MU100M080AQ_CP

MU100MxxxAQ_CP General-Outdoor ■ Features ◆ Input voltage: 90-305Vac ◆Built-in active PFC function 0.98 Typ. ◆ High efficiency: up to 91% Typ. ◆ Built-in Lightning protection ◆ Waterproof (IP67) ◆Constant Current / 0-10V Dimming ◆ Clock Dimming(CLK)/PWM Dimming ◆Protection: OVP, SCP, OTP ◆Full Power at 65%Iomax～100%Iomax (Constant Power) ◆UL Type TL, Type HL ■ Specification Model (MU100MxxxAQ_CP ) Input Efficiency(120Vac) Efficiency(230Vac) Voltage Range (Vac) Rated Input Voltage (Vac) Frequency Range (Hz) Power Factor THD AC Current(Typ.) Inrush Current(Typ.) Output Dimming Control Leakage Current(max.) Rated Output Voltage (V) Output Voltage Range (V)Note.1 Rated Current(mA) Output Current Range(mA) Rated Power (W) Output Current Set Range Constant Power Output Set Ri l C t(（PK AV）/AV) Ripple Current(（PK-AV）/AV) Current ToleranceNote.2 Line Regulation Load Regulation Setup, Rise Time Hold Up Time 12Vdc Output Voltage (Vdc) 12Vdc Output Current(Vdc) 0~10V/DMI+ Voltage 0~10V/DMI+ Short Current DIMMING FUNCTION Over Voltage(V) Protection Short Circuit Over Temperature Operating Temp. Tcase Operating Humidity Environment Storage Temp., Humidity Temp. Coefficient Vibration Safety Standard Withstand Voltage Safety & EMC Isolation Resistance EMC Emission EMC Immunity MTBF Others Lifetime 080 105 150 210 320 480 89.0% 91.0% 88.0% 90.0% 88.0% 90.0% 87.0% 89.0% 86.0% 88.0% 85.0% 87.0% 90～305 100-277 47~63 0.98（Typical）at 230Vac; >0.9 with 55%~100% load, at 100~277Vac =50 KHrs lifetime (continous) at Tcase = 75 ℃ 183 x67.5 x37 mm（LxWxH） 0.85kg Dimension Weight Note.1: refer to V/I curve Note.2: At Rated Current ,Includes set up tolerance, line regulation and load regulation. Page 1 of 5 SHANGHAI MOONS' AUTOMATION CONTROL CO., LTD. Add: No.168, Mingjia Road, Minbei Industrial Park, Shanghai 201107, P.R.China Tel: +86 (0)21 52634688 Website: www.moons.com.cn Page 1 of 5 MU100MxxxAQ_CP General-Outdoor ■ Curve Derating Curve V/I Curve Efficiency VS. Load Curve（MU100M105AQ_CP） 92.00% Efficiency 90.00% 176Vac 88.00% 220Vac 277Vac 86.00% 84.00% 0.6 0.7 0.8 0.9 1 Load Power Factor VS. Load Curve THD Curve 16 00% 16.00% 1 14.00% 0.99 12.00% 0.97 10.00% PF 0.96 0.95 176Vac 0.94 220Vac 0.93 277Vac 0.92 THD 0.98 8.00% 176Vac 6.00% 220Vac 4.00% 277Vac 2.00% 0.91 0.00% 0.9 0.55 0.6 0.7 0.8 Load 0.9 1 0.6 0.7 0.8 0.9 1 Load Life Time VS. Tcase (Ref.) Page 2 of 5 SHANGHAI MOONS' AUTOMATION CONTROL CO., LTD. Add: No.168, Mingjia Road, Minbei Industrial Park, Shanghai 201107, P.R.China ) 52634688 Website: www.moons.com.cn Tel: +86 ((0)21 MU100MxxxAQ_CP General-Outdoor ■ Instruction 1.Field Programmable Topology The programmable driver can be programmed by using special PC software and the programmer module. 2.Dimming Interface Description Pin description Pin 1 2 3 Name Vaux 12V Dim+/Program Dim- Value 10.8V-13.2V 0-10V 0V Description Passive dimmers power supply Dimming/Programming input DC Ground 3.Dimming Software Function Instruction Adjustable Output Current(AOC) PWM Input a PWM signal from the 2nd pin(Dim+/Program) of the dimming interface to change the output current. PWM duty circle: 1%~99%(it has both positive and negative logics ), frequency: 500Hz~5kHz, 3V~10V is high,-0.3V~0.8V is low. ■ Users can set the rated current between 10%~100% by 1% per step. Adjustable Startup Time(AST) At power ON, the fast fade-up of light can be unpleasant in certain applications. To avoid such a situation, the driver fade-up time at start-up can be programmed to a value among 0s 0s、1s、2s、5s、10s 1s 2s 5s 10s 、20s、40s. The default start fade Set Module Working Hrs Use to reset the working hour counting in the microcontroller of the driver and collaborate with CLO. 1-10V Allow users to set the max and min output current and corresponding output voltage to clarify the 1-10V dimming curve. Input a 0~10V signal from 2nd pin of the dimming interface. Default: input ≤1V, output current 10%; input ≥ 