MBP-10-T1-LL-0

厂商：
YAMAICHI
封装：
描述：
MBP-10-T1-LL-0 - MatchCon - Yamaichi Electronics Co., Ltd.

数据手册：

下载MBP-10-T1-LL-0.pdf

立即购买

详情介绍
数据手册
价格&库存

MBP-10-T1-LL-0 数据手册

Internal Connectors Specifications Insulation Resistance: Withstanding Voltage: Contact Resistance: Current Rating: Voltage Rating: Operating Temp. Range: Series MatchCon 180° Female Box Header w. and w/o Lock, (1.27mm Pitch) TH Part Number (Details) 1,000MΩ min. 500V ACrms for 1 minute 20mΩ max. 1.0A AC/DC 30V AC/DC –40°C to +105°C MBS Series (female) Pin Count - 16 - T 1 - LL - * Termination Type: T = TH 1 = 180° Type Plating: Mating / Termination Area LL = Tin / Tin 1 = with Locking 0 = without Locking Materials and Finish Insulator: High Temperature Plastic UL94V-0 Contacts: Phosphor Bronze Plating: Tin over Nickel (matt finish) Features  1.27mm staggered centre line  Additional positioning spring absorbs relative movements  Air tight connection Outline Dimensions with locking Outline Dimensions without locking PCB Layout Standard Types Part Number MBS-6-T1-LL-* MBS-8-T1-LL-* MBS-10-T1-LL-* MBS-12-T1-LL-* MBS-14-T1-LL-* MBS-16-T1-LL-* Pin Count 6 8 10 12 14 16 A 12.24 14.78 17.32 19.86 22.40 24.94 B 6.35 8.89 11.43 13.97 16.51 19.05 C 8.14 10.68 13.22 15.76 18.30 20.84 D 9.54 12.08 14.62 17.16 19.70 22.24 For the following pin counts are available on request, please contact Yamaichi Part Number MBS-4-T1-LL-* MBS-18-T1-LL-* MBS-20-T1-LL-* MBS-22-T1-LL-* MBS-24-T1-LL-* MBS-26-T1-LL-* Pin Count 4 18 20 22 24 26 A 9.70 27.48 30.02 32.56 35.10 37.64 B 3.81 21.59 24.13 26.67 29.21 31.75 C 5.60 23.38 25.92 28.46 31.00 33.54 D 7.00 24.78 27.32 29.86 32.40 34.94 Trading Division D-50 Connectors SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER Series MatchCon 180° Female Box Header w. and w/o Lock, (1.27mm Pitch) SMT Specifications Insulation Resistance: Withstanding Voltage: Contact Resistance: Current Rating: Voltage Rating: Operating Temp. Range: 1,000MΩ min. 500V ACrms for 1 minute 20mΩ max. 1.0A AC/DC 30V AC/DC –40°C to +105°C Internal Connectors LL * Part Number (Details) MBS Series (female) No. of Pins - 16 - S 1 - Termination Type: S = SMT 1 = 180° Type Plating: Mating / Termination Area LL = Tin / Tin 1 = with Locking 0 = without Locking Materials and Finish Insulator: High Temperature Plastic UL94V-0 Contacts: Phosphor Bronze Plating: Tin over Nickel (matt finish) Features  1.27mm staggered centre line  Additional positioning spring absorbs relative movements  Air tight connection Outline Dimensions with locking Outline Dimensions without locking PCB Layout Standard Types Part Number MBS-6-S1-LL-* MBS-8-S1-LL-* MBS-10-S1-LL-* MBS-12-S1-LL-* MBS-14-S1-LL-* MBS-16-S1-LL-* Pin Count 6 8 10 12 14 16 A 12.24 14.78 17.32 19.86 22.40 24.94 B 6.35 8.89 11.43 13.97 16.51 19.05 C 8.14 10.68 13.22 15.76 18.30 20.84 D 9.54 12.08 14.62 17.16 19.70 22.24 For the following pin counts are available on request, please contact Yamaichi Part Number MBS-4-S1-LL-* MBS-18-S1-LL-* MBS-20-S1-LL-* MBS-22-S1-LL-* MBS-24-S1-LL-* MBS-26-S1-LL-* Trading Division Pin Count 4 18 20 22 24 26 A 9.70 27.48 30.02 32.56 35.10 37.64 B 3.81 21.59 24.13 26.67 29.21 31.75 C 5.60 23.38 25.92 28.46 31.00 33.54 D 7.00 24.78 27.32 29.86 32.40 34.94 Connectors SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER D-51 1.27mm Board-to-Board Connectors Internal Connectors Specifications Insulation Resistance: Withstanding Voltage: Contact Resistance: Current Rating: Voltage Rating: Operating Temp. Range: Series MatchCon 180° Male Box Header, (1.27mm Pitch) TH Part Number (Details) 1,000MΩ min. 500V ACrms for 1 minute 20mΩ max. 1.0A AC/DC 30V AC/DC –40°C to +105°C MBP Series (male) Pin Count - 16 - T1 - LL - 0 Materials and Finish Insulator: High Temperature Plastic UL94V-0 Contacts: Phosphor Bronze Plating: Tin over Nickel (matt finish) Termination Type: T1 = TH (180° ) Plating: Mating / Termination Area LL = Tin / Tin 0 = Without Locking Features  1.27mm staggered centre line  Additional positioning spring absorbs relative movements  Air tight connection Outline Dimensions 180° PCB Layout Standard Types Part Number MBP-6-T1-LL-0 MBP-8-T1-LL-0 MBP-10-T1-LL-0 MBP-12-T1-LL-0 MBP-14-T1-LL-0 MBP-16-T1-LL-0 Pin Count 6 8 10 12 14 16 A 9.74 12.28 14.82 17.36 19.90 22.44 B 5.08 7.62 10.16 12.70 15.24 17.78 For the following pin counts are available on request, please contact Yamaichi Part Number MBP-4-T1-LL-0 MBP-18-T1-LL-0 