ROHS&HF
承 认 书
SPECIFICATION FOR APPROVAL
客户名称:
Customer
品
名:
Part name
规
色码电感器
Axial color code inductor
格:
LGA 0510-XXX X X XX E
Product SPEC
版 本 号:
V1.4
Version
日
期:
2021/10/14
Date
客户
Customer
确认
Approval
检验
审核
Inspector Checker
批准
Approver
制造
Manufacturer
确认
Approval
拟制
审核
批准
Designer Checker Approver
夏少平
贺义勇
张惠霞
1、订货代码 HOW TO ORDER
举例 For example
LGA 0510 — 102
K
A:
B
A
C
D
P
52
E
E
F
G
B:
尺 寸
Dimensions(mm)
产 品 类 别
Product type
LGA
轴向色码电感器
Axial color code inductor
类型
Type
外径 Dmax
体长 Lmax
0510
5.0
10.5
C:
标称电感量
Inductance (μH)
前两位数字为有效数字,后一位数字表示
零的个数。
The first two digits are significant, and the
third digit is number of zeros.
*例如 For example:
100=10μH
101=100μH
5R6=5.6μH
R22=0.22μH
D:
感量偏差
Tolerance
J
5.0%
K
10%
M
20%
F:
E:
编带
Tape&
reel
散包装
Bulk
包装方式
Packaging style
盒带包装
P
Ammo
卷带包装
T
Reel
直脚轴向
F
Axial
直脚成型
L
Straight lead formed
弯脚成型
V
Bent lead formed
弯脚 K 型
VK
Bent lead K formed
编带
Tape&
reel
引脚形式
Lead configuration
编带内距:26mm
26
Tape width:
编带内距:52mm
52
Tape width:
05
07
10
引脚成型
Formed
lead
12
15
17
20
G:
E
空格
Blank
备注
Remark
无铅
Lead Free
含铅
Lead Contained
Page 1 of 7
引脚脚距:5.08mm
Formed lead pitch:
引脚脚距:7.5mm
Formed lead pitch:
引脚脚距:10.0mm
Formed lead pitch:
引脚脚距:12.5mm
Formed lead pitch:
引脚脚距:15.0mm
Formed lead pitch:
引脚脚距:17.5mm
Formed lead pitch:
引脚脚距:20.0mm
Formed lead pitch:
2、外形尺寸 EXTERNAL DIMENSIONS
尺 寸
Body size(mm)
类型
Type
φD≤
L≤
t = t 00.6
φd
H≥
轴向(Axial)
直脚成型(L type)
t 0=12.5;
LGA0510
5.0
10.5
15.0;
17.5;
20.0
0.60
0.05
20
弯脚成型(V type)
Page 2 of 7
弯脚 K 型(VK type)
3、色码标记代号 MARKING
标称电感量
Nominal inductance(μH)
第一色环
1 color zone
第二色环
2 color zone
第三色环
3 color zone
第一数字
1st digit
第二数字
2nd digit
第三数字
3rd digit
0
0
× 100(1)
1
1
× 101(10)
2
2
× 102(100)
3
3
× 103(1000)
4
4
× 104(10000)
5
5
× 105(100000)
6
6
7
7
8
8
9
9
/
/
× 10-1(0.1)
J:±5%
/
/
× 10-2(0.01)
K:±10%
st
黑
Black
棕
Brown
红
Red
橙
Orange
黄
Yellow
绿
Green
蓝
Blue
紫
Purple
灰
Gray
白
White
金
Gold
银
Silver
感量偏差
Tolerance
nd
rd
第四色环
4 color zone
th
M:±20%
*例如 e.g. :
标称电感量及偏差为 22uH,±5%的电感器其色码为:红+红+黑+金;
If nominal inductance & tolerance is22uH,±5%, respectively red+red+black+gold should be marked;
标称电感量及偏差为 1.0uH,±10%的电感器其色码为:棕+黑+金+银;
If nominal inductance & tolerance is 1.0uH,±10%, respectively brown+black+gold+silver should be marked;
标称电感量及偏差为 0.22uH,±20%的电感器其色码为:红+红+银+黑。
If nominal inductance & tolerance is 0.22uH,±20%, respectively red+red+silver+black should be marked.
