KRTB AILMS1
DATASHEET
Micro SIDELED® 3806
KRTB AILMS1
This Micro SIDELED® is a RGB device in an SMT package with
side emission. Due to its low package height it is ideal for applications in limited space
environments and perfect for coupling into lightguides.
Applications
- Access Control & Security
- Material Processing
- Appliances & Tools
- Projection & Display
- Factory Automation
- Robotics
- Home & Building Automation
Features
- Package: SMT package, silicone resin
- Chip technology: Thinfilm / Volume emitter on Sapphire (AlInGaN)
- Typ. Radiation: 120° (Lambertian emitter)
- Color: λdom = 625 nm (● red); λdom = 520 nm (● true green); λdom = 470 nm (● blue)
- Corrosion Robustness Class: 1B
- ESD: 2 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 2)
- Binned in white color: Cx = 0.313, Cy = 0.329 acc to CIE 1931
- Typ. Luminous Intensity @20mA: red = 690 mcd; green = 1749 mcd; blue = 488 mcd
2 | Version 1.5 | 2024-11-27
KRTB AILMS1
DATASHEET
Ordering Information
Type
KRTB AILMS1-5B5C-B1B12
3 | Version 1.5 | 2024-11-27
Ordering Code
Q65113A2872
KRTB AILMS1
DATASHEET
Maximum Ratings
Parameter
Symbol
Values
● red
Values
● true green
Values
● blue
Operating Temperature
Top
min.
max.
-40 °C
85 °C
-40 °C
85 °C
-40 °C
85 °C
Storage Temperature
Tstg
min.
max.
-40 °C
100 °C
-40 °C
100 °C
-40 °C
100 °C
Junction Temperature
Tj
max.
100 °C
100 °C
100 °C
Forward Current
TS = 25 °C
IF
min.
max.
1 mA
30 mA
1 mA
30 mA
1 mA
30 mA
Surge Current
t ≤ 10 µs; D = 0.005 ; TS = 25 °C
IFS
max.
100 mA
100 mA
100 mA
ESD withstand voltage
acc. to ANSI/ESDA/JEDEC JS-001
(HBM, Class 2)
VESD
2 kV
2 kV
2 kV
Notes:
1. The product is not designed for reverse operation.
4 | Version 1.5 | 2024-11-27
KRTB AILMS1
DATASHEET
Characteristics
I F = 20 mA; TS = 25 °C
Parameter
Symbol
Values
● red
Values
● true green
Values
● blue
Dominant Wavelength 1)
λdom
typ.
625 nm
520 nm
470 nm
Spectral bandwidth at 50% Irel,max
∆λ
typ.
15 nm
26 nm
20 nm
Viewing angle at 50% IV
2φ
typ.
120 °
120 °
120 °
Forward Voltage 2)
IF = 20 mA
VF
min.
typ.
max.
1.9 V
2.2 V
2.5 V
2.8 V
3.0 V
3.4 V
2.9 V
3.1 V
3.5 V
Real thermal resistance junction/solderpoint 3)
RthJS real
typ.
max.
160 K / W
200 K / W
190 K / W
220 K / W
210 K / W
250 K / W
Electrical thermal resistance junction/
solderpoint 3)
with optical efficiency of each color
RthJS elec.
typ.
max.
120 K / W
150 K / W
150 K / W
170 K / W
130 K / W
160 K / W
Notes:
1. Efficiency of each color: Red 24%; Green 22%; Blue 39%
5 | Version 1.5 | 2024-11-27
KRTB AILMS1
DATASHEET
Brightness Groups
IF(● red) = 20 mA; IF(● green) = 15 mA; IF(● blue) = 7 mA
Group
Luminous Intensity 4)
IF = f(T); all chips on
min.
Iv
Luminous Intensity 4)
IF = f(T); all chips on
max.
