Dimensions: [mm]
Recommended Land Pattern: [mm]
Electrical Properties:
Properties
Test conditions
Value
Unit
Tol.
100 MHz
110
Ω
±25%
Zmax 226 MHz
135
Ω
typ.
Rated Current 2
IR 2
ΔT = 40 K
4100
mA
max.
DC Resistance
RDC
@ 20 °C
20
mΩ
max.
DC Resistance
RDC
@ 20 °C
14.5
mΩ
typ.
Impedance @ 100 MHz
W
Z
Maximum Impedance
0,7
0,7
0,3 ±0,2
Type
High Current
Certification:
WIDE BAND / HIGH SPEED: W = 2,2
HIGH CURRENT:
W = 2,6
0,8±0,2
1,6±0,2
Scale - 20:1
RoHS Approval
Compliant [2011/65/EU&2015/863]
REACh Approval
Conform or declared [(EC)1907/2006]
Halogen Free
Conform [JEDEC JS709B]
Halogen Free
Conform [IEC 61249-2-21]
Component Qualification
AEC-Q200 Grade 1
Schematic:
General Information:
0,8±0,2
Do not use this part constantly beyond the Rated Current, as this will create excessive heat and can
harm the component
Operating Temperature
-55 up to +125 °C
Storage Conditions (in original
packaging)
< 40 °C ; < 75 % RH
Moisture Sensitivity Level (MSL)
1
Test conditions of Electrical Properties: +20 °C, 33 % RH if not specified differently
Scale - 20:1
CHECKED
REVISION
DATE (YYYY-MM-DD)
GENERAL TOLERANCE
MHB
001.003
2021-01-18
DIN ISO 2768-1m
PROJECTION
METHOD
DESCRIPTION
Würth Elektronik eiSos GmbH & Co. KG
EMC & Inductive Solutions
Max-Eyth-Str. 1
74638 Waldenburg
Germany
Tel. +49 (0) 79 42 945 - 0
www.we-online.com
eiSos@we-online.com
WE-MPSB EMI Multilayer Power
Suppression Bead
ORDER CODE
74279228111
SIZE/TYPE
BUSINESS UNIT
STATUS
PAGE
0603
eiSos
Valid
1/10
This electronic component has been designed and developed for usage in general electronic equipment only. This product is not authorized for use in equipment where a higher safety standard and reliability standard is especially required or where a failure of the product is reasonably expected to cause severe personal injury or death, unless the parties have executed an agreement specifically governing such use. Moreover Würth Elektronik eiSos GmbH
& Co KG products are neither designed nor intended for use in areas such as military, aerospace, aviation, nuclear control, submarine, transportation (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network etc.. Würth Elektronik eiSos GmbH & Co KG must be informed about the intent of such usage before the design-in stage. In addition, sufficient reliability evaluation checks for safety
must be performed on every electronic component which is used in electrical circuits that require high safety and reliability functions or performance.
Typical Impedance Characteristics:
DC bias current:
1000
100
100
Impedance [Ω]
Impedance [Ω]
1000
10
1
10
1
10
100
1000
1
1
10
Frequency [MHz]
Z
XL
100
1000
Frequency [MHz]
R
Z @ 1A
Z @ 2A
Z @ 3A
CHECKED
REVISION
DATE (YYYY-MM-DD)
GENERAL TOLERANCE
MHB
001.003
2021-01-18
DIN ISO 2768-1m
Z @ 4A
PROJECTION
METHOD
DESCRIPTION
Würth Elektronik eiSos GmbH & Co. KG
EMC & Inductive Solutions
Max-Eyth-Str. 1
74638 Waldenburg
Germany
Tel. +49 (0) 79 42 945 - 0
www.we-online.com
eiSos@we-online.com
WE-MPSB EMI Multilayer Power
Suppression Bead
ORDER CODE
74279228111
SIZE/TYPE
BUSINESS UNIT
STATUS
PAGE
0603
eiSos
Valid
2/10
This electronic component has been designed and developed for usage in general electronic equipment only. This product is not authorized for use in equipment where a higher safety standard and reliability standard is especially required or where a failure of the product is reasonably expected to cause severe personal injury or death, unless the parties have executed an agreement specifically governing such use. Moreover Würth Elektronik eiSos GmbH
& Co KG products are neither designed nor intended for use in areas such as military, aerospace, aviation, nuclear control, submarine, transportation (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network etc.. Würth Elektronik eiSos GmbH & Co KG must be informed about the intent of such usage before the design-in stage. In addition, sufficient reliability evaluation checks for safety
must be performed on every electronic component which is used in electrical circuits that require high safety and reliability functions or performance.