8.5V, output current 100%. Page 3 of 5 SHANGHAI MOONS' AUTOMATION CONTROL CO., LTD. Add: No.168, Mingjia Road, Minbei Industrial Park, Shanghai 201107, P.R.China Tel: +86 ((0)21 ) 52634688 Website: www.moons.com.cn MU100MxxxAQ_CP General-Outdoor ■ Instruction Integrated Dynadimmer Integrated Dynadimmer Time Based Integrated Dynadimmer allows dimming to predefined light levels based on the nightly operating time. With flexibility in setting time and light levels, the user can configure the driver for specific locations and application needs. Using Integrated Dynadimmer, it is possible to set up to 5 dim levels and time intervals. The driver does not have a real time clock. Instead it runs a virtual clock, determined by the length of nightly operating hours. After 3 ON-OFF cycles, the driver will calculate the virtual clock time. A valid ON-time is defined as a period during which the driver operates continuously for ≥4 hours to ≤24 hours. For example, if the requirement in summer is: 23:00-00:00: 75%, 00:00-04:00: 50%, 04:00-05:00: 75% (other time 100% or Off). The driver should be powered on for 7h, so it can calculate the virtual clock time as 22:00. Then we can set the dimming plan: 22:00~23:00: 22:00 23:00: 100% 100%, 23:00-00:00: 75% 75%, 00:00-04:00: 50%, 04:00-05:00: 75%. From summer to winter, the valid ON-time changes day by day. The driver should be powered on for 17h in winter, and it also can calculate the virtual clock time as 17:00. Then the dimming plan is 17:00~23:00: 100%, 23:00-00:00: 75%, 00:0004:00: 50%, 04:00-05:00: 75%, 05:00~10:00: 100%. From the above, if we set the dimming plan as shown in the picture, after repeating the driver ON-time for 3 consecutive days, the dimming plan takes effect from the 4th day onwards. Each day the driver powered on, it has a different start time according to the virtual clock time. So the driver can satisfy different requirements for different seasons. Constant Light Output(CLO) Allow users to separate 24hrs into 5 sections and corresponding output current. No Dimming The driver will be in constant output mode. Traditional light sources suffer from depreciation in light output over time. This applies to LED light sources as well. The CLO feature enables LED solutions to deliver constant lumen output through the life of the light engine. Based on the type of LEDs used, heat sinking and driver current, it is possible to estimate the depreciation of light output for specific LEDs and this information can be entered into the driver. The driver counts the number of light source working hours and will increase output current based on this input to enable CLO. When the CLO feature is enabled, the driver nominal output current will be defined by the CLO percentage as shown by the equation below: Driver target nominal output current = CLO percentage * AOC. For example, in the CLO profile shown in Figure, between 52,000-60,000 working hours, the CLO percentage is set at 120%. Assuming the nominal AOC is set to 500mA, the driver output current with CLO enabled will be 1.20 x 500 = 600 mA. The CLO percentage can be set to a value between 100%-120%, in increments of 1%. The LED module working hours can be set at any value between (0100,000 hours). Page 4 of 5 SHANGHAI MOONS' AUTOMATION CONTROL CO., LTD. Add: No.168, Mingjia Road, Minbei Industrial Park, Shanghai 201107, P.R.China Tel: +86 (0)21 52634688 Website: www.moons.com.cn www moons com cn MU100MxxxAQ_CP General-Outdoo ■ Mechanical Specification Dimensions(Unit:mm) RoHS Compliance: Our products comply with the European Directive of LVD (2014/35/EU), WEEE (2012/19/EU) and ROHS (2011/65/EU and（EU）2015/863), calling for the elimination of lead and other hazardous substances from electronic products. Page 5 of 5 SHANGHAI MOONS' AUTOMATION CONTROL CO., LTD. Add: No.168, Mingjia Road, Minbei Industrial Park, Shanghai 201107, P.R.China Tel: +86 ((0)21 ) 52634688 Website: www.moons.com.cn
