XT2055
Standalone Linear Li-Ion Battery Charger with Thermal Regulation
■ General Description
■ Applications
The XT2055 is a complete constant-current /constant
Cellular Telephones, PDAs, MP3 Players
-voltage linear charger for single cell lithium-ion batteries.
Bluetooth Applications
Its Thin SOT package and low external component count
■ Features
make the XT2055 ideally suited for portable applications.
Furthermore, the XT2055 is specifically designed to work
Programmable charge current up to 500mA
within USB power specifications.
No MOSFET, sense resistor or blocking diode
No external sense resistor is needed, and no blocking
required
diode is required due to the internal MOSFET architecture.
Thermal feedback regulates the charge current to limit the
Complete linear charger in thinsot package for single
cell lithium-ion batteries
die temperature during high power operation or high
Constant-current/constant-voltage
operation
with
ambient temperature. The charge voltage is fixed at 4.2V,
thermal regulation to maximize charge rate without
and the charge current can be programmed externally with
risk of overheating
a single resistor. The XT2055 automatically terminates the
th
charge cycle when the charge current drops to 1/10 the
Charges single cell li-ion batteries directly from USB
port
1% accuracy
programmed value after the final float voltage is reached.
Preset 4.2V charge voltage with
When the input supply (wall adapter or USB supply) is
Charge current monitor output for gas gaugin
removed, the XT2055 automatically enters a low current
Charge status output pin
state, dropping the battery drain current to less than 2µA.
C/10 charge termination
The XT2055 can be put into shutdown mode, reducing the
25µA supply current in shutdown
supply current to 25µA.
2.9V trickle charge threshold (XT2055)
monitor,
Soft-start limits inrush current
under-voltage lockout, automatic recharge and a status pin
Available in 6-Lead SOT-23
Other
features
include
charge
current
to indicate charge termination and the presence of an input
■ Package
voltage.
SOT-23-6L
■ Typical Application Circuit
VIN
VBAT
BAT
VIN
1K
RLED
C1
GLED
C2
DONE
PROG
CHRG
RPROG
GND
GND
Rev.1.1 — Feb. 29. 2016
GND
1
http://www.silinktek.com
XT2055
注:C1=4.7uF,C2=10uF,IBAT = (VPROG/RPROG)*1000
■ Ordering Information
XT2055 ①②③④⑤⑥
Designator
Description
①
Type
Symbol
X
Without trickle charge
Y
With trickle charge
0
4.0
1
4.1
2
4.2
A
00
The second part of regulator
B
25
Output Voltage
C
50
D
75
M
SOT-23-6L
R
Embossed tape: Standard feed
L
Embossed tape: Reverse feed
The first part of regulator
②③
Output Voltage
④
Description
⑤
Packaging Types
⑥
Device Orientation
■ Pin Configuration
6
5
4
PROG
DONE
VIN
CHRG
GND
BAT
1
2
3
SOT-23-6L
(TOP VIEW)
■ Pin Assignment
Pin Number
Pin Name
SOT-23-6L
Rev.1.1 — Feb. 29. 2016
1
CHRG
2
GND
3
BAT
4
VIN
5
DONE
6
PROG
2
http://www.silinktek.com
XT2055
■ Pin Function
CHRG (Pin 1): Open-Drain Charge Status Output. When the battery is charging, the CHRG pin is pulled low by an internal
N-channel MOSFET. When the charge cycle is completed, a weak pull-down of approximately 20µA is connected to the
CHRG pin, indicating an “AC present” condition. When the XT2055 detects an under voltage lockout condition, CHRG is
forced high impedance.
GND (Pin 2): Ground.
BAT (Pin 3): Charge current output. Provides charge current to the battery and regulates the final float voltage to 4.2V. An
internal precision resistor divider from this pin sets the float voltage which is disconnected in shutdown mode.
