RoHS
MBR20100CD
COMPLIANT
Schottky Diodes
Pin 3
Features
● High frequency operation
● High purity, high temperature epoxy encapsulation for
enhanced mechanical strength and moisture resistance
● Guard ring for enhanced ruggedness and long term reliability
● Meets MSL level 1, per J-STD-020, LF maximum peak
of 260 °C
Typical Applications
Typical applications are in switching power supplies, converters,
freewheeling diodes, and reverse battery protection.
Mechanical Data
● Package: TO-252
Pin 1
Pin 2
Molding compound meets UL 94 V-0 flammability
rating, RoHS-compliant
● Terminals: Tin plated leads, solderable per J-STD002 and JESD22-B102
● Polarity: As marked
■Maximum Ratings (Ta=25℃ Unless otherwise specified)
PARAMETER
SYMBOL
MBR20100CD
UNIT
MBR20100CD
Device marking code
VRRM
V
100
IO
A
20
IFSM
A
150
I2t
As
94
Storage Temperature
Tstg
℃
-55 ~ +150
Junction Temperature
Tj
℃
-55 ~ +150
Repetitive Peak Reverse Voltage
Average Rectified Output Current
@60Hz sine wave, R-load, Ta=25℃
Surge(Non-repetitive)Forward Current
@60Hz half sine-wave, 1 cycle, Ta=25℃
Current Squared Time
@1ms≤t≤8.3ms Tj=25℃
2
■Electrical Characteristics (Ta=25℃ Unless otherwise specified)
PARAMETER
Maximum instantaneous
forward voltage drop per diode
Maximum DC reverse current
at rated DC blocking voltage
per diode
SYMBOL UNIT
VFM
V
IRRM1
mA
IRRM2
TEST
CONDITIONS
MBR20100CD
IFM=10A
0.9
VRM=VRRM
Tj=25℃
VRM=VRRM
Tj=125℃
0.05
6
■Thermal Characteristics (Ta=25℃ Unless otherwise specified)
PARAMETER
Thermal
Resistance
Between
junction
and case
SYMBOL
UNIT
MBR20100CD
RθJ-C
℃/W
3.0
1/3
S-S1336
Rev. 1.0, 30-Nov-17
Yangzhou Yangjie Electronic Technology Co., Ltd.
www.21yangjie.com
MBR20100CD
■Ordering Information (Example)
PREFERED P/N
UNIT WEIGHT(g)
MINIIMUM
PACKAGE(pcs)
INNER BOX
QUANTITY(pcs)
OUTER CARTON
QUANTITY(pcs)
DELIVERY MODE
MBR20100CD
Approximate 1.9
3000
3000
30000
Reel
■Characteristics (Typical)
FIG2:Surge Forward Current Capability
35.0
175
Peak Forward Surge Current (A)
Average Forward Output Current (A)
FIG1:Io -Tc Curve
30.0
25.0
20.0
15.0
10.0
5.0
0
50
0
125
8.3ms Single
Half Sine-Wave
JEDEC Method
100
75
50
25
150
100
150
1
2
5
Case Temperature(℃)
50
100
FIG.4: Instantaneous Reverse Characteristics
100
100
Instantaneous Reverse Current (mA)
60
Instantaneous Forward Current (A)
20
Number of Cycles
FIG3: Forward Voltage
20
10
5.0
1.0
0.5
0.2
0.1
10
Ta=25℃
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
10
Tj=125℃
1.0
0.1
Tj=25℃
0.01
0.001
Instantaneous Forward Voltage (V)
0
20
40
60
80
100
Percent of Rated Peak Reverse Voltage (%)
2/3
S-S1336
Rev. 1.0, 30-Nov-17
Yangzhou Yangjie Electronic Technology Co., Ltd.
www.21yangjie.com
MBR20100CD
■Outline Dimensions
TO-252
TO-252
A
B
J
I
K
C
H
D
E
M
L
F
G
N
Dimensions in millimeters
Dim
Min
Max
A
6.500
6.700
B
5.100
5.460
C
1.400
1.600
D
6.000
6.200
E
10.000
10.400
F
2.166
2.366
G
0.660
0.860
H
Ф1.100
Ф1.300
I
0.460
0.580
J
2.200
2.400
K
0
0.300
L
0.890
2.290
M
2.730
3.080
N
0.430
0.580
Disclaimer
The information presented in this document is for reference only. Yangzhou Yangjie Electronic Technology Co., Ltd. reserves the
right to make changes without notice for the specification of the products displayed herein to improve reliability, function or design
or otherwise.
The product listed herein is designed to be used with ordinary electronic equipment or devices, and not designed to be used with
equipment or devices which require high level of reliability and the malfunction of with would directly endanger human life (such as
medical instruments, transportation equipment, aerospace machinery, nuclear-reactor controllers, fuel controllers and other safety
devices), Yangjie or anyone on its behalf, assumes no responsibility or liability for any damages resulting from such improper use
of sale.
This publication supersedes & replaces all information previously supplied. For additional information, please visit our website
http:// www.21yangjie.com , or consult your nearest Yangjie’s sales office for further assistance.
3/3
S-S1336
Rev. 1.0, 30-Nov-17
Yangzhou Yangjie Electronic Technology Co., Ltd.
www.21yangjie.com
