1XXB26000MAA

Serial No. : 2014-1357 DATE : 2014/12/22 CRYSTAL OSCILLATOR ITEM : DSB221SDN TYPE : ---------------------- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- -- - 26.000MHz NOMINAL FREQUENCY : ---------------------- - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - 1XXB26000MAA SPEC No. : ---------------------- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- -- - ---------------------- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- -- - RECEIPT DATE RECEIVED (signature) (name) General Manufacture of Quartz Devices 1389 Shinzaike, Hiraoka-cho, Kakogawa, Hyogo 675-0194 Japan Phone (81)79-425-3141 Fax (81)79-425-1134 http://www.kds.info/index_en.htm C.ENG. ENG. Serial No.2014-1357 1. Device Name TCXO 2. Model Name DSB221SDN 3. Nominal Frequency 26.000 MHz 4. Mass 0.02g max. 5. Absolute Maximum Ratings 1 2 Item Supply Voltage Storage Temperature Range Symbol VCC T_STG Rating -0.3~+4.6 -40~+85 unit V C 6. Recommended Operating Conditions Item 1 Supply Voltage Symbol VCC 2 Load Impedance (resistance part) (parallel capacitance) Operating Temperature Range LOAD_R LOAD_C T_OPR 3 min. +1.71 +2.09 +2.66 9 9 -40 typ. +1.8 +2.2 +2.8 10 10 - max. +1.89 +2.31 +2.94 11 11 +85 unit V kΩ pF C 7. Electrical Characteristics (TA=-40~+85C, LOAD_R//C=10kΩ//10pF, VCC=+1.8V or +2.2V or +2.8V, unless otherwise noted) Item 1 2 3 4 Current Consumption Output Level Symmetry Frequency Stability 1.Tolerance 2.vs Temperature 3.vs Drift Rate/Slope 4.vs Hysteresys 5.vs Supply Voltage 6.vs Load Variation 7.vs Aging 5 6 7 G Sensitivity Start Up Time SSB Phase Noise Conditions GND level (DC cut) After 2 times reflow TA=-30~+85C TA=-40~-30C @ 0.3C/s VCC=+1.8V±5%,+2.2V±5%,+2.8V±5% LOAD_R//C=(10kΩ//10pF)±10% TA=Room ambient TA=Room ambient TA=Room ambient TA=Room ambient Gamma Vector of all 3axes from 30 to 1500Hz @90% of final VOUT level Relative to f0 level offset 1Hz Relative to f0 level offset 5Hz Relative to f0 level offset 10Hz Relative to f0 level offset 100Hz Relative to f0 level offset 1kHz Relative to f0 level offset 10kHz Relative to f0 level offset 100kHz min. 0.8 40/60 Limits typ - - - - - max. 1.5 60/40 ±1.5 ±0.5 ±1.0 ±10.0 ±0.6 ±0.1 ±0.1 ±1.0 ±1.5 ±2.5 ±5.0 ±2.0 2.0 -50 -73 -80 -106 -134 -144 -152 unit Notes mA VP-P % 1 ppm ppm ppm ppb/s ppm ppm ppm ppm/year 2,3 4 4 ppm/2years ppm/5years ppm/10years ppb/G ms dBc/Hz dBc/Hz dBc/Hz dBc/Hz dBc/Hz dBc/Hz dBc/Hz Notes 1. Clipped sine wave (DC-coupled) 2. Ref. to nominal frequency 3. Please leave after reflow in 2h or more at room ambient. 4. Ref. to frequency (TA=+25C) TITLE Remark DSB221SDN TYPE SPECIFICATION Date 2014/12/22 Spec. No. Rev. 1XXB26000MAA DAISHINKU CORP. - Page 1/13 DM-Z0002: Style-010 Ver.1 Serial No.2014-1357 8. Outline, Pin Connections Outline Pin Connections #4 Pin No. #1 #2 #3 #4 #3 (1) (2) (3) Connection GND GND Output VCC Marking (4) #1 #2 #1 Index (1) Model code BN (2) Frequency 26.0 (MHz, 3digits) (3) Logo D (4) Date code Year (1digit) +Week (2digits) 401 e.g.2014/1/1 unit: mm Dimensional Tolerance: ±0.15 (Unless otherwise noted) #1 #2 #4 #3 9. Measurement Circuit 1000pF T.P. mA Power Supply #3 #4 + 10000pF TCXO V - Output Vcc GND #1 GND LOAD_R #2 LOAD_C LOAD_R=10kΩ LOAD_C=10pF (Include Jig stray capacitance) TITLE Remark DSB221SDN TYPE SPECIFICATION Date 2014/12/22 Spec. No. Rev. 1XXB26000MAA DAISHINKU CORP. - Page 2/13 DM-Z0002: Style-010 Ver.1 Serial No.2014-1357 10. Mechanical Characteristics All test is performed after 3times reflow (Clause.13) except 10.10 (Resistance to soldering heat) Item 1 2 3 4 5 Drop Vibration Shock PCB bend strength Adherence nature 6 Package strength 7 Gross leak 8 Fine leak 9 Solderability 10 Resistance to soldering heat Description Requirements Natural drop (On concrete) Mounting on the set or test fixture.(Total weight 100g) Height : 150cm Direction : X,Y,Z, 6directions Test cycle : 3cycles Reference specification : EIAJ-ED-4702A Method5 Sweep range : 10~500Hz Sweep speed : 11min/cycle Amplitude : 1.5mm (10~55Hz) 2 Acceleration : 200m/s (55~500Hz) Direction : X,Y,Z, 3directions Test cycle : 10cycles Reference specification : IEC 60068-2-6 2 Acceleration : 1000m/s Direction : X,Y,Z, 6directions Duration : 6ms Test cycle : 3cycles/each directions Reference specification : IEC 60068-2-27 PWB : t=1.6mm Pressure speed : 1.0mm/s Bend width : 1 2 3mm Duration : 10±1s Reference specification : IEC 60068-2-21 Ue1 PWB : t=1.6mm Direction : X,Y, 2directions Pressure : 10N Duration : 10±1s Reference specification : IEC 60068-2-21 Ue3 Pressure : 10N Duration : 10±1s Reference specification : IEC 60068-2-77 It is immersed for 3min into +125±5C Chlorofluorocarbon (CFCs) liquid. Reference specification : IEC 60068-2-17 It shall be measured by the helium leak detector after pressurization for 60min by the pressure 5 of (3.92±0.49) x10 Pa in a helium gas atmosphere. Reference specification : IEC 60068-2-17 Solder bath temperature : +245±5C Duration : 3±0.3s Reference specification : IEC 60068-2-58 1) Solder iron method Bit size : B(φ3) Bit temperature : +350±10C Duration : 3+1/-0s /each terminal It shall be measured after 2h at room temperature, humidity. Reference specification : IEC 60068-2-20 2) Reflow In refer to temperature profile shown in clause13. Test cycle : 3cycles It shall be measured after 2h at room temperature, humidity. Reference specification : IEC 60068-2-58 TITLE df/f=