Typical Peak Current vs. Pulse Length Characteristics:
Typical Number of Pulse Repetition:
50
100.000
45
40
10.000
30
Typical Number of Pulse repetition
Current [A]
35
25
20
15
10
1.000
100
10
5
0
1
0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0 6.5 7.0 7.5 8.0
Pulse Length [ms]
valid for ambient temperature: +25°C; 8 ms pulse length, single pulse
0
10
20
30
40
50
Current [A]
60
70
80
valid for ambient temperature: +25°C; 8 ms pulse length, 10 s break between pulse
CHECKED
REVISION
DATE (YYYY-MM-DD)
GENERAL TOLERANCE
MHB
001.003
2021-01-18
DIN ISO 2768-1m
PROJECTION
METHOD
DESCRIPTION
Würth Elektronik eiSos GmbH & Co. KG
EMC & Inductive Solutions
Max-Eyth-Str. 1
74638 Waldenburg
Germany
Tel. +49 (0) 79 42 945 - 0
www.we-online.com
eiSos@we-online.com
WE-MPSB EMI Multilayer Power
Suppression Bead
ORDER CODE
74279228111
SIZE/TYPE
BUSINESS UNIT
STATUS
PAGE
0603
eiSos
Valid
3/10
This electronic component has been designed and developed for usage in general electronic equipment only. This product is not authorized for use in equipment where a higher safety standard and reliability standard is especially required or where a failure of the product is reasonably expected to cause severe personal injury or death, unless the parties have executed an agreement specifically governing such use. Moreover Würth Elektronik eiSos GmbH
& Co KG products are neither designed nor intended for use in areas such as military, aerospace, aviation, nuclear control, submarine, transportation (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network etc.. Würth Elektronik eiSos GmbH & Co KG must be informed about the intent of such usage before the design-in stage. In addition, sufficient reliability evaluation checks for safety
must be performed on every electronic component which is used in electrical circuits that require high safety and reliability functions or performance.
Derating Curve:
120%
100%
Current [A]
80%
60%
40%
20%
0%
0
20
40
60
80
100
120
140
160
Temperature [°C]
valid for ambient temperature: -55°C to +85°C
CHECKED
REVISION
DATE (YYYY-MM-DD)
GENERAL TOLERANCE
MHB
001.003
2021-01-18
DIN ISO 2768-1m
PROJECTION
METHOD
DESCRIPTION
Würth Elektronik eiSos GmbH & Co. KG
EMC & Inductive Solutions
Max-Eyth-Str. 1
74638 Waldenburg
Germany
Tel. +49 (0) 79 42 945 - 0
www.we-online.com
eiSos@we-online.com
WE-MPSB EMI Multilayer Power
Suppression Bead
ORDER CODE
74279228111
SIZE/TYPE
BUSINESS UNIT
STATUS
PAGE
0603
eiSos
Valid
4/10
This electronic component has been designed and developed for usage in general electronic equipment only. This product is not authorized for use in equipment where a higher safety standard and reliability standard is especially required or where a failure of the product is reasonably expected to cause severe personal injury or death, unless the parties have executed an agreement specifically governing such use. Moreover Würth Elektronik eiSos GmbH
& Co KG products are neither designed nor intended for use in areas such as military, aerospace, aviation, nuclear control, submarine, transportation (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network etc.. Würth Elektronik eiSos GmbH & Co KG must be informed about the intent of such usage before the design-in stage. In addition, sufficient reliability evaluation checks for safety
must be performed on every electronic component which is used in electrical circuits that require high safety and reliability functions or performance.
