CSNP1GCR01-AOW

CSNP1GCR01-AOW Version：V1.0 Apr03, 2021 CSNP1GCR01-AOW Revision History Version Date Description V1.0 03/04/2021 Origin Draft CSNP1GCR01-AOW Contents REVISION HISTORY ......................................................................................................................... I 1. INTRODUCTION ........................................................................................................................... 1 1.1 OVERVIEW.................................................................................................................................. 1 1.2 FEATURES .................................................................................................................................. 1 1.4 BLOCK DIAGRAM ......................................................................................................................... 1 2. PRODUCT SPECIFICATIONS ...................................................................................................... 2 2.1 PIN ASSIGNMENTS (TOP VIEW) .................................................................................................... 2 2.2 PACKAGE DIMENSIONS ................................................................................................................ 2 3. PERFORMANCE .......................................................................................................................... 4 4. DC CHARACTERISTICS .............................................................................................................. 5 5. AC CHARACTERISTICS .............................................................................................................. 6 5.1 BUS TIMING (DEFAULT MODE) ...................................................................................................... 6 5.2 BUS TIMING (HIGH-SPEED MODE) ................................................................................................ 6 6. SDNAND INITIALIZATION ........................................................................................................... 8 7. DATA TRANSFER MODE ............................................................................................................. 9 8. SDNAND REGISTERS ............................................................................................................... 10 8.1 OCR REGISTER ........................................................................................................................ 10 8.2 CID REGISTER .......................................................................................................................... 11 8.3 CSD REGISTER ........................................................................................................................ 11 8.4 RCA REGISTER ......................................................................................................................... 12 8.5 DSR REGISTER......................................................................................................................... 12 8.6 SCR REGISTER......................................................................................................................... 12 9. POWER UP ................................................................................................................................. 14 9.2 POWER UP TIME ....................................................................................................................... 14 9.2.1Power On or Power Cycle ................................................................................................. 14 9.2.2 Power Supply Ramp Up ................................................................................................... 15 10. REFERENCE DESIGN ............................................................................................................. 