DSX321G 12MHz 12PF 20PPM

Serial No. : 2014-0416 DATE : 2014/04/04 Lierda Science & Technology Group Co.,Ltd. CRYSTAL RESONATOR ITEM : DSX321G 12.000MHz ----- ---------- ---------- ---------- ---------- ---------- ---------- ---------- ---------- ---------- ---------- ---------- ---------- ---- (INDONESIA) 1C212000BC0AK ----- ---------- ---------- ---------- ---------- ---------- ---------- --------- ---------- ---------- ---------- ---------- ---------- ---- (THAILAND) 1N212000BC0AK ----- ---------- ---------- ---------- ---------- ---------- ---------- ---------- ---------- ---------- ---------- ---------- ---------- ---- ----- ---------- ---------- ---------- ---------- ---------- ---------- ---------- ---------- ---------- ---------- ---------- ---------- ---- RECEIPT DATE RECEIVED (signature) (name) General Manufacture of Quartz Devices 1389 Shinzaike, Hiraoka-cho, Kakogawa, Hyogo 675-0194 Japan Phone (81)79-425-3141 Fax (81)79-425-1134 http://www.kds.info/index_en.htm C.ENG. ENG. 2014-0416 Serial No. 1. ELECTRICAL CHARACTERISTICS (This test shall be performed under the conditions of temp.at +25 ± 3°C, Relative Humidity 60% max.) (1) NOMINAL FREQUENCY 12.000000 MHz (2) OVERTONE ORDER Fundamental (3) LOAD CAPACITANCE(CL) 12.0 pF (4) FREQUENCY TOLERANCE ±20 ppm max. (at +25 ± 3 °C) (5) DRIVE LEVEL 175 ± 10 μW 80 Ω max. (at Series) (6) SERIES RESISTANCE (7) OPERATING TEMPERATURE RANGE -10 ~ +70 °C (8) FREQUENCY CHARACTERISTICS ±30 ppm max. / -10 ~ +70 °C (ref. to +25°C) OVER TEMPERATURE 2.0pF max. (9) SHUNT CAPACITANCE (10) INSULATION RESISTANCE (11) STORAGE TEMPERATURE RANGE 500MΩ min. / DC 100 ± 15V -40 ~ +85 °C 2. CONSTRUCTION (1) DIMENSIONS AND MARKING Refer to 4. 3. OTHER SPECIFICATIONS (1) EMBOSS CARRIER TAPE & REEL Refer to 5. (2) PACKING Refer to 6. (3) REFLOW CONDITIONS (REFERENCE) Refer to 7. (4) LAND PATTERN (REFERENCE) Refer to 8. (5) RELIABILITY SPECIFICATION Refer to 9. ~ 11. (6) OTHER HANDLING INSTRUCTIONS Refer to 12. TITLE DSX321G TYPE QUARTZ CRYSTAL SPECIFICATION REMARK SPEC. No. DATE 1C212000BC0AK 1N212000BC0AK 2014/04/04 DAISHINKU CORP. REV. PAGE 1 / 12 DM-Z0002:Style-010 Serial No. 2014-0416 4. DIMENSIONS AND MARKING (1) (2) (3) 0.75+/-0.15 2.5+/-0.1 3.2+/-0.1 (Internal connections) 2.1 #2 #4 #3 #3 #1 #2 #1 ,#3 Connected to quartz element #2 ,#4 Open (unconnected) 0.7 1.6 #1 #4 0.9 Unit : mm Tolerance : ±0.1 Figure-1 Logo(1) and Nominal Frequency (2) should be printed as follows by producing district Made in INDONESIA --> Spec. No.: 1C212000BC0AK , Logo : D , Frequency: 12 Made in THAILAND --> Spec. No.: 1N212000BC0AK , Logo : D , Frequency: 12 _ * Made in INDONESIA * Made in THAILAND : Under Bar with D : Top Bar with D Nominal Frequency ( 2 ) = Mark two digits from upper decimal point (ex. 12.000000 MHz ----> 12 ) Manufacturing lot No.( 3 ) 2014 (year) ex. Apr. (Month)ex. (Table-1.) Month Jan. Mark A Feb. B shall be marked as ' shall be marked as ' Mar. C Apr. D May. E 4 D Jun. F ' (The last digit of the year) ' (As shown in Table-1.) Jul. G Aug. H Sep. J Oct. K Nov. L Dec. M Plating material of a terminal. : Ni Plating + Au Plating. A clearance between the soldering terminal portion and a print circuit board side should be less than 0.1mm. TITLE DSX321G TYPE QUARTZ CRYSTAL SPECIFICATION REMARK SPEC. No. DATE 1C212000BC0AK 1N212000BC0AK 2014/04/04 DAISHINKU CORP. REV. PAGE 2 / 12 DM-Z0002:Style-010 Serial No. 2014-0416 5. EMBOSS CARRIER TAPE & REEL 3.5+/-0.05 D249B 0.25+/-0.05 1.75+/-0.1 1.55dia.+/-0.05 4.0+/-0.1 8.0+/-0.2 3.5+/-0.1 (1) Dimensions of embossed carrier tape 1.15 dia.