Packaging Specification - Tape: [mm]
Packaging Specification - Reel: [mm]
P0
A
D0
T (=K0)
W3
E1
P2
D
A
A0
N
B0
E2
C
Top Cover
Tape
T1
A
P1
W2
T1
Feeding direction
End
W1
close to center
W
F
B
Carrier Tape
Start
Cover Tape
detail B
B
Top
Cover Tape
Chip Cavity
Sprocket Hole
No Component
min. 160mm
Components
No Component
min.100mm
Embossment
Bottom
Cover Tape
Cover Tape
min. 400mm
Packaging is referred to the international standard IEC 60286-3:2019
Tape Type
Tolerance
Value
1a
A0
(mm)
typ.
1,10
B0
(mm)
typ.
1,88
W
(mm)
+0,3/ -0,1
8,00
T
(mm)
ref.
1,10
T1
(mm)
ref.
0,10
P0
(mm)
±0,1
4,00
P1
(mm)
±0,1
4,00
P2
(mm)
+0,05
2,00
D0
(mm)
+0,1 / -0,0
1,50
E1
(mm)
±0,1
1,75
E2
(mm)
min.
6,25
F
(mm)
±0,05
3,50
Material
Qty.
(pcs.)
Paper
4000
165° - 180°
Tolerance
Value
A
(mm)
± 2,0
178
B
(mm)
min.
1.5
C
(mm)
min.
12.8
D
(mm)
min.
20.2
N
(mm)
min.
50
W1
(mm)
+1,5
8.4
W2
(mm)
max.
14.4
CHECKED
REVISION
DATE (YYYY-MM-DD)
GENERAL TOLERANCE
MHB
001.003
2021-01-18
DIN ISO 2768-1m
W3
(mm)
min.
7.9
W3
(mm)
max.
10.9
Material
Polystyrene
PROJECTION
METHOD
DESCRIPTION
Pull-of force
Tape width
8 mm
0,1 N - 1,0 N
Würth Elektronik eiSos GmbH & Co. KG
EMC & Inductive Solutions
Max-Eyth-Str. 1
74638 Waldenburg
Germany
Tel. +49 (0) 79 42 945 - 0
www.we-online.com
eiSos@we-online.com
WE-MPSB EMI Multilayer Power
Suppression Bead
ORDER CODE
74279228111
SIZE/TYPE
BUSINESS UNIT
STATUS
PAGE
0603
eiSos
Valid
5/10
This electronic component has been designed and developed for usage in general electronic equipment only. This product is not authorized for use in equipment where a higher safety standard and reliability standard is especially required or where a failure of the product is reasonably expected to cause severe personal injury or death, unless the parties have executed an agreement specifically governing such use. Moreover Würth Elektronik eiSos GmbH
& Co KG products are neither designed nor intended for use in areas such as military, aerospace, aviation, nuclear control, submarine, transportation (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network etc.. Würth Elektronik eiSos GmbH & Co KG must be informed about the intent of such usage before the design-in stage. In addition, sufficient reliability evaluation checks for safety
must be performed on every electronic component which is used in electrical circuits that require high safety and reliability functions or performance.
Packaging Specification - Inner Carton: [mm]
H
IC
H
MC
Packaging Specification - Reel in Carton: [mm]
L
MC
W
MC
L
IC
W
IC
Tolerance
Value
LIC
(mm)
typ.
185,00
WIC
(mm)
typ.
91,00
HIC
(mm)
typ.
188,00
No. of
Reel (pcs.)
5
Qty.
(pcs.)
20000
Material
Paper
Tolerance
Value
LMC
(mm)
typ.
485,00
WMC
(mm)
typ.
197,00
HMC
(mm)
typ.
200,00
No. of
Inner Carton (pcs.)
Qty.
(pcs.)