16 CSNP1GCR01-AOW 1. Introduction 1.1 Overview CSNP1GCR01-AOW is an 1Gb density of embedded storage based on NAND Flash and SD controller. This product has many advantages comparing to raw NAND, it has embedded bad block management, and stronger embedded ECC. Even on abnormal power down it still keep your data safely. CSNP1GCR01-AOW is LGA-8 package. The size is 8mm x 6mm x0.75mm. 1.2 Features l Interface: Standard SD Specification Version 2.0 with 1-I/O and 4-I/O. l Power supply: Vcc = 2.7V - 3.6V l Default mode: Variable clock rate 0 - 25 MHz, up to 12.5 MB/sec interface speed (using 4 parallel data lines) l High-Speed mode: Variable clock rate 0 - 50 MHz, up to 25 MB/sec interface speed (using 4 parallel data lines) l Operating Temperature: -40°C to +85°C l Storage Temperature: -55°C to +125°C l Standby Current：< 250uA l Switch function command supports High-Speed, eCommerce, and future functions l Correction of memory field errors l Content Protection Mechanism - Complies with highest security of SDMI standard. l Password Protection of SDNAND (CMD42 - LOCK_UNLOCK) l Write Protect feature using mechanical switch l Built-in write protection features (permanent and temporary) l Application specific commands l Comfortable erase mechanism 1.4 Block Diagram 1 CSNP1GCR01-AOW 2. Product Specifications 2.1 Pin Assignments (Top View) PIN# SD MODE TYPE1 DESCRIPTION NAME 1 SDD2 I/O/PP 2 3 NAME Data Line [Bit2] SPI MODE TYPE DESCRIPTION RSV Reserved 3 2 CD/SDD3 I/O/PP SDNAND Detect/ Data Line [Bit3] CS I Chip Select (Neg True) 3 SCLK I Clock SCLK I Clock 4 VSS S Supply Voltage Ground VSS S Supply Voltage Ground 5 CMD PP Command/Response DI I Data In 6 SDD0 I/O/PP Data Line [Bit0] DO O/PP Data Out 7 SDD1 I/O/PP Data Line [Bit1] RSV 8 VCC S Supply Voltage VCC Reserved S Supply Voltage 1) S: power supply; I: input; O: output using push-pull drivers; PP: I/O using push-pull drivers; 2) The extended SDD lines (SDD1-SDD3) are input on power up. They start to operate as SDD lines after SET_BUS_WIDTH command. The Host shall keep its own SDD1-SDD3 lines in input mode, as well, while they are not used. It is defined so, in order to keep compatibility to SDNAND. 2.2 Package Dimensions TOP VIEW SIDE VIEW 2 CSNP1GCR01-AOW Common Dimensions Symbol Min Nom Max A 0.65 0.75 0.85 B 1.17 1.27 1.37 C 6.90 7 7.10 D 7.90 8 8.10 E 5.90 6 6.10 F 10.90 11 11.1 H 0.75 0.85 0.95 SDNAND Package Dimensions (unit: mm) 3 Note CSNP1GCR01-AOW 3. Performance Test Item HD Bench (100MB) Crystal Disk Mark (100MB) IO Meter (100MB) Test Metrix H2test Parameter Temperature Test Mode Result Sequential Read (MB/s) 18.4 Sequential Write (MB/s) 4.2 Sequential Read (MB/s) 19.03 Sequential Write (MB/s) 4.4 Random Write (IOPS) 33.54 Random Read (IOPS) 505.25 Sequential Read (MB/s) 20.68 Sequential Write (MB/s) 4.07 Sequential Read (MB/s) 18.9 Sequential Write (MB/s) 4.06 Range Work Model -40°~ 85℃ Storage Model -55°~ 125℃ Work Model 8% to 95%, Non-condensing Storage Model 8% to 95%, Non-condensing Humidity 4 CSNP1GCR01-AOW 4. DC Characteristics Symbol PARAMETER VIL Input low voltage VIH Input high voltage VOL Output low voltage VOH Output high voltage IIN Input leakage current IOUT CONDITIONS MIN IOP Operation current UNITS VSS-0.3 0.25VCC V 0.625VCC VCC+0.3 V 0.125VCC V @VCC_min IOH=100μA 0.75VCC @VCC_min VIN=VCC or 0 current Standby current MAX IOL=100μA Tri-state output leakage ISTBY TYP 3.3V@clock stop 3.3v@50MHz (Write) 3.3v@50MHz (Read) 5 V -10 +/-1 10 μA -10 +/-1 10 μA 180 250 μA 15 50 mA 15 60 mA CSNP1GCR01-AOW 5. AC Characteristics 5.1 Bus Timing (Default Mode) SYMBOL PARAMETER MIN MAX UNIT FSD SD clock frequency 0 25 MHz TWL Clock low time 10 ns TWH Clock high time 10 ns TTLH Clock rise time 10 ns TTHL Clock fall time 10 ns TISU Input setup time 5 ns TIH Input hold time 5 ns TODLY Output delay time 0 14 5.2 Bus Timing (High-speed Mode) 6 ns NOTE CSNP1GCR01-AOW SYMBOL PARAMETER MIN MAX UNIT FSD SD clock frequency 0 25 MHz TWL Clock low time 10 ns TWH Clock high time 10 ns TTLH Clock rise time 10 ns TTHL Clock fall time 10 ns TISU Input setup time 5 ns TIH Input hold time 5 ns TODLY Output delay time 0 TOH Output hold time 2.5 14 ns ns 7 NOTE CSNP1GCR01-AOW 6. SDNAND Initialization After the bus is activated the host starts SDNAND initialization and identification process. The initialization process starts with SD_ SEND_OP_COND (ACMD41) by setting its operational conditions and the HCS bit in the OCR. The HCS (Host Capacity Support) bit set to 1 indicates that the host supports High Capacity SDNAND. The HCS (Host Capacity Support) bit set to 0 indicates that the host does not support High Capacity SDNAND. Receiving of CMD8 expands the ACMD41 function; HCS in