+/-0.05 2.0+/-0.05 4.0+/-0.1 1.0+/-0.1 2.8+/-0.1 User Direction of feed (Unit : mm) Figure-2 (2) Dimensions of tape reel U F3 θ θ E F2 V B A C F1 W2 W1 Figure-3 TITLE DSX321G TYPE QUARTZ CRYSTAL SPECIFICATION REMARK SPEC. No. DATE 1C212000BC0AK 1N212000BC0AK 2014/04/04 DAISHINKU CORP. REV. PAGE 3 / 12 DM-Z0002:Style-010 Serial No. 2014-0416 (Unit:mm) Item Mark Dimensions Angle Diameter A Φ180 +0.0 / -3.0 Inside of Frange W1 9.0 ± 0.3 Outside of Frange W2 11.4 ± 1.0 Inside Diameter B Φ60 +1.0-0 F1 3.0 ± 0.2 F2 4.0 ± 0.2 F3 5.0 ± 0.2 Length V 11.9 +0.5 / -0.0 Angle θ 120° Spindle Diameter C Φ13 ± 0.2 Width E 2.0 ± 0.5 Length U 10.5 ± 0.4 Angle θ 120° Flange Width Center Core Slit Center Core Key Seats (3) Material of the reel Polystyrene+Carbon（ Black ） Reel Polystyrene(White) (4) Storage condition Temperature : +40 °C max. Relative Humidity : 80% max. ( It is a guaranteed term because it obtains an excellent soldering: 6 months) (5) Standard packing quantity 3,000 pcs/reel (6) Material of the tape Tape Material Carrier tape Polystyrene+Carbon Cover tape Polyester TITLE DSX321G TYPE QUARTZ CRYSTAL SPECIFICATION REMARK SPEC. No. DATE 1C212000BC0AK 1N212000BC0AK 2014/04/04 DAISHINKU CORP. REV. PAGE 4 / 12 DM-Z0002:Style-010 Serial No. 2014-0416 (7) Label contents Type Our specification No. Your Part No. Lot No. Nominal Frequency Quantity Our Company Name Producting Country Stick a label on the each reel. (8) Taping dimension Cover-tape Leader Carrier-tape Cover-tape Terminal Carrier-tape The length of cover-tape in the leader is more than 400mm including empty embossed area. After all products were packaged, must remain more than twenty pieces or 400mm empty area, which should be sealed by cover-tape. The tip of cover-tape shall be fixed temporary by paper tape and roll around the core of reel one round. The empty embossed area which are sealed by cover-tape must remain more than 40mm. Terminal Leader Components Empty Components Unreeling direction Empty Components Cover-tape Carrier-tape Figure-4 (9) Joint of tape The carrier-tape and cover-tape should not be jointed. (10) Release strength of cover tape It has to between 0.1 ~ 0.7N under following condition. Pulling direction 165 ~ 180 ° Speed 300mm/min Otherwise unless specified. 165 ~ 180 ° Pulling direction Figure-5 Other standards shall be based on JIS C 0806 -1990. TITLE DSX321G TYPE QUARTZ CRYSTAL SPECIFICATION REMARK SPEC. No. DATE 1C212000BC0AK 1N212000BC0AK 2014/04/04 DAISHINKU CORP. REV. PAGE 5 / 12 DM-Z0002:Style-010 Serial No. 2014-0416 6. PACKING (1) STORAGE METHOD Label contents The type of product Lot No. Specification Quantity Shipment Day Remark Label Figure-6 (2) BOX SIZE From lot size packingsize shall be changed. In the upper and lower part and the opening in box it shall be protected products using aircushion sheets. TITLE DSX321G TYPE QUARTZ CRYSTAL SPECIFICATION REMARK SPEC. No. DATE 1C212000BC0AK 1N212000BC0AK 2014/04/04 DAISHINKU CORP. REV. PAGE 6 / 12 DM-Z0002:Style-010 Serial No. 2014-0416 7. REFLOW CONDITIONS (REFERENCE) During the solder reflow process, please complete within following temperature, period. Reflow soldering shall be allowed only 2 times. +260 ± 5 °C +220 ± 5 °C +160 ~ +180 °C 10 s 120 s 60 s Total time : 240 s max. Figure-7 HANDSOLDERING METHOD : +350 ± 10 °C , 3+1/-0s Each terminal once (Please take care so that a soldering iron should not touch a product directly.) 8. LAND PATTERN (REFERENCE) 1 .2 1 .7 2 .2 1 .4 Unit : mm Figure-8 TITLE DSX321G TYPE QUARTZ CRYSTAL SPECIFICATION REMARK SPEC. No. DATE 1C212000BC0AK 1N212000BC0AK 2014/04/04 DAISHINKU CORP. REV. PAGE 7 / 12 DM-Z0002:Style-010 Serial No. 2014-0416 9. MECHANICAL ENDURANCE (1) SHOCK (ACCELERATION) After the following test,parts shall conform specification 11.C 1000m/s2 by 6ms X,Y,Z each axis (6 directions) , 3cycles (2) SHOCK (MOUNTING DROP) After the following test,parts shall conform specification 11.C 3cycles(18times) drop from 150 cm heights to concrete. Further,parts shall be solderd on substrate, fixed Aluminum materials(about 100g). Substrate materials : Glass Epoxy 1 cycle : each 1 times of 6 directions (3) VIBRATION After the following test,parts shall conform specification 11.C and no abnormal appearance shall be observed. Frequency of Vibration : 10 ~ 500 ~ 10 Hz Amplitude(p-p) : Sine waves of 1.5mm or 100m/s 2 Cycle : 11min Vibration axis : X.Y.Z Vibration period : 2 h for each axis (4) SEAL Less than 2.0×10-9 Pa m3/s by Helium leak detector. Also, no serial bubble is observed by Fluorocarbon tests. (5) SOLDERABILITY After the following test, more than 95% of terminal shall be covered by new solder. 3 ± 0.5 s dip in +245 ± 5 °C solder. (Solder composition : Sn-3Ag-0.5Cu) (Use rosin type flux for solder.) (6) RESISTANCE TO SOLDERING HEAT (REFLOW) 48 h past at room temperature from following test,parts shall conform specification 11.C perform the attached Reflow conditions to reference. (7) RESISTANCE TO SOLDERING HEAT (HAND SOLDERING METHOD) 48 h past at room temperature from following test,parts shall conform specification 11.C +350 ± 10°C , 3+1/-0s Each terminal once. (8) SUBSTRATE BENDING After the following test,parts shall conform specification 11.C and no abnormality shall be observed in external appearance and sealing tightnen and others shall be based on ET-7403 of EIAJ. Mount the specimen on substrate. Apply the following pressure Direction : see right figure Speed : about 1.0 mm/s Hours : 5±1s pr essur e j i g Amount of substrate : 3 mm max. 20 R230 P. C. B. 45+/ - 2 TITLE DSX321G TYPE QUARTZ CRYSTAL SPECIFICATION 45+/ - 2 REMARK SPEC. No. DATE 1C212000BC0AK 1N212000BC0AK 2014/04/04 DAISHINKU CORP. REV. PAGE 8 / 12 DM-Z0002:Style-010 2014-0416 Serial No. (9) SHEAR After the following test,parts shall conform specification 11.C and no abnormality shall be observed in external appearance and sealing tightness and others shall be based on ET-7403 of EIAJ. P. C. B. Mount the specimen on substrate. Apply the following pressure Weight : 10 N Hours : 10 ± 1 s Direction : see right figure pr essur e j i g R0. 5 speci men (10) BODY STRENGTH After the following test,parts shall conform specification 11.C and no abnormality shall be observed in external appearance and sealing tightness and others shall be based on ET-7403 of EIAJ. Mount the specimen on substrate. Apply the following pressure Presure jig : R0.5 Weight : 10N Hours : 10 ± 1 s Direction : see right figure pr essuer j i g R0. 5 s peci men W L L > = W 0. 5L L TITLE DSX321G TYPE QUARTZ CRYSTAL SPECIFICATION REMARK SPEC. No. DATE 1C212000BC0AK 1N212000BC0AK 2014/04/04 DAISHINKU CORP. REV. PAGE 9 / 12 DM-Z0002:Style-010 Serial No. 2014-0416 10. ENVIRONMENTAL ENDURANCE (1) LOW TEMPERATURE 2 h past at room temperature after following test, parts shall conform specification 11.C 240 h , -40 ± 3 °C. (2) HUMIDITY 2 h past at room temperature after following test, parts shall conform specification 11.D 240 h , +85 ± 2 °C , relative humidity 85 ± 5%. (3) HIGH TEMPERATURE 2 h past at room temperature after following test, parts shall conform specification 11.D 240 h , +85 ± 2 °C. (4) TEMPERATURE CYCLE 2 h past at room temperature after 25 cycles of following test, parts shall conform specification 11.D 30min +85°C +25°C Transport Time 2-3min 30min -40°C 1 cycle 11. SPECIFICATION Frequency Variation and Equivalent Resistance shall be within Table below after the reliability test. Spec. A B C D E Frequency Variation ±2ppm ±5ppm ±5ppm ±10ppm ±20ppm Equivalent Resistance ±15 % or 2.0 Ω max. (Use larger specification) ±15 % or 2.0 Ω max. (Use larger specification) ±20 % or 3.0 Ω max. (Use larger specification) ±20 % or 3.0 Ω max. (Use larger specification) ±25 % or 10.0 Ω max. (Use larger specification) TITLE DSX321G TYPE QUARTZ CRYSTAL SPECIFICATION REMARK SPEC. No. DATE 1C212000BC0AK 1N212000BC0AK 2014/04/04 DAISHINKU CORP. REV. PAGE 10 / 12 DM-Z0002:Style-010 Serial No. 2014-0416 12. DSX321G TYPE QUARTZ CRYSTAL HANDLING INSTRUCTIONS (1) SOLDERING Please perform the attached Reflow conditions to reference within 2 times. (2) MOUNT Crystal products are designed to be compatible with automatic mounting. Be sure to have a mounting test in advance by using the actual mounting machine and check that the characteristics of the products are not damaged by the automatic mounting. In the process where the boad is warped, such as board separation process, be careful that the warping does not influence the characteristics and soldering of crystal products. Since mounting by Ultrasonic welding and processing have a possibility of an excessive vibration spreading inside a crystal resonator and becoming the cause of characteristic deterioration and not oscillating, it does not recommend. Underfilling Material for DSX321G Types,KDS considers underfilling material such as heat-cured resin would not affect the characteristics of the DSX321G crystal mounted, however, we recommend the crystal be tested and checked in such a case prior to use so that there are the possibility that the crystal may have a cap off or a crack in the ceramic base. (3) WASHING About use of the washing liquid of a basin system, an alcoholic system, and a chlorofluorocarbon-replacing material system, it is checking that it is satisfactory. However please consult in advance about other washing liquid. Although the check about ultrasonic washing is performed, since it is an examination with a simple substance, the check for the second time by the use state is recommended. (4) THE CAUTIONS ON USE The piece of crystal it is processed very smaller than the conventional thing inside DSX321G series crystal unit may be damaged, if excessive excitation electric power is applied. Please use it below with the value specified on a catalog and specifications. Please refrain from forming patterns between crystal land pattern's since there is a possibility to cause crack in base. If the temperature is higher than +280 °C, there is a possibility for the sealing glass to remelt. Avoid using the product at temperature higher than specified. (5) HANDLING OF A PRODUCT DSX321G series has sufficient intensity to fall and vibration. However when too much shock is added according to a certain cause, the use after a characteristic check is recommended. (6) STORAGE Since the soldering nature of a terminal may be degraded, please avoid storage in high temperature and a humid place. Please keep it in the place which direct rays do not hit and dew condensation does not generate. TITLE DSX321G TYPE QUARTZ CRYSTAL SPECIFICATION REMARK SPEC. No. DATE 1C212000BC0AK 1N212000BC0AK 2014/04/04 DAISHINKU CORP. REV. PAGE 11 / 12 DM-Z0002:Style-010 2014-0416 REVISION RECORD Rev.No Date Reason - 2014/04/04 - Contents The first edition. - 12 / 12 - Approved Checked Drawn T.Okishio Y.Maeda S.Miura DM-Z0002:Style-005