Material
5
100000
Paper
CHECKED
REVISION
DATE (YYYY-MM-DD)
GENERAL TOLERANCE
MHB
001.003
2021-01-18
DIN ISO 2768-1m
PROJECTION
METHOD
DESCRIPTION
Würth Elektronik eiSos GmbH & Co. KG
EMC & Inductive Solutions
Max-Eyth-Str. 1
74638 Waldenburg
Germany
Tel. +49 (0) 79 42 945 - 0
www.we-online.com
eiSos@we-online.com
WE-MPSB EMI Multilayer Power
Suppression Bead
ORDER CODE
74279228111
SIZE/TYPE
BUSINESS UNIT
STATUS
PAGE
0603
eiSos
Valid
6/10
This electronic component has been designed and developed for usage in general electronic equipment only. This product is not authorized for use in equipment where a higher safety standard and reliability standard is especially required or where a failure of the product is reasonably expected to cause severe personal injury or death, unless the parties have executed an agreement specifically governing such use. Moreover Würth Elektronik eiSos GmbH
& Co KG products are neither designed nor intended for use in areas such as military, aerospace, aviation, nuclear control, submarine, transportation (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network etc.. Würth Elektronik eiSos GmbH & Co KG must be informed about the intent of such usage before the design-in stage. In addition, sufficient reliability evaluation checks for safety
must be performed on every electronic component which is used in electrical circuits that require high safety and reliability functions or performance.
H
C
Packaging Specification - Outer Carton: [mm]
L
W
C
C
Tolerance
Value
LC
(mm)
typ.
500,00
WC
(mm)
typ.
412,00
HC
(mm)
typ.
224,00
No. of
Medium Carton (pcs.)
Qty.
(pcs.)
Material
2
200000
Paper
CHECKED
REVISION
DATE (YYYY-MM-DD)
GENERAL TOLERANCE
MHB
001.003
2021-01-18
DIN ISO 2768-1m
PROJECTION
METHOD
DESCRIPTION
Würth Elektronik eiSos GmbH & Co. KG
EMC & Inductive Solutions
Max-Eyth-Str. 1
74638 Waldenburg
Germany
Tel. +49 (0) 79 42 945 - 0
www.we-online.com
eiSos@we-online.com
WE-MPSB EMI Multilayer Power
Suppression Bead
ORDER CODE
74279228111
SIZE/TYPE
BUSINESS UNIT
STATUS
PAGE
0603
eiSos
Valid
7/10
This electronic component has been designed and developed for usage in general electronic equipment only. This product is not authorized for use in equipment where a higher safety standard and reliability standard is especially required or where a failure of the product is reasonably expected to cause severe personal injury or death, unless the parties have executed an agreement specifically governing such use. Moreover Würth Elektronik eiSos GmbH
& Co KG products are neither designed nor intended for use in areas such as military, aerospace, aviation, nuclear control, submarine, transportation (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network etc.. Würth Elektronik eiSos GmbH & Co KG must be informed about the intent of such usage before the design-in stage. In addition, sufficient reliability evaluation checks for safety
must be performed on every electronic component which is used in electrical circuits that require high safety and reliability functions or performance.
Classification Reflow Profile for SMT components:
Classification Reflow Soldering Profile:
Profile Feature
Tp
tp
Max. Ramp Up Rate
Max. Ramp Down Rate
TL
Temperature
Ts max
Ts min
Ts min 150 °C
Preheat Temperature Max
Ts max 200 °C
Preheat Time ts from Ts min to Ts max
ts
Ramp-up Rate (TL to TP)
Liquidous Temperature
tL
Preheat Area
TC –5°C
Value
Preheat Temperature Min
60 - 120 seconds
3 °C/ second max.
TL
217 °C
Time tL maintained above TL
tL
60 - 150 seconds
Peak package body temperature
Tp
Tp ≤ Tc, see Table below
Time within 5°C of actual peak
temperature
tp
20 - 30 seconds
Ramp-down Rate (TP to TL)
6 °C/ second max.
Time 25°C to peak temperature
8 minutes max.
refer to IPC/ JEDEC J-STD-020E
tS
Package Classification Reflow Temperature (Tc):
Volume mm³
350-2000
Volume mm³
>2000
PB-Free Assembly | Package Thickness 260 °C
< 1.6 mm
260 °C
260 °C
PB-Free Assembly | Package Thickness 260 °C
1.6 mm - 2.5 mm
250 °C
245 °C
PB-Free Assembly | Package Thickness 250 °C
> 2.5 mm
245 °C
245 °C
Properties
25
Time 25°C to Peak
Time
Volume mm³
