FAS-16-17

Internal Connectors Specifications Insulation Resistance: Withstanding Voltage: Contact Resistance: Current Rating: Operating Temp. Range: Series FAS MIL Std. IDC Type Socket, (2.54mm Pitch) Part Number (Details) 1,000MΩ min. at 500V DC 700V ACrms for 1 minute 30mΩ max. at 10mA 1A –20°C to +105°C FAS Series (socket) No. of Leads - 3401 - 2 2 01 - * - 0 * F Materials and Finish Housing: PBT, glass filled UL 94V-0 rated Contacts: Phosphor Bronze Plating: Contacts - Au over Ni IDC Terminals - Flash Au over Nickel Housing Type: 2 = MIL std. key (with central key) Pressure Cover Type: 1 = Open End 2 = Closed End Strain Relief Features  2.54 mm contact pitch connectors for 50 MIL standard flat cables  Variations include latch header plugs, box header plugs, and flat cable sockets Housing Colour: 1 = Black 2 = Blue (Standard) 0 = Mating Cables (1.27 pitch): AWG 28 Stranded Wire or AWG 30 Solid Wire Contact Plating: A = G old (0.76µm over Ni 2.5~4.5µm) B = G ol d (0.3µm over Ni 2.5~4.5µm) IDC Terminal Plating: F = Flash Au over Ni Jigs and Tools (For FAS / FAP Type)  Hand press: FX-003  Applicable jig: FA-005 Applicable Cables AWG 28 stranded wire, 1.27mm pitch AWG 30 solid wire, 1.27mm pitch (e.g. DK**-*, FLEX-S*, TPFLEX-N*, FS-FLEX-B*, see Section F) Outline Dimensions Contact Details Strain Relief Pressure Cover Socket Cable Connection D-16 Connectors SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER Series FAS MIL Std. IDC Type Socket, (2.54mm Pitch) Part Numbers Part Number No. of Leads A Internal Connectors Standard types see table. For other versions please contact Yamaichi, minimum order quantity may be required B C D E SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER Connectors D-17 2.54mm Board-to-Cable Connectors FAS-1001-2101-2-0AF FAS-1001-2101-2-0BF FAS-1401-2101-2-0AF FAS-1401-2101-2-0BF FAS-1601-2101-2-0AF FAS-1601-2101-2-0BF FAS-1601-2101-2-0BF FAS-2001-2101-2-0AF FAS-2001-2101-2-0BF FAS-2001-2201-2-0AF FAS-2601-2101-1-0BF FAS-2601-2101-2-0AF FAS-2601-2101-2-0BF FAS-2601-2201-2-0AF FAS-3001-2101-2-0BF FAS-3401-2101-1-0BF FAS-3401-2101-2-0AF FAS-3401-2101-2-0BF FAS-4001-2101-1-0BF FAS-4001-2101-2-0AF FAS-4001-2101-2-0BF FAS-4001-2201-2-0AF FAS-5001-2101-2-0AF FAS-5001-2101-2-0BF FAS-6001-2101-2-0AF FAS-6401-2101-1-0BF FAS-6401-2101-2-0AF FAS-6401-2101-2-0BF 10 10 14 14 16 16 16 20 20 20 26 26 26 26 30 34 34 34 40 40 40 40 50 50 60 64 64 64 10.16 10.16 16.16 16.16 17.78 17.78 17.78 22.86 22.86 22.86 30.48 30.48 30.48 30.48 35.56 40.64 40.64 40.64 48.26 48.26 48.26 48.26 60.96 60.96 73.66 78.74 78.74 78.74 17.28 17.28 22.28 22.28 24.90 24.90 24.90 29.98 29.98 29.98 37.60 37.60 37.60 37.60 42.68 47.76 47.76 47.76 55.38 55.38 55.38 55.38 68.08 68.08 80.78 85.86 85.86 85.86 12.86 12.86 17.86 17.86 20.48 20.48 20.48 25.56 25.56 25.56 33.18 33.18 33.18 33.18 38.26 43.34 43.34 43.34 50.96 50.96 50.96 50.96 63.66 63.66 76.36 81.44 81.44 81.44 13.76 13.76 18.72 18.72 21.38 21.38 21.38 26.46 26.46 26.46 34.08 34.08 34.08 34.08 39.16 44.24 44.24 44.24 51.86 51.86 51.86 51.86 64.56 64.56 77.26 82.34 82.34 82.34 15.76 15.76 20.56 20.56 23.38 23.38 23.38 28.46 28.46 28.46 36.08 36.08 36.08 36.08 41.16 46.24 46.24 46.24 53.86 53.86 53.86 53.86 66.56 66.56 79.26 84.34 84.34 84.34 Internal Connectors Specifications Insulation Resistance: Withstanding Voltage: Contact Resistance: Current Rating: Operating Temp. Range: Series FAS IDC - Socket, 2.54mm Pitch (2-Point Contact) Part Number (Details) 1,000MΩ min. at 500V DC 700V ACrms for 1 minute 30mΩ max. at 10mA 1A –20°C to +105°C FAS Series (socket) No. of Leads Center Key - 34 - 17 Materials and Finish Housing: PBT, glass filled UL 94V-0 rated Contacts: Copper Alloy Plating: Contacts - Au 0.3µm over Ni IDC Terminals - Flash Au over Ni Features  2.54mm contact pitch sockets for flat cables with cable-end strain relief Applicable Cables  Variations include latch header plugs (for PC-board connection AWG 28 stranded wire, 1.27mm pitch and IDC) and IDC sockets AWG 30 solid wire, 1.27mm pitch  Two-point contact of the flat cable sockets ensures high reliability (e.g. DK**-*, FLEX-S*, TPFLEX-N*, FS-FLEX-B*, see Section F) Jigs and Tools  Hand press: FX-003  Applicable jig: FA-005 Outline Dimensions Contact Details Standard types see table. For other versions from 10 to 64 leads please contact Yamaichi, minimum order quantity may be required Part Number FAS-16-17 FAS-20-17 No. of Leads 16 20 A 24.90 29.98 B 17.78 22.86 Part Number FAS-26-17 FAS-34-17 No. of Leads 26 34 A 37.60 47.76 B 30.48 40.64 D-18 Connectors SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER
