Multilayer Chip Inductor for Choke – MCL Series
Operating Temp. : -40℃~+85℃
FEATURES
Monolithic structure for high reliability
Excellent solderability and high heat resistance
No cross coupling due to magnetic shield
High DC bias current due to developed material
Low DC resistance
●
●
●
●
●
APPLICATIONS
●
Choke circuits in DC power line of consumer electronics such as personal computers, mobile phones,
digital cameras, digital video cameras, and music players
PRODUCT IDENTIFICATION
MCL
1608
S
1R0
M
T
①
②
③
④
⑤
⑥
②
①
MCL
③
Type
External Dimensions (L×W) (mm)
Chip Inductor for
Choke
1608 [0603]
1.6×0.8
2012 [0805]
2.0×1.25
Feature Type
S
H
Standard
Ir-Improved
④
Nominal Inductance
Example
Nominal Value
1R0
1.0μH
※R=小数点
⑤
⑥
Inductance Tolerance
M
±20%
N
±30%
T
Packing
Tape & Reel
SHAPE AND DIMENSIONS
Unit: mm [inch]
Type
L
W
T
a
MCL1608
[0603]
1.6±0.15
[.063±.006]
0.8±0.15
[.031±.006]
0.8±0.15
[.031±.006]
0.3±0.2
[.012±.008]
MCL2012
[0805]
Sunlord
2.0 (+0.3, -0.1)
[.079 (+.012, -.004)]
1.25±0.2
[.049±.008]
0.85±0.2
[.033±.008]
1.25±0.2
[.049±.008]
Specifications subject to change without notice. Please check our website for latest information.
0.5±0.3
[.020±.012]
Revised 2016/04/15
Sunlord Industrial Park, Dafuyuan Industrial Zone, Guanlan, Shenzhen, China 518110 Tel: 0086-755-29832660 Fax: 0086-755-82269029 E-Mail: sunlord@sunlordinc.com
SPECIFICATIONS
MCL1608 TYPE
Part Number
Inductance
L Test Freq.
Min. Self-resonant
Frequency
DC
Resistance
Max. Rated
Current
Thickness
Units
μH
MHz
MHz
Ω
mA
mm [inch]
Symbol
MCL1608SR10□T
MCL1608SR22□T
MCL1608SR47□T
MCL1608S1R0□T
MCL1608S2R2□T
MCL1608S4R7□T
MCL1608S100□T
L
0.1
0.22
0.47
1.0
2.2
4.7
10
Freq.
1
1
1
1
1
1
1
S.R.F
240
150
105
75
50
35
20
DCR
0.14±30%
0.27±30%
0.42±30%
0.20±30%
0.40±30%
0.60±30%
0.90±30%
Ir*
700
550
400
190
140
100
50
T
Part Number
Inductance
L Test Freq.
Min. Self-resonant
Frequency
DC
Resistance
Max. Rated
Current
Thickness
Units
μH
MHz
MHz
Ω
mA
mm [inch]
Symbol
MCL2012SR10□T
MCL2012SR22□T
MCL2012SR47□T
MCL2012S1R0□T
MCL2012S2R2□T
MCL2012S4R7□T
MCL2012S100□T
MCL2012H100□T
L
0.1
0.22
0.47
1.0
2.2
4.7
10
10
Freq.
1
1
1
1
1
1
1
1
S.R.F
235
170
125
75
50
25
15
20
DCR
0.07±30%
0.13±30%
0.18±30%
0.20±30%
0.28±30%
0.30±30%
0.50±30%
0.50±30%
Ir*
1000
800
550
300
220
180
60
100
T
0.8±0.15
[.031±.006]
MCL2012 TYPE
0.85±0.2
[.033±.008]
1.25±0.2
[.049±.008]
※□: Please specify the inductance tolerance code (M=±20%, N=±30%);
※*: The rated current is the value of DC current at which the inductance value is dropped within 50% with the application
of DC bias.
Sunlord
Specifications subject to change without notice. Please check our website for latest information.
Revised 2016/04/15
Sunlord Industrial Park, Dafuyuan Industrial Zone, Guanlan, Shenzhen, China 518110 Tel: 0086-755-29832660 Fax: 0086-755-82269029 E-Mail: sunlord@sunlordinc.com
TYPICAL ELECTRICAL CHARACTERISTICS
Inductance vs. Frequency Characteristics
Impedance vs. Frequency Characteristics
2
Inductance vs. DC Current Characteristics
Sunlord
Specifications subject to change without notice. Please check our website for latest information.
Revised 2016/04/15
Sunlord Industrial Park, Dafuyuan Industrial Zone, Guanlan, Shenzhen, China 518110 Tel: 0086-755-29832660 Fax: 0086-755-82269029 E-Mail: sunlord@sunlordinc.com
