Wireless Module BluetoothⓇ low energy Module Overview Dec. 9, 2016 Version 1.4 Taiyo Yuden BluetoothⓇ low energy Module Line-Up Taiyo Yuden BluetoothⓇ low energy Module nRF52832 Module EYSHCN Series EYSHJN Series Big Small Embedded antenna Int. 32kHz X’tal Int. LC for DC/DC 9.6 x 12.9 x 2.0 mm EYSHCN ZXZ RAM 64kB SoftDevice S132 Embedded antenna Ext. 32kHz X’tal Ext. LC for DC/DC nRF51422 Module nRF51822 Module EYSGCN Series EYSGJN Series EYAGJN Series 5.1 x 11.3 x 1.3 mm EYSHJN ZXZ RAM 64kB SoftDevice S132 2 Taiyo Yuden BluetoothⓇ low energy Module Line-Up nRF51x22 BluetoothⓇ low energy Module Big Embedded antenna Int. 32kHz X’tal Int. LC for DC/DC Small 9.6 x 12.9 x 2.0 mm 5.1 x 11.3 x 1.3 mm EYSGCN Series Basic EYSGCN EYSGCN ZXX ZWY RAM 16kB RAM 32kB SoftDevice SoftDevice S110 S120 Application Embedded EYSGCN AWY-1X TY’s App Lite GPIO Control EYSGCN AWY-WX Embedded antenna Ext. 32kHz X’tal Ext. LC for DC/DC Basic EYSGJN Series EYAGJN Series Application TY’s App EYAGJN EYSGJN EYSGJN ZXX ZXX ZWY RAM 32kB RAM 16kB RAM 32kB UART Control ANT + BLE SoftDevice SoftDevice S110 S120 SoftDevice S310 Embedded EYSGJN AWY-1X EYSGJN AWY-WX TY’s App Lite GPIO Control TY’s App UART Control 3 Latest Documents for BluetoothⓇ low energy Module EYSHCNZXZ EYSHJNZXZ http://www.yuden.co.jp/or/product/category/module/EYSHCNZXZ.html http://www.yuden.co.jp/or/product/category/module/EYSHJNZXZ.html EYSGCNZXX EYSGCNZWY EYSGJNZXX EYSGJNZWY http://www.yuden.co.jp/or/product/category/module/EYSGCNZXX.html http://www.yuden.co.jp/or/product/category/module/EYSGCNZWY.html http://www.yuden.co.jp/or/product/category/module/EYSGJNZXX.html http://www.yuden.co.jp/or/product/category/module/EYSGJNZWY.html EYAGJNZXX http://www.yuden.co.jp/or/product/category/module/EYAGJNZXX.html EYSGCNAWY-1X EYSGJNAWY-1X http://www.yuden.co.jp/or/product/category/module/EYSGCNAWY-1X.html http://www.yuden.co.jp/or/product/category/module/EYSGJNAWY-1X.html EYSGCNAWY-WX http://www.yuden.co.jp/or/product/category/module/EYSGJNAWY-WX.html EYSGJNAWY-WX http://www.yuden.co.jp/or/product/category/module/EYSGJNAWY-WX.html EYSFCNZXX http://www.yuden.co.jp/or/product/category/module/EYSFCNZXX.html -The documents for the evaluation board and evaluation kit are also available on the above page. - The Japanese documents are available on the following page. http://www.yuden.co.jp/jp/product/category/module/lineup.html#Bluetooth 4 Bluetooth® low energy Module: EYSHCNZXZ Outline •Frequency: 2402 to 2480 MHz with +4dBm Output power •Single power supply: 1.7 – 3.6V •Single Mode Bluetooth low energy Slave/Master (ANTTM Available) •Chip: nRF52832 (Nordic) •Integrated System/Sleep Clock, LC for DC/DC •Integrated high performance ceramic chip antenna •ARM Cortex M4F 32bit processor •512kB Flash and 64kB RAM •Interface: SPI, UART, I2C, I2S, PDM and 12bit ADC •Support NFC-A Type-2 for Touch-to-Pair •Outline: 9.6 x 12.9 x 2.0 mm with 1mm pad pitch •Operating Temperature range: -40 to 85 deg-C •Bluetooth and Japan, FCC, IC qualified Block Diagram •CE Conducted Test Report Available •RoHS compliant / Complete Lead Free Unit: mm 9.6 12.9 Features Top View Bottom View VCC Applications •Cycle computer •Heart rate monitor •Blood pressure monitor •Blood glucose meter •Weighing machine •Thermometer •Mobile accessories •Sports and fitness sensors •Remote controllers / Toys Filter SWD (2) RF+BB I/O ARM Cortex M4F I/O (30) Reset X’tal (32MHz) X’tal (32kHz) GND All specifications are subject to change without notice. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by TAIYO YUDEN CO., LTD. is under license. BluetoothⓇ low energy Module Sample, Evaluation Board / Kit EYSHCNZXZ (Module) Module samples EBSHCNZXZ (EV-B) Evaluation board EKSHCNZXZ (EV-K) Evaluation kit SEGGER J-Link LITE Attached Bluetooth® low energy Module: EYSHJNZXZ •Frequency: 2402 to 2480 MHz with +4dBm Output power •Single power supply: 1.7– 3.6V •Single Mode Bluetooth low energy Slave (ANTTM Available) •Chip: nRF52832 (Nordic) •Integrated System Clock •ARM Cortex M4F 32bit processor •512kB Flash and 64kB RAM •Interface: SPI, UART, I2C, I2S, PDM and 12bit ADC •Support NFC-A Type-2 for Touch-to-Pair •Integrated high performance pattern antenna •Outline: 5.1 x 11.3 x 1.3mm MAX •Operating Temperature range: -40 to 85 deg-C •Bluetooth and Japan, FCC, IC qualified •CE Conducted Test Report Available •RoHS compliant / Complete Lead Free Block Diagram Outline 5.1 Top View Applications •Cycle computer •Heart rate monitor •Blood pressure monitor •Blood glucose meter •Weighing machine •Thermometer •Mobile accessories •Sports and fitness sensors •Remote controllers / Toys Unit: mm 11.3 Features Bottom View VCC DCC Filter RF+BB ARM Cortex M4F X’tal (32MHz) I/O SWD (2) RESET GPIO (15) External 32.768kHz X’tal connectable GND All specifications are subject to change without notice. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by TAIYO YUDEN CO., LTD. is under license. BluetoothⓇ low energy Module Sample, Evaluation Board / Kit EYSHJNZXZ (Module) Module samples EBSHJNZXZ (EV-B) Evaluation board EKSHJNZXZ (EV-K) Evaluation kit SEGGER J-Link LITE Attached Bluetooth® low energy Module: EYSGCNZXX Features Outline 9.6 12.9 •Frequency: 2402 to 2480 MHz •Output power: +4dBm typ. •Single power supply: 1.8 – 3.6V •Single Mode Bluetooth low energy Slave •Chip: nRF51822 Rev.3 (Nordic) •Integrated System/Sleep Clock •Integrated high performance ceramic chip antenna •ARM Cortex M0 32bit processor •256kB Flash and 16kB RAM •Interface: SPI, UART, I2C and 8/9/10bit ADC •Outline: 9.6 x 12.9 x 2.0 mm with 1mm pad pitch •Operating Temperature range: -25 to 75 deg-C •Bluetooth and Japan, FCC, IC qualified Block Diagram •CE Conducted Test Report Available •RoHS compliant / Complete Lead Free Unit: mm Bottom View Top View VCC Applications •Cycle computer •Heart rate monitor •Blood pressure monitor •Blood glucose meter •Weighing machine •Thermometer •Mobile accessories •Sports and fitness sensors •Remote controllers / Toys Filter SWD (2) RF+BB I/O ARM Cortex M0 X’tal (32MHz) X’tal (32kHz) I/O (29) GND All specifications are subject to change without notice. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by TAIYO YUDEN CO., LTD. is under license. Bluetooth® low energy Module: EYSGCNZWY Features Outline 9.6 12.9 •Frequency: 2402 to 2480 MHz •Output power: +4dBm typ. •Single power supply: 1.8 – 3.6V •Single Mode Bluetooth low energy Slave / Master •Chip: nRF51822 Rev.3 (Nordic) •Integrated System/Sleep Clock •Integrated high performance ceramic chip antenna •ARM Cortex M0 32bit processor •256kB Flash and 32kB RAM •Interface: SPI, UART, I2C and 8/9/10bit ADC •Outline: 9.6 x 12.9 x 2.0 mm with 1mm pad pitch •Operating Temperature range: -25 to 75 deg-C •Bluetooth and Japan, FCC, IC qualified Block Diagram •CE Conducted Test Report Available •RoHS compliant / Complete Lead Free Unit: mm Bottom View Top View VCC Applications •Cycle computer •Heart rate monitor •Blood pressure monitor •Blood glucose meter •Weighing machine •Thermometer •Mobile accessories •Sports and fitness sensors •Remote controllers / Toys Filter SWD (2) RF+BB I/O ARM Cortex M0 X’tal (32MHz) X’tal (32kHz) I/O (29) GND All specifications are subject to change without notice. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by TAIYO YUDEN CO., LTD. is under license. BluetoothⓇ low energy Module Sample, Evaluation Board / Kit EYSGCNZXX, EYSGCNZWY EBSGCNZWY (EV-B) EKSGCNZWY (EV-K) (Module) Module samples Evaluation board Evaluation kit SEGGER J-Link LITE Attached Bluetooth® low energy Module EYSGJNZXX Outline •Frequency: 2402 to 2480 MHz •Output power: +4dBm typ. •Single power supply: 1.8 – 3.6V •Single Mode Bluetooth low energy Slave •Chip: nRF51822 Rev.3 (Nordic) •Integrated System Clock •ARM Cortex M0 32bit processor •256kB Flash and 16kB RAM •Interface: SPI, UART, I2C and 8/9/10bit ADC •Integrated high performance pattern antenna •Outline: 5.1 x 11.3 x 1.3mm MAX •Operating Temperature range: -25 to 75 deg-C •Bluetooth and Japan, FCC, IC qualified •CE Conducted Test Report Available •RoHS compliant / Complete Lead Free Block Diagram 5.1 Top View Applications •Cycle computer •Heart rate monitor •Blood pressure monitor •Blood glucose meter •Weighing machine •Thermometer •Mobile accessories •Sports and fitness sensors •Remote controllers / Toys Unit: mm 11.3 Features Bottom View VCC AVDD DCC Filter RF+BB ARM Cortex M0 X’tal (32MHz) I/O SWD (2) GPIO (14) External 32.768kHz X’tal connectable GND All specifications are subject to change without notice. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by TAIYO YUDEN CO., LTD. is under license. Bluetooth® low energy Module EYSGJNZWY Outline •Frequency: 2402 to 2480 MHz •Output power: +4dBm typ. •Single power supply: 1.8 – 3.6V •Single Mode Bluetooth low energy Slave / Master •Chip: nRF51822 Rev.3 (Nordic) •Integrated System Clock •ARM Cortex M0 32bit processor •256kB Flash and 32kB RAM •Interface: SPI, UART, I2C and 8/9/10bit ADC •Integrated high performance pattern antenna •Outline: 5.1 x 11.3 x 1.3mm MAX •Operating Temperature range: -25 to 75 deg-C •Bluetooth and Japan, FCC, IC qualified •CE Conducted Test Report Available •RoHS compliant / Complete Lead Free Block Diagram 5.1 Top View Applications •Cycle computer •Heart rate monitor •Blood pressure monitor •Blood glucose meter •Weighing machine •Thermometer •Mobile accessories •Sports and fitness sensors •Remote controllers / Toys Unit: mm 11.3 Features Bottom View VCC AVDD DCC Filter RF+BB ARM Cortex M0 X’tal (32MHz) I/O SWD (2) GPIO (14) External 32.768kHz X’tal connectable GND All specifications are subject to change without notice. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by TAIYO YUDEN CO., LTD. is under license. ANT + Bluetooth® low energy Module EYAGJNZXX Outline •Frequency: 2402 to 2480 MHz •Output power: +4dBm typ. •Single power supply: 1.8 – 3.6V •ANT + Single Mode Bluetooth low energy Slave •Chip: nRF51422 Rev 3 (Nordic) •Integrated System Clock •ARM Cortex M0 32bit processor •256kB Flash and 32kB RAM •Interface: SPI, UART, I2C and 8/9/10bit ADC •Integrated high performance pattern antenna •Outline: 5.1 x 11.3 x 1.3mm MAX •Operating Temperature range: -25 to 75 deg-C •Bluetooth and Japan, FCC, IC qualified •CE Conducted Test Report Available •RoHS compliant / Complete Lead Free Block Diagram 5.1 Top View Applications •Cycle computer •Heart rate monitor •Blood pressure monitor •Blood glucose meter •Weighing machine •Thermometer •Mobile accessories •Sports and fitness sensors •Remote controllers / Toys Unit: mm 11.3 Features Bottom View VCC AVDD DCC Filter RF+BB ARM Cortex M0 X’tal (32MHz) I/O SWD (2) GPIO (14) External 32.768kHz X’tal connectable GND All specifications are subject to change without notice. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by TAIYO YUDEN CO., LTD. is under license. BluetoothⓇ low energy Module Sample, Evaluation Board / Kit EYSGJNZXX, EYSGJNZWY, EYAGJNZXX (Module) Module samples EBSGJNZWY, EBAGJNZXX EKSGJNZWY, EKAGJNZXX (EV-B) (EV-K) Evaluation board Evaluation kit SEGGER J-Link LITE Attached Application Layer image for Basic Module BluetoothⓇ low energy Device Power Management nRF51822, 422 module Application (Profiles) Switch Sensors Clock LED Temperature Sensor Power Regulator 32MHz X’tal Generic Attribute Server Generic Attribute Client SM ATT L2CAP •Alert Notification Nordic SDK •Blood Pressure •Cycling Speed and Cadence •Glucose •HID Mouse •Heart Rate •Phone Alert Status •Proximity •Running Speed and Cadence •Time Basic module will be written under GATT. LL Data 32kHz X’tal (EYSGCN) PHY Antenna EYSGCN, EYSGJN, EYAGJN Basic Module DTM Softdevice GAP: SM: ATT: L2CAP: LL: PHY: DTM: Generic Access Profile Security Manager Attribute Protocol Logical Link Control and Adaptation Protocol Link Layer Physical Layer Direct Test Mode Bluetooth® low energy Module: EYSGCNAWY-1X Features Outline Unit: mm 12.9 •Frequency: 2402 to 2480 MHz 9.6 •Output power: +4dBm typ. •Single power supply: 1.8 – 3.6V •Single Mode Bluetooth low energy Slave / Master •Chip: nRF51822 (Nordic) •Integrated System/Sleep Clock •Integrated high performance ceramic chip antenna •ARM Cortex M0 32bit processor •Application Embedded by Taiyo Yuden • (TY’s App Lite Generic Data transfer, Battery Service) •Interface: UART •Outline: 9.6 x 12.9 x 2.0 mm with 1mm pad pitch Top View •Operating Temperature range: -25 to 75 deg-C Block Diagram •Bluetooth and Japan, FCC, IC qualified •CE Conducted Test Report Available •RoHS compliant / Complete Lead Free Bottom View VCC Applications •Cycle computer •Heart rate monitor •Blood pressure monitor •Blood glucose meter •Weighing machine •Thermometer •Mobile accessories •Sports and fitness sensors •Remote controllers / Toys Filter UART (4) RF+BB I/O ARM Cortex M0 X’tal (32MHz) X’tal (32kHz) Control (8) GND All specifications are subject to change without notice. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by TAIYO YUDEN CO., LTD. is under license. BluetoothⓇ low energy Module Sample, Evaluation Board EYSGCNAWY-1X (Module) Module samples EBSGCNAWY-1X (EV-B) Evaluation board Bluetooth® low energy Module EYSGJNAWY-1X Outline •Frequency: 2402 to 2480 MHz •Output power: +4dBm typ. •Single power supply: 1.8 – 3.6V •Single Mode Bluetooth low energy Slave / Master •Chip: nRF51822 Rev3 (Nordic) •Integrated System Clock •ARM Cortex M0 32bit processor •Application Embedded by Taiyo Yuden • (TY’s App : Generic Data transfer, Battery Service) •Interface: UART •Integrated high performance pattern antenna •Outline: 5.1 x 11.3 x 1.3mm MAX •Operating Temperature range: -25 to 75 deg-C •Bluetooth and Japan, FCC, IC qualified •CE Conducted Test Report Available Block Diagram •RoHS compliant / Complete Lead Free Top View Bottom View VCC AVDD Applications •Cycle computer •Heart rate monitor •Blood pressure monitor •Blood glucose meter •Weighing machine •Thermometer •Mobile accessories •Sports and fitness sensors •Remote controllers / Toys Unit: mm 5.1 11.3 Features DCC Filter RF+BB ARM Cortex M0 I/O UART (4) Control (8) External 32.768kHz X’tal connectable X’tal (32MHz) GND All specifications are subject to change without notice. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by TAIYO YUDEN CO., LTD. is under license. BluetoothⓇ low energy Module Sample, Evaluation Board EYSGJNAWY-1X (Module) Module samples EBSGJNAWY-1X (EV-B) Evaluation board Bluetooth® low energy Module: EYSGCNAWY-WX Features Outline Unit: mm 12.9 •Frequency: 2402 to 2480 MHz 9.6 •Output power: +4dBm typ. •Single power supply: 1.8 – 3.6V •Single Mode Bluetooth low energy Slave / Master •Chip: nRF51822 (Nordic) •Integrated System/Sleep Clock •Integrated high performance ceramic chip antenna •ARM Cortex M0 32bit processor •Application Embedded by Taiyo Yuden • (TY’s App : Generic Data transfer, Battery Service) •Interface: UART •Outline: 9.6 x 12.9 x 2.0 mm with 1mm pad pitch Top View •Operating Temperature range: -25 to 75 deg-C Block Diagram •Bluetooth and Japan, FCC, IC qualified •CE Conducted Test Report Available •RoHS compliant / Complete Lead Free Bottom View VCC Applications •Cycle computer •Heart rate monitor •Blood pressure monitor •Blood glucose meter •Weighing machine •Thermometer •Mobile accessories •Sports and fitness sensors •Remote controllers / Toys Filter UART (4) RF+BB I/O ARM Cortex M0 X’tal (32MHz) X’tal (32kHz) Control (8) GND All specifications are subject to change without notice. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by TAIYO YUDEN CO., LTD. is under license. BluetoothⓇ low energy Module Sample, Evaluation Board EYSGCNAWY-WX (Module) EBSGCNAWY-WX (EV-B) Module samples Evaluation board Bluetooth® low energy Module EYSGJNAWY-WX Outline •Frequency: 2402 to 2480 MHz •Output power: +4dBm typ. •Single power supply: 1.8 – 3.6V •Single Mode Bluetooth low energy Slave / Master •Chip: nRF51822 Rev3 (Nordic) •Integrated System Clock •ARM Cortex M0 32bit processor •Application Embedded by Taiyo Yuden • (TY’s App : Generic Data transfer, Battery Service) •Interface: UART •Integrated high performance pattern antenna •Outline: 5.1 x 11.3 x 1.3mm MAX •Operating Temperature range: -25 to 75 deg-C •Bluetooth and Japan, FCC, IC qualified •CE Conducted Test Report Available Block Diagram •RoHS compliant / Complete Lead Free 5.1 Top View Bottom View VCC AVDD Applications •Cycle computer •Heart rate monitor •Blood pressure monitor •Blood glucose meter •Weighing machine •Thermometer •Mobile accessories •Sports and fitness sensors •Remote controllers / Toys Unit: mm 11.3 Features DCC Filter RF+BB ARM Cortex M0 I/O UART (4) Control (8) External 32.768kHz X’tal connectable X’tal (32MHz) GND All specifications are subject to change without notice. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by TAIYO YUDEN CO., LTD. is under license. BluetoothⓇ low energy Module Sample, Evaluation Board EYSGJNAWY-WX (Module) Module samples EBSGJNAWY-WX (EV-B) Evaluation board Application Layer image for Application Embedded Module BluetoothⓇ low energy Device Nordic SDK Connection option Power Management -1X module for nRF51822 module Application Switch Sensors Clock LED Power Regulator 32MHz X’tal Module - Module only Generic Attribute Server Generic Attribute Client -WX module for SM ATT Module – Module L2CAP Module – Smart phone LL Data 32kHz X’tal (EYSGCN) PHY DTM Antenna EYSGCN, EYSGJN Application Embedded Module Softdevice GAP: SM: ATT: L2CAP: LL: PHY: DTM: Generic Access Profile Security Manager Attribute Protocol Logical Link Control and Adaptation Protocol Link Layer Physical Layer Direct Test Mode Bluetooth® low energy standard module ANTTM Support Type Part No. Size (LxWxH) High Performance Basic EYSHCNZXZ 9.6x12.9 X2.0mm ✔ 64kB EYSHJNZXZ 5.1x11.3 X1.3mm ✔ 64kB EYSGCNZXX Basic (Software Support : Nordic) EYSGCNZWY I/F UART SPI I2C 9.6x12.9 x2.0mm EYSGJNZXX EYSGJNZWY RAM Certification Temperature -40~+85 deg-C 16kB 32kB 16kB 5.1x11.3 x1.3mm EYAGJNZXX Application Embedded Module – Module (Software Support : Taiyo Yuden) Application Embedded Module – Smart phone (Software Support : Taiyo Yuden) Specification EYSGCNAWY-1X 9.6x12.9 x2.0mm EYSGJNAWY-1X 5.1x11.3 x1.3mm Bluetooth V4.2 BLE Single Slave/ Master 32kB ✔ 32kB UART EYSGCNAWY-WX 9.6x12.9 x2.0mm EYSGJNAWY-WX 5.1x11.3 x1.3mm Japan FCC IC (CE)※ -25~+75 deg-C N/A ※ CE conducted test report available 26