the argument and CCS (SDNAND Capacity Status) in the response. HCS is ignored by SDNANDs, which didn’t respond to CMD8. However, the host should set HCS to 0 if the SDNAND returns no response to CMD8. Standard Capacity SDNAND ignores HCS. If HCS is set to 0, High Capacity SDNAND never return ready statue (keep busy bit to 0). The busy bit in the OCR is used by the SDNAND to inform the host that initialization of ACMD41 is completed. Setting the busy bit to 0 indicates that the SDNAND is still initializing. Setting the busy bit to 1 indicates completion of initialization. The host repeatedly issues ACMD41 until the busy bit is set to 1. The SDNAND checks the operational conditions and the HCS bit in the OCR only at the first ACMD41. While repeating ACMD41, the host shall not issue another command except CMD0. If the SDNAND responds to CMD8, the response of ACMD41 includes the CCS field information. CCS is valid when the SDNAND returns ready (the busy bit is set to 1). CCS=1 means that the SDNAND is a High Capacity SDNAND. CCS=0 means that the SDNAND is a Standard Capacity SDNAND. The host performs the same initialization sequence to all of the new SDNANDs in the system. Incompatible SDNANDs are sent into Inactive State. The host then issues the command ALL_SEND_CID (CMD2), to each SDNAND to get its unique SDNAND identification (CID) number. SDNAND that is unidentified (i.e. which is in Ready State) sends its CID number as the response (on the CMD line). After the CID was sent by the SDNAND it goes into Identification State. Thereafter, the host issues CMD3 (SEND_RELATIVE_ADDR) asks the SDNAND to publish a new relative SDNAND address (RCA), which is shorter than CID and which is used to address the SDNAND in the future data transfer mode. Once the RCA is received the SDNAND state changes to the Stand-by State. At this point, if the host wants to assign another RCA number, it can ask the SDNAND to publish a new number by sending another CMD3 command to the SDNAND. The last published RCA is the actual RCA number of the SDNAND. The host repeats the identification process, i.e. the cycles with CMD2 and CMD3 for each SDNAND in the system. SDNAND Initialization and Identification Flow 8 CSNP1GCR01-AOW 7. Data Transfer Mode Until the end of SDNAND Identification Mode the host shall remain at FOD frequency because some SDNAND may have operating frequency restrictions during the SDNAND identification mode. In Data Transfer Mode the host may operate the SDNAND in f PP frequency range. The host issues SEND_CSD (CMD9) to obtain the SDNAND Specific Data (CSD register), e.g. block length, SDNAND storage capacity, etc. The broadcast command SET_DSR (CMD4) configures the driver stages of all identified SDNAND. It programs their DSR registers corresponding to the application bus layout (length) and the number of SDNAND on the bus and the data transfer frequency. The clock rate is also switched from FOD to FPP at that point. SET_DSR command is an option for the SDNAND and the host. SDNAND State Diagram (data transfer mode) 9 CSNP1GCR01-AOW 8. SDNAND Registers Six registers are defined within the SDNAND interface: OCR, CID, CSD, RCA, DSR and SCR. These can be accessed only by corresponding commands. The OCR, CID, CSD and SCR registers carry the SDNAND/content specific information, while the RCA and DSR registers are configuration registers storing actual configuration parameters. In order to enable future extension, The SDNAND shallreturn0inthereserved bits of the registers. Name Width Description CID 128 SDNAND identification number; SDNAND individual number for identification RCA1 16 Relative SDNAND address; local system address of a SDNAND, dynamically suggested by the SDNAND and approved by the host during initialization DSR 16 Driver Stage Register; to configure the SDNAND’s output drivers CSD 128 SDNAND Specific Data; information about the SDNAND operation conditions SCR 64 SD Configuration Register; information about the SDNAND’s Special Features capabilities OCR 32 Operation conditions register. SSR 512 SD Status; information about the SDNAND proprietary features CSR 32 SDNAND Status; information about the SDNAND status SDNAND Registers 8.1 OCR register The32-bit operation conditions register stores the VCC voltage profile of the