IC-176-2

IC176 Series Specifications Single Inline Memory Module (SIMM) Part Number (Details) Insulation Resistance: 1,000M W min. at 500V DC Dielectric Withstanding Voltage: 700V AC for 1 minute Contact Resistance: 30m W max. at 10mA/20mV max. Current Rating: 1A max. Operating Temperature Range: –40°C to +150°C Mating Cycles: 10,000 insertions min. IC-176 - 4 - MF Series No. Design Number MF = Flanged Unmarked = Not Flanged Materials and Finish Housing: Polyethersulphone (PES), Polyetherimide (PEI) Contacts: Beryllium Copper (BeCu) Plating: Gold over Nickel Features í Card thickness 1.27mm í Kelvin type contact which utiIizes both sides of the contact system í Easy insertion and extraction by latch Outline Socket Dimensions IC-176-2-** Recommended PC Board Layout Top View from Socket 134.0 1.27 x 35 = 44.45 1.27 6.35 1.27 x 35 = 44.45 A 8.28 5.08 B 144- Æ0.8 2- Æ3.2 C Matching IC Dimensions Pitch 1.8 min 107.95 101.19 Æ3.18 9.14 1.27 12.95 min R- 1.57 10.16 6.35 Component area 2.03 1.27 44.45 6.35 1.04 44.45 Part Number IC-176-4-** IC-176-6-** IC-176-8-** IC-176-2-** IC-176-10-** Pin Count 30 35 64 72 100 Pitch 2.54 2.54 1.27 1.27 1.27 A 100.0 115.0 115.0 125.0 161.4 B 9.0 9.0 15.0 15.0 17.0 C 30.0 30.0 30.0 30.0 30.0 Test & Burn-In SPECIFICATIONS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE – DIMENSIONS IN MILLIMETER 3.17 min 2.79 IC176 Series Single Inline Memory Module (SIMM) IC-176-4-** Recommended PC Board Layout Top View from Socket IC-176-6-** Recommended PC Board Layout Top View from Socket 106.0 2.54 x 29 = 73.66 2.54 2.54 121.0 2.54 x 34 = 86.36 5.08 60- Æ0.8 5.08 2- Æ3.5 70- Æ0.8 2- Æ3.5 Matching IC Dimensions 88.9 82.14 Æ3.18 1.27 Matching IC Dimensions 101.6 94.84 1.8 min Æ3.18 1.27 1.905 2.54 min 1.905 12.94 min R- 1.57 10.16 6.35 Component area R- 1.57 10.16 Component area 6.35 2.03 2.54 73.66 1.778 2.03 2.54 86.36 1.78 IC-176-8-** Recommended PC Board Layout Top View from Socket IC-176-10-** Recommended PC Board Layout Top View from Socket 8.28±0.05 5.08±0.05 1.27 x 31= 39.37 ±0.1 1.27 ±0.05 6.35±0.1 1.27 x 31= 39.37 ±0.1 1.27 ±0.05 8.28±0.05 5.08±0.05 124.0 ±0.1 170.4 ±0.1 1.27 x 49 = 62.23 ±0.1 1.27 ±0.05 6.35±0.1 1.27 x 49 = 62.23 ±0.1 1.27 ±0.05 128- Æ0.8 +0.1 -0 2- Æ3.2 +0.1 -0 200- Æ0.8 +0.1 -0 2- Æ3.2 +0.1 -0 Test & Burn-In SPECIFICATIONS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE – DIMENSIONS IN MILLIMETER 2.54 min
