USB-M08-003A

Series USB-M Mini USB - 90° Receptacle 8 Pin (PCB, SMT Type) Specifications Insulation Resistance: Current Rating: Voltage Rating: Withstanding Voltage: Contact Resistance: 100MΩ at 500 V 0.5A 5V AC 100V AC (rms) for 1 minute 50mΩ max. I/O Connectors Part Number USB-M08-003A Materials and Finish Housing: Shell: Contacts: High Temp. Thermoplastic, glass filled (UL94V-0) Phosphor Bronze Phosphor Bronze, 10µ“ Au over Ni Outline Dimensions Recommended PCB Layout Top View Trading Division SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER Connectors E-13 USB (Universal Serial Bus and IEEE1394 I/O Connectors Specifications Insulation Resistance: Current Rating: Voltage Rating: Withstanding Voltage: Contact Resistance: Series USB-M Mini USB - 180° Plug 8 Pin (Solder Port) Part Number 100MΩ at 500V 0.5A 5V AC 100V AC (rms) for 1 minute 30mΩ max. (initial) USB-M08-P Note: Materials and Finish Housing: Shell: Contacts: Contact Plating: High Temp. Thermoplastic, glass filled (UL94V-0) Steel, 100µ Nickel Plated Phosphor Bronze Solder area - Sn over Ni Mating area - 10µ“ Au over Ni USB-M08-P is also available in assembled version with moulded strain relief. For more details please contact Yamaichi. Features  Assembly version Outline Dimensions E-14 Connectors SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER Trading Division