SDNAND. Additionally, this register includes status information bits. One status bit is set if the SDNAND power up procedure has been finished. This register includes another status bit indicating the SDNAND capacity status after set powerup status bit. The OCR register shall be implemented by the SDNAND. The 32-bit operation conditions register stores the VCC voltage profile of the SDNAND. Bit 7 of OCR is newly defined for Dual Voltage SDNAND and set to0 in default. If a Dual Voltage SDNAND does not receive CMD8, OCR bit 7in the response indicates 0, and the Dual Voltage SDNAND which received CMD8, sets this bit to1. Additionally, this register includes 2 more status information bits. Bit 31 - SDNAND power up status bit, this status bit is set if the SDNAND power up procedure has been finished. Bit30 - SDNAND capacity status bit, this status bit is set to 1 if SDNAND is High Capacity SDNAND.0 indicates that the SDNAND is Standard Capacity SDNAND. The SDNAND Capacity status bit is valid after the SDNAND power up procedure is completed and the SDNAND powerup status bit is set to 1. The Host shall read this status bit to identify a Standard or High Capacity SDNAND. The OCR register shall be implemented by the SDNANDs. Initial Value OCR bit position VCC voltage window 31 SDNAND powerup status bit (busy) 30 SDNAND Capacity Status 29-25 Reserved All ‘0’ 24 Switching to1.8V Accepted (S18A) 0 23 3.6-3.5 1 22 3.5-3.4 1 21 3.4-3.3 1 20 3.3-3.2 1 19 3.2-3.1 1 18 3.1-3.0 1 1Gb “0” = busy “1” = ready “0” =SDNAND “1” = SDHC Memory SDNAND 10 CSNP1GCR01-AOW 17 3.0-2.9 1 16 2.9-2.8 1 15 2.8-2.7 1 14 Reserved 0 13 Reserved 0 12 Reserved 0 11 Reserved 0 10 Reserved 0 9 Reserved 0 8 Reserved 0 7 Reserved for Low Voltage Range 0 6 Reserved 0 5 Reserved 0 4 Reserved 0 3-0 Reserved All ‘0’ 8.2 CID register The SDNAND Identification (CID) register is 128 bits wide. It contains the SDNAND identification information used during the SDNAND identification phase. Every individual Read/Write (RW) SDNAND shall have a unique identification number. The structure of the CID register is defined in the following paragraphs: Initial Value Name Field Width CID-slice Manufacturer ID MID 8 [127:120] 66 OEM/Application ID OID 16 [119:104] 2346 Product name PNM 40 [103:64] CS011 Product revision PRV 8 [63:56] 01 Product serial number PSN 32 [55:24] (a) (Product serial number) Reserved - 4 [23:20] All “0b” Manufacturing date MDT 12 [19:8] (a)(Manufacture date) CRC7 checksum CRC 7 [7:1] (b)(CRC) Not used, always 1 - 1 [0:0] 1b 1Gb 8.3 CSD Register The SDNAND-Specific Data register provides information regarding access to the SDNAND contents. The CSD defines the data format, error correction type, maximum data access time, whether the DSR register can be used, etc. The programmable part of the register (entries marked by W or E, see below) can be changed by CMD27. The types of the entries in the table below are coded as follows: R = readable, W (1) = writable once, W = multiple writable. Name Field Width Value Cell Type CSD-slice CSD structure CSD_STRUCTURE 2 00b R [127:126] Reserved - 6 00 0000b R [125:120] Data read access-time (TAAC) 8 0x7fh R [119:112] Data read access-time in CLK (NSAC) 8 0xffh R [111:104] 11 CSNP1GCR01-AOW Cycles (NSAC*100) Max. data transfer rate (TRAN_SPEED) 8 32h R [103:96] SDNAND command classes CCC 12 0x5b5h R [95:84] Max. read data block length (READ_BL_LEN) 4 0x9h(1001b) R [83:80] Partial blocks for read allowed (READ_BL_PARTIAL) 1 1b R [79:79] Write block misalignment (WRITE_BLK_MISALIGN) 1 0b R [78:78] Read block misalignment (READ_BLK_MISALIGN) 1 0b R [77:77] DSR implemented DSR_IMP 1 0b R [76:76] Reserved - 2 00b R [75:70] Device size C_SIZE 12 0x787h R [69:48] Reserved - 1 0 R [47:47] Erase single block enable (ERASE_BLK_EN) 1 1b R [46:46] Erase sector size (SECTOR_SIZE) 7 0x3fh R [45:39] Write protect group size (WP_GRP_SIZE) 7 0x7fh R [38:32] Write protect group enable (WP_GRP_ENABLE) 1 1b R [31:31] 2 00b R [30:29] Reserved Write speed factor (R2W_FACTOR) 3 011b R [28:26] Max. write data block length (WRITE_BL_LEN) 4 1010b R [25:22] Partial blocks for write allowed (WRITE_BL_PARTIAL) 1 0b R [21:21] Reserved - 5 00000b R [20:16] File format group (FILE_FORMAT_GRP) 1 0b R [15:15] Copy flag (OTP) COPY 1 0b R/W(1) [14:14] Permanent