SR10100L

RoHS SR1040L THRU SR10100L  COMPLIANT Schottky Barrier Rectifier Features ● Guardring for overvoltage protection ● Low forward voltage drop,Low power losses ● High forward surge capability ● High frequency operation ● Solder dip 275 °C max. 7 s, per JESD 22-B106 Typical Applications For use in low voltage high frequency inverters, freewheeling, DC/DC converters, and polarity protection applications. Mechanical Data ● Package: DO-201AD(DO-27) Molding compound meets UL 94 V-0 flammability rating, RoHS-compliant ● Terminals: Tin plated leads, solderable per J-STD-002 and JESD22-B102 ● Polarity: Color band denotes the cathode end　 ■Maximum Ratings (Ta=25℃ Unless otherwise specified） PARAMETER SYMBOL UNIT Device marking code SR1040L SR1060L SR10100L SR1040L SR1060L SR10100L 40 60 100 VRRM V IO A 10.0 Forward Surge Current (Non-repetitive) @60Hz Half-sine wave,1 cycle, Ta=25℃ IFSM A 120 Storage Temperature Tstg ℃ -55 ~+150 Junction Temperature Tj ℃ Repetitive Peak Reverse Voltage Average Rectified Output Current @60Hz sine wave, Resistance load, Ta (FIG.1) -55 ~+125 -55 ~+150 ■Electrical Characteristics（Ta=25℃ Unless otherwise specified） PARAMETER SYMBOL UNIT TEST CONDITIONS Maximum instantaneous forward voltage drop per diode VF V IFM=10.0A Maximum DC reverse current at rated DC blocking voltage per diode IR mA Typical junction capacitance Cj pF SR1040L SR1060L 0.48 0.75 Ta=25℃ 0.2 Ta=100℃ 50 Measured at 1MHz and Applied Reverse Voltage of 4.0 V.D.C 600 SR10100L 700 Note (1) Typical junction capacitance measured at 1MHZ and applied reverse voltage of 4.0 V.D.C. 1/4 S-A984 Rev.1.1,23-May-20 Yangzhou Yangjie Electronic Technology Co., Ltd. www.21yangjie.com SR1040L THRU SR10100L    ■Thermal Characteristics （Ta=25℃ Unless otherwise specified） PARAMETER Thermal Resistance SYMBOL UNIT RθJ-A ℃/W Junction to ambient SR1040L SR1060L SR10100L 10 ■Ordering Information (Example) PREFERED P/N PACKAGE CODE UNIT WEIGHT(g) MINIMUM PACKAGE(pcs) INNER BOX QUANTITY(pcs) OUTER CARTON QUANTITY(pcs) DELIVERY MODE SR1040L~SR10100L D1 Approximate 1.05 1250 1250 12500 Tape SR1040L~SR10100L C1 Approximate 1.05 250 250 12500 Bulk ■ Characteristics(Typical) FIG2:Surge Forward Current Capability FIG.1: Io-Ta Curve Peak Forward Surge Current (A) L 00 01 R1 L-S 60 10 SR 40L R10 SRS 8 140 6 4 S Average Forward Output Current (A) 10 ingle Phase Half Wave 60HZ Resistive or Inductive Load 0.375''(9.5mm) Lead Length 2 100 8.3ms Single Half Sine-Wave JEDEC Method 80 60 40 20 0 1 0 0 1 0 120 50 2 5 150 100 20 50 100 Number of Cycles Ambient Temperature (℃) FIG.3: Forward Voltage FIG.4: Typical Reverse Characteristics 100 20 Instantaneous Reverse Current (mA) 2.0 SR 10 10 0L 4.0 SR 10 60 L SR 10 40 L 10 Instantaneous Forward Current (A) 10 1.0 0.4 0.2 0.1 TJ=25℃ Pulse width=300us 1% Duty Cycle SR10100L SR1040L-SR1060L 10 Tj=100℃ 1.0 0.1 Tj=25℃ 0.01 0.02 0.01 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.001 0.9 Instantaneous Forward Voltage (V) 0 20 40 60 80 100 Percent of Rated Peak Reverse Voltage (%) 2/4 S-A984 Rev.1.1,23-May-20 Yangzhou Yangjie Electronic Technology Co., Ltd. www.21yangjie.com SR1040L THRU SR10100L    ■ Outline Dimensions DO-201AD(DO-27) DO-201AD(DO-27) Dim Min Max A 8.50 9.50 B C 5.00 5.60 25.4 / D 1.2 1.3 Dimensions in millimeters 3/4 S-A984 Rev.1.1,23-May-20 Yangzhou Yangjie Electronic Technology Co., Ltd. www.21yangjie.com SR1040L THRU SR10100L    Disclaimer The information presented in this document is for reference only. Yangzhou Yangjie Electronic Technology Co., Ltd. reserves the right to make changes without notice for the specification of the products displayed herein to improve reliability, function or design or otherwise. The product listed herein is designed to be used with ordinary electronic equipment or devices, and not designed to be used with equipment or devices which require high level of reliability and the malfunction of with would directly endanger human life (such as medical instruments, transportation equipment, aerospace machinery, nuclear-reactor controllers, fuel controllers and other safety devices), Yangjie or anyone on its behalf, assumes no responsibility or liability for any damages resulting from such improper use of sale. This publication supersedes & replaces all information previously supplied. For additional information, please visit our website http:// www.21yangjie.com , or consult your nearest Yangjie’s sales office for further assistance. 4/4 S-A984 Rev.1.1,23-May-20 Yangzhou Yangjie Electronic Technology Co., Ltd. www.21yangjie.com
