RoHS
1N5400G THRU 1N5408G
COMPLIANT
General Purpose Rectifier
Features
● High efficiency
● High current capability
● High reliability
● High surge current capability
● Low power loss
● Glass passivated chip junction
● Solder dip 275 °C max. 7 s, per JESD 22-B106
Typical Applications
For use in general purpose rectification of power
supplies, inverters, converters, and freewheeling diodes for
consumer, and telecommunication.
Mechanical Data
● Package:DO-201AD(DO-27)
Molding compound meets UL 94 V-0 flammability rating,
RoHS-compliant
● Terminals: Tin plated leads, solderable per J-STD002 and JESD22-B102
● Polarity:Color band denotes cathode end
■Maximum Ratings (Ta=25℃ Unless otherwise specified)
PARAMETER
SYMBOL UNIT
1N5400G 1N5401G 1N5402G 1N5404G 1N5406G 1N5407G 1N5408G
1N5400G 1N5401G 1N5402G 1N5404G 1N5406G 1N5407G 1N5408G
Device marking code
Maximum Repetitive Peak Reverse Voltage
VRRM
V
50
100
200
400
600
800
1000
Maximum RMS Voltage
VRMS
V
35
70
140
280
420
560
700
Maximum DC blocking Voltage
VDC
V
50
100
200
400
600
800
1000
IF(AV)
A
IFSM
A
Average Forward Current
@60Hz sine wave, Resistance load, Ta =70℃
Forward Surge Current (Non-repetitive)
@60Hz Half-sine wave,1 cycle, Tj=25℃
Forward Surge Current (Non-repetitive)
@1ms, square wave, 1 cycle, Tj=25℃
3.0
200
400
Current squared time
@1ms≤t8.3≤ms Tj=25℃,Rating of per diode
Typical junction capacitance
@Measured at 1MHz and Applied Reverse
Voltage of 4.0 V.D.C
I2t
A2s
166
Cj
pF
40
Storage Temperature
Tstg
℃
-55 ~ +150
Junction Temperature
Tj
℃
-55 ~ +150
■Electrical Characteristics(Ta=25℃ Unless otherwise specified)
PARAMETER
SYMBOL UNIT
Maximum instantaneous
forward voltage drop per diode
VF
V
Maximum DC reverse current
at rated DC blocking voltage
per diode
IR
μA
TEST CONDITIONS 1N5400G 1N5401G 1N5402G 1N5404G 1N5406G 1N5407G 1N5408G
IF=3.0A
1.0
Tj =25℃
2.5
Tj =125℃
100
1/4
S-A029
Rev.2.3,30-Jan-21
Yangzhou Yangjie Electronic Technology Co., Ltd.
www.21yangjie.com
1N5400G THRU 1N5408G
■Thermal Characteristics (Ta=25℃ Unless otherwise specified)
PARAMETER
SYMBOL
UNIT
Typical Thermal Resistance
RθJ-A
℃/W
1N5400G
1N5401G
1N5402G
1N5404G
1N5406G
1N5407G
1N5408G
30
■Ordering Information (Example)
PREFERED P/N
PACKAGE CODE
UNIT WEIGHT(g)
MINIMUM
PACKAGE(pcs)
INNER BOX
QUANTITY(pcs)
OUTER CARTON
DELIVERY MODE
QUANTITY(pcs)
1N5400G~1N5408G
D1
Approximate 1.05
1250
1250
12500
Tape
1N5400G~1N5408G
C1
Approximate 1.05
250
250
12500
Bulk
■ Characteristics (Typical)
FIG.1: Io-Ta Curve
FIG.2: Forward Surge Current Capability
Peak Forward Surge Current (A)
200
2.4
1.8
1.2
S
Average Forward Output Current (A)
3.0
ingle Phase
Half Wave 60HZ
Resistive or
Inductive Load
0.375''(9.5mm)
Lead Length
0.6
0
50
8.3ms Single Half Sine Wave
JEDEC Method
120
80
40
0
0
0
1
0
160
100
150
1
2
4
20
40
60 80 100
100
Instantaneous Reverse Current (uA)
Instantaneous Forward Current (A)
8 10
FIG.4: Typical Reverse Characteristics
FIG.3: Forward Voltage
100
10
1.0
0.1
0.01
0.6
6
Number of Cycles
Ambient Temperature (℃)
TJ=25℃
Pulse width=300us
1% Duty Cycle
0.8
1.0
1.2
1.4
1.6
1.8
10
Tj=100℃
1.0
0.1
Tj=25℃
0.01
0.001
2.0
Tj=125℃
0
20
Instantaneous Forward Voltage (V)
40
60
80
100
2/4
S-A029
Rev.2.3,30-Jan-21
Yangzhou Yangjie Electronic Technology Co., Ltd.
www.21yangjie.com
1N5400G THRU 1N5408G
■ Outline Dimensions
DO-201AD(DO-27)
DO-201AD(DO-27)
Dim
Min
Max
A
8.50
9.50
B
C
5.00
5.60
25.4
/
D
1.20
1.30
Dimensions in millimeters
3/4
S-A029
Rev.2.3,30-Jan-21
Yangzhou Yangjie Electronic Technology Co., Ltd.
www.21yangjie.com
1N5400G THRU 1N5408G
Disclaimer
The information presented in this document is for reference only. Yangzhou Yangjie Electronic Technology Co., Ltd. reserves the
right to make changes without notice for the specification of the products displayed herein to improve reliability, function or design
or otherwise.
The product listed herein is designed to be used with ordinary electronic equipment or devices, and not designed to be used with
equipment or devices which require high level of reliability and the malfunction of with would directly endanger human life (such as
medical instruments, transportation equipment, aerospace machinery, nuclear-reactor controllers, fuel controllers and other safety
devices), Yangjie or anyone on its behalf, assumes no responsibility or liability for any damages resulting from such improper use
of sale.
This publication supersedes & replaces all information previously supplied. For additional information, please visit our website
http:// www.21yangjie.com , or consult your nearest Yangjie’s sales office for further assistance.