Iv
5B
1800 mcd
2010 mcd
6B
2010 mcd
2240 mcd
7B
2240 mcd
2500 mcd
8B
2500 mcd
2800 mcd
5C
2800 mcd
3150 mcd
6 | Version 1.5 | 2024-11-27
KRTB AILMS1
DATASHEET
Chromaticity Coordinate Groups
IF(● red) = 20 mA; IF(● true green) = 15 mA; IF(● blue) = 7 mA
Chromaticity Coordinate Groups
Group
Cx
Cy
Group
Cx
Cy
Group
Cx
Cy
B1
0.2890
0.3635
B2
0.2830
0.3405
B6
0.3050
0.3405
0.2950
0.3865
0.2890
0.3635
0.3110
0.3635
0.3170
0.3865
0.3110
0.3635
0.3330
0.3635
0.3110
0.3635
0.3050
0.3405
0.3270
0.3405
0.3270
0.3405
0.2770
0.3175
0.2990
0.3175
0.3330
0.3635
0.2830
0.3405
0.3050
0.3405
0.3550
0.3635
0.3050
0.3405
0.3270
0.3405
0.3490
0.3405
0.2990
0.3175
0.3210
0.3175
0.3210
0.3175
0.2710
0.2945
0.2930
0.2945
0.3270
0.3405
0.2770
0.3175
0.2990
0.3175
0.3490
0.3405
0.2990
0.3175
0.3210
0.3175
0.3430
0.3175
0.2930
0.2945
0.3150
0.2945
0.3150
0.2945
0.3110
0.3635
0.3330
0.3635
0.3210
0.3175
0.3170
0.3865
0.3390
0.3865
0.3430
0.3175
0.3390
0.3865
0.3610
0.3865
0.3370
0.2945
0.3330
0.3635
0.3550
0.3635
B10
B11
B12
7 | Version 1.5 | 2024-11-27
B3
B4
B5
B7
B8
B9
KRTB AILMS1
DATASHEET
Group Name on Label
Example: 5B-B1
Brightness
Color Chromaticity
5B
B1
8 | Version 1.5 | 2024-11-27
KRTB AILMS1
DATASHEET
Relative Spectral Emission
5)
Irel = f (λ); IF = 20 mA; TS = 25 °C
Irel
KRTB AILMS1
1,0
: Vλ
: red
: green
: blue
0,8
0,6
0,4
0,2
0,0
350
400
9 | Version 1.5 | 2024-11-27
450
500
550
600
650
700
750
800
λ / nm
KRTB AILMS1
DATASHEET
Radiation Characteristic (horizontal)
5)
Irel = f (φ); TS = 25 °C
Irel
KRTB AILMS1
1,0
:red
:green
:blue
0,8
0,6
0,4
0,2
0,0
-100
-80
-60
-40
-20
0
20
40
60
80
100
ϕ/°
Radiation Characteristic (vertical)
5)
Irel = f (φ); TS = 25 °C
Irel
KRTB AILMS1
1,0
0,8
0,6
: red
: green
: blue
0,4
0,2
0,0
-100
-80
-60
-40
-20
0
20
40
60
80
100
ϕ/°
10 | Version 1.5 | 2024-11-27
KRTB AILMS1
DATASHEET
Forward current
Forward current
5)
IF = f(VF); TS = 25 °C
IF / mA
IF = f(VF); TS = 25 °C
KRTB AILMS1
30
IF / mA
: red
20
20
15
15
10
10
5
5
2,0
2,2
2,4
VF / V
5)
IF = f(VF); TS = 25 °C
IF / mA
: green
25
1
1,7 1,8
KRTB AILMS1
30
: blue
25
20
15
10
5
2,6
2,8
1
2,4
11 | Version 1.5 | 2024-11-27
3,0
3,2 3,3
VF / V
KRTB AILMS1
30
25
Forward current
5)
1
2,2
2,4
2,6
2,8
3,0
3,2
VF / V
5),
6)
Iv/Iv(20 mA) = f(IF); TS = 25 °C
IV(20mA) 1,4
5),
6)
Iv/Iv(15 mA) = f(IF); TS = 25 °C
KRTB AILMS1
IV
Relative Luminous Intensity
30
Relative Luminous Intensity
25
KRTB AILMS1
DATASHEET
KRTB AILMS1
IV
IV(15mA) 1,6
: red
: green
1,4
1,2
1,2
1,0
1,0
0,8
0,8
0,6
0,6
0,4
5),
6)
30
Relative Luminous Intensity
25
IF / mA
