USB-M04-P

Series USB-M Mini USB - 90° Receptacle (4 Pin, SMT) Specifications Insulation Resistance: Current Rating: Voltage Rating: Withstanding Voltage: Contact Resistance: . 1000MΩ at 100 V DC for 1 minute 1A max. per contact 30V ACrms max. 500V AC (rms) for 1 minute 30mΩ max. (initial) I/O Connectors Part Number USB-M04-003 Materials and Finish Housing: Shell: Contacts: Contact Plating: Thermoplastic, glass filled (UL94V-0) Tin over Copper Alloy Copper Alloy Solder area - Solder over Nickel Mating area - Au over Nickel Outline Dimensions SMT Type 12 3 4 Recommended PCB Layout Top View 4 3 2 1 Trading Division SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER Connectors E-17 USB (Universal Serial Bus and IEEE1394 I/O Connectors Specifications Insulation Resistance: Withstanding Voltage: Voltage Rating: Current Rating: Contact Resistance: . Series USB-M Mini USB - Plug (4 Pin Solder Port ) 1000MΩ at 100V DC for 1 minute 500V ACrms for 1 minute 30V AC (rms) max. 1A max. per contact 15mΩ max. (initial) Part Number USB-M04-P Assembly set with plastic cover Note: USB-M04-P is also available in assembled version with moulded strain relief. For more details please contact Yamaichi. Materials and Finish Housing: Shell: Contacts: Contact Plating: Thermoplastic, glass filled (UL94V-0) Tin over Copper Alloy Copper Alloy Solder area - Sn over Nickel Mating area - Au over Nickel Outline Dimensions Plug E-18 Connectors SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER Trading Division