Page 3 of 7
4. 电性能参数及测试条件 ELECTRICAL CHARACTERISTICS & TEST CONDITIONS
LGA0510 型电感器电性能参数及测试条件
LGA0510 TYPE INDUCTORS ELECTRICAL CHARACTERISTICS & TEST CONDITIONS
LGA0510
类型 Type
电感量
Inductance
(μH)
Q
(min)
直流电阻
RDC
(Ω)max
测试频率
Test frequency
(MHz)
自谐频率
SRF
(MHz)min
额定电流
Rated current
IDC(mA)max
LGA0510-470
47
30
1.22
2.52
6.3
340
LGA0510-101
100
30
1.80
4.8
275
LGA0510-151
150
40
4.20
3.5
175
LGA0510-221
220
50
5.10
3.0
155
LGA0510-331
330
50
6.40
2.6
137
LGA0510-471
470
60
7.70
1.9
126
LGA0510-561
560
50
8.50
1.8
120
LGA0510-681
680
55
9.00
1.5
113
LGA0510-821
820
45
10.5
1.2
105
LGA0510-102
1000
45
14.0
1.0
100
LGA0510-122
1200
40
16.9
0.95
95
LGA0510-152
1500
40
21.6
0.90
90
LGA0510-182
1800
40
24.0
0.85
85
LGA0510-202
2000
40
30.0
0.82
82
LGA0510-222
2200
40
34.7
0.80
80
LGA0510-272
2700
40
40.0
0.75
75
LGA0510-302
3000
40
50.0
0.72
70
LGA0510-332
3300
40
59.5
0.70
62
LGA0510-392
3900
40
66.0
0.65
59
LGA0510-472
4700
40
74.0
0.60
55
LGA0510-562
5600
30
80.0
0.50
40
LGA0510-682
6800
30
85.0
0.45
35
LGA0510-822
8200
30
95.0
0.40
30
LGA0510-103
10000
20
105.0
0.35
25
HM9461
HP42841A
测试仪器
Test equipment
误差
Tolerance
M:
±20%
K:
±10%
J:
±5%
HP4285A
(HP4286A,HP4287A)
0.796
0.252
0.0796
HP4338B
环境温度
18~25℃
Ambient
temperature
环境湿度
45%~75%
Ambient
humidity
特 殊 要 求 的 产 品 可 以 根 据 客 户 要 求 生 产 The products can be customized according to customer
requirement.
Page 4 of 7
5. 可靠性试验项目及要求: ITEM AND REQUIREMENT OF RELIABILITY TEST
项目
Item
性能要求
Specification
试验条件及方法
Test methods and remarks
工作温度范围
1
Operating
temperature range
2
Storage temperature
range
-25~+85℃
储存温度范围
3
外观和外形尺寸
Appearance & dimensions
+5~+35℃
符合产品规范和公差要求
Conformity to the product specification
目测,精度不低于 0.02 ㎜的游标卡尺测量
Eyeball; vernier calliper with precision no lower than 0.02mm
4
L 值、Q 值
Inductance、Q
在规定的允许范围内
Within the specified tolerance
电感量和 Q 值在规定的测试频率下,用 HP4285A 进行测试。
Condition: at specified test frequency.
Test equipment:HP4285A
5
直流电阻
DC resistance
在规定的允许范围内
Within the specified tolerance
测试仪器:HP4338B
Test equipment:HP4338B
6
自谐振频率
Self-resonance
frequency
在规定的允许范围内
Within the specified tolerance
测试仪器:射频/阻抗材料分析仪 HP4291A
Test equipment:HP4291A
7
额定电流
Rated current
在规定的允许范围内
Within the specified tolerance
8
引出端强度
Terminal strength
9
耐焊接热
Resistance to
soldering heat
ΔL/L ≤±5%
ΔQ/Q ≤±20%
焊锡温度: 270±5℃ 浸锡时间:10±1s
恢复时间:1~2 小时
Tin review: 270±5℃ Duration: 10±1s
Recovery: 1~2hours
10
可焊性
Solder ability
引线的表面圆周覆盖率不小于 95%
Leads shall be at least 95% areas covered
with a new solder coating.