Iv/Iv(7 mA) = f(IF); TS = 25 °C
IV
KRTB AILMS1
3,5
IV(7mA)
: blue
3,0
2,5
2,0
1,5
1,0
0,5
20
15
10
5
1
0,0
IF / mA
12 | Version 1.5 | 2024-11-27
20
15
10
1
30
25
15
20
0,0
10
0,0
5
0,2
1
0,2
5
0,4
IF / mA
KRTB AILMS1
DATASHEET
Dominant Wavelength
Dominant Wavelength
5)
λdom = f(IF); TS = 25 °C
λdom = f(IF); TS = 25 °C
KRTB AILMS1
dom / nm
dom / nm
: red
4
5)
KRTB AILMS1
8
: green
6
4
2
2
0
0
-2
-2
-4
IF / mA
Dominant Wavelength
5)
λdom = f(IF); TS = 25 °C
dom / nm
KRTB AILMS1
6
: blue
4
2
0
-2
-4
30
25
20
15
10
5
1
-6
IF / mA
13 | Version 1.5 | 2024-11-27
30
25
20
15
10
5
1
30
25
20
15
10
-6
5
1
-4
IF / mA
KRTB AILMS1
DATASHEET
Forward Voltage
Forward Voltage
5)
ΔVF = VF - VF(25 °C) = f(Tj); IF = 20 mA
∆VF / V
ΔVF = VF - VF(25 °C) = f(Tj); IF = 15 mA
KRTB AILMS1
KRTB AILMS1
0,4
5)
∆VF / V
: red
: green
0,4
0,2
0,2
0,0
0,0
-0,2
-0,2
-40 -20
0
Forward Voltage
5)
20
40
60
80 100
Tj / °C
ΔVF = VF - VF(25 °C) = f(Tj); IF = 7 mA
KRTB AILMS1
∆VF / V
: blue
0,4
0,2
0,0
-0,2
0
20
-40 -20
14 | Version 1.5 | 2024-11-27
40
60
80 100
Tj / °C
-40 -20
0
20
40
60
80 100
Tj / °C
KRTB AILMS1
DATASHEET
Relative Luminous Intensity
5)
Iv/Iv(25 °C) = f(Tj); IF = 20 mA
Iv
Iv(25°C)
1,6
5)
Iv/Iv(25 °C) = f(Tj); IF = 15 mA
KRTB AILMS1
1,8
Relative Luminous Intensity
Iv
Iv(25°C)
: red
KRTB AILMS1
1,4
: green
1,2
1,4
1,0
1,2
1,0
0,8
0,8
0,6
0,6
0,4
0,4
0,2
0,2
0,0
-40 -20
0
20
40
60
Relative Luminous Intensity
80 100
Tj / °C
5)
Iv/Iv(25 °C) = f(Tj); IF = 7 mA
Iv
KRTB AILMS1
1,2
Iv(25°C)
: blue
1,0
0,8
0,6
0,4
0,2
0
20
0,0
-40 -20
15 | Version 1.5 | 2024-11-27
40
60
80 100
Tj / °C
0,0
-40 -20
0
20
40
60
80 100
Tj / °C
KRTB AILMS1
DATASHEET
Dominant Wavelength
Dominant Wavelength
5)
λdom = f(Tj); IF = 20 mA
λdom = f(Tj); IF = 15 mA
KRTB AILMS1
10
dom / nm
5)
dom / nm
: red
KRTB AILMS1
8
: green
6
5
4
2
0
0
-2
-5
-4
-10
-40 -20
-6
0
20
Dominant Wavelength
40
60
80 100
Tj / °C
5)
λdom = f(Tj); IF = 7 mA
dom / nm
KRTB AILMS1
8
: blue
6
4
2
0
-2
-4
0
20
-6
-40 -20
16 | Version 1.5 | 2024-11-27
40
60
80 100
Tj / °C
-40 -20
0
20
40
60
80 100
Tj / °C
KRTB AILMS1
DATASHEET
Max. Permissible Forward Current
3)
IF = f(T); ● red
IF / mA
25
20
20
15
10
15
10
5
5
Don't use below 1 mA
0
20
Don't use below 1 mA
40
60
IF = f(T); ● blue
3)
0
40
60
80
Ts / °C
Max. Permissible Forward Current
all chips on
KRTB AILMS1
IF / mA
30
25
KRTB AILMS1
30
25
20
20
15
15
10
10
5
: red
: blue
: green
5
Don't use below 1 mA
0
20
40
0
20
IF = f(T); all chips on
one chip on
blue
0
80
Ts / °C
Max. Permissible Forward Current
IF / mA
KRTB AILMS1
30
25
green
