger Tab Up & Down 12-18 09/08 www.we-online.com NEW Horizontal 6P6C Half Shielded Modular Jack Tab Down WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max JEDEC lead free wave soldering PACKAGING • Tray 12 09/08 Order Code Pins Description 615 006 143 421 6P6C Modular Jack Horizontal Half Shilded Tab Down 12-19 www.we-online.com NEW Horizontal Half Shielded 8P8C Modular Jack Tab Down WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: • System application: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max CAT 5 Compatible JEDEC lead free wave soldering PACKAGING • Tray 12 Order Code Pins Description 615 008 143 521 8P8C Modular Jack Horizontal Half Shilded Tab Down 12-20 09/08 www.we-online.com NEW Horizontal Plastic 6P6C Modular Jack Tab Down WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max JEDEC lead free wave soldering PACKAGING • Tray 12 09/08 Order Code Pins Description 615 006 143 621 6P6C Modular Jack Horizontal Plastic Tab Down 12-21 www.we-online.com NEW Horizontal Plastic 8P8C Modular Jack Tab Down WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max JEDEC lead free wave soldering PACKAGING • Tray 12 Order Code Pins Description 615 008 143 721 8P8C Modular Jack Horizontal Plastic Tab Down 12-22 09/08 www.we-online.com NEW Horizontal Plastic 6PxC Modular Jack Tab Down WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max JEDEC lead free wave soldering PACKAGING • Tray 12 09/08 Order Code Pins Description 615 004 141 121 6P4C Modular Jack Horizontal Plastic Tab Down 615 006 141 121 6P6C Modular Jack Horizontal Plastic Tab Down 12-23 www.we-online.com Horizontal Plastic 6PxC Modular Jack Tab Up WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max JEDEC lead free wave soldering PACKAGING • Tray 12 Order Code Pins Description 615 002 138 421 6P2C Modular Jack Horizontal Plastic Tab Up 615 004 138 421 6P4C Modular Jack Horizontal Plastic Tab Up 615 006 138 421 6P6C Modular Jack Horizontal Plastic Tab Up 12-24 09/08 www.we-online.com NEW Horizontal Plastic 4P4C Modular Jack Tab Up WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max JEDEC lead free wave soldering PACKAGING • Tray 12 09/08 Order Code Pins Description 615 004 143 821 4P4C Modular Jack Horizontal Plastic Tab Up 12-25 www.we-online.com Horizontal Plastic 8P8C Modular Jack Tab Down WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max JEDEC lead free wave soldering PACKAGING • Tray 12 Order Code Pins Description 615 008 137 121 8P8C Horizontal Plastic Modular Jack Tab Down 12-26 09/08 www.we-online.com Horizontal Plastic SMT 8P8C Modular Jack Tab Down WR-MJ HIGH TEMPERATURE MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Quality class: PA46 UL94-V0 Black Copper alloy Stamped Selective gold 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max JEDEC lead free reflow soldering PACKAGING • Tray 12 09/08 Order Code Pins Description 634 008 137 221 8P8C SMT Horizontal Plastic Modular Jack Tab Down 12-27 www.we-online.com NEW Horizontal Plastic Dual Port 6P6C Modular Jack Tab Up WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max JEDEC lead free wave soldering PACKAGING • Tray 12 Order Code Pins Description 615 012 143 921 2 x 6P6C Plastic Horizontal Dual Port Modular Jack Tab Up 12-28 09/08 www.we-online.com NEW Horizontal Plastic 4 Port 6P6C Modular Jack Tab Up WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: 09/08 –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max JEDEC lead free wave soldering PACKAGING • Tray Order Code Pins Description 615 024 143 921 4 x 6P6C Plastic Horizontal Four Port Modular Jack Tab Up 12-29 12 www.we-online.com Vertical Shielded 8P8C Front Post Modular Jack WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: • System application: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max CAT 5 Compatible JEDEC lead free wave soldering PACKAGING • Tray 12 Order