USB-A-005A-30

I/O Connectors Specifications Insulation Resistance: Current Rating: Voltage Rating: Withstanding Voltage: Contact Resistance: . Series USB-A Universal Serial Bus, Type A - 180° Receptacle (TH) Part Numbers 1000MΩ min. 1A max. per contact 30V ACrms max. 500V AC 30mΩ max. (initial) USB-A-004 *USB-A-004-30 * see Materials and Finish Materials and Finish Housing: Shell: Contacts: Contact Plating: Thermoplastic, glass filled (UL94V-0) Copper Alloy, Nickel Plating Copper Alloy Solder Terminal - Sn over Ni Mating Area - USB-A-004 = Au Flash over Ni - USB-A-004-30 = 30µ“ Au over Ni 180° Through Hole Type Recommended PCB Layout Top View E-4 Connectors SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER Trading Division Series USB-A Universal Serial Bus - 90° Single Port Receptacle (TH) Specifications Insulation Resistance: Current Rating: Voltage Rating: Withstanding Voltage: Contact Resistance: . 1000MΩ min. 1A max. per contact 30V ACrms max. 500V AC 30mΩ max. (initial) I/O Connectors Part Numbers USB-A-005A *USB-A-005A-30 * see Materials and Finish Materials and Finish Housing: Shell: Contacts: Contact Plating: PBT, glass filled (UL94V-0) Copper Alloy, Nickel Plating Copper Alloy Solder Terminal - Sn over Ni Mating Area - USB-A-005A = Au Flash over Ni - USB-A-005A-30 = 30µ“ Au over Ni Vertical Through Hole Type 5.12 1.1 19.3 Recommended PCB Layout ∅0.92 ∅1.35 0.27 2.0 6.0 7.0 ∅2.30 Top View 2.72 5.44 0.73 Trading Division SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER Connectors E-5 USB (Universal Serial Bus and IEEE1394 7.32 12.5 5.72 13.85