red
one chip on
KRTB AILMS1
30
0
3)
IF = f(T); ● true green
one chip on
IF / mA
Max. Permissible Forward Current
17 | Version 1.5 | 2024-11-27
Don't use below 1 mA
60
80
Ts / °C
0
0
20
40
60
80
Ts / °C
3)
KRTB AILMS1
DATASHEET
Permissible Pulse Handling Capability
Permissible Pulse Handling Capability
IF = f(tp); D: Duty cycle; TS = 25 °C; ● red
IF = f(tp); D: Duty cycle; TS = 25 °C; ● true green
KRTB AILMS1
KRTB AILMS1
TS = 0°C ... 85°C
IF / A
0,12
0,10
0,08
0,08
: D = 1.0
: D = 0.5
: D = 0.2
: D = 0.1
: D = 0.05
: D = 0.02
: D = 0.01
: D = 0.005
0,06
0,04
10-6 10-5 10-4 10-3 0,01 0,1
1 10
Pulse time / s
Permissible Pulse Handling Capability
IF = f(tp); D: Duty cycle; TS = 25 °C; ● blue
KRTB AILMS1
TS = 0°C ... 63°C
IF / A
0,12
0,10
blue
0,12
0,10
green
red
IF / A
TS = 0°C ... 70°C
0,08
0,06
0,04
10-6 10-5 10-4 10-3 0,01 0,1
18 | Version 1.5 | 2024-11-27
: D = 1.0
: D = 0.5
: D = 0.2
: D = 0.1
: D = 0.05
: D = 0.02
: D = 0.01
: D = 0.005
1 10
Pulse time / s
0,06
0,04
10-6 10-5 10-4 10-3 0,01 0,1
: D = 1.0
: D = 0.5
: D = 0.2
: D = 0.1
: D = 0.05
: D = 0.02
: D = 0.01
: D = 0.005
1 10
Pulse time / s
KRTB AILMS1
DATASHEET
Permissible Pulse Handling Capability
Permissible Pulse Handling Capability
IF = f(tp); D: Duty cycle; TS = 85 °C; ● red
IF = f(tp); D: Duty cycle; TS = 85 °C; ● true green
KRTB AILMS1
KRTB AILMS1
TS = 85°C
IF / A
TS = 85°C
IF / A 0,12
0,12
0,10
0,10
green
red
0,08
0,08
: D = 1.0
: D = 0.5
: D = 0.2
: D = 0.1
: D = 0.05
: D = 0.02
: D = 0.01
: D = 0.005
0,06
0,04
10-6 10-5 10-4 10-3 0,01 0,1
1 10
Pulse time / s
Permissible Pulse Handling Capability
IF = f(tp); D: Duty cycle; TS = 85 °C; ● blue
KRTB AILMS1
TS = 85°C
IF / A 0,12
0,10
blue
0,08
0,06
0,04
0,02
10-6 10-5 10-4 10-3 0,01 0,1
19 | Version 1.5 | 2024-11-27
: D = 1.0
: D = 0.5
: D = 0.2
: D = 0.1
: D = 0.05
: D = 0.02
: D = 0.01
: D = 0.005
1 10
Pulse time / s
0,06
0,04
0,02
10-6 10-5 10-4 10-3 0,01 0,1
: D = 1.0
: D = 0.5
: D = 0.2
: D = 0.1
: D = 0.05
: D = 0.02
: D = 0.01
: D = 0.005
1 10
Pulse time / s
KRTB AILMS1
DATASHEET
Dimensional Drawing
7)
Further Information:
Approximate Weight:
4.7 mg
Corrosion test:
Class: 1B
Test condition: 25°C / 75 % RH / 200ppb SO2, 200ppb NO2, 10ppb H2S,
10ppb Cl2 / 21 days (EN 60068-2-60 (Method 4))
20 | Version 1.5 | 2024-11-27
KRTB AILMS1
DATASHEET
Electrical Internal Circuit
Recommended Solder Pad
7)
For superior solder joint connectivity results we recommend soldering under standard nitrogen atmosphere. Package not
suitable for any kind of wet cleaning or ultrasonic cleaning.