write protection PERM_WRITE_PROTECT 1 0b R/W(1) [13:13] Temporary write protection TMP_WRITE_PROTECT 1 0b R/W [12:12] File format (FILE_FORMAT) 2 00b R [11:10] Reserved - 2 00b R [9:8] CRC CRC 7 0x2eh R/W [7:1] Not used, always’1’ - 1 1b - [0:0] 8.4 RCA register The writable 16-bit relative SDNAND address register carries the SDNAND address that is published by the SDNAND during the SDNAND identification. This address is used for the addressed host-SDNAND communication after the SDNAND identification procedure. The default value of the RCA register is 0x0000. The value 0x0000 is reserved to set all SDNANDs into the Stand-by State with CMD7. 8.5 DSR register The 16-bit driver stage register is described in detail in Chapter 6.5. It can be optionally used to improve the bus performance for extended operating conditions (depending on parameters like bus length, transfer rate or number of SDNANDs). The CSD register carries the information about the DSR register usage. The default value of the DSR register is 0x404. 8.6 SCR register In addition to the CSD register, there is another configuration register named SDNAND Configuration Register (SCR). SCR provides information on the SDNAND's special features that were configured into the given card. The size of SCR register is 64 bits. This register shall be set in the factory by the SDNAND The following table describes the SCR register content. 12 CSNP1GCR01-AOW Description Field Width Cell Type SCR Slice SCR Structure SCR_STRUCTURE 4 R [63:60] SD Memory Card - Spec. Version SD_SPEC 4 R [59:56] DATA_STAT_AFTER_ERASE DATA_STAT_AFTER_ERASE 1 R [55:55] SD Security Support SD_SECURITY 3 R [54:52] DAT Bus widths supported SD_BUS_WIDTHS 4 R [51:48] Reserved - 16 R [47:32] Reserved for manufacturer usage - 32 R [31:0] The SCR Fields SCR_STRUCTURE SCR structure version SD Physical Layer Specification Version 0 SCR version No. 1.0 Version 1.01-2.00 1-15 reserved SCR Register Structure Version 13 CSNP1GCR01-AOW 9. Power Up Power-up Diagram 'Power up time' is defined as voltage rising time from 0 volt to VCC min. 'Supply ramp up time' provides the time that the power is built up to the operating level (Host SupplyVoltage) and the time to wait until the SDNAND can accept the first command, The host shall supply power to the SDNAND so that the voltage is reached to Vcc_min within 250ms andstart to supply at least 74 SD clocks to the SDNAND with keeping CMD line to high. 9.2 Power Up Time Host needs to keep power line level less than 0.5V and more than 1ms before power ramp up. 9.2.1Power On or Power Cycle Followings are requirements for Power on and Power cycle to assure a reliable SDNAND hard reset. (1) Voltage level shall be below 0.5V 14 CSNP1GCR01-AOW (2) Duration shall be at least 1ms. 9.2.2 Power Supply Ramp Up The power ramp up time is defined from 0.5V threshold level up to the operating supply voltage which is stable between VCC (min.) and VCC (max.) and host can supply SDCLK. Followings are recommendation of Power ramp up: (1) Voltage of power ramp up should be monotonic as much as possible. (2) The minimum ramp up time should be 0.1ms. (3) The maximum ramp up time should be 35ms for 2.7-3.6V power supply. When the host shuts down the power, the VCC shall be lowered to less than 0.5Volt for a minimum period of 1ms. During power down, DAT, CMD, and CLK should be disconnected or driven to logical 0 by the host to avoid a situation that the operating current is drawn through the signal lines. If the host needs to change the operating voltage, a power cycle is required. Power cycle means the power is turned off and supplied again. Power cycle is also needed for accessing SDNAND that are already in Inactive State. To create a power cycle the host shall follow the power down description before power up the SDNAND (i.e. the VCC shall be once lowered to less than 0.5Volt for a minimum period of 1ms). 15 CSNP1GCR01-AOW 10. Reference Design Note： RDAT and RCMD (10K~100 kΩ) are pull-up resistors protecting the CMD and the DAT lines against bus floating when SDNAND is in a high-impedance mode. The host shall pull-up all DAT0-3 lines by RDAT, even if the host uses the SDNAND as 1-bit mode only in SD mode. It is recommended to have 2.2uF capacitance on VCC. RCLK reference 0~120 Ω. 16