VCC (Pin 4): Positive input supply voltage. Provides power to the charger. VCC should be bypassed with at least a 1µF
capacitor. When VCC drops to within 30mV of the BAT pin voltage, the XT2055 enters shutdown mode, dropping IBAT to
less than 2µA.
DONE (Pin5): Full indication output, when fully charged, DONE port is an internal N-channel MOSFET placed in low
position. In the charging process, low-power lock condition is detected; the input is too high to detect locking conditions,
DONE-Z state.
PROG (Pin 5): Charge current program, charge current monitor and shutdown pin. The charge current is programmed by
connecting a 1% resistor, RPROG to ground. When charging in constant-current mode, this pin servos to 1V. In all modes,
the voltage on this pin can be used to measure the charge current using the following formula:
IBAT = (VPROG/RPROG) × 1000
The PROG pin can also be used to shut down the charger. Disconnecting the program resistor from ground allows a 3µA
current to pull the PROG pin high. When it reaches the 1.21V shutdown threshold voltage, the charger enters shutdown
mode, charging stops and the input supply current drops to 25µA. This pin is also clamped to approximately 2.4V. Driving
this pin to voltages beyond the clamp voltage will draw currents as high as 1.5mA. Reconnecting RPROG to ground will
return the charger to normal operation.
■ Marking Rule
SOT-23-6L
. . . ..
.
① ② ③ ④
SOT-23-6L
(TOP VIEW)
①
Represents the product name
Rev.1.1 — Feb. 29. 2016
Symbol
Product Name
2
XT2055◆◆◆◆◆
3
http://www.silinktek.com
XT2055
②
Represents the type of the trickle charge voltage and CHRG pin
Symbol
Product Series
Description
C
XT2055X◆◆◆◆
Without trickle charge
D
XT2055Y◆◆◆◆
With trickle charge
③ Represents the regulator output voltage
④
Symbol
Voltage
Symbol
Voltage
A
4.0
H
4.150
B
4.025
K
4.175
C
4.05
L
4.2
D
4.075
M
4.225
E
4.1
N
4.250
F
4.125
P
4.275
Represents the assembly lot No.
0-9,A-Z; 0-9,A-Z mirror writing,repeated(G,I,J,O,Q,W exception)
■ Absolute Maximum Ratings
Parameter
Symbol
Maximum Rating
Vcc
VSS-0.3~VSS+10
Vprog
VSS-0.3~Vcc+0.3
BAT pin Voltage
Vbat
Vss-0.3~7
CHAG pin Voltage
Vchrg
VSS-0.3~VSS+10
Power Dissipation
PD
BAT pin Current
Ibat
500
mA
PROG pin Current
Iprog
800
µA
Operating Ambient Temperature
Topa
-40~+85
Storage Temperature
Tstr
-65~+125
Input Supply Voltage
PROG pin Voltage
SOT-23-6L
250
Unit
V
mW
°C
Caution: The absolute maximum ratings are rated values exceeding which the product could suffer physical damage.
These values must therefore not be exceeded under any conditions.
Rev.1.1 — Feb. 29. 2016
4
http://www.silinktek.com
XT2055
■ Block Diagram
VIN
4
120℃
TA
1x
1000x
TDIE
5uA
3 BAT
MA
R1
CA
VA
-
6.8V
+
VIN
OVP
SHDN
DONE
R2
C1
REF
1.21V
R3
5
1V
STDBY
R4
VA
0.1V
C2
CHRG
R5
1
STANDBY
C3
TO
BAT
VIN
3uA
2.9V
6
PROG
Rev.1.1 — Feb. 29. 2016
5
RPROG
2
GND
http://www.silinktek.com
XT2055
■ Electrical Characteristics
Parameter
Input supply voltage
Input supply current
Symbol
Condition
Vcc
Icc
Min
4.25
BAT pin Current
Ibat
Unit
6.5
V
300
2000
µA
Standby mode
200
500
µA
25
50
µA
connected, Vcc