21 | Version 1.5 | 2024-11-27
KRTB AILMS1
DATASHEET
Reflow Soldering Profile
Product complies to MSL Level 3 acc. to JEDEC J-STD-020E
OHA04525
300
˚C
T 250
Tp 245 ˚C
240 ˚C
tP
217 ˚C
200
tL
150
tS
100
50
25 ˚C
0
0
50
100
150
200
250
s 300
t
Profile Feature
Symbol
Pb-Free (SnAgCu) Assembly
Minimum
Recommendation Maximum
Ramp-up rate to preheat*)
25 °C to 150 °C
tS
Time tS
TSmin to TSmax
Ramp-up rate to peak*)
TSmax to TP
Liquidus temperature
60
2
3
100
120
2
3
Unit
K/s
s
K/s
TL
217
Time above liquidus temperature
tL
80
100
s
Peak temperature
TP
245
260
°C
Time within 5 °C of the specified peak
temperature TP - 5 K
tP
20
30
3
6
Ramp-down rate*
TP to 100 °C
10
Time
25 °C to TP
All temperatures refer to the center of the package, measured on the top of the component
* slope calculation DT/Dt: Dt max. 5 s; fulfillment for the whole T-range
22 | Version 1.5 | 2024-11-27
°C
480
s
K/s
s
KRTB AILMS1
DATASHEET
Taping
7)
23 | Version 1.5 | 2024-11-27
KRTB AILMS1
DATASHEET
Tape and Reel
8)
Reel Dimensions
A
180 mm
W
Nmin
12 + 0.3 / - 0.1 mm
24 | Version 1.5 | 2024-11-27
W1
60 mm
W2 max
12.4 + 2 mm
18.4 mm
Pieces per PU
3000
KRTB AILMS1
DATASHEET
Barcode-Product-Label (BPL)
Dry Packing Process and Materials
7)
Moisture-sensitive label or print
L
E
E
V
l
e be
sela
).
k,
H
de
L
If
an
bl r co
ba
(R
id
m
ity
.
H
R
hu
0%
e
e
/6
tiv
˚C
la ared ag
ck
re
fr
30
_
<
in pa
%
k
of
to
90
rs
ea
s
d
).
rs
ou
or
te (p
on
rs
H
de
,
ou
iti
H
an bjec ng
ou rs
co
˚C
72
si
nd
H ou
5
te
48
˚C su es
e
H
co
±
24 6
da
e
y
40 be oc
tim
˚C
e
or
<
ith
tim
ill pr).
or
ct
w
O
w nt
23
tim e
at
lo
or
fa
M TO
F
s
al
tim
at le ˚C at
lo
at
or
e.
P
th
F
l
tic
th va
lo or
ur
O
F lo
s ui
on
be
if: read
en
w
ed
l 4 5
F
m
la
ce eq
id
lo
g, n
oc
l
ve
vi
5a
is
in
or
be
24
de
pr
ve l
6
Le
de ,
nt whe
e
te
co
g:
, w
e
Le ve l
ke
r
ou
se
da
ba ed flo
ur
e
Le ve
m %
ba
e
ba
al
st
ur e
Le
r
en re
ed
e
re> 10
oi
st
e
e
fo
tim
ur
se
al
op
fo
M
se
oi st ur
as
k,
is
or .
33
se
is
M oi st
bed
k,
lo H
an
,
g ph
-0
M oi
in
an in F R ng ar
rbl
D
M
e
ba
T
r
po If bl ith
%
lif
ki r C.
(if
S
is
p.
w
ea r ks
lf
J10 ba to et
th va
Y ea
m
rs
m
_
r w,
<
he
ed
1
ee
te
Y
d, EC
iredicat
S
fte
at
nt
>
1
W Hou
D
A flody
qu In no ire
1.
d
e
ou
4 8
re
reity is
qu/JE
re
2.
bo
e
M
tim
to es id 2b
re C
16
:
e
a)
S
tim
is IP
ic
ed loor
tim e
b) ev Humor
or
e
en
F
tim
lo
or
D
2a king
nc
te
F
op
a)
lo or
3.
b) ba re
F lo
da
e
fe
l 1 2
F
If
al
re
tim ve
l
4.
se
d
l 2a
ve
Le
3
an
ve l
ag
e
Le
e
B
ve
ur
e
Le
at
st
ur
e
Le
D
oi
st
ur e
M
oi
st ur
M
oi st
M oi
M
N
E RS
s
in IV O
IT T
S C
nta
N U
TIO
U coSEND
Ais bUagRMEICO
T E
CThIS
S
d
Barcode label
<
M
RA
OS
Humidity indicator
Barcode label
Please check the HIC immidiately after
bag opening.
Discard if circles overrun.
Avoid metal contact.
Do not eat.
Comparator
check dot
WET
If wet,
examine units, if necessary
bake units
15%
If wet,
examine units, if necessary
bake units
10%
5%
If wet,
parts still adequately dry.
change desiccant
Humidity Indicator
MIL-I-8835
Desiccant
AM
OSR
OHA00539
Moisture-sensitive product is packed in a dry bag containing desiccant and a humidity card according JEDEC-STD-033.