焊锡温度: 250±5℃
Tin review: 250±5℃
11
标记耐溶剂性
Resistance to
solvent
标志无可见损伤
There shall be no evidence of damage
溶剂温度:25±5℃ Solvent temperature: 25±5℃
将棉球和样品浸在溶剂中 1min,在样品有标志部位用棉球擦 3 次。
There shall be put the cotton ball and sample steep in
dissolvent 1min, at sample’s notation area brush 10 times,
repeat 3 times
无弧光、击穿或损伤。
There shall be no arc, breakdown or damage.
在外封和引线间施加直流电压 500V,持续 60 秒。
Apply 500VDC between outer coating and terminal for 60sec.
IR≥100MΩ
在外包封和引线间施加直流电压 500V,持续 60 秒。
Apply 500VDC between outer coating and terminal for 60sec.
ΔL/L ≤±5%
ΔQ/Q ≤±20%
以 20℃电感量为基准,在-25℃—+85℃测量电感量
Measurement shall be made at an ambient temp of –25℃—+85℃
reference inductance shall be measured at 20℃.
ΔL/L ≤±10%
ΔQ/Q ≤±30%
温度:85±2℃,试验时间:96 小时
Test temperature:85±2℃,Time:96hours
12
13
14
15
介质耐压
Dielectric Withstanding
Voltage
绝缘电阻
Insulation
resistance
温度特性
Temperature
characteristic
高温试验
High temperature
life test
外观无可见损伤、引线不断
There shall be no evidence of damage during
the test and the lead no breakage.
电感值变化 10%、温升 20℃以内的最大直流电流。
The maximum DC value having inductance within 10% and temperature
increase within 20℃ by the application of DC bias.
拉力:沿轴向施加 2kgf,持续时间:5s
Pull: adding 2kgf down axial Duration: 5s
弯折循环:在靠近端子末端将引线弯折 90 度后还原持续 5s,再向
反方向重复一次为一个循环。重复 2 次
Bucking cycle: buck lead 90°at the end of closing terminal
and then reset keeping 5s, redoing one time at the counter
is one cycle. Repeat two times.
浸锡时间: 2±0.5s
Duration: 2±0.5s
备注:1、如无特别指定时,电性能测试应在常温、常湿中恢复 1~2 小时,然后立即测试。
2、若测试结果有争议时,仲裁试验结果用标准大气条件为:温度:25±1℃,相对湿度
48%~52%,气压:86~106kPa。
Note:1. In the event of no special requirement, the measurement shall be conducted immediately after a
recovery of 1~2 hours under the standard condition.
2. In the event of any dispute, the standard condition for arbitration shall be as follows: 25±1℃ of
temperature, 48%~52% RH and 86~106kPa air pressure.
Page 5 of 7
7. 包装方式 PACKAGING STYLE
●
编带尺寸 Taping dimensions
编带方式
Tape style
编带内距:26
Tape width
编带内距:52
Tape width
单位 UNIT:mm
L
Z
26±1.0
0.8 Max
52
+2.0
-1.0
● 卷带包装尺寸 Tape & reel packaging dimensions
Page 6 of 7
1.2 Max
∣L1-L2∣
1.0 Max
● 盒带包装尺寸 Ammo packaging dimensions
包装盒尺寸 Dimensions of box
A
尺寸
Dimensions(±5mm)
B
C
52
75
85
256
26
50
110
256
盒带包装
Ammo
卷带包装
Tape & reel
散包装
Bulk
1000
2500
1000
编带类型
Tape type
单位 UNIT:mm
包装数量 Packaging quantity
包装方式
Packaging
style
包装数量
Quantity
# 可根据用户需求包装
Packaging according to customer’s requirement
Page 7 of 7
