Plastic-Encapsulate Mosfets
FEATURES
SI2300
Advanced Trench Process Technology
N-Channel MOSFET
High Density Cell Design for Ultra Low On-Resistance
Fully Characterized Avalanche Voltage and Current
Absolute Maximum Ratings (TA=25oC, unless otherwise noted)
Parameter
Symbol
Ratings
Units
Drain-Source Voltage
VDS
20
V
Gate-Source Voltage
VGS
8
V
1.Gate
2.Source
3.Drain
Drain Current (Continuous)
Drain Current (Pulsed)
1
o
ID
6
A
IDM
18
A
Total Power Dissipation @TA=25 C
PD
1.25
W
Maximum Diode Forward Current
IS
1.6
A
Tj, Tstg
-55 to +150
°C
RθJA
140
°C/W
SOT-23
D
Operating Junction and Storage Temperature Range
Thermal Resistance Junction to Ambient (PCB mounted)
2
G
1: Repetitive Rating: Pulse width limited by the maximum junction temperation. 2: 1-in2 2oz Cu PCB board
S
Electrical Characteristics (TA=25°C, unless otherwise noted)
Symbol
Characteristic
Test Conditions
Min.
Typ.
Max.
Unit
• Off Characteristics
BVDSS
Drain-Source Breakdown Voltage
VGS=0V, ID=250uA
20
-
-
V
IDSS
Zero Gate Voltage Drain Current
VDS=20V, VGS=0V
-
-
1
uA
IGSS
Gate-Body Leakage Current
VGS=±8V, VDS=0V
-
-
±100
nA
VDS=VGS, ID=250uA
0.6
0.8
1.2
V
VGS=4.5V, ID=2.8A
-
40
60
VGS=2.5V, ID=2A
-
50
115
VDS=5V, ID=3.6A
-
10
-
S
-
426
-
PF
-
79.5
-
PF
-
56
-
PF
•On Characteristics3
VGS(th)
Gate Threshold Voltage
RDS(on)
Drain-Source On-State Resistance
gFS
Forward Transconductance
•Dynamic Characteristics
mΩ
4
Ciss
Input Capacitance
Coss
Output Capacitance
Crss
Reverse Transfer Capacitance
GUANGDONG HOTTECH
VDS=6V, VGS=0V, f=1MHz
INDUSTRIAL CO., LTD
Page:P3-P1
Plastic-Encapsulate Mosfets
Electrical Characteristics (TA=25°C, unless otherwise noted)
•Switching Characteristics4
Qg
Total Gate Charge
Qgs
Gate-Source Charge
Qgd
td(on)
tr
td(off)
tf
3.73
-
-
0.75
-
Gate-Drain Charge
-
1.04
-
Turn-on Delay Time
-
5.9
-
VDD=6V, RL=6Ω, ID=1A,
-
7.45
-
VGEN=4.5V, RG=6Ω
-
16
-
-
3.96
-
VDS=6V, ID=2.8A, VGS=4.5V
Turn-on Rise Time
Turn-off Delay Time
Turn-off Fall Time
nC
nS
• Drain-Source Diode Characteristics
VSD
Drain-Source Diode Forward Voltage
3 : Pulse Test : Pulse Width < 300μs, Duty Cycle < 2%.
SI2300
Typical
VGS=0V, IS=-1.6A
-
1.2
V
4: Guaranteed by design, not subject to production testing
