SOD1F7

SOD1F1 THRU SOD1F7 Reverse Voltage - 50 to 1000 Volts Forward Current - 1.0 Ampere SURFACE MOUNT FAST RECOVERY RECTIFIER Features SOD-123FL  Glass passivated device  Ideal for surface mouted applications  Low reverse leakage  Metallurgically bonded construction 0.075(1.90) 0.067(1.70) 0.031 (0.80) 0.043 (1.10) 0.114(2.90) 0.102(2.60)  High temperature soldering guaranteed: 250°C/10 seconds,0.375”(9.5mm) lead length, 0.051(1.30) 0.039(1.00) 5 lbs. (2.3kg) tension 0.010(0.25) 0.004(0.10) 0.035(0.90) 0.028(0.70) Mechanical Data 0.154(3.90) 0.141(3.60) Case : JEDEC 6OD-123FL molded plastic body Terminals : Solderable per MIL-STD-750,Method 2026 Polarity : Polarity symbol marking on body Mounting Position : Any Weight : 0.007 ounce, 0.02 grams Dimensions in inches and (millimeters) Maximum Ratings And Electrical Characteristics Ratings at 25 C ambient temperature unless otherwise specified. Single phase half-wave 60Hz,resistive or inductive load,for capacitive load current derate by 20%. Parameter SYMBOLS Marking Code Maximum repetitive peak reverse voltage Maximum RMS voltage Maximum DC blocking voltage Maximum average forward rectified current at TL(see fig.1) VRRM VRMS VDC SOD1F1 SOD1F2 SOD1F3 SOD1F4 SOD1F5 SOD1F6 SOD1F7 F1 F2 F3 F4 F5 F6 F7 50 35 50 100 70 100 200 140 200 400 280 400 600 420 600 800 560 800 1000 700 1000 UNITS V V V I(AV) 1.0 A Peak forward surge current 8.3ms single half sine-wave superimposed onrated load (JEDEC Method) IFSM 30 A Maximum instantaneous forward voltage at 1.0A VF IR 1.3 5 100 V Maximum DC reverse current rated DCblocking voltage TA=25℃ at TA=125℃ Typical junction capacitance (NOTE 1) Maximum Reverse Recovery Time Typical thermal resistance (NOTE 2) Operating junction temperature range Storage temperature range CJ trr uA pF 15 150 250 500 ns RJA 85 ℃/W TJ -55 to +150 ℃ TSTG -55 to +150 ℃ Note: 1.Averaged over any 20ms period. 2.Measured with IF=0.5A, IR=1A, Irr=0.25A. 3.Measured at 1MHz and applied reverse voltage of 4.0V D.C. 4.Thermal resistance junction to ambient, 6.0 mm2 coppeer pads to each terminal. http://www.microdiode.com Rev:2024A2 Page :1 SOD1F1 THRU SOD1F7 Reverse Voltage - 50 to 1000 Volts Forward Current - 1.0 Ampere Typical Characterisitics Fig.2 Typical Reverse Characteristics 1.2 1.0 0.8 0.6 0.4 0.2 Single phase half-wave 60 Hz resistive or inductive load 0.0 25 75 50 100 125 150 175 Instaneous Reverse Current（μ A） Average Forward Current (A) Fig.1 Forward Current Derating Curve 100 T J =125°C 10 1.0 T J =25°C 0.1 00 T J =25°C 1.0 0.1 pulse with 300μs 1% duty cycle 0.01 0.0 40 60 80 100 120 140 Fig.4 Typical Junction Capacitance Junction Capacitance (pF) Instaneous Forward Current (A) Fig.3 Typical Instaneous Forward Characteristics 10 20 percent of Rated Peak Reverse Voltage (%) Case Temperature (°C) 100 T J =25°C 10 1 0.5 1.0 1.5 2.0 2.5 0.1 1.0 10 100 Reverse Voltage (V) Instaneous Forward Voltage (V) Peak Forward Surge Current (A) Fig.5 Maximum Non-Repetitive Peak Forward Surge Current 35 30 25 20 15 10 05 8.3 ms Single Half Sine Wave (JEDEC Method) 00 1 10 100 Number of Cycles The curve above is for reference only. http://www.microdiode.com Rev:2024A2 Page :2 SOD1F1 THRU SOD1F7 Reverse Voltage - 50 to 1000 Volts Forward Current - 1.0 Ampere Packing information unit:mm P0 P1 d Item Symbol Tolerance SOD-123FL A B C d D D1 D2 E F P P0 P1 T W W1 0.1 0.1 0.1 0.05 2.0 min 0.5 0.1 0.1 0.1 0.1 0.1 0.1 0.3 1.0 2.1 4.0 1.60 1.55 178.00 50.0 13.00 1.75 3.50 4.00 4.00 2.00 E F B A Carrier width Carrier length Carrier depth Sprocket hole 7" Reel outside diameter 7" Reel inner diameter Feed hole diameter Sprocket hole position Punch hole position Punch hole pitch Sprocket hole pitch Embossment center Overall tape thickness Tape width Reel width W P D2 T D1 C W1 D 0.25 8.15 10.5 Note:Devices are packed in accor dance with EIA standar RS-481-A and specifications listed above. Reel packing PACKAGE REEL SIZE REEL (pcs) COMPONENT SPACING (m/m) BOX (pcs) INNER BOX (m/m) REEL DIA, (m/m) CARTON SIZE (m/m) CARTON (pcs) SOD-123FL 7" 3,000 4.0 45,000 210*208*203 178 430*430*235 180,000 APPROX. GROSS WEIGHT (kg) 9.0 Suggested Pad Layout Symbol Unit (mm) Unit (inch) A 1.2 0.047 B 1.2 3.2 0.126 D 2 0.079 E 4.4 0.173 C http://www.microdiode.com 0.047 Rev:2024A2 Page :3