Code Pins Description 615 008 138 221 8P8C Shielded Vertical Modular Jack 12-30 09/08 www.we-online.com NEW Vertical Shielded 8P8C Rear Post Modular Jack WR-MJ PCB LAYOUT - COMPONENT VIEW MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: • System application: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max CAT 5 Compatible JEDEC lead free wave soldering PACKAGING • Tray 12 09/08 Order Code Pins Description 615 008 140 421 8P8C Shielded Vertical Modular Jack 12-31 www.we-online.com Vertical Shielded with LED 8P8C Modular Jack WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Shielding: • Quality class: ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: • System application: PBT UL94-V0 Black Copper alloy Stamped Selective gold Bronze Ni Plated 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: SOLDERING • Solder temperature: –25 °C up to 85 °C Lead free and RoHS 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max CAT 5 Compatible JEDEC lead free wave soldering PACKAGING • Tray 12 Order Code Pins LED 1 LED 2 LED Colour Status Description 615 008 138 321 8P8C Green Yellow - Vertical Shielded Modular Jack 12-32 09/08 www.we-online.com Vertical Plastic 6P6C Modular Jack with Ears WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max JEDEC lead free wave soldering PACKAGING • Tray 12 09/08 Order Code Pins Description 615 006 138 521 6P6C Vertical Plastic Modular Jack 12-33 www.we-online.com NEW Vertical Plastic 4P4C Modular Jack with Ears WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max JEDEC lead free wave soldering PACKAGING • Tray 12 Order Code Pins Description 615 004 144 021 4P4C Vertical Plastic Modular Jack 12-34 09/08 www.we-online.com NEW Vertical Plastic 6PxC Modular Jack with Ears WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max JEDEC lead free wave soldering PACKAGING • Tray 12 09/08 Order Code Pins Description 615 004 144 121 6P4C Vertical Plastic Modular Jack 615 006 144 121 6P6C Vertical Plastic Modular Jack 12-35 www.we-online.com NEW Vertical Plastic 8P8C Modular Jack with Ears WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max JEDEC lead free wave soldering PACKAGING • Tray 12 Order Code Pins Description 615 008 144 221 8P8C Vertical Plastic Modular Jack 12-36 09/08 www.we-online.com Vertical Plastic 8P8C Modular Jack WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Quality class: PBT UL94-V0 Black Copper alloy Stamped Selective gold 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max JEDEC lead free wave soldering PACKAGING • Tray 12 09/08 Order Code Pins Description 615 008 138 021 8P8C Vertical Plastic Modular Jack 12-37 www.we-online.com Vertical Plastic 8P8C SMT Modular Jack WR-MJ HIGH TEMPERATURE MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Quality class: PA46 UL94-V0 Black Copper alloy Stamped Selective gold 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max JEDEC lead free reflow soldering PACKAGING • Tray 12 Order Code Pins Description 634 008 138 121 8P8C Vertical Plastic SMT Modular Jack 12-38 09/08 www.we-online.com NEW ° 45° Plastic 8P8C Modular Jack WR-MJ MATERIAL • Insulator material: • Flammability rating • Colour: • Contact material: • Contact type: • Contact plating: • Quality class: PBT UL94-V0 White Copper alloy Stamped Selective gold 500 mating cycles ENVIRONMENTAL • Operating temperature: • Compliance: –25 °C up to 85 °C Lead free and RoHS ELECTRICAL • Current rating: • Working voltage: • Insulation resistance: • Dielectric withstanding voltage: • Contact resistance: SOLDERING • Solder temperature: 1.5 A 120 Vac >500 MOhm 1 000 Vac/mn 20 mOhm max JEDEC lead free wave soldering PACKAGING • Tray 12 09/08 Order Code Pins Description 615 008 142 521 8P8C 45° Plastic Modular Jack 12-39 www.we-online.com Modular Jack & Communication Connector Design Kit Order Code 615 001 Design Kit WR-MJ All the parts of the assortment