USB-M05-003

Series USB-M Mini USB - 90° Receptacle (5 Pin SMT) Specifications Insulation Resistance: Current Rating: Voltage Rating: Withstanding Voltage: Contact Resistance: . 100MΩ at 100 V DC for 1 minute 1A max. per contact 100V ACrms max. 500V AC for 1 minute 50mΩ max. at20mV max. / 100mA max. I/O Connectors Part Number USB-M05-003 Materials and Finish Housing: Shell: Contacts: Contact Plating: PA 6T, glass filled (UL94V-0) Copper Alloy, Tin over Cu Copper Alloy Solder area - Tin over Ni Mating area - 30µ“ Au over Ni Features  According to Hi-Speed USB standard, data transmission rate up to 480 Mbit / sec Outline Dimensions SMT Type 1 5 Recommended PCB Layout 1 Top View 5 Trading Division SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER Connectors E-15 USB (Universal Serial Bus and IEEE1394 I/O Connectors Specifications Insulation Resistance: Withstanding Voltage: Voltage Rating: Current Rating: Contact Resistance: . Series USB-M Mini USB - Plug (5 Pin Solder Port ) Part Number 100MΩ at 100 V DC for 1 minute 100V AC for 1 minute 30V ACrms max. 1A max. per contact 30mΩ max. at20mV max. / 100mA max. USB-M05-P Note: USB-M05-P is only available in assembled versions with moulded strain relief. For more details please contact Yamaichi. Materials and Finish Shell: Housing: Contacts: Contact Plating: Ni plated over Copper Thermoplastic, glass filled (UL94V-0) Copper Alloy Mating area - 30µ“ Au over Nickel Photo showing plug without plastic molding Features  Premating contacts to secure data protection when hot plug / unplug  According to Hi-Speed USB standard, data transmission rate up to 480 Mbit / sec Outline Dimensions Plug E-16 Connectors SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER Trading Division
