78M05

Plastic-Encapsulate Voltage Regulator 78M05 FEATURES Maximum output current IOM: 0.5 A Output voltage VO: 5V Continuous total dissipation PD: 1.25 W 1. 2. 3. ABSOLUTE MAXIMUM RATINGS (Operating temperature range applies) Parameter Symbol Value Unit VI 25 V Operating Junction Temperature Range TOPR 0-125 Storage Temperature Range TSTG -65-150 Input Voltage 1. IN 2. GND TO-252 3. OUT ELECTRICAL CHARACTERISTICS AT SPECIFIED VIRTUAL JINCTION TEMPERATURE (Vi=10V,Io=350mA, Ci=0.33μF,Co=0.1μF,unless otherwise specified) Parameter Symbol Test conditions Min 25℃ Output Voltage Vo 7V≤V i≤20V, Io=5mA-350mA 0-125℃ Po≤ 15W Load Regulation ΔVo Line Regulation ΔVo Quiescent Current Iq Quiescent Current Change Typ Max Unit 4.8 5 5.2 V 4.75 5 5.25 V Io=5mA-0.5A 25℃ 15 100 mV Io=5mA-200mA 25℃ 5 50 mV 7V≤V i≤25V, Io=200mA 25℃ 3 100 mV 8V≤V i≤25V, Io=200mA 25℃ 1 50 mV 25℃ 4.2 6 mA ΔIq 8V≤V i≤25V, Io=200mA 0-125℃ 0.8 mA ΔIq 5mA≤IO≤350mA 0-125℃ 0.5 mA μV Output Noise Voltage VN 10Hz≤ f ≤100KHz Ripple Rejection RR 8V≤Vi≤18V,f=120Hz,Io=300mA Dropout Voltage Vd Io=350mA 25℃ 2 Short Circuit Current Isc Vi=10V 25℃ 300 mA Peak Current Ipk 25℃ 0.5 A GUANGDONG HOTTECH 40 25℃ 0-125℃ INDUSTRIAL CO., LTD 62 200 80 dB 2.5 V Page:P1-P1