25 | Version 1.5 | 2024-11-27
KRTB AILMS1
DATASHEET
Notes
The evaluation of eye safety occurs according to the standard IEC 62471:2006 (photo biological safety of
lamps and lamp systems). Within the risk grouping system of this IEC standard, the device specified in this
data sheet fall into the class exempt group (exposure time 10000 s). Under real circumstances (for exposure time, conditions of the eye pupils, observation distance), it is assumed that no endangerment to the
eye exists from these devices. As a matter of principle, however, it should be mentioned that intense light
sources have a high secondary exposure potential due to their blinding effect. When looking at bright light
sources (e.g. headlights), temporary reduction in visual acuity and afterimages can occur, leading to irritation, annoyance, visual impairment, and even accidents, depending on the situation.
Subcomponents of this device contain, in addition to other substances, metal filled materials including silver.
Metal filled materials can be affected by environments that contain traces of aggressive substances. Therefore, we recommend that customers minimize device exposure to aggressive substances during storage,
production, and use. Devices that showed visible discoloration when tested using the described tests above
did show no performance deviations within failure limits during the stated test duration. Respective failure
limits are described in the IEC60810.
For further application related information please visit https://ams-osram.com/support/application-notes
26 | Version 1.5 | 2024-11-27
KRTB AILMS1
DATASHEET
Disclaimer
Attention please!
The information describes the type of component and shall not be considered as assured characteristics.
Terms of delivery and rights to change design reserved. Due to technical requirements components may
contain dangerous substances.
For information on the types in question please contact our Sales Organization.
If printed or downloaded, please find the latest version on our website.
Packing
Please use the recycling operators known to you. We can also help you – get in touch with your nearest
sales office. By agreement we will take packing material back, if it is sorted. You must bear the costs of
transport. For packing material that is returned to us unsorted or which we are not obliged to accept, we
shall have to invoice you for any costs incurred.
Product and functional safety devices/applications or medical devices/applications
Our components are not developed, constructed or tested for the application as safety relevant component
or for the application in medical devices.
Our products are not qualified at module and system level for such application.
In case buyer – or customer supplied by buyer – considers using our components in product safety devices/
applications or medical devices/applications, buyer and/or customer has to inform our local sales partner
immediately and we and buyer and /or customer will analyze and coordinate the customer-specific request
between us and buyer and/or customer.
27 | Version 1.5 | 2024-11-27
KRTB AILMS1
DATASHEET
Glossary
1)
Wavelength: Wavelengths are tested at a current pulse duration of 25 ms and a tolerance of ±1 nm.
2)
Forward Voltage: Forward voltages are tested at a current pulse duration of 1 ms and a tolerance of
±0.1 V.
3)
Thermal Resistance: Rth max is based on statistic values (6σ) used for Derating.
4)
Brightness: Brightness groups are tested at a current pulse duration of 25 ms and a tolerance of
±11 %.
5)
Typical Values: Due to the special conditions of the manufacturing processes of semiconductor devices, the typical data or calculated correlations of technical parameters can only reflect statistical figures.
These do not necessarily correspond to the actual parameters of each single product, which could differ from the typical data and calculated correlations or the typical characteristic line. If requested, e.g.
because of technical improvements, these typ. data will be changed without any further notice.
6)
Characteristic curve: In the range where the line of the graph is broken, you must expect higher differences between single devices within one packing unit.
7)
Tolerance of Measure: Unless otherwise noted in drawing, tolerances are specified with ±0.1 and
dimensions are specified in mm.
8)
Tape and Reel: All dimensions and tolerances are specified acc. IEC 60286-3 and specified in mm.
28 | Version 1.5 | 2024-11-27
KRTB AILMS1
DATASHEET
Revision History
Version
Date
Change
1.0
2021-06-02
Initial Version
1.1
2021-07-29
Derating (Diagrams)
1.2
2022-01-11
Dimensional Drawing
Taping
1.3
2022-07-27
New Layout
Applications
1.4
2024-08-15
Maximum Ratings
1.5
2024-11-27
Taping
29 | Version 1.5 | 2024-11-27
KRTB AILMS1
DATASHEET
Published by ams-OSRAM AG
Tobelbader Strasse 30, 8141 Premstaetten, Austria
Phone +43 3136 500-0
ams-osram.com
© All rights reserved
30 | Version 1.5 | 2024-11-27