MBP-20-T1-LL-0 MBP-22-T1-LL-0 MBP-24-T1-LL-0 MBP-26-ST1-LL-0* Pin Count 4 18 20 22 24 26 A 7.20 24.98 27.52 30.06 32.60 35.14 B 2.54 20.32 22.86 25.40 27.94 30.48 Trading Division D-52 Connectors SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER Series MatchCon 90° Female Box Header (1.27mm Pitch) TH Specifications Insulation Resistance: Withstanding Voltage: Contact Resistance: Current Rating: Voltage Rating: Operating Temp. Range: 1,000MΩ min. 500V ACrms for 1 minute 20mΩ max. 1.0A AC/DC 30V AC/DC –40°C to +105°C Internal Connectors Part Number (Details) MBS Series (female) Pin Count - 16 - T9 - LL - 0 Materials and Finish Insulator: High Temperature Plastic UL94V-0 Contacts: Phosphor Bronze Plating: Tin over Nickel (matt finish) Termination Type: T9 = TH (90° ) Plating: Mating / Termination Area LL = Tin / Tin 0 = Without Locking Features  1.27mm staggered centre line  Additional positioning spring absorbs relative movements  Air tight connection Outline Dimensions (90°) Standard Types Part Number MBS-6-T9-LL-0 MBS-8-T9-LL-0 MBS-10-T9-LL-0 MBS-12-T9-LL-0 MBS-14-T9-LL-0 MBS-16-T9-LL-0 Pin Count 6 8 10 12 14 16 A 9.74 12.28 14.82 17.36 19.90 22.44 B 5.08 7.62 10.16 12.70 15.24 17.78 For the following pin counts are available on request, please contact Yamaichi Part Number MBS-4-T9-LL-0 MBS-18-T9-LL-0 MBS-20-T9-LL-0 MBS-22-T9-LL-0 MBS-24-T9-LL-0 MBS-26-ST9-LL-0 Trading Division Pin Count 4 18 20 22 24 26 A 7.20 24.98 27.52 30.06 32.60 35.14 B 2.54 20.32 22.86 25.40 27.94 30.48 Connectors SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER D-53 1.27mm Board-to-Board Connectors PCB Layout Internal Connectors Specifications Insulation Resistance: Withstanding Voltage: Contact Resistance: Current Rating: Voltage Rating: Operating Temp. Range: Series MatchCon 90° Male IDC Paddle Type (1.27mm Pitch) TH Part Number (Details) 1,000MΩ min. 500V ACrms for 1 minute 20mΩ max. 1.0A AC/DC 30V AC/DC –40°C to +105°C MCP Series (male) No. of Pins - 16 - T I 9 - LL Materials and Finish Insulator: High Temperature Plastic UL94V-0 Contacts: Phosphor Bronze Plating: Tin over Nickel (matt finish) Termination Type: T = TH I = IDC 9 = 90° Type Plating: Mating / Termination Area LL = Tin / Tin Features  1.27mm staggered centre line  Additional positioning spring absorbs relative movements  Air tight connection Applicable Cables AWG 27 stranded wire, 1.27mm pitch (e.g. DK**-*, see Section F) Outline Dimensions (TH 90°) PCB Layout Standard Types Part Number MCP-6-TI9-LL MCP-8-TI9-LL MCP-10-TI9-LL MCP-12-TI9-LL MCP-14-TI9-LL MCP-16-TI9-LL Pin Count 6 8 10 12 14 16 A 10.99 13.53 16.07 18.61 21.15 23.69 B 5.08 7.62 10.16 12.70 15.24 17.78 For the followiing pin counts are available on request, please contact Yamaichi Part Number MCP-4-TI9-LL MCP-18-TI9-LL MCP-20-TI9-LL MCP-22-TI9-LL MCP-24-TI9-LL MCP-26-TI9-LL Pin Count 4 18 20 22 24 26 A 8.45 26.23 28.77 31.31 33.85 36.39 B 2.54 20.32 22.86 25.40 27.94 30.48 Trading Division D-54 Connectors SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER Series MatchCon 90° Male IDC for Flat Cable (1.27mm Pitch) Specifications Insulation Resistance: Withstanding Voltage: Contact Resistance: Current Rating: Voltage Rating: Operating Temp. Range: 1,000MΩ min. 500V ACrms for 1 minute 20mΩ max. 1.0A AC/DC 30V AC/DC –40°C to +105°C Internal Connectors Part Number (Details) MCP Series (male) No. of Pins - 16 - I 9 - LL Materials and Finish Insulator: High Temperature Plastic UL94V-0 Contacts: Phosphor Bronze Plating: Tin over Nickel (matt finish) Termination Type: I = IDC 9 = 90° Type Plating: Mating / Termination Area LL = Tin / Tin Features  1.27mm staggered centre line  Additional positioning spring absorbs relative movements  Air tight connection Applicable Cables AWG 27 stranded wire, 1.27mm pitch (e.g. DK**-*, see Section F) Outline Dimensions (90°) 1.27mm Board-to-Board Connectors Standard Types Part Number MCP-6-I9-LL MCP-8-I9-LL MCP-10-I9-LL MCP-12-I9-LL MCP-14-I9-LL MCP-16-I9-LL Pin Count 6 8 10 12 14 16 A 10.99 13.53 16.07 18.61 21.15 23.69 B 5.08 7.62 10.16 12.70 15.24 17.78 For the followiing pin counts are available on request, please contact Yamaichi Part Number MCP-4-I9-LL MCP-18-I9-LL MCP-20-I9-LL MCP-22-I9-LL MCP-24-I9-LL MCP-26-I9-LL Trading Division Pin Count 4 18 20 22 24 26 A 8.45 26.23 28.77 31.31 33.85 36.39 B 2.54 20.32 22.86 25.40 27.94 30.48 Connectors SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER D-55

