ADE-1

Surface Mount Frequency Mixer Level 7 (LO Power +7dBm) Features • • • • • • low conversion loss, 5.0 dB typ. excellent L-R isolation, 55 dB typ. excellent IP3, 15 dBm typ. low profile package aqueous washable protected under US patent 6133525 ADE-1 0.5 to 500 MHz CASE STYLE: CD636 PRICE: $1.99 ea. QTY (100) Applications • VHF/UHF Mixer Electrical Specifications MODEL NO. FREQUENCY (MHz) LO/RF fL- fU ADE-1 0.5-500 IF CONVERSION LOSS (dB) _ x Mid-Band m σ .10 Max. 6.5 LO-RF ISOLATION (dB) M Typ. Min. 55 35 LO-IF ISOLATION (dB) M Typ. Min. 40 25 U Typ. Min. 30 20 Total Range L Max. Typ. Min. 7.8 70 50 L U Typ. Min. Typ. Min. 45 30 65 45 E IP3@ center FACTOR band Typ. (dBm) 15 0.8 DC-500 5.0 1 dB COMP.: +1 dBm typ. L = low range [fL to 10 fL] m = mid band [2fL to fU/2] E= [IP3(dBm)-LO Power(dBm)]/10 M = mid range [10 fL to fU/2] U = upper range [fU/2 to fU] Pin Connections PORT LO RF IF GROUND EXT. ht 6 3 2 1,4,5 Maximum Ratings Operating Temperature Storage Temperature RF Power IF Current -40°C to 85°C -55°C to 100°C 50mW 40mA electrical schematic Outline Drawing Demo Board MCL P/N: TB-03 Suggested PCB Layout (PL-052) Outline Dimensions ( inch ) mm A .280 7.11 B .310 7.87 C .220 5.58 D .100 2.54 E .162 4.11 F .055 1.40 G .100 2.54 ® H .030 0.76 J .030 0.76 K .065 1.65 L wt. .300 grams 7.62 .25 Mini-Circuits INTERNET http://www.minicircuits.com P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 Distribution Centers NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010 ISO 9001 CERTIFIED REV. C M92526 ED-7605/1 ADE-1 WL/TD/CP 040304 Page 1 of 2 ADE-1 Typical Performance Data Frequency RF MHz 0.50 0.80 1.00 5.00 10.00 20.00 40.00 63.25 94.82 100.00 126.39 157.97 221.12 250.00 284.26 347.41 378.98 410.56 470.00 500.00 LO MHz 30.50 30.80 31.00 35.00 40.00 50.00 70.00 93.25 124.82 130.00 156.39 187.97 251.12 280.00 314.26 377.41 408.98 440.56 500.00 530.00 Conversion Loss (dB) LO +7dBm 5.68 5.55 5.35 5.06 4.95 5.02 4.89 4.93 4.99 5.08 4.96 5.11 5.15 5.10 5.20 5.43 5.33 5.54 5.81 5.91 Isolation L-R (dB) LO +7dBm 67.49 67.50 67.51 66.17 65.17 63.50 61.00 58.84 58.00 58.00 56.67 54.16 51.84 53.00 48.33 47.66 47.00 45.50 44.67 43.82 Isolation L-I (dB) LO +7dBm 56.67 56.83 56.67 55.50 54.17 52.17 48.83 46.33 44.34 43.84 42.17 41.16 40.00 38.67 36.50 33.34 30.67 29.17 28.16 28.50 VSWR RF port (:1) LO +7dBm 1.46 1.32 1.29 1.19 1.18 1.17 1.14 1.11 1.08 1.08 1.08 1.10 1.05 1.03 1.04 1.10 1.15 1.17 1.14 1.23 VSWR LO port (:1) LO +7dBm 2.51 2.56 2.56 2.51 2.51 2.56 2.51 2.51 2.56 2.56 2.56 2.51 2.67 2.61 2.67 2.56 2.80 2.80 3.01 3.09 Performance Charts 7.0 CONVERSION LOSS (dB) 6.0 ISOLATION (dB) 5.0 4.0 3.0 2.0 1.0 0.0 0 100 200 300 FREQUENCY (MHz) 400 500 LO=+4 dBm LO=+7 dBm LO=+10 dBm at IF Freq of 30 MHz ADE-1 CONVERSION LOSS 80 70 ADE-1 L-R ISOLATION 70 60 ISOLATION (dB) 50 40 30 20 10 0 0 100 200 300 FREQUENCY (MHz) 400 500 0 100 ADE-1 L-I ISOLATION LO=+4 dBm LO=+7 dBm LO=+10 dBm 60 50 40 30 20 10 0 LO=+4 dBm LO=+7 dBm LO=+10 dBm 200 300 FREQUENCY (MHz) 400 500 ADE-1 RF VSWR 1.6 1.5 1.4 VSWR 1.2 1.1 1.0 0.9 0.8 0 100 200 300 FREQUENCY (MHz) 400 500 LO=+4 dBm LO=+7 dBm LO=+10 dBm VSWR 1.3 4.5 4.0 3.5 2.5 2.0 1.5 1.0 0.5 0 100 LO=+4 dBm 3.0 ADE-1 LO VSWR 3.0 2.5 VSWR 2.0 1.5 1.0 LO=+7 dBm LO=+10 dBm 400 500 0.5 0.0 200 300 FREQUENCY (MHz) 0 100 LO=+4 dBm ADE-1 IF VSWR LO=+7 dBm LO=+10 dBm 400 500 200 300 FREQUENCY (MHz) Mini-Circuits ® INTERNET http://www.minicircuits.com P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 Distribution Centers NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010 ISO 9001 CERTIFIED Page 2 of 2