are detailled below Note: Modular Jack design kit is the same that WR-COM chapter. WR-COM see chapter 11 12 12-40 09/08 www.we-online.com Modular Jack & Communication Connector Design Kit P/N in the Kit 09/08 Pins Description 614 004 160 21 4 614 008 260 21 2x4 USB Type A Receptacle Horizontal Single THT 615 016 338 621 (2 x 4) + 8 614 004 134 726 4 USB Type A Receptacle Up right Single THT 614 004 135 023 4 USB Type A Receptacle Vertical Single THT 614 008 235 023 2x4 629 004 160 21 4 USB Type A Receptacle Horizontal Single SMT 629 004 113 921 4 USB Type A Plug Horizontal Single SMT 614 004 161 21 4 USB Type B Receptacle Horizontal Single THT 629 104 161 21 4 USB Type B Receptacle Horizontal Single SMT 614 004 133 21 4 USB Type B Receptacle Vertical Single THT 651 005 136 521 5 Mini USB Type B Receptacle Horizontal Single THT 651 005 161 21 5 Mini USB Type B Receptacle Horizontal Single SMT 651 005 136 421 5 Mini USB Type B Receptacle Vertical Single THT 629 105 136 821 5 Micro USB Type B Receptacle Horizontal Single SMT With peg 631 0xx 112 021 3 to 8 631 006 136 x21 6 631 012 212 021 2x5 Mini DIN Shielded Receptacle Horizontal Dual Green & Purple 631 0xx 110 21 3 to 8 Mini DIN Unshielded Receptacle Horizontal Single Black 685 119 134 923 19 HDMI Shielded Receptacle Horizontal SMT 685 119 135 725 19 HDMI Shielded Receptacle Horizontal SMT With screw 685 119 136 923 19 Mini HDMI Shielded Receptacle Horizontal SMT 675 024 321 221 24 + 1 DVI Shielded Receptacle Horizontal Digital THT With screw 675 024 321 321 24 +5 DVI Shielded Receptacle Horizontal Analogic & digital THT With screw P/N in the Kit Pins 615 008 137 121 8 RJ45 Unshielded Receptacle Horizontal Single THT 634 008 137 221 8 RJ45 Unshielded Receptacle Horizontal Single SMT USB Type A Receptacle Horizontal Dual THT USB Type A Shielded Receptacle Horizontal Triple THT + RJ45 With LED USB Type A Receptacle Vertical Dual THT Mini DIN Shielded Receptacle Horizontal Single Black Mini DIN Shielded Receptacle Horizontal Single Green or Purple Description 615 008 142 21 8 RJ45 Shielded Receptacle Horizontal Single THT 615 008 137 421 8 RJ45 Shielded Receptacle Horizontal Single THT EMI + LED 634 008 137 521 8 RJ45 Shielded Receptacle Horizontal Single SMT EMI + LED 615 016 137 621 2x8 RJ45 Shielded Receptacle Horizontal Double THT 615 016 137 721 2x8 RJ45 Shielded Receptacle Horizontal Double THT EMI + LED 615 032 137 821 4x8 RJ45 Shielded Receptacle Horizontal Four THT 615 032 137 921 4x8 RJ45 Shielded Receptacle Horizontal Four THT EMI + LED 615 008 138 021 8 RJ45 Unshielded Receptacle Vertical Single THT 634 008 138 121 8 RJ45 Unshielded Receptacle Vertical Single SMT 615 008 138 221 8 RJ45 Shielded Receptacle Vertical Single THT 615 008 138 321 8 RJ45 Shielded Receptacle Vertical Single THT LED 615 006 138 421 6 RJ11 Unshielded Receptacle Horizontal Single THT Tab Up 615 006 138 521 6 RJ11 Unshielded Receptacle Vertical Single THT 12 12-41 www.we-online.com Notes: Würth Elektronik has understood the requirements of design engineers offering also ESD and EMI suppression parts for its communication connectors. In the EMC labs customers are often faced with unsatisfied protection of its designs due to the rigorous tests against ESD and EMI. Related Products 12 WESURGE ESD Protection WERI Shielding Connector 12-42 Varistor or TVS eiSos EMI Filter Ferrite bead or Suppression Choke I/O IC Driver • Recommended parts for LAN transforming LAN Transformer 10/100 BaseT WE-LAN e.g. 749 010 012 LAN Transformer Gigabit WE-LAN e.g. 749 020 010 • Recommended parts for EMI suppression Chip Bead Ferrites WE-CBF e.g. 742 792 040 with 600Ohm in size 0805 Common Mode Chokes WE-CNSW e.g. 744 232 222 with 2200Ohm • Recommended parts for ESD suppression ESD Suppressor WE-VE “ULC” e.g. 823 07 050 029 with 0.2pF in size 0402 TVS Diodes WE-TVS e.g. 824 015 with 4 I/O lines + VDD protection 09/08