下载 PDF

MBP-10-T1-LL-0

1. 物料型号： - 180° Female Box Header w. and w/o Lock, (1.27mm Pitch) TH - 180° Male Box Header, (1.27mm Pitch) TH - 90° Female Box Header (1.27mm Pitch) TH Connectors - 90° Male IDC Paddle Type (1.27mm Pitch) TH - 90° Male IDC for Flat Cable (1.27mm Pitch) Connectors

2. 器件简介： - 提供了多种角度（180°和90°）和类型的Box Header连接器，包括有锁和无锁版本，以及通过IDC连接的平电缆连接器。

3. 引脚分配： - 文档提供了不同引脚数量的连接器尺寸和布局，例如： - MBS-6-T1-LL- (6引脚) - MBS-16-T1-LL- (16引脚) - MCP-6-TI9-LL (6引脚) - MCP-16-TI9-LL (16引脚)

4. 参数特性： - 绝缘电阻：最小1,000MΩ - 耐压：500V ACrms，持续1分钟 - 接触电阻：最大20mΩ - 电流额定值：1.0A AC/DC - 电压额定值：30V AC/DC - 操作温度范围：-40°C至+105°C

5. 功能详解： - 提供了1.27mm错位中心线、额外定位弹簧吸收相对运动和气密连接等功能。

6. 应用信息： - 适用于需要紧密连接和相对运动吸收的应用场合，如电子设备内部连接。

7. 封装信息： - 绝缘体材料为高温塑料UL94V-0，接触材料为磷青铜，镀层为镍上镀锡（亚光 finish）